fuel filter CADILLAC ESCALADE 2017 4.G Owners Manual

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
IN BRIEF 25
appropriate DIC message displays.
SeeRide Control System
Messages 0150.
. Press and release
gagain to turn
on both systems.
StabiliTrak will automatically turn on
if the vehicle exceeds 56 km/h
(35 mph). Traction control will
remain off.
See Traction Control/Electronic Stability
Control 0216.
Tire Pressure Monitor
This vehicle may have a Tire Pressure
Monitor System (TPMS).
The low tire pressure warning light
alerts to a significant loss in pressure
of one of the vehicle's tires. If the
warning light comes on, stop as soon
as possible and inflate the tires to the
recommended pressure shown on the Tire and Loading Information label.
See
Vehicle Load Limits 0192. The
warning light will remain on until the
tire pressure is corrected.
The low tire pressure warning light
may come on in cool weather when
the vehicle is first started, and then
turn off as the vehicle is driven. This
may be an early indicator that the tire
pressures are getting low and the tires
need to be inflated to the proper
pressure.
The TPMS does not replace normal
monthly tire maintenance. Maintain
the correct tire pressures.
See Tire Pressure Monitor
System 0293.
Fuel
Premium Recommended Fuel
Use unleaded petrol rated at 95 RON
or higher in your vehicle. Unleaded
petrol with an octane rating as low as
91 RON may be used, but it will
reduce performance and fuel economy.
See Fuel 0242.
Engine Oil Life System
The engine oil life system calculates
engine oil life based on vehicle use
and displays the CHANGE ENGINE
OIL SOON message when it is time to
change the engine oil and filter. The
oil life system should be reset to 100%
only following an oil change.
Resetting the Oil Life System
1. Using the DIC controls on the right side of the steering wheel,
display OIL LIFE on the DIC. See
Driver Information Center (DIC)
0138. When remaining oil life is
low, the CHANGE ENGINE OIL
SOON message will appear on
the display. See Engine Oil
Messages 0146.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
SERVICE AND MAINTENANCE 329
checks and services. The Additional
Required Services - Normal are for
vehicles that:
.Carry passengers and cargo within
recommended limits on the Tire
and Loading Information label. See
Vehicle Load Limits 0192.
. Are driven on reasonable road
surfaces within legal driving limits.
. Use the recommended fuel. See
Fuel 0242.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart.
The Additional Required Services -
Severe are for vehicles that are:
. Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer.
. Used for high speed or competitive
driving.
. Used for taxi, police, or delivery
service. Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause serious
injury. Perform maintenance work
only if the required information,
proper tools, and equipment are
available. If they are not, see your
dealer to have a trained technician
do the work. See
Doing Your Own
Service Work 0256.
Maintenance Schedule
Owner Checks and Services
At Each Fuel Stop
.
Check the engine oil level. See
Engine Oil 0258.
Once a Month
. Check the tire inflation pressures.
See Tire Pressure 0291.
. Inspect the tires for wear. See Tire
Inspection 0296.
. Check the windshield washer fluid
level. See Washer Fluid 0268.
Engine Oil Change
Change the engine oil and filter when
the CHANGE ENGINE OIL SOON
message displays, 12 000 km/7,500 mi,
or at one year, whichever comes first.
If driven under the best conditions,
the engine oil life system may not
indicate the need for vehicle service
for up to a year. The engine oil and
filter must be changed at least once a
year and the oil life system must be
reset. Your trained dealer technician
can perform this work. If the engine

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
330 SERVICE AND MAINTENANCE
oil life system is reset accidentally,
service the vehicle within 5 000 km/
3,000 mi since the last service. Reset
the oil life system when the oil is
changed. SeeEngine Oil Life
System 0260.
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the following
services. See Tire Rotation0297.
. Check engine oil level and oil
life percentage. If needed, change
engine oil and filter, and reset oil
life system. See Engine Oil0258
and Engine Oil Life System 0260.
. Check engine coolant level. See
Engine Coolant 0264.
. Check windshield washer fluid
level. See Washer Fluid 0268.
. Visually inspect windshield wiper
blades for wear, cracking,
or contamination. See Exterior
Care 0320. Replace worn or
damaged wiper blades. See Wiper
Blade Replacement 0274. .
Check tire inflation pressures. See
Tire Pressure 0291.
. Inspect tire wear. See Tire
Inspection 0296.
. Visually check for fluid leaks.
. Inspect engine air cleaner filter.
See Engine Air Cleaner/Filter 0262.
. Inspect brake system. See Exterior
Care 0320.
. Visually inspect steering,
suspension, and chassis
components for damaged, loose,
or missing parts or signs of wear.
See Exterior Care 0320.
. Lubricate the suspension and
steering components at least every
other oil change (if equipped with
grease fittings).
. Check restraint system
components. See Safety System
Check 077.
. Visually inspect fuel system for
damage or leaks.
. Visually inspect exhaust system
and nearby heat shields for loose
or damaged parts. .
Lubricate body components. See
Exterior Care 0320.
. Check starter switch. See Starter
Switch Check 0273.
. Check automatic transmission
shift lock control function. See
Automatic Transmission Shift Lock
Control Function Check 0274.
. Check parking brake and
automatic transmission park
mechanism. See Park Brake and
P (Park) Mechanism Check 0274.
. Check accelerator pedal for
damage, high effort, or binding.
Replace if needed.
. Visually inspect gas strut for signs
of wear, cracks, or other damage.
Check the hold open ability of the
strut. See your dealer if service is
required.
. Inspect sunroof track and seal,
if equipped. See Sunroof052.
. Verify spare tire key lock operation
and lubricate as needed. See Tire
Changing 0303.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
SERVICE AND MAINTENANCE 331
Maintenance Schedule
Additional Required Services -
Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@ @ @ @ @ @ @ @ @ @
Change transfer case fluid, if equipped with 4WD. (4)@
Replace spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Footnotes—Maintenance Schedule
Additional Required Services -
Normal
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2)
Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition. (3)
Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(4) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
334 SERVICE AND MAINTENANCE
Footnotes—Maintenance Schedule
Additional Required Services -
Severe
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2) Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.
(3) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(4) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated fluid will decrease the life of the
transfer case and/or axles and should
be replaced.
(5)
Or every five years, whichever
comes first. See Cooling System0263.
(6) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed.
(7) Replace brake fluid every five
years. See Brake Fluid 0269.Special Application
Services
Severe Conditions Requiring
More Frequent Maintenance
.
Public service, military,
or commercial use vehicles to
include the following:
‐Ambulances, police cars and
emergency rescue vehicles.
‐ Civilian vehicles such as light
duty pick-up trucks, SUVs and
passenger cars that are used in
military applications.
‐ Recovery vehicles such as tow
trucks and flatbed single vehicle
carriers or any vehicle that is
consistently used in towing
trailers or other loads.
‐ High use commercial vehicles
such as courier delivery vehicles,
private security patrol vehicles
or any vehicles that operate on
a 24 hour basis.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
340 TECHNICAL DATA
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions. SeeRecommended Fluids and Lubricants
0 336 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and
charge amount, see the refrigerant label under the hood. See your dealer for more information.
Cooling System 16.5 L17.4 qt
Engine Oil with Filter 7.6 L8.0 qt
Fuel Tank Regular 98.4 L26.0 gal
Extended 1500 Series 119.2 L31.5 gal
Transfer Case Fluid 1.5 L1.6 qt
Wheel Nut Torque 190Y 140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
344 INDEX
IndexA
Accessories and Modifications . . . . . 255
Accessory Power . . . . . . . . . . . . . . . . . . . . 200
Active Fuel Management
®. . . . . . . . . 202
Adaptive Cruise Control . . . . . . . . . . . . 222
Add-On Electrical Equipment . . . . . . 252
Adjustable Throttle and Brake
Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 57
Air Cleaner/Filter, Engine . . . . . . . . . . 262
Air Conditioning . . . . . . . . . . . . . . .173, 177
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 180
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
How Does an Airbag Restrain? . . . . . 82
Passenger Sensing System . . . . . . . . . 84
What Makes an Airbag Inflate? . . . . 82
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 83
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Where Are the Airbags? . . . . . . . . . . . . 80
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88 Airbags (cont'd)
Passenger Status Indicator . . . . . . . 129
Readiness Light . . . . . . . . . . . . . . . . . . . 129
Servicing Airbag-Equipped
Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
System Check . . . . . . . . . . . . . . . . . . . . . . . 78
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 43
Alert
Lane Change . . . . . . . . . . . . . . . . . . . . . . 238
Side Blind Zone (SBZA) . . . . . . . . . . 238
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 290
All-Terrain Tires . . . . . . . . . . . . . . . . . . . . 291
Antilock Brake System (ABS) . . . . . . 212 Warning Light . . . . . . . . . . . . . . . . . . . . 133
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 324
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 110
Ashtrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Assistance Systems for Driving . . . . 234
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 230
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Forward Braking . . . . . . . . . . . . . . . . . . 237
Headlamp System . . . . . . . . . . . . . . . . 167
Level Control . . . . . . . . . . . . . . . . . . . . . . 219

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
346 INDEX
Coolant (cont'd)Engine Temperature Gauge . . . . . . 127
Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .173, 177
Cooling System . . . . . . . . . . . . . . . . . . . . . 263 Engine Messages . . . . . . . . . . . . . . . . . . 146
Cornering Lamps . . . . . . . . . . . . . . . . . . . 169
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 220 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Cruise Control, Adaptive . . . . . . . . . . . 222
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . 110
D
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 343
Data Recorders, Event . . . . . . . . . . . . . . 342
Daytime Running Lamps (DRL) . . . 166
Defensive Driving . . . . . . . . . . . . . . . . . . . 183
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 36
Distracted Driving . . . . . . . . . . . . . . . . . . 182
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 169
Door
Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . 138
Ajar Messages . . . . . . . . . . . . . . . . . . . . . 145
Delayed Locking . . . . . . . . . . . . . . . . . . . . 36
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Door (cont'd)
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 36
Drive Belt Routing, Engine . . . . . . . . . 341
Driver Assistance Systems . . . . . . . . . 229
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 138
Driver Mode Control . . . . . . . . . . . . . . . . 217
Driving Assistance Systems . . . . . . . . . . . . . . . 234
Characteristics and
Towing Tips . . . . . . . . . . . . . . . . . . . . . 245
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 183
For Better Fuel Economy . . . . . . . . . . . 26
Hill and Mountain Roads . . . . . . . . 190
If the Vehicle is Stuck . . . . . . . . . . . . 191
Loss of Control . . . . . . . . . . . . . . . . . . . . 184
Off-Road . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Off-Road Recovery . . . . . . . . . . . . . . . . 184
Vehicle Load Limits . . . . . . . . . . . . . . 192
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 189
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Winter Mode Light . . . . . . . . . . . . . . . 134
Dual Automatic Climate
Control System . . . . . . . . . . . . . . . . . . . . 173
E
Electric Parking Brake . . . . . . . . . . . . . . 213
Electric Parking Brake Light . . . . . . . 132
Electrical Equipment, Add-On . . . . . 252
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 283, 286
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Engine
Air Cleaner/Filter . . . . . . . . . . . . . . . . . 262
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . . . . . . 130
Compartment Overview . . . . . . . . . . 257
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Coolant Temperature Gauge . . . . . 127
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 135
Cooling System . . . . . . . . . . . . . . . . . . . 263
Cooling System Messages . . . . . . . . 146
Drive Belt Routing . . . . . . . . . . . . . . . . 341
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Oil Life System . . . . . . . . . . . . . . . . . . . . 260

Cadillac Escalade Owner Manual (GMNA-Localizing-MidEast-10293077) -
2017 - crc - 8/24/16
INDEX 347
Engine (cont'd)Oil Messages . . . . . . . . . . . . . . . . . . . . . . 146
Oil Pressure Light . . . . . . . . . . . . . . . . . 136
Overheating . . . . . . . . . . . . . . . . . . . . . . . 266
Power Messages . . . . . . . . . . . . . . . . . . 147
Running While Parked . . . . . . . . . . . 203
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 170
Equipment, Towing . . . . . . . . . . . . . . . . . 249
Event Data Recorders . . . . . . . . . . . . . . 342
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 170
Extended Parking . . . . . . . . . . . . . . . . . . . 202
Exterior Lamp Controls . . . . . . . . . . . . 164
Exterior Lamps Off Reminder . . . . . . 166
F
Fan Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Features
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 262
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 166
Flashers, Hazard Warning . . . . . . . . . . 168
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Fluid Automatic Transmission . . . . . . . . . 261 Fluid (cont'd)
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Four-Wheel Drive
Transfer Case . . . . . . . . . . . . . . . . . . . . 209
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 46
Forward Automatic Braking . . . . . . . . 237
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Four-Wheel Drive . . . . . . . . . . . . . .209, 272
Front Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Front Seats Heated and Cooled . . . . . . . . . . . . . . . . . 62
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Economy Driving . . . . . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 244
Filling the Tank . . . . . . . . . . . . . . . . . . . 242
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Low Fuel Warning Light . . . . . . . . . 137
Management, Active . . . . . . . . . . . . . . 202
System Messages . . . . . . . . . . . . . . . . . 147
Full-Size Spare Tire . . . . . . . . . . . . . . . . . 311
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278 Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278 Fuses (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 283, 286
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
G
Garage Door OpenerProgramming . . . . . . . . . . . . . . . . . . . . . . 161
Gauges
Engine Coolant Temperature . . . . 127
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Speedometer . . . . . . . . . . . . . . . . . . . . . . 126
Tachometer . . . . . . . . . . . . . . . . . . . . . . . 127
Trip Odometer . . . . . . . . . . . . . . . . . . . . 126
Warning Lights andIndicators . . . . . . . . . . . . . . . . . . . . . . . . 123
General Information
Service and Maintenance . . . . . . . . 328
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 255
Glass Replacement . . . . . . . . . . . . . . . . . 275
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
