Recommended Fluids and
Lubricants
Fluids and lubricants identied below by name, part
number or specication may be obtained from your
dealer.
Usage Fluid/Lubricant
Engine OilEngine oil which meets GM Standard
GM6094M and displays the
American Petroleum Institute
Certied for Gasoline Engines
starburst symbol. GM Goodwrench
oil meets all the requirements for your
vehicle. To determine the proper
viscosity for your vehicle’s engine,
seeEngine Oil on page 5-14.
Engine Coolant50/50 mixture of clean, drinkable
water and use only
DEX-COOL
®Coolant. SeeEngine
Coolant on page 5-24.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid or
equivalent DOT-3 brake uid.
Usage Fluid/Lubricant
Windshield
Washer SolventGM Optikleen
®Washer Solvent.
Power Steering
SystemGM Power Steering Fluid (GM Part
No. U.S. 89021184, in Canada
89021186).
Automatic
TransmissionDEXRON
®-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474).
Chassis
LubricationChassis Lubricant (GM Part No.
U.S. 12377985, in Canada
88901242) or lubricant meeting
requirements of NLGI #2, Category
LB or GC-LB.
Front and
Rear AxleSAE 75W-90 Synthetic Axle
Lubricant (GM Part No. U.S.
12378261, in Canada 10953455)
meeting GM Specication 9986115.
Transfer CaseDEXRON
®-III Automatic
Transmission Fluid.
6-13

D
Daytime Running Lamps..................................3-16
Defensive Driving............................................. 4-2
Defogging and Defrosting.................................3-29
Delayed Locking............................................... 2-9
Dinghy Towing and Dolly Towing.......................4-49
Diversity Antenna System...............................3-106
Doing Your Own Service Work........................... 5-4
Dome Lamps.................................................3-17
Door
Delayed Locking........................................... 2-9
Locks.......................................................... 2-8
Power Door Locks......................................... 2-9
Programmable Automatic Door Locks.............2-10
Rear Door Security Locks.............................2-12
Driver
Position, Safety Belt.....................................1-36
DRIVER DOOR AJAR.....................................3-66
Driver Information Center (DIC).........................3-50
DIC Operation and Displays..........................3-51
DIC Warnings and Messages........................3-62
Driving
At Night.....................................................4-32
City...........................................................4-36
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Freeway.....................................................4-37
Hill and Mountain Roads..............................4-40Driving (cont.)
In Rain and on Wet Roads...........................4-33
Winter........................................................4-42
Driving Across an Incline..................................4-28
Driving Downhill..............................................4-26
Driving in Mud, Sand, Snow or Ice....................4-29
Driving in Water..............................................4-30
Driving On Grades..........................................4-65
Driving on Off-Road Hills.................................4-22
Driving on Snow or Ice....................................4-42
Driving Through Deep Standing Water...............4-35
Driving Through Flowing Water.........................4-35
Driving Uphill..................................................4-23
Driving with a Trailer.......................................4-64
DVD
Rear Seat Entertainment System...................3-86
DVD Distortion...............................................3-97
DVD Messages..............................................3-96
DVD Player....................................................3-89
E
Easy Exit Seat...............................................2-50
Rear Window Defogger....................................3-29
Electrical System
Add-On Equipment.....................................5-114
Fuses and Circuit Breakers.........................5-115
Power Windows and Other Power Options.......5-114
5

Maintenance Schedule (cont.)
At Least Once a Month................................6-10
At Least Once a Year..................................6-11
Introduction.................................................. 6-2
Maintenance Footnotes.................................. 6-8
Maintenance Record....................................6-17
Maintenance Requirements............................. 6-2
Normal Maintenance Replacement Parts.........6-15
Owner Checks and Services.........................6-10
Recommended Fluids and Lubricants.............6-13
Scheduled Maintenance................................. 6-5
Using Your................................................... 6-3
Your Vehicle and the Environment................... 6-2
Maintenance When Trailer Towing.....................4-67
Making Turns.................................................4-65
Malfunction Indicator Light................................3-45
Matching Transmitter(s) to Your Vehicle............... 2-6
Memory Seat.................................................2-48
Message
DIC Warnings and Messages........................3-62
Mexico, Central America and Caribbean
Islands/Countries (Except Puerto Rico and
U.S. Virgin Islands) – Customer Assistance....... 7-5
Mirrors
Automatic Dimming Rearview with OnStar
®,
Compass and Temperature Display.............2-31Mirrors (cont.)
Outside Automatic Dimming Mirror with Curb
View Assist.............................................2-36
Outside Convex Mirror.................................2-35
Outside Heated Mirrors................................2-36
Outside Power Mirrors..................................2-34
MyGMLink.com................................................ 7-4
N
Navigation/Radio System..................................3-86
New Vehicle Break-In......................................2-18
Normal Maintenance Replacement Parts............6-15
O
Odometer......................................................3-36
Off-Road Recovery..........................................4-15
Oil
Engine.......................................................5-14
Pressure Gage............................................3-47
OIL LIFE RESET............................................3-62
OIL PRESSURE LOW.....................................3-62
Older Children, Restraints................................1-53
Online Owner Center........................................ 7-4
10

Power (cont.)
Steering Fluid.............................................5-37
Windows....................................................2-15
Power Steering...............................................4-13
Programmable Automatic Door Locks.................2-10
Programming the HomeLink
®Transmitter...........2-39
Q
Questions and Answers About Safety Belts.........1-34
R
Radio Data System (RDS)...............................3-70
Radio Messages.............................................3-77
Radios..........................................................3-69
Care of Your Cassette Tape Player...............3-104
Care of Your CD and DVD Player................3-105
Care of Your CD Player..............................3-105
Care of Your CDs and DVDs.......................3-105
CD Changer...............................................3-99
Navigation/Radio System..............................3-86
Radio with Cassette and CD.........................3-70
Rear Seat Audio..........................................3-97
Setting the Time..........................................3-70
Theft-Deterrent..........................................3-102
Understanding Reception............................3-104RDS Messages..............................................3-76
Reaching Roadside Service............................... 7-7
Reading Lamps..............................................3-18
REAR ACCESS OPEN....................................3-67
Rear Axle......................................................5-50
Rear Climate Control System............................3-30
Rear Door Security Locks................................2-12
Rear Heated Seats.........................................1-11
Rear Safety Belt Comfort Guides......................1-49
Rear Seat Armrest..........................................2-45
Rear Seat Audio (RSA)....................................3-97
Rear Seat Entertainment System.......................3-86
Rear Seat Operation......................................... 1-9
Rear Seat Outside Passenger Positions.............1-46
Rear Seat Passengers, Safety Belts..................1-46
Rear Storage Area..........................................2-45
Rearview Mirror, Automatic Dimming with OnStar
®,
Compass and Temperature Display..................2-31
Reclining Seatbacks.......................................... 1-7
Reclining the Seatbacks...................................1-27
Recommended Fluids and Lubricants.................6-13
Recreational Vehicle Towing.............................4-49
REDUCED ENGINE POWER...........................3-63
Remote Control..............................................3-91
Remote Keyless Entry System............................ 2-4
Remote Keyless Entry System, Operation............ 2-5
Removing the 50/50 Split Bench Seats..............1-18
Removing the Bench Seat................................1-24
12

Split Bench Seat (50/50)..................................1-14
Split Bench Seat (60/40)..................................1-12
Stabilitrak
®System.........................................4-10
STABILITY SYS ACTIVE..................................3-68
STABILITY SYS DISABLED..............................3-68
Stalling on an Incline.......................................4-29
Starting Your Engine.......................................2-19
Steering........................................................4-13
Steering in Emergencies..................................4-14
Steering Tips..................................................4-13
Steering Wheel Controls, Audio.......................3-103
Steering Wheel, Tilt Wheel................................. 3-7
Stereo RCA Jacks..........................................3-87
Storage Areas
Center Console Storage Area........................2-43
Convenience Net.........................................2-45
Cupholder(s)...............................................2-43
Glove Box..................................................2-43
Luggage Carrier..........................................2-44
Rear Seat Armrest.......................................2-45
Rear Storage Area.......................................2-45
Storing a Flat or Spare Tire, Jack and Tools.......5-97
Stuck in Sand, Mud, Ice or Snow......................4-46
Sun Visors.....................................................2-15
Sunroof.........................................................2-47
T
Tachometer....................................................3-36
Taillamps.......................................................5-62
Temperature and Compass Display....................2-32
Testing the Alarm............................................2-17
Theft-Deterrent, Radio....................................3-102
Theft-Deterrent Systems...................................2-16
Content Theft-Deterrent................................2-16
Passlock
®...................................................2-17
Third Row......................................................1-73
Third Row – Lap Belt......................................1-45
Throttle, Adjustable..........................................2-20
TIGHTEN FUEL CAP......................................3-65
Tilt Wheel........................................................ 3-7
Tilting the 50/50 Split Bench Seat.....................1-16
Tilting the Full Bench Seat...............................1-22
Tire Sidewall Labeling......................................5-66
Tire Size.......................................................5-69
Tire Terminology and Denitions........................5-71
Tires.............................................................5-65
Buying New Tires........................................5-80
Chains.......................................................5-84
Changing a Flat Tire....................................5-86
If a Tire Goes Flat.......................................5-85
15
