Electric Power Management
The vehicle has Electric Power Management
(EPM) that estimates the battery’s temperature and
state of charge. It then adjusts the voltage for
best performance and extended life of the battery.
When the battery’s state of charge is low, the
voltage is raised slightly to quickly put the charge
back in. When the state of charge is high, the
voltage is lowered slightly to prevent overcharging.
If the vehicle has a voltmeter gage or voltage
display on the Driver Information Center (DIC), you
may see the voltage move up or down. This is
normal. If there is a problem, an alert will be
displayed.
The battery can be discharged at idle if the
electrical loads are very high. This is true for all
vehicles. This is because the generator (alternator)
may not be spinning fast enough at idle to
produce all the power that is needed for very high
electrical loads.A high electrical load occurs when several of the
following loads are on: headlamps, high beams, fog
lamps, rear window defogger, climate control fan at
high speed, heated seats, engine cooling fans,
trailer loads, and loads plugged into accessory
power outlets.
EPM works to prevent excessive discharge of the
battery. It does this by balancing the generator’s
output and the vehicle’s electrical needs. It
can increase engine idle speed to generate more
power, whenever needed. It can temporarily
reduce the power demands of some accessories.
Normally, these actions occur in steps or levels,
without being noticeable. In rare cases at the
highest levels of corrective action, this action may
be noticeable to the driver. If so, a Driver
Information Center (DIC) message might be
displayed, such as Battery Saver Active or Service
Battery Charging System. If this message is
displayed, it is recommended that the driver
reduce the electrical loads as much as possible.
SeeDIC Warnings and Messages on page 220.
183

?(Recirculation):This mode recirculates air
inside the vehicle and keeps outside air from
coming into the vehicle. It can be used to help cool
the vehicle more quickly or to prevent odors
from entering the vehicle.
Recirculation is not available in the defrost mode.
It is also cancelled when oor or defog mode
is selected. In some conditions using recirculation
for long periods of time can cause the air inside
the vehicle to become too dry or stuffy. To prevent
this from happening, after the air in the vehicle
has cooled, select auto air inlet or outside air.
:(Outside Air):This mode pulls fresh air from
outside the vehicle. Outside air is always
selected in defrost mode to prevent fogging.
Air Conditioning
#
(Air Conditioning):Press this button to turn
the air conditioning on or off, and override the
automatic system. When selecting the AUTO fan
or AUTO mode, the air conditioning compressor
comes on automatically, as necessary.The air conditioning system removes moisture
from the air, so you might notice water dripping
underneath the vehicle while idling or after turning
off the engine. This is normal.
Sensors
There is a solar sensor located on top of the
instrument panel, near the windshield.
192

Rear Air Conditioning System
If your vehicle has the rear air conditioning system
it has two fan speed selectors. One fan speed
selector is located in the front overhead console
and the other is located in the headliner above the
second row seats. The rear air conditioning
system is designed to provide cooled air only.
To operate the rear system using the front control,
just turn the knob to the fan position you want.
To use the rear control, rst turn the front control
to AUX, then the rear control can be used to
increase and decrease the airow.
Passenger Compartment Air Filter
The passenger compartment air lter helps remove
dust and pollen from the air entering the vehicle.
Like the vehicle’s engine air cleaner/lter, it
needs to be changed periodically. For how often
to change the passenger compartment air
lter, seeScheduled Maintenance on page 471.
The passenger compartment air lter is located
underneath the hood below the windshield
wiper arm on the passenger’s side of the vehicle.
SeeEngine Compartment Overview on page 356
for more information on location.
Front ControlRear Control
195

Use the procedure listed below to replace the
passenger compartment air lter:
1. Open the hood to access the engine
compartment. SeeHood Release on page 355
for more information. Locate the passenger
compartment air lter access panel door.
2. Push the two tabs on the access panel door
towards the windshield.3. While pressing forward, lift the access panel
out of the clipped position and pull towards
the front of the vehicle. This releases the clips
and allows the panel door to be removed.
4. Remove the old lter and insert a new one.
Make sure the arrow on the lter is pointing
toward the passenger compartment.
SeeNormal Maintenance Replacement Parts
on page 482for the correct part number
for the lter.
5. Reverse Steps 1 through 3 to reinstall the
cover.
196

Warning Lights, Gages, and
Indicators
This part describes the warning lights and gages
that may be on your vehicle. The pictures will
help you locate them.
Warning lights and gages can signal that something
is wrong before it becomes serious enough to
cause an expensive repair or replacement. Paying
attention to the warning lights and gages could also
save you or others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle’s functions. As
you will see in the details on the next few
pages, some warning lights come on briey when
you start the engine just to let you know they
are working. If you are familiar with this section,
you should not be alarmed when this happens.Gages can indicate when there may be or is a
problem with one of your vehicle’s functions. Often
gages and warning lights work together to let
you know when there is a problem with your
vehicle.
When one of the warning lights comes on and
stays on while you are driving, or when one of the
gages shows there may be a problem, check
the section that tells you what to do about
it. Waiting to do repairs can be costly – and even
dangerous. So please get to know your warning
lights and gages. They are a big help.
Your vehicle also has a Driver Information Center
(DIC) that works along with the warning lights
and gages. SeeDriver Information Center (DIC)
on page 214for more information.
197

Speedometer and Odometer
The speedometer lets you see your speed
in both miles per hour (mph) and kilometers
per hour (km/h). See “SPEEDOMETER” under
DIC Controls and Displays on page 215for more
information.
The odometer mileage can be checked without the
vehicle running. Your vehicle’s odometer works
together with the driver information center.
You can set a Trip A and a Trip B odometer. See
“Trip Fuel” underDIC Controls and Displays on
page 215for more information.
If your vehicle ever needs a new odometer
installed, the new one will be set to the correct
mileage total of the old odometer.
Tachometer
This gage indicates the engine speed in
revolutions per minute (rpm).
Engine Speed Limiter
This feature prevents the engine from operating at
too many revolutions per minute (rpm). When
the engine’s rpms are too high, the throttle
is closed to reduce speed. If this is not sufficient,
then the fuel supply to the engine will be
limited. When the rpms return to normal, the fuel
supply will return to normal. This helps prevent
damage to the engine.
199

Charging System Light
This light will come on
briey when the ignition
is turned to ON to
show that it is working.
It should turn off once the engine is running. If it
stays on, or comes on while you are driving,
you may have a problem with the charging system.
It could indicate that there is a problem with the
generator, generator drive belt or another electrical
problem. Have is checked right away. Driving
while this light is on could drain your battery. If you
must drive a short distance with the light on, be
certain to turn off all unnecessary accessories,
such as the radio and air conditioner.
Brake System Warning Light
Your vehicle’s hydraulic brake system is divided
into two parts. If one part is not working, the other
part can still work and stop you. For good
braking, though, you need both parts working well.
If the warning light comes on, there is a brake
problem. Have your brake system inspected
right away.
This light should come on briey when you turn
the ignition key to ON. If it does not come on then,
have it xed so it will be ready to warn you if
there is a problem.
United StatesCanada
204

When the ignition is on, the brake system warning
light will also come on when you set your parking
brake. The light will stay on if your parking brake
does not release fully. If it stays on after your
parking brake is fully released, it means you have a
brake problem.
If the light comes on while you are driving, pull off
the road and stop carefully. You may notice
that the pedal is harder to push, or the pedal may
go closer to the oor. It may take longer to
stop. If the light is still on, have the vehicle towed
for service. SeeTowing Your Vehicle on
page 328.
{CAUTION:
Your brake system may not be working
properly if the brake system warning light
is on. Driving with the brake system
warning light on can lead to an accident.
If the light is still on after you have pulled
off the road and stopped carefully, have
the vehicle towed for service.
Anti-Lock Brake System Warning
Light
With the Anti-Lock
Brake System (ABS),
the light will come on
when your engine is
started and stay on for
several seconds. This is
normal.
If the ABS warning light comes on and stays on,
there may be a problem with the anti-lock
portion of the brake system. If the brake system
warning light is not on, you still have brakes,
but you do not have anti-lock brakes. SeeBrake
System Warning Light on page 204for more
information.
If the light stays on, turn the ignition to OFF. If the
light comes on when you are driving, stop as
soon as possible and turn the ignition off. Then
start the engine again to reset the system. If
the light still stays on, or comes on again while
you are driving, your vehicle needs service.
205
