INSTRUMENTS AND CONTROLS 157
Chime Volume
This allows the selection of the chime
volume level.
Press + or−to adjust the volume.
Reverse Tilt Mirror
When on, the driver and/or passenger
mirrors will tilt downward when the
vehicle is shifted to R (Reverse) to
improve visibility of the ground near
the rear wheels.
Select Off, On - Driver and Passenger,
On - Driver, or On - Passenger.
Auto Mirror Folding
When on, the outside rearview mirrors
will automatically fold or unfold when
the Remote Keyless Entry (RKE)
transmitter
QorKbutton is pressed
and held.
Select Off or On.
Auto Wipe in Reverse Gear
When on, the rear wiper will
automatically activate when the
vehicle is shifted to R (Reverse).
Select Off or On. Lighting
Select and the following may display:
.
Vehicle Locator Lights
. Exit Lighting
. Auto High Beam
Vehicle Locator Lights
This feature will flash the exterior
lamps when
Kon the Remote Keyless
Entry (RKE) transmitter is pressed to
locate the vehicle.
Select Off or On.
Exit Lighting
This allows the selection of how long
the exterior lamps stay on when
leaving the vehicle when it is dark
outside.
Select Off, 30 Seconds, 60 Seconds,
or 120 Seconds.
Auto High Beam
This allows the feature to be turned
on or off. See “IntelliBeam System ”in
Exterior Lamp Controls 0164. Select On or Off. On some vehicles
select Off, Normal Sensitivity, or Low
Sensitivity.
Power Door Locks
Select and the following may display:
.
Unlocked Door Anti-Lockout
. Auto Door Lock
. Delayed Door Lock
Unlocked Door Anti-Lockout
When on, this feature will keep the
driver door from locking when the
vehicle is off, the driver door is open,
and locking is requested. All the doors
will lock and only the driver door will
unlock. See Lockout Protection 037.
If Off is selected, the Delayed Door
Lock menu will be available.
Select On or Off.
Auto Door Lock
When this feature is turned on, all
doors will automatically lock when the
vehicle is shifted out of P (Park). The
doors will automatically unlock when
the vehicle is shifted into P (Park).
Select Off or On.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
176 CLIMATE CONTROLS
The climate control system may have
a sensor to detect air pollution. When
using automatic air recirculation, the
air quality control system may
operate. To adjust the sensitivity of
the air quality sensor, see“Climate
and Air Quality” underVehicle
Personalization 0154.
@(Recirculation) : Press to
alternate between recirculating air
inside the vehicle or pulling in outside
air. The indicator light on the button
is lit when recirculation mode is
active. This helps to quickly cool the
air inside the vehicle and reduce the
entry of outside air and odors.
Pressing this button cancels automatic
recirculation. Press AUTO to return to
automatic operation; recirculation
runs automatically as needed.
Manual recirculation mode is not
available when in Defrost or Defog
modes.
Auto Defog : The climate control
system uses a sensor to automatically
detect high humidity inside the
vehicle. When high humidity is
detected, the climate control system
may adjust to outside air supply, turn on the air conditioner, and direct
more air to the windshield. If the
climate control system does not
detect possible window fogging, it
returns to normal operation. To turn
Auto Defog off or on, see
“Climate and
Air Quality” underVehicle
Personalization 0154.Rear Window Defogger
=(Rear Window Defogger) : Press
to turn the rear window defogger on
or off. An indicator light on the button
comes on to show that the rear
window defogger is on.
The rear window defogger only works
when the ignition is in ON/RUN. The
defogger turns off if the ignition is
turned to ACC/ACCESSORY or
LOCK/OFF.
The rear window defogger can be set
to automatic operation. When Auto
Rear Defog is selected, the rear
window defogger turns on
automatically when the vehicle is first
started in cold weather and turns off
when the vehicle is warmed. To turn
Auto Rear Defog on or off, see
“Climate and Air Quality” under
Vehicle Personalization 0154. The heated outside rearview mirrors
turn on when the rear window
defogger button is on and help to
clear fog or frost from the surface of
the mirrors.
Caution
Do not try to clear frost or other
material from the inside of the
front windshield and rear window
with a razor blade or anything else
that is sharp. This may damage the
rear window defogger grid and
affect the radio's ability to pick up
stations clearly. The repairs would
not be covered by the vehicle
warranty.
Driver and Passenger Heated and
Cooled Seats : Press
Ior+to heat
the driver or passenger seatback only.
Press
Jorzto heat the driver or
passenger seat cushion and seatback.
Press
Cor{to cool the driver or
passenger seat.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
INDEX 347
Engine (cont'd)Oil Messages . . . . . . . . . . . . . . . . . . . . . . 146
Oil Pressure Light . . . . . . . . . . . . . . . . . 136
Overheating . . . . . . . . . . . . . . . . . . . . . . . 266
Power Messages . . . . . . . . . . . . . . . . . . 147
Running While Parked . . . . . . . . . . . 203
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 170
Equipment, Towing . . . . . . . . . . . . . . . . . 249
Event Data Recorders . . . . . . . . . . . . . . 342
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 170
Extended Parking . . . . . . . . . . . . . . . . . . . 202
Exterior Lamp Controls . . . . . . . . . . . . 164
Exterior Lamps Off Reminder . . . . . . 166
F
Fan Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Features
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 262
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 166
Flashers, Hazard Warning . . . . . . . . . . 168
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Fluid Automatic Transmission . . . . . . . . . 261 Fluid (cont'd)
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Four-Wheel Drive
Transfer Case . . . . . . . . . . . . . . . . . . . . 209
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 46
Forward Automatic Braking . . . . . . . . 237
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Four-Wheel Drive . . . . . . . . . . . . . .209, 272
Front Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Front Seats Heated and Cooled . . . . . . . . . . . . . . . . . 62
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Economy Driving . . . . . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 244
Filling the Tank . . . . . . . . . . . . . . . . . . . 242
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Low Fuel Warning Light . . . . . . . . . 137
Management, Active . . . . . . . . . . . . . . 202
System Messages . . . . . . . . . . . . . . . . . 147
Full-Size Spare Tire . . . . . . . . . . . . . . . . . 311
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278 Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 283, 286
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
G
Garage Door OpenerProgramming . . . . . . . . . . . . . . . . . . . . . . 161
Gauges
Engine Coolant Temperature . . . . 127
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Speedometer . . . . . . . . . . . . . . . . . . . . . . 126
Tachometer . . . . . . . . . . . . . . . . . . . . . . . 127
Trip Odometer . . . . . . . . . . . . . . . . . . . . 126
Warning Lights andIndicators . . . . . . . . . . . . . . . . . . . . . . . . 123
General Information
Service and Maintenance . . . . . . . . 328
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 255
Glass Replacement . . . . . . . . . . . . . . . . . 275
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
348 INDEX
H
Hazard Warning Flashers . . . . . . . . . . 168
Head Restraints . . . . . . . . . . . . . . . . . . . . . . 55
Head-up Display . . . . . . . . . . . . . . . . . . . . 141
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 167
Bulb Replacement . . . . . . . . . . . . . . . . 276
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . . . . . 166
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 166
High-Beam On Light . . . . . . . . . . . . . . 137
High/Low Beam Changer . . . . . . . . . 166
Lamps On Reminder . . . . . . . . . . . . . . 137
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Steering Wheel . . . . . . . . . . . . . . . . . . . . 115
Heated and Cooled Front Seats . . . . . 62
Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . 46
Heating . . . . . . . . . . . . . . . . . . . . . . . . .173, 177
High-Beam On Light . . . . . . . . . . . . . . . . 137
High-Speed Operation . . . . . . . . . . . . . . 292
Hill and Mountain Roads . . . . . . . . . . 190
Hill Start Assist (HSA) . . . . . . . . . . . . . 215
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . .173, 177I
Ignition Positions . . . . . . . . . . . . . . . . . . . 197
Indicator
Vehicle Ahead . . . . . . . . . . . . . . . . . . . . . 134
Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Infotainment . . . . . . . . . . . . . . . . . . . . . . . . 172
Infotainment System . . . . . . . . . . . . . . . 343
Instrument Cluster . . . . . . . . . . . . . . . . . 124
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . . . . 109
Interior Rearview Mirrors . . . . . . . . . . . 48
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . 312
K
Key and Lock Messages . . . . . . . . . . . . 147
Keyless Entry Remote (RKE) System . . . . . . . . . . . . . . 28
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
L
Lamps Cornering . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Daytime Running (DRL) . . . . . . . . . . 166
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Exterior Controls . . . . . . . . . . . . . . . . . . 164 Lamps (cont'd)
Exterior Lamps Off Reminder . . . . 166
License Plate . . . . . . . . . . . . . . . . . . . . . . 277
Malfunction Indicator . . . . . . . . . . . . 130
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 148
On Reminder . . . . . . . . . . . . . . . . . . . . . . 137
Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Lane Change Alert (LCA) . . . . . . . . . . . 238
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . . . . 240
Lane Keep Assist (LKA) . . . . . . . . . . . . 240
Lane Keep Assist Light . . . . . . . . . . . . . 134
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . 72
LATCH System Replacing Parts after a Crash . . . . 103
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . . . . 96
LED Lighting . . . . . . . . . . . . . . . . . . . . . . . . 276
Level Control
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 219
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . 122
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Illumination Control . . . . . . . . . . . . . . 169
LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
