sensor CADILLAC ESCALADE 1999 1.G Owners Manual

yellowblue
1-29
NOTICE:
If you damage the covering for the driver's or the
right front passenger's air bag, the bag may not
work properly. You may have to replace the air
bag module in the steering wheel or both the air
bag module and the instrument panel for the
right front passenger's air bag. Do not open or
break the air bag coverings.
If your vehicle ever gets into a lot of water -- such as
water up to the carpeting or higher
-- or if water enters
your vehicle and soaks the carpet, the air bag controller
can be soaked and ruined. If this ever happens, and then
you start your vehicle, the damage could make the air
bags inflate, even if there's no crash. You would have to
replace the air bags as well as the sensors and related
parts. If your vehicle is ever in a flood, or if it's exposed
to water that soaks the carpet, you can avoid needless
repair costs by turning off the vehicle immediately and
disconnecting the battery cables. Don't let anyone start
the vehicle under any circumstances. See your dealer
for service.
Servicing Your Air Bag-Equipped Vehicle
Air bags affect how your vehicle should be serviced.
There are parts of the air bag system in several places
around your vehicle. You don't want the system to
inflate while someone is working on your vehicle. Your
dealer and the service manual have information about
servicing your vehicle and the air bag system. To
purchase a service manual, see ªService and Owner
Publicationsº in the Index.
CAUTION:
For up to 10 minutes after the ignition key is
turned off and the battery is disconnected, an air
bag can still inflate during improper service. You
can be injured if you are close to an air bag when
it inflates. Avoid yellow connectors. They are
probably part of the air bag system. Be sure to
follow proper service procedures, and make sure
the person performing work for you is qualified
to do so.
The air bag system does not need regular maintenance.

yellowblue
1-30 Adding Equipment to Your Air
Bag-Equipped Vehicle
Q:If I add a push bumper or a bicycle rack to the
front of my vehicle, will it keep the air bags
from working properly?
A:As long as the push bumper or bicycle rack is
attached to your vehicle so that the vehicle's basic
structure isn't changed, it's not likely to keep the
air bags from working properly in a crash.
Q:Is there anything I might add to the front of the
vehicle that could keep the air bags from
working properly?
A:Yes. If you add things that change your vehicle's
frame, bumper system, front end sheet metal or
height, they may keep the air bag system from
working properly. Also, the air bag system may not
work properly if you relocate any of the air bag
sensors. If you have any questions about this, you
should contact Customer Assistance before you
modify your vehicle. (The phone numbers and
addresses for Customer Assistance are in Step Two of
the Customer Satisfaction Procedure in this manual.
See ªCustomer Satisfaction Procedureº in the Index.)
Rear Seat Passengers
It's very important for rear seat passengers to buckle up!
Accident statistics show that unbelted people in the rear
seat are hurt more often in crashes than those who are
wearing safety belts.
Rear passengers who aren't safety belted can be thrown
out of the vehicle in a crash. And they can strike others
in the vehicle who are wearing safety belts.
Rear Seat Outside Passenger Positions

yellowblue
2-13 Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key? What if
you have to leave something valuable in your vehicle?

Put your valuables in a storage area, like your
glove box.

Valuables can also be locked in the center floor
console. Make sure that you take the console key
with you.

Take the remote keyless entry system transmitter
with you.

Lock all the doors except the driver's.
Theft-Deterrent System
Your vehicle has a theft-deterrent alarm system. Once
armed, the system will sound the horn and flash the
parking lamps if the vehicle is tampered with.
Opening the doors may activate the alarm. See
ªDisarming the Systemº later in this section for further
information on turning the system off.
Shock Sensor
A shock sensor triggers the alarm when it detects a blow
to your vehicle. It is located in the center floor console.
There are two levels of alarms via the shock sensor: two
horn blasts and the headlamp/parking lamps flash for
non
-threatening blows to the vehicle or a full
two
-minute alarm for harder blows to the vehicle. The
sensitivity can be adjusted if more or less is desired. If
sensitivity is increased too much, it may give false
alarms caused by gusts of wind or other natural events
that may shake the vehicle.

yellowblue
2-14
The adjustment for the
shock sensor sensitivity can
be accessed through a hole
in the forward wall of the
main bin of the center
floor console.
Using a small flat
-tipped screwdriver, turn the adjuster
clockwise to increase sensitivity and turn
counterclockwise to decrease sensitivity. The shock
sensor is ignored by the alarm system when the ignition
is on, when the tailgate or panel doors are open, when
the alarm is disarmed, when customized to be ignored
and for five seconds after the horn sounds an alarm or
chirp. The shock sensor is ignored after triggering three
full alarms until the system is rearmed.
Arming the System
The alarm system can be armed to detect break-ins by
locking your vehicle using the keyless entry or by
locking the doors with the power door lock switch.
Passive arming is also available if you would like the
system to arm all by itself after the doors have been
closed, the ignition is OFF and the keys have been
removed from the ignition. When the system is armed, a
red light will flash on the center floor console briefly
once every two seconds. If you return to your vehicle
and the red light is flashing two brief flashes every two
seconds, the system is armed and the shock sensor had
triggered a two minute alarm. If the red light is flashing
three times every two seconds, the system is armed and
there was an intrusion that sounded the alarm.
Horn chirps and parking lamp flashes can be set to your
choice. See ªFeature Customizationº in the Index.

yellowblue
2-15
Remote Keyless Entry Transmitter Locking
If all the doors are closed, locking the vehicle with the
transmitter will immediately arm the system. If any door
is open when the transmitter LOCK button is pressed,
the system goes into an armed wait mode, waiting for
the doors to close. Once they are closed, the system will
arm and the headlamps and parking lamps will flash. If
the tailgate or panel doors are open or ajar at the time
the system is arming, the headlamps and parking lamps
flash once.
Power Door Lock Switch Locking
If any door is open when the power door lock switch is
pressed, the system goes into an armed wait mode,
waiting for the doors, tailgate or panel doors to close.
Once they are closed, the system will arm and the
parking lamps will flash. If a door is closed when the
power lock switch is pressed, the system assumes you
are inside the vehicle, so it will not arm. Locking the
doors by using the manual door locks will not arm
the system.Passive Arming
If the ignition was just turned off and a door was
opened, the system will arm six seconds after the doors,
tailgate or panel doors are closed. If a door is opened
without the ignition being turned on, the system will
wait 30 seconds after the doors, tailgate or panel doors
are closed before arming. This provides time to get into
the vehicle and put the key in the ignition. The parking
lamps will flash when the system arms. Passive arming
is not enabled from the factory.
If the LOCK button on the keyless entry transmitter or
the power door lock switch is pressed, the system will
arm immediately.
Disarming the System
There are two ways to disarm the system:
1. Press the UNLOCK button on the keyless entry
transmitter. If the horn chirps two or three times
when you unlock the vehicle, the alarm sounded in
your absence. Two chirps means that the shock
sensor was set off and three chirps means that a door,
tailgate or the panel doors were opened.
2. Turn the ignition to RUN with the proper key.
For more information on customizing the features
mentioned here, see ªFeature Customizationº in the Index.

yellowblue
2-16 Turning Off the Alarm
If you started the alarm by pressing the panic button on
the keyless entry transmitter, you must either push that
button again or turn the ignition to RUN to stop
the alarm.
If the alarm is sounding due to the shock sensor or a
door, tailgate or panel door opening, it can be turned off
by either turning the ignition switch with a proper key
inserted or by pressing any button on the keyless entry
transmitter. If you use your keyless entry transmitter to
silence the alarm, additional things will happen
depending upon which button you press.

Pressing the UNLOCK button will turn the alarm
off, unlock the driver's door and disarm the system.

Pressing the LOCK button will turn the alarm off,
keep the doors locked and keep the system armed.

Pressing the REAR 2X button will turn the alarm off
and disarm the system.

Pressing the panic button will turn the alarm off,
keep the doors locked and keep the system armed.
If the alarm is sounding because an incorrect ignition
key was used, press any button on the keyless entry
transmitter to turn the alarm off.
The alarm will stop by itself after two minutes.
Driver's Door Alarm Delay
The alarm will sound eight seconds after the driver's
door is opened with your key.
Feature Customization
Your vehicle's locks and lighting systems can be
programmed with several different features. The
following list tells you the features that can
be programmed.

Lockout Prevention

Keyless Entry Verification

Theft
-Deterrent Arming Method

Theft
-Deterrent Arming Verification
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. Put your key in the ignition.
2. Turn the ignition to RUN to disarm the
theft
-deterrent system.
3. Turn the ignition to OFF.

yellowblue
2-58
The console has two cupholders and two storage trays
for the front passenger and driver to use.
Your console also has a
cupholder that swings down
for the rear seat passengers
to use.
The console also contains the following components:

Rear Seat Audio System Controls

Rear Heated Seat Switches

Rear Seat Accessory Power Outlet

Six
-Disc CD Changer

Subwoofer

Audio Amplifier
Shock Sensor Adjuster

LED (Light Emitting Diode) Theft
-Deterrent
System Indicator
For more information on these components, please see
the Index for that item.
Rear Armrest Storage Compartment
Your vehicle has a center armrest storage compartment
in the rear seat.
Other Storage Compartments
Your vehicle includes a number of storage
compartments for storage of often
-used items.
Your vehicle has a storage pocket on each of the front doors.
You can use the pocket to store a variety of small items.
Convenience Net
Your vehicle has a convenience net, which is used to
keep small loads, like grocery bags, in place during
sharp turns or quick starts and stops.
The net is not designed for larger, heavier loads.
It is stored in a pouch attached at the driver's side of the
vehicle. You can also unhook the net so that it will lie
flat when you're not using it.

yellowblue
2-73 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
This light will come on
when you start your engine,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
engine or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Charging System Warning Light
The charging system
warning light should come
on briefly when you turn on
the ignition, before starting
the engine, as a check to
show you it is working.
After the engine starts, the light should go out. If it stays
on or comes on while you are driving, you may have a
problem with your charging system. It could indicate a
problem with the generator drive belt, or some other
charging system problem. Have it checked right away.
Driving while this light is on could drain your battery.
If you must drive a short distance with this light on, it
helps to turn off all your accessories, such as the radio
and the air conditioner.

yellowblue
8-10
Shifting
Automatic Transmission 2-26 . . . . . . . . . . . . . . . . . . . . . . .
Into Park (P) 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of Park (P) 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shoulder Belt Height Adjuster 1-16, 1-33 . . . . . . . . . . . . . . . .
Signaling Turns 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding 3-21 . . . . . . . . . . . . . . . . . . . . . . . .
Specifications and Capacities 6-63 . . . . . . . . . . . . . . . . . . . . . .
Specifications, Engine 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . . .
Speedometer 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed-Sensitive Steering 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains, Cleaning 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steam 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed-Sensitive 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel, Tilt 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage, Overhead 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage, Vehicle 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-32 . . . . . . . . . . . . . . . . . .
Sun Visors 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle v. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tailgate 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tailgate, Glass Release 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft-Deterrent Feature 3-18 . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft-Deterrent System 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver's Door Alarm Delay 2-16 . . . . . . . . . . . . . . . . . . . . .
Shock Sensor 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turning Off 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
THEFTLOCK
3-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Third Gear, Automatic Transmission 2-28 . . . . . . . . . . . . . . . .
Tilt Steering Wheel 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Time, Setting the 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Chains 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Loading 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information Label 4-41 . . . . . . . . . . . . . . . . . . .
Tires 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance 6-45 . . . . . . . . . . . . . . . . . . . . . . . .
Buying New 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
