4-35 Total Weight on Your Vehicle's Tires
Be sure your vehicle's tires are inflated to the upper
limit for cold tires. You'll find these numbers on the
Tire
-Loading Information label at the rear edge of
the driver's door or see ªLoading Your Vehicleº in
the Index. Then be sure you don't go over the GVW
limit for your vehicle, including the weight of the
trailer tongue.
Hitches
It's important to have the correct hitch equipment.
Crosswinds, large trucks going by and rough roads
are a few reasons why you'll need the right hitch. Here
are some rules to follow:

The rear bumper on your vehicle is not intended for
hitches. Do not attach rental hitches or other
bumper
-type hitches to it. Use only a frame-mounted
hitch that does not attach to the bumper.

If you'll be pulling a trailer that, when loaded, will
weigh more than 2,000 lbs. (900 kg), be sure to use a
properly mounted, weight
-distributing hitch and
sway control of the proper size. This equipment is
very important for proper vehicle loading and good
handling when you're driving.
Will you have to make any holes in the body of your
vehicle when you install a trailer hitch? If you do,
then be sure to seal the holes later when you remove
the hitch. If you don't seal them, deadly carbon
monoxide (CO) from your exhaust can get into your
vehicle (see ªCarbon Monoxideº in the Index). Dirt
and water can, too.
Safety Chains
You should always attach chains between your vehicle
and your trailer. Cross the safety chains under the tongue
of the trailer so that the tongue will not drop to the road
if it becomes separated from the hitch. Instructions
about safety chains may be provided by the hitch
manufacturer or by the trailer manufacturer. Follow the
manufacturer's recommendation for attaching safety
chains and do not attach them to the bumper. Always
leave just enough slack so you can turn with your rig.
And, never allow safety chains to drag on the ground.

yellowblue
4-36 Trailer Brakes
Because you have anti-lock brakes, don't try to tap into
your vehicle's hydraulic brake system. If you do, both
brake systems won't work well, or at all. If you tow
more than 1,000 lbs. (450 kg), use trailer brakes. Be sure
to follow the instructions that come with the trailer or
from the brake manufacturer.
Be sure to read and follow the instructions for the trailer
brakes so you'll be able to install, adjust and maintain
them properly.
Driving with a Trailer
Towing a trailer requires a certain amount of experience.
Before setting out for the open road, you'll want to get
to know your rig. Acquaint yourself with the feel of
handling and braking with the added weight of the
trailer. And always keep in mind that the vehicle you are
driving is now a good deal longer and not nearly as
responsive as your vehicle is by itself.Before you start, check the trailer hitch and platform
(and attachments), safety chains, electrical connector,
lamps, tires and mirror adjustment. If the trailer has
electric brakes, start your vehicle and trailer moving and
then apply the trailer brake controller by hand to be sure
the brakes are working. This lets you check your
electrical connection at the same time.
During your trip, check occasionally to be sure that the
load is secure, and that the lamps and any trailer brakes
are still working.
Following Distance
Stay at least twice as far behind the vehicle ahead as you
would when driving your vehicle without a trailer. This
can help you avoid situations that require heavy braking
and sudden turns.

yellowblue
8-6
Fog Lamp Light 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway Driving 4-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps, Bulb Replacement 6
-39 . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Release 6-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Level Low Message 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses
Circuit Breakers 6
-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underseat 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-72 . . . . . . . . . . . . . . . . . . . .
Fuel 2-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garment Hooks 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transaxle 2-24 . . . . . . . . . . . . . . . .
Glove Box 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 7-5 . . . . .
Gross Axle Weight Rating (GAWR) 4-30 . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating (GAWR) 4-30 . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handles, Assist 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aiming 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suggested Message 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Activated 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing, Damage 3-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . .
Heated Seats 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Road Driving 4-23 . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hooks, Garment 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn Sounds at Lock 2-88 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Add Coolant to the Coolant Surge Tank 5-14 . . . . . . .
How to Reset the Oil Life Indicator 6-15 . . . . . . . . . . . . . . . . .
HVAC Steering Wheel Controls 3-10 . . . . . . . . . . . . . . . . . . .
Hydraulic Brake Warning Lights 2-69 . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-13
Trailer
Brakes 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving on Grades 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving with 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling When Towing 4-39 . . . . . . . . . . . . . . . . . . .
Hitches 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Towing 4-39 . . . . . . . . . . . . . . . . . . . . .
Parking on Hills 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tongue Weight 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total Weight on Tires 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signals 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trans Hot Idle Engine Message 2-85 . . . . . . . . . . . . . . . . . . . .
Transaxle Fluid, Automatic 6-19 . . . . . . . . . . . . . . . . . . . . . . .
Transmitter, Universal 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmitters, Remote Keyless Entry 2-7 . . . . . . . . . . . . . . . . .
Transportation, Courtesy 7-8 . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip Odometer 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk 2-11
Lid Tie Down 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lock Release 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Open Message 2-86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage System 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn and Lane Change Signals 2-36 . . . . . . . . . . . . . . . . . . . .
Turn Signal On Chime 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal On Message 2-86 . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal/Multifunction Lever 2-36 . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-37 . . . . . . . . . . . . . . . .
Twilight Sentinel
2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Umbrella Holder 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-56 . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Junction Block 6-60 . . . . . . . . . . . . . . . . . . . . . . .
Underhood Lamp 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Understanding Radio Reception 3-32 . . . . . . . . . . . . . . . . . . .
Universal Transmitter 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Valet Lock 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Care/Appearance Materials 6
-57 . . . . . . . . . . . . . . . . . . . . .
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control, Loss of 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-58 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overspeed Message 2-86 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed Limiter 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols v. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing, Recreational 4
-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VIN 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Devices 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-67 . . . . . . . . . . . . . . .
Warranty Information 7-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wastebasket 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
