Black plate (2,1)Cadillac SRX Owner Manual - 2011
10-2 Vehicle Care
Buying New Tires . . . . . . . . . . . 10-70
Different Size Tires andWheels . . . . . . . . . . . . . . . . . . . 10-72
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . 10-73
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . 10-75
Wheel Replacement . . . . . . . . 10-75
Tire Chains . . . . . . . . . . . . . . . . . 10-76
If a Tire Goes Flat . . . . . . . . . . 10-77
Tire Sealant and Compressor Kit . . . . . . . . . . . 10-79
Storing the Tire Sealant and Compressor Kit . . . . . . . . . . . 10-86
Tire Changing . . . . . . . . . . . . . . 10-86
Compact Spare Tire . . . . . . . . 10-93
Jump Starting
Jump Starting . . . . . . . . . . . . . . 10-94
Towing
Towing the Vehicle . . . . . . . . . 10-98
Recreational Vehicle Towing . . . . . . . . . . . . . . . . . . . . 10-98
Appearance Care
Exterior Care . . . . . . . . . . . . . . 10-101
Interior Care . . . . . . . . . . . . . . . 10-106
Floor Mats . . . . . . . . . . . . . . . . 10-108
General Information
For service and parts needs,
visit your dealer. You will receive
genuine GM parts and GM-trained
and supported service people.
Genuine GM parts have one of
these marks:
California Proposition
65 Warning
Most motor vehicles, including this
one, contain and/or emit chemicals
known to the State of California to
cause cancer and birth defects or
other reproductive harm. Engine
exhaust, many parts and systems,
many fluids, and some component
wear by-products contain and/or
emit these chemicals.

Black plate (68,1)Cadillac SRX Owner Manual - 2011
10-68 Vehicle Care
Tire Inspection
We recommend that you
regularly inspect your vehicle's
tires, including the spare tire,
if the vehicle has one, for signs
of wear or damage at least once
a month.
Always remove the tires if
any of the following statements
are true:
.You can see the indicators at
three or more places around
the tire.
.You can see cord or fabric
showing through the tire's
rubber.
.The tread or sidewall is
cracked, cut, or snagged
deep enough to show cord
or fabric.
.The tire has a bump, bulge,
or split.
.The tire has a puncture, cut,
or other damage that cannot
be repaired well because of
the size or location of the
damage.
Tire Rotation
Tires should be rotated
every 12 000 km (7,500 miles).
SeeScheduled Maintenance on
page 11‑2.
The purpose of a regular tire
rotation is to achieve a uniform
wear for all tires on the vehicle.
This will ensure that the vehicle
continues to perform most like it
did when the tires were new.
Any time you notice unusual
wear, rotate the tires as soon
as possible and check wheel
alignment. Also check for
damaged tires or wheels. See
When It Is Time for New
Tires on page 10‑69 andWheel
Replacement on page 10‑75.
When rotating the vehicle's tires,
always use the correct rotation
pattern shown here.
Do not include the compact
spare tire in the tire rotation.

Black plate (75,1)Cadillac SRX Owner Manual - 2011
Vehicle Care 10-75
Warning: The temperature grade
for this tire is established for a
tire that is properly inflated and
not overloaded. Excessive
speed, underinflation,
or excessive loading, either
separately or in combination,
can cause heat buildup and
possible tire failure.
Wheel Alignment and Tire
Balance
The tires and wheels on the vehicle
were aligned and balanced carefully
at the factory to give the longest tire
life and best overall performance.
Adjustments to wheel alignment and
tire balancing will not be necessary
on a regular basis. However, if there
is unusual tire wear or the vehicle
pulls to one side or the other, the
alignment should be checked. If the
vehicle vibrates when driving on a
smooth road, the tires and wheels
might need to be rebalanced. See
your dealer for proper diagnosis.
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts, and
wheel nuts should be replaced.
If the wheel leaks air, replace it,
except some aluminum wheels,
which can sometimes be repaired.
See your dealer if any of these
conditions exist.
Your dealer will know the kind of
wheel you need.
Each new wheel should have
the same load-carrying capacity,
diameter, width, offset, and be
mounted the same way as the
one it replaces.
If you need to replace any of the
wheels, wheel bolts, wheel nuts,
or Tire Pressure Monitor System
(TPMS) sensors, replace them only
with new GM original equipment
parts. This way, you will be sure to
have the right wheel, wheel bolts,
wheel nuts, and TPMS sensors for
the vehicle.{WARNING
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts on your vehicle can be
dangerous. It could affect the
braking and handling of your
vehicle, make your tires lose
air and make you lose control.
You could have a collision in
which you or others could be
injured. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Notice: The wrong wheel can
also cause problems with
bearing life, brake cooling,
speedometer or odometer
calibration, headlamp aim,
bumper height, vehicle ground
clearance, and tire or tire chain
clearance to the body and
chassis.
See If a Tire Goes Flat on
page 10‑77 for more information.

Black plate (12,1)Cadillac SRX Owner Manual - 2011
i-12 INDEX
Steering . . . . . . . . . . . . . . . . . . . . . . . . 9-5Fluid, Power . . . . . . . . . . . . . . . . 10-24
Wheel Adjustment . . . . . . . . . . . . . 5-2
Wheel Controls . . . . . . . . . . . . . . . . 5-2
Storage Mass Media (MEM) . . . . . . . . . . . 7-27
Storage Areas
Armrest . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Cargo Cover . . . . . . . . . . . . . . . . . . . 4-3
Cargo Management System . . . 4-5
Center Console . . . . . . . . . . . . . . . . 4-2
Convenience Net . . . . . . . . . . . . . 4-10
Front . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Glove Box . . . . . . . . . . . . . . . . . . . . . 4-1
Roof Rack System . . . . . . . . . . . . 4-11
Storing the Tire Sealant
and Compressor Kit . . . . . . . . . 10-86
Stuck Vehicle . . . . . . . . . . . . . . . . . . 9-11
Sun Visors . . . . . . . . . . . . . . . . . . . . . 2-27
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . iv
System Roof Rack . . . . . . . . . . . . . . . . . . . . 4-11T
Tachometer . . . . . . . . . . . . . . . . . . . . 5-12
Text Telephone (TTY) Users . . . 13-6
Theft-Deterrent Systems . . . . . . . 2-20Immobilizer . . . . . . . . . . . . . . . . . . . 2-20
Thigh Support Adjustment . . . . . . 3-8
Throttle, Adjustable . . . . . . . . . . . . 9-17
Time . . . . . . . . . . . . . . . . . . . . . . . . 5-7, 5-8
Tires Buying New Tires . . . . . . . . . . . 10-70
Chains . . . . . . . . . . . . . . . . . . . . . . 10-76
Changing . . . . . . . . . . . . . . . . . . . 10-86
Compact Spare . . . . . . . . . . . . . 10-93
Designations . . . . . . . . . . . . . . . 10-57
Different Size . . . . . . . . . . . . . . . 10-72
If a Tire Goes Flat . . . . . . . . . . 10-77
Inflation Monitor System . . . . 10-64
Inspection . . . . . . . . . . . . . . . . . . 10-68
Messages . . . . . . . . . . . . . . . . . . . . 5-39
Pressure . . . . . . . . . . . . . . . . . . . . 10-62
Pressure Light . . . . . . . . . . . . . . . . 5-25
Pressure Monitor System . . . 10-63
Rotation . . . . . . . . . . . . . . . . . . . . 10-68 Tires (cont.)
Sealant and
Compressor Kit . . . . . . . . . . . 10-79
Sealant and Compressor
Kit, Storing . . . . . . . . . . . . . . . . 10-86
Sidewall Labeling . . . . . . . . . . . 10-55
Terminology and Definitions . . . . . . . . . . . . . . . . . 10-58
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . 10-73
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . 10-75
Wheel Replacement . . . . . . . . 10-75
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . 10-69
Towing Driving Characteristics . . . . . . . . 9-54
Equipment . . . . . . . . . . . . . . . . . . . . 9-61
General Information . . . . . . . . . . 9-54
Recreational Vehicle . . . . . . . . 10-98
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 9-58
Trailer Sway Control (TSC) . . . 9-62
Vehicle . . . . . . . . . . . . . . . . . . . . . 10-98

Black plate (14,1)Cadillac SRX Owner Manual - 2011
i-14 INDEX
W
WarningBrake System Light . . . . . . . . . . . 5-22
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . 5-10
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . iv Cautions and Danger . . . . . . . . . . . .iv
Hazard Flashers . . . . . . . . . . . . . . . 6-5
Washer Fluid . . . . . . . . . . . . . . . . . 10-24
Washer Fluid Messages . . . . . . . 5-40
Washer, Headlamps . . . . . . . . . . . . 5-6
Wheels Alignment and TireBalance . . . . . . . . . . . . . . . . . . . 10-75
Different Size . . . . . . . . . . . . . . . 10-72
Replacement . . . . . . . . . . . . . . . 10-75 When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 10-69
Where to Put the Restraint . . . . 3-53
Windows . . . . . . . . . . . . . . . . . . . . . . 2-24 Power . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Windshield Wiper/Washer . . . . . . . . . . . . . . . . . 5-3
Winter Driving . . . . . . . . . . . . . . . . . . 9-9
Wiper Blade Replacement . . . . 10-31
Wipers Rear Washer . . . . . . . . . . . . . . . . . . 5-5
