bulb CADILLAC ESCALADE EXT 2007 3.G Owners Manual

Headlamp Aiming
................................. 447
Bulb Replacement
................................ 450
Windshield Wiper Blade
Replacement
..................................... 453
Tires
..................................................... 454
Appearance Care
.................................. 496
Vehicle Identication
............................. 508
Electrical System
.................................. 509
Capacities and Specications
................ 518Maintenance Schedule
.............................. 519
Maintenance Schedule
.......................... 520
Customer Assistance Information
............. 541
Customer Assistance and
Information
........................................ 542
Reporting Safety Defects
...................... 560
Index
.......................................................... 565
2

Holding the turn signal lever for more than
one second will cause the turn signals to ash
until you release the lever. The lever will return
by itself when it is released.
An arrow on the
instrument panel
cluster will ash in
the direction of the
turn or lane change.
As you signal a turn or a lane change, if the
arrows ash more quickly than normal, a signal
bulb may be burned out and other drivers will
not see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when
you signal a turn, check for burned-out bulbs and
a blown fuse. SeeInstrument Panel Fuse
Block on page 510andUnderhood Fuse Block
on page 513.Turn Signal On Chime
If your turn signal is left on for more than
3/4 of a mile (1.2 km), a chime will sound at
each ash of the turn signal and the message
TURN SIGNAL ON will also appear in the
DIC. SeeDIC Warnings and Messages on
page 248. To turn the chime and message off,
move the turn signal lever to the off position.
Headlamp High/Low-Beam Changer
53(Headlamp High/Low Beam Changer):To
change the headlamps from low to high beam, push
the lever toward the instrument panel. To return to
low-beam headlamps, pull the multifunction lever
toward you. Then release it.
When the high beams
are on, this indicator
light on the instrument
panel cluster will
also be on.
197

Making Turns
Notice:Making very sharp turns while
trailering could cause the trailer to come in
contact with the vehicle. Your vehicle could be
damaged. Avoid making very sharp turns
while trailering.
When you’re turning with a trailer, make wider
turns than normal. Do this so your trailer
won’t strike soft shoulders, curbs, road signs,
trees or other objects. Avoid jerky or sudden
maneuvers. Signal well in advance.
Turn Signals When Towing a Trailer
The arrows on your instrument panel will
ash whenever you signal a turn or lane change.
Properly hooked up, the trailer lamps will also
ash, telling other drivers you’re about to
turn, change lanes or stop.
When towing a trailer, the arrows on your
instrument panel will ash for turns even if the
bulbs on the trailer are burned out. Thus, you may
think drivers behind you are seeing your signal
when they are not. It’s important to check
occasionally to be sure the trailer bulbs are still
working.
Driving On Grades
Reduce speed and shift to a lower gearbefore
you start down a long or steep downgrade. If you
don’t shift down, you might have to use your
brakes so much that they would get hot and no
longer work well.
You can tow in DRIVE (D). You may want to shift
the transmission to THIRD (3) or, if necessary,
a lower gear selection if the transmission shifts too
often (e.g., under heavy loads and/or hilly
conditions).
You may also want to activate the tow/haul mode
if the transmission shifts too often. See “Tow/Haul
Mode” earlier.
When towing at high altitude on steep uphill
grades, consider the following: Engine coolant at
or near sea level will boil at a lower temperature
than at higher altitudes. If you turn your engine off
immediately after towing at high altitude on
steep uphill grades, your vehicle may show signs
similar to engine overheating. To avoid this, let
the engine run while parked (preferably on
level ground) with the automatic transmission in
PARK (P) for a few minutes before turning
the engine off. If you do get the overheat warning,
seeEngine Overheating on page 422.
389

Service........................................................ 396
Accessories and Modications................... 397
California Proposition 65 Warning.............. 397
Doing Your Own Service Work.................. 398
Adding Equipment to the Outside of
Your Vehicle.......................................... 399
Fuel............................................................. 399
Gasoline Octane........................................ 399
Gasoline Specications.............................. 399
California Fuel........................................... 400
Additives................................................... 400
Fuels in Foreign Countries........................ 401
Filling the Tank......................................... 402
Filling a Portable Fuel Container............... 404
Checking Things Under the Hood.............. 404
Hood Release........................................... 405
Engine Compartment Overview.................. 406
Engine Oil................................................. 407
Engine Oil Life System.............................. 410
Engine Air Cleaner/Filter............................ 412
Automatic Transmission Fluid.................... 415
Engine Coolant.......................................... 419Coolant Surge Tank Pressure Cap............ 422
Engine Overheating................................... 422
Overheated Engine Protection
Operating Mode..................................... 425
Cooling System......................................... 426
Engine Fan Noise..................................... 431
Power Steering Fluid ................................. 431
Windshield Washer Fluid........................... 432
Brakes...................................................... 433
Battery...................................................... 437
Jump Starting............................................ 438
All-Wheel Drive........................................... 443
Rear Axle.................................................... 444
Front Axle................................................... 446
Headlamp Aiming........................................ 447
Bulb Replacement....................................... 450
High Intensity Discharge (HID) Lighting..... 450
Taillamps, Turn Signal, Sidemarker,
Stoplamps and Back-up Lamps.............. 450
License Plate Lamp................................... 452
Replacement Bulbs................................... 452
Section 5 Service and Appearance Care
393

Bulb Replacement
For the proper type of replacement bulbs, see
Replacement Bulbs on page 452.
For any bulb changing procedure not listed in this
section, contact your dealer.
High Intensity Discharge (HID)
Lighting
{CAUTION:
The low beam high intensity discharge
lighting system operates at a very high
voltage. If you try to service any of the
system components, you could be
seriously injured. Have your dealer or a
qualied technician service them.
Your vehicle has HID headlamps. After your
vehicle’s HID headlamp bulb has been replaced,
you may notice that the beam is a slightly different
shade than it was originally. This is normal.
Taillamps, Turn Signal, Sidemarker,
Stoplamps and Back-up Lamps
To replace one of these bulbs, do the following:
A. Stoplamp/Turn
Signal/Taillamp
B. Stoplamp/Turn
Signal/Taillamp
C. Back-up Lamp
D. Sidemarker Lamp
1. Open the tailgate. SeeTailgate on page 114
for more information.
450

2. Remove the two
screws from the
taillamp assembly.
3. Pull the taillamp assembly straight back to
remove.4. Turn the bulb socket counterclockwise to
remove it from the taillamp assembly.
5. Pull the bulb straight out from the socket.
6. Press a new bulb into the socket, insert it into
the taillamp assembly and turn the bulb
socket clockwise until it clicks.
7. Reinstall the taillamp assembly and tighten
the screws.
451

License Plate Lamp
To replace one of these bulbs, do the following:
1. Reach under the rear bumper for the bulb
socket.
2. Turn the bulb socket counterclockwise and
pull the bulb socket out of the connector.3. Pull the old bulb from the bulb socket,
keeping the bulb straight as you pull it out.
4. Install the new bulb.
5. Reverse Steps 1 through 3 to reinstall the
bulb socket.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up Lamp 7441
License Plate Lamp 168
Sidemarker Lamp 194
Stoplamp/Taillamp/Turn Signal Lamp 3057
For replacement bulbs not listed here, contact
your dealer.
452

Appearance Care (cont.)
Weatherstrips........................................... 501
Windshield and Wiper Blades................... 503
Wood Panels........................................... 500
Ashtray(s).................................................... 218
Audio System(s).......................................... 267
Audio Steering Wheel Controls................. 316
Care of Your CD and DVD Player............ 318
Care of Your CDs and DVDs................... 318
Chime Level Adjustment........................... 319
Fixed Mast Antenna................................. 318
Navigation/Radio System, see Navigation
Manual................................................. 302
Radio with CD and DVD.......................... 270
Rear Seat Audio (RSA)............................ 313
Setting the Time...................................... 269
Theft-Deterrent Feature............................ 315
Understanding Radio Reception............... 317
XM™ Satellite Radio Antenna System...... 319
Automatic Headlamp System....................... 210
Automatic Transmission
Fluid........................................................ 415
Operation................................................. 129
Autoride
®..................................................... 379
B
Battery........................................................ 437
Run-Down Protection............................... 212
Before Leaving on a Long Trip.................... 362
Brake
Anti-Lock Brake System (ABS)................. 327
Emergencies............................................ 329
Parking.................................................... 136
System Warning Light.............................. 232
Brake Pedal, Throttle................................... 128
Brakes........................................................ 433
Braking....................................................... 326
Braking in Emergencies............................... 329
Break-In, New Vehicle................................. 123
Bulb Replacement....................................... 450
Headlamp Aiming..................................... 447
High Intensity Discharge (HID) Lighting.... 450
License Plate Lamps................................ 452
Replacement Bulbs.................................. 452
Taillamps, Turn Signal, Sidemarker,
Stoplamps, and Back-Up Lamps........... 450
Buying New Tires........................................ 470
566

H
Hazard Warning Flashers............................ 194
Head Restraints............................................ 15
Headlamp
Aiming..................................................... 447
Headlamps
Automatic Headlamp System.................... 210
Bulb Replacement.................................... 450
Daytime Running Lamps.......................... 209
Flash-to-Pass........................................... 198
High Intensity Discharge (HID) Lighting.... 450
High/Low Beam Changer......................... 197
On Reminder........................................... 209
Heated Seats......................................... 10, 11
Heated Steering Wheel............................... 195
Heater......................................................... 219
Highbeam On Light..................................... 241
High-Speed Operation, Tires........................ 462
Highway Hypnosis....................................... 363
Hill and Mountain Roads............................. 364
Hood
Checking Things Under............................ 404
Release................................................... 405Horn............................................................ 194
How to Use This Manual ................................ 4
How to Wear Safety Belts Properly............... 23
I
Ignition Positions......................................... 124
Infants and Young Children, Restraints .......... 42
Ination - Tire Pressure............................... 460
Instrument Panel
Overview.................................................. 192
Storage Area............................................ 166
Instrument Panel (I/P)
Brightness................................................ 211
Cluster..................................................... 226
J
Jump Starting.............................................. 438
K
Keyless Entry System................................... 92
Keys............................................................. 91
571

Power (cont.)
Retained Accessory (RAP)....................... 125
Running Boards....................................... 114
Seat............................................................ 8
Steering Fluid.......................................... 431
Windows.................................................. 116
Pretensioners, Safety Belt............................. 38
Programmable Automatic Door Locks.......... 102
Q
Questions and Answers About
Safety Belts............................................... 22
R
Radios........................................................ 267
Care of Your CD and DVD Player............ 318
Care of Your CDs and DVDs................... 318
Navigation/Radio System, see Navigation
Manual................................................. 302
Radio with CD and DVD.......................... 270
Rear Seat Audio...................................... 313
Setting the Time...................................... 269
Theft-Deterrent......................................... 315
Understanding Reception......................... 317
Rainsense™ II Wipers................................. 199Reading Lamps........................................... 212
Rear Axle.................................................... 444
Rear Door Security Locks........................... 103
Rear Safety Belt Comfort Guides.................. 35
Rear Seat Armrest...................................... 168
Rear Seat Audio (RSA)............................... 313
Rear Seat Entertainment System................. 302
Rear Seat Operation..................................... 16
Rear Seat Passengers, Safety Belts.............. 32
Rearview Mirror, Automatic Dimming with
OnStar
®, Compass and Temperature
Display..................................................... 145
Reclining Seatbacks, Power.......................... 14
Recommended Fluids and Lubricants.......... 533
Recovery Hooks.......................................... 371
Recreational Vehicle Towing........................ 379
Remote Keyless Entry System...................... 92
Remote Keyless Entry System, Operation..... 93
Removing the Flat Tire and Installing the
Spare Tire................................................ 482
Removing the Spare Tire and Tools............ 478
Replacement Bulbs..................................... 452
Reporting Safety Defects
Canadian Government............................. 561
General Motors........................................ 561
United States Government....................... 560
575
