Black plate (76,1)Cadillac Escalade EXT Owner Manual - 2011
10-76 Vehicle Care
Jacking Locations (Overall View)A. Front Position
B. Rear Position
{WARNING
Getting under a vehicle when it is
jacked up is dangerous. If the
vehicle slips off the jack, you
could be badly injured or killed.
Never get under a vehicle when it
is supported only by a jack.
{WARNING
Raising your vehicle with the
jack improperly positioned can
damage the vehicle and even
make the vehicle fall. To help
avoid personal injury and vehicle
damage, be sure to fit the jack lift
head into the proper location
before raising the vehicle.
4. Position the jack under the vehicle as shown.
Front Position
Front Tire Flat: If the flat tire is
on a front tire of the vehicle,
you will need to use the jack
handle (B) and only one jack
handle extension (C). Attach the
wheel wrench (D) to the jack
handle extension (C). Attach the
jack handle (B) to the jack (A).
Position the jack on the frame
behind the flat tire near the
front body mount (E) as shown.
Turn the wheel wrench (D)
clockwise to raise the vehicle.

Black plate (77,1)Cadillac Escalade EXT Owner Manual - 2011
Vehicle Care 10-77
Raise the vehicle far enough off
the ground so there is enough
room for the spare tire to clear
the ground.
Rear Position
Rear Tire Flat: If the flat tire
is on a rear tire of the vehicle,
use the jack handle (B) and both
jack handle extensions (C). Attach the wheel wrench (D) to
the jack handle extensions (C).
Attach the jack handle (B) to the
jack (A). Use the jacking pad (E)
provided on the rear axle. Turn
the wheel wrench (D) clockwise
to raise the vehicle. Raise the
vehicle far enough off the
ground so there is enough room
for the spare tire to clear the
ground.
5. Remove all the wheel nuts.
6. Take off the flat tire.
