Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
166 Driving and Operating
Hill and Mountain Roads
Driving on steep hills or through
mountains is different than driving
on flat or rolling terrain. Tips include:
.Keep the vehicle serviced and in
good shape.
. Check all fluid levels and brakes,
tires, cooling system, and
transmission.
. Shift to a lower gear when going
down steep or long hills.
{Warning
Using the brakes to slow the
vehicle on a long downhill slope
can cause brake overheating, can
reduce brake performance, and
could result in a loss of braking.
Shift the transmission to a lower
gear to let the engine assist the
brakes on a steep downhill slope.
{Warning
Coasting downhill in N (Neutral)
or with the ignition off is
dangerous. This can cause
overheating of the brakes and
loss of steering. Always have the
engine running and the vehicle
in gear.
. Drive at speeds that keep the
vehicle in its own lane. Do not
swing wide or cross the
center line.
. Be alert on top of hills;
something could be in your lane
(e.g., stalled car, accident).
. Pay attention to special road
signs (e.g., falling rocks area,
winding roads, long grades,
passing or no-passing zones)
and take appropriate action.
Winter Driving
Driving on Snow or Ice
Snow or ice between the tires and
the road creates less traction or
grip, so drive carefully. Wet ice can
occur at about 0 °C (32 °F) when
freezing rain begins to fall. Avoid
driving on wet ice or in freezing rain
until roads can be treated.
For Slippery Road Driving:
.Accelerate gently. Accelerating
too quickly causes the wheels to
spin and makes the surface
under the tires slick.
. Turn on Traction Control. See
Traction Control/Electronic
Stability Control 0186.
. Antilock Brake System (ABS)
improves vehicle stability during
hard stops, but the brakes
should be applied sooner than
when on dry pavement. See
Antilock Brake System (ABS)
0182.
. Allow greater following distance
and watch for slippery spots. Icy
patches can occur on otherwise

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
Vehicle Care 221
Vehicle Care
General Information
General Information . . . . . . . . . . 222
Accessories andModifications . . . . . . . . . . . . . . . . 222
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 223
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 223
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 224
Engine Cover . . . . . . . . . . . . . . . . . 225
Engine Oil . . . . . . . . . . . . . . . . . . . . 225
Engine Oil Life System . . . . . . . 228
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . 229
Engine Air Cleaner/Filter . . . . . . 229
Cooling System . . . . . . . . . . . . . . 231
Engine Coolant . . . . . . . . . . . . . . . 231
Engine Overheating . . . . . . . . . . 235
Power Steering Fluid . . . . . . . . . 236
Washer Fluid . . . . . . . . . . . . . . . . . 237
Brakes . . . . . . . . . . . . . . . . . . . . . . . 237
Brake Fluid . . . . . . . . . . . . . . . . . . . 238
Battery . . . . . . . . . . . . . . . . . . . . . . . . 239
All-Wheel Drive . . . . . . . . . . . . . . . 240
Starter Switch Check . . . . . . . . . 240 Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 240
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 241
Wiper Blade Replacement . . . . 241
Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . 243
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 243
Halogen Bulbs . . . . . . . . . . . . . . . . 243
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . . . . . . . 243
Headlamps . . . . . . . . . . . . . . . . . . . 244
Turn Signal Lamps . . . . . . . . . . . 247
Back-Up Lamps . . . . . . . . . . . . . . 248
License Plate Lamp . . . . . . . . . . 248
Replacement Bulbs . . . . . . . . . . . 249
Electrical System
Electrical System Overload . . . 249
Fuses and Circuit Breakers . . . 250
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 250
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 253
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 255
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 258
All-Season Tires . . . . . . . . . . . . . . 259
Winter Tires . . . . . . . . . . . . . . . . . . 259
Summer Tires . . . . . . . . . . . . . . . . 259
Tire Pressure . . . . . . . . . . . . . . . . . 260
Tire Pressure for High-SpeedOperation . . . . . . . . . . . . . . . . . . . 261
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 262
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 263
Tire Inspection . . . . . . . . . . . . . . . . 265
Tire Rotation . . . . . . . . . . . . . . . . . 266
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 267
Buying New Tires . . . . . . . . . . . . . 268
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 269
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 269
Wheel Replacement . . . . . . . . . . 270
Tire Chains . . . . . . . . . . . . . . . . . . . 270
If a Tire Goes Flat . . . . . . . . . . . . 271
Tire Changing . . . . . . . . . . . . . . . . 272
Compact Spare Tire . . . . . . . . . . 278
Jump Starting
Jump Starting . . . . . . . . . . . . . . . . 279

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
Vehicle Care 259
All-Season Tires
This vehicle may come with
all-season tires. These tires are
designed to provide good overall
performance on most road surfaces
and weather conditions. Original
equipment tires designed to GM's
specific tire performance criteria
have a TPC specification code
molded onto the sidewall. Original
equipment all-season tires can be
identified by the last two characters
of this TPC code, which will
be“MS.”
Consider installing winter tires on
the vehicle if frequent driving on
snow or ice-covered roads is
expected. All-season tires provide
adequate performance for most
winter driving conditions, but they
may not offer the same level of
traction or performance as winter
tires on snow or ice-covered roads.
See Winter Tires 0259.
Winter Tires
This vehicle was not originally
equipped with winter tires. Winter
tires are designed for increased traction on snow and ice-covered
roads. Consider installing winter
tires on the vehicle if frequent
driving on ice or snow covered
roads is expected. See your dealer
for details regarding winter tire
availability and proper tire selection.
Also, see
Buying New Tires 0268.
With winter tires, there may be
decreased dry road traction,
increased road noise, and shorter
tread life. After changing to winter
tires, be alert for changes in vehicle
handling and braking.
If using winter tires:
. Use tires of the same brand and
tread type on all four wheel
positions.
. Use only radial ply tires of the
same size, load range, and
speed rating as the original
equipment tires.
Winter tires with the same speed
rating as the original equipment tires
may not be available for H, V, W, Y,
and ZR speed rated tires. If winter tires with a lower speed rating are
chosen, never exceed the tire's
maximum speed capability.
Summer Tires
This vehicle may come with high
performance summer tires. These
tires have a special tread and
compound that are optimized for
maximum dry and wet road
performance. This special tread and
compound will have decreased
performance in cold climates, and
on ice and snow. It is recommended
that winter tires be installed on the
vehicle if frequent driving at
temperatures below approximately
5 °C (40 °F) or on ice or snow
covered roads is expected. See
Winter Tires
0259.
Caution
High performance summer tires
have rubber compounds that lose
flexibility and may develop
surface cracks in the tread area
at temperatures below −7 °C (20 °
(Continued)

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
268 Vehicle Care
Buying New Tires
GM has developed and matched
specific tires for the vehicle. The
original equipment tires installed
were designed to meet General
Motors Tire Performance Criteria
Specification (TPC Spec)
system rating. When
replacement tires are needed,
GM strongly recommends
buying tires with the same TPC
Spec rating.
GM's exclusive TPC Spec
system considers over a dozen
critical specifications that impact
the overall performance of the
vehicle, including brake system
performance, ride and handling,
traction control, and tire
pressure monitoring
performance. GM's TPC Spec
number is molded onto the tire's
sidewall near the tire size. If the
tires have an all-season tread
design, the TPC Spec number
will be followed by MS for mud
and snow.GM recommends replacing worn
tires in complete sets of four.
Uniform tread depth on all tires
will help to maintain the
performance of the vehicle.
Braking and handling
performance may be adversely
affected if all the tires are not
replaced at the same time.
If proper rotation and
maintenance have been done,
all four tires should wear out at
about the same time. See
Tire
Rotation 0266 for information
on proper tire rotation. However,
if it is necessary to replace only
one axle set of worn tires, place
the new tires on the rear axle.
Winter tires with the same speed
rating as the original equipment
tires may not be available for H,
V, W, Y, and ZR speed rated
tires. Never exceed the winter
tire's maximum speed capability
when using winter tires with a
lower speed rating.{Warning
Tires could explode during
improper service. Attempting
to mount or dismount a tire
could cause injury or death.
Only your dealer or authorized
tire service center should
mount or dismount the tires.
{Warning
Mixing tires of different sizes,
brands, or types may cause
loss of control of the vehicle,
resulting in a crash or other
vehicle damage. Use the
correct size, brand, and type
of tires on all wheels.

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
310 Index
Assistance Systems forDriving . . . . . . . . . . . . . . . . . . . . . . . . 202
Assistance Systems for Parking and Backing . . . . . . . . . . 198
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 41
Door Locks . . . . . . . . . . . . . . . . . . . . . 32
Transmission . . . . . . . . . . . . . . . . . 178
Transmission Fluid . . . . . . . . . . . 229
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 180
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 240
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 239Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . 151
Jump Starting . . . . . . . . . . . . . . . . . 279
Load Management . . . . . . . . . . . . 150
Power Protection . . . . . . . . . . . . . 151
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . 126
Blade Replacement, Wiper . . . . . 241
Brake Pedal and Adjustable
Throttle . . . . . . . . . . . . . . . . . . . . . . 172
System Warning Light . . . . . . . . .116
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 237 Brakes (cont'd)
Antilock . . . . . . . . . . . . . . . . . . . . . . . 182
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 185
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Parking . . . . . . . . . . . . . . . . . . . . . . . 183
System Messages . . . . . . . . . . . . 126
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 163
Break-In, New Vehicle . . . . . . . . . . 172
Bulb Replacement . . . . . . . . . . . . . . 249 Back-up Lamps . . . . . . . . . . . . . . . 248
Halogen Bulbs . . . . . . . . . . . . . . . . 243
Headlamp Aiming . . . . . . . . . . . . . 243
Headlamps . . . . . . . . . . . . . . 243, 244
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 243
License Plate Lamps . . . . . . . . . 248
Turn Signal Lamps . . . . . . . . . . . 247
Buying New Tires . . . . . . . . . . . . . . . 268
C
Capacities and
Specifications . . . . . . . . . . . . . . . . . 305
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 177
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 33
Winter Driving . . . . . . . . . . . . . . . . 166
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Management System . . . . . . . . . . . 94 Cargo (cont'd)
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . 94
Cargo Lamp . . . . . . . . . . . . . . . . . . . . 149
Cargo Net . . . . . . . . . . . . . . . . . . . . . . . 97
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . . 92
Chains, Tire . . . . . . . . . . . . . . . . . . . . 270
Charging System Light . . . . . . . . . 114
Check Malfunction IndicatorEngine Light . . . . . . . . . . . . . . . . .115
Child Restraints Infants and Young Children . . . . . 74
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 79
Older Children . . . . . . . . . . . . . . . . . . 73
Securing . . . . . . . . . . . . . . . . . . . . 84, 86
Systems . . . . . . . . . . . . . . . . . . . . . . . . 76
Cigarette Lighter . . . . . . . . . . . . . . . . 107
Circuit Breakers . . . . . . . . . . . . . . . . 250
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 287
Interior Care . . . . . . . . . . . . . . . . . . 291
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . 153
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Cluster, Instrument . . . . . . . . . . . . . 108

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
Index 317
Shift Lock Control FunctionCheck, Automatic
Transmission . . . . . . . . . . . . . . . . . . 240
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 176
Out of Park . . . . . . . . . . . . . . . . . . . 176
Side Blind Zone Alert (SBZA) . . . 206
Signals, Turn and
Lane-Change . . . . . . . . . . . . . . . . . 148
Spare Tire Compact . . . . . . . . . . . . . . . . . . . . . . 278
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 305
Speedometer . . . . . . . . . . . . . . . . . . . 109
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . .119
Start Assist, Hills . . . . . . . . . . . . . . . 185
Start Vehicle, Remote . . . . . . . . . . . 30
Starter Switch Check . . . . . . . . . . . 240
Starting the Gasoline Engine . . . 174
Starting the Vehicle Messages . . . . . . . . . . . . . . . . . . . . . 134
Steering . . . . . . . . . . . . . . . . . . . . . . . . 163 Fluid, Power . . . . . . . . . . . . . . . . . . 236
Heated Wheel . . . . . . . . . . . . . . . . 102
Wheel Adjustment . . . . . . . . . . . . 102
Wheel Controls . . . . . . . . . . . . . . . 102 Storage Areas
Armrest . . . . . . . . . . . . . . . . . . . . . . . . . 91
Cargo Cover . . . . . . . . . . . . . . . . . . . . 92
Cargo Management System . . . . 94
Center Console . . . . . . . . . . . . . . . . . 92
Convenience Net . . . . . . . . . . . . . . . 99
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Glove Box . . . . . . . . . . . . . . . . . . . . . . 90
Roof Rack System . . . . . . . . . . . . . . 99
Storage Compartments . . . . . . . . . . 90
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 167
Summer Tires . . . . . . . . . . . . . . . . . . 259
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 44
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Switches Airbag On-Off . . . . . . . . . . . . . . . . . . . 69
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 202
Infotainment . . . . . . . . . . . . . 152, 308
Roof Rack . . . . . . . . . . . . . . . . . . . . . . 99
Systems Driver Assistance . . . . . . . . . . . . . 198T
Tachometer . . . . . . . . . . . . . . . . . . . . . 110
Theft-Deterrent Systems . . . . . . . . . 39
Thigh Support Adjustment . . . . . . . 50
Throttle, Adjustable . . . . . . . . . . . . . 172
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258All-Season . . . . . . . . . . . . . . . . . . . . 259
Buying New Tires . . . . . . . . . . . . . 268
Chains . . . . . . . . . . . . . . . . . . . . . . . . 270
Changing . . . . . . . . . . . . . . . . . . . . . 272
Compact Spare . . . . . . . . . . . . . . . 278
Different Size . . . . . . . . . . . . . . . . . 269
If a Tire Goes Flat . . . . . . . . . . . . 271
Inspection . . . . . . . . . . . . . . . . . . . . 265
Messages . . . . . . . . . . . . . . . . . . . . 134
Pressure . . . . . . . . . . . . . . . . . . . . . . 261
Pressure Light . . . . . . . . . . . . . . . . 120
Pressure Monitor Operation . . 263
Pressure Monitor System . . . . . 262
Rotation . . . . . . . . . . . . . . . . . . . . . . 266
Wheel Alignment and TireBalance . . . . . . . . . . . . . . . . . . . . . 269
Wheel Replacement . . . . . . . . . . 270
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 267
Winter . . . . . . . . . . . . . . . . . . . . . . . . 259

Cadillac SRX Owner Manual (GMNA-Localizing-MidEast-9369636) - 2016 -
crc - 6/1/15
318 Index
TowingDriving Characteristics . . . . . . . . 212
Equipment . . . . . . . . . . . . . . . . . . . . 218
General Information . . . . . . . . . . 212
Recreational Vehicle . . . . . . . . . . 284
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 215
Trailer Sway Control (TSC) . . . 219
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 283
Traction Control System (TCS)/StabiliTrak
®Light . . . . . . . . . . . . .119
Limited-Slip Rear Axle . . . . . . . . 187
Off Light . . . . . . . . . . . . . . . . . . . . . . .119
Selective Ride Control . . . . . . . . 188
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 186
Trailer Sway Control (TSC) . . . . . . . . . . 219
Towing . . . . . . . . . . . . . . . . . . . . . . . . 215
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 178
Fluid, Automatic . . . . . . . . . . . . . . 229
Messages . . . . . . . . . . . . . . . . . . . . 135
Trip Odometer . . . . . . . . . . . . . . . . . . 110
Turn and Lane-Change Signals . . . . . . . . . . . . . . . . . . . . . . . . 148
Twilight Sentinel . . . . . . . . . . . . . . . . 146
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . 37
Control . . . . . . . . . . . . . . . . . . . . . . . 163
Identification Number (VIN) . . . 304
Load Limits . . . . . . . . . . . . . . . . . . . 168
Messages . . . . . . . . . . . . . . . . . . . . 126
Personalization . . . . . . . . . . . . . . . 136
Reminder Messages . . . . . . . . . . 135
Remote Start . . . . . . . . . . . . . . . . . . . 30
Security . . . . . . . . . . . . . . . . . . . . . . . . 37
Speed Messages . . . . . . . . . . . . . 135
Towing . . . . . . . . . . . . . . . . . . . . . . . . 283
Vehicle Ahead Indicator . . . . . . . . 118
Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . . . 260
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 307
Ventilation, Air . . . . . . . . . . . . . . . . . . 159
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
W
Warning Brake System Light . . . . . . . . . . . .116
Caution and Danger . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . 208
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 107 Warnings
Hazard Flashers . . . . . . . . . . . . . . 147
Washer Fluid . . . . . . . . . . . . . . . . . . . 237 Messages . . . . . . . . . . . . . . . . . . . . 136
Washer, Headlamps . . . . . . . . . . . . 105
Wheels Alignment and Tire Balance . . 269
Different Size . . . . . . . . . . . . . . . . . 269
Replacement . . . . . . . . . . . . . . . . . 270
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Where to Put the Restraint . . . . . . 78
Windows . . . . . . . . . . . . . . . . . . . . . . . . 42 Power . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Windshield Wiper/Washer . . . . . . . . . . . . . . . . 103
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . 166
Winter Tires . . . . . . . . . . . . . . . . . . . . 259
Wiper Blade Replacement . . . . . . 241
Wipers Rear Washer . . . . . . . . . . . . . . . . . 104
