6-59
Fuse/Circuit
BreakerUsage
14 4WD Indicator, Cluster, Front and
Rear Comfort Controls, Instrument
Switches, Radio Illumination,
Chime Module
15 DRL Relay, Fog Lamp Relay
16 Front and Rear Turn Signals,
Back
-Up Lamps, Anti-lock Shift
Brake Control Solenoid
17 Radio (Ignition)
18 4WAL/VCM, ABS, Cruise Control
19 Radio (Battery)Fuse/Circuit
BreakerUsage
20 PRNDL, Automatic Transmission,
Speedometer, Check Gages,
Warning Lights
21 Security/Steering
22 Auxiliary Power, Headlamp Delay
23 Rear Wiper, Rear Washer Pump
24 Front Axle, 4WD Indicator Lamp,
TP2 Relay
A Power Door Lock, Six
-Way Power
Seat, Keyless Entry Module
B Power Windows

6-60
Underhood Fuse/Relay Center
The underhood fuse/relay center is located in the rear of
the engine compartment near the brake fluid reservoir.
Move the retainer clips for the cover to access the
fuse block.
You can remove fuses with a fuse extractor. The fuse
extractor is mounted to the interior fuse block. To
remove fuses if you don't have a fuse extractor, hold the
end of the fuse between your thumb and index finger
and pull straight out.
Name Circuits Protected
ECM
-B Fuel Pump, PCM/VCM
RR DEFOG Rear Window Defogger
IGN
-E Auxiliary Fan Relay Coil, A/C
Compressor Relay, Hot Fuel
Module
FUEL SOL Not Used

6-61
Name Circuits Protected
GLOW PLUG Not Used
HORN Horn, Underhood Lamp
AUX FAN Auxiliary Fan
ECM
-1 Injectors, PCM/VCM
HTD ST
-FR Heated Front Seats
A/C Air Conditioning
HTD MIR Heated Outside Mirrors
ENG
-1 Ignition Switch, EGR, Canister
Purge, EVRV Idle Coast Solenoid,
Heated O
2
HTD ST-RR Heated Rear Seats
AUX B Trailer WiringName Circuits Protected
AUX A SEO Wiring
LIGHTING Headlamp and Panel Dimmer
Switch, Fog and Courtesy Fuses
BATT Battery, Fuse Block Busbar
IGN A Ignition Switch
IGN B Ignition Switch
ABS Anti
-Lock Brake Module
BLOWER High Blower and Rear Blower
Relays
STOP/HAZ Stoplamps
HEATED
SEATSHeated Seats

6-62
Replacement Bulbs
LAMP OR BULB TRADE NO. POWER RATING
AT 12.8V, WATTSQTY
HEADLAMPS
Low Beam 9006 HB4 55 2
High Beam 9005 HB3 65 2
LAMP OR BULB TRADE NO. QTY
EXTERIOR
Front Marker Lamp 194 2
Front Parking and Turn Lamp 2357NA 4
Rear Parking Lamp 3057 2
Rear Stop and Turn Lamp 3057 2
Back
-up Lamp3156 2
Fog Lamp 894 2

6-63
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº in the Maintenance Schedule booklet for more information.
Engine Identification
EngineªVORTECº 5700
Type V8
RPO Code L31
VIN Code R
Fuel System SFI*
*Sequential Fuel Injection
Wheels and Tires
MODEL DESCRIPTION TORQUE
K 1500 6 bolts (14 mm)
140 lb
-ft (190 N´m)
Tire Pressure See the Certification/Tire label on
the rear edge of the driver's door.
Cooling System Capacity (Approximate)
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
ENGINE VIN QTY
ªVORTECº 5700 V8 R 17.5 Quarts (16.5 L)
Crankcase Capacity (Approximate)
After refill, the level must be rechecked. See ªEngine Oilº in the Index.
ENGINE VIN
QUANTITY WITH FILTER

ªVORTECº 5700 V8 R 5.0 Quarts (4.8 L)

Oil filter should be changed at every oil change.

6-64 Fuel Tank Capacity (Approximate)
Quantity 30.0 Gallons (113.0 L)
Normal Maintenance
Replacement Parts
Replacement part numbers listed in this section are
based on the latest information available at the time of
printing, and are subject to change. If a part listed in this
manual is not the same as the part used in your vehicle
when it was built, or if you have any questions, please
contact your Cadillac dealer.
Engine ªVORTECº 5700 V8
VIN R
Oil Filter AC Type PF52
Engine Air
Cleaner/FilterAC Type A1300C

Spark Plugs
AC Type 41
-932Engine ªVORTECº 5700 V8
Spark Plug Gap 0.060 in. (1.52 mm)
Fuel Filter AC Type GF626
Wiper Blades (Front) GM Part No. 22154886
Wiper Blade Type
(Front)Trico
Wiper Blade Length
(Front)18.0 inches (45.0 cm)
Wiper Blade (Rear) GM Part No. 22154396
Wiper Blade Type
(Rear)Trico
Wiper Blade Length
(Rear)14.0 inches (35.5 cm)

A1301C high
-capacity air cleaner filter.

7-
7-1
Section 7 Customer Assistance Information
Here you will find out how to contact Cadillac if you need assistance. This section also tells you how to obtain service
publications and how to report any safety defects.
