jacking CADILLAC STS 2006 1.G Owners Manual

Notice:Lifting your vehicle improperly can damage
your vehicle and result in costly repairs not
covered by your warranty. To lift your vehicle
properly, follow the advice in this part.
To help prevent vehicle damage:
Be sure the jack you are using meets the weight
standards for your vehicle and is in good
working order.
Be sure to place a block or pad between the
jack and the vehicle.
Make sure the jack you are using only contacts
the jacking location lift points and is not leaning
on any other vehicle components such as the
rocker panels, the oor pan, or the stone guard
moldings.
Lift only in the areas shown in the following
pictures.
Lifting From the Front
The front lifting points can be accessed from either side
of your vehicle, behind the front tires.
1. Locate the front lifting points using the diagram
above. The front lifting location is about 15 inches
(37 cm) from the rear edge of the front wheel well.
2. Be sure to place a block or pad between the jack
and the vehicle.
3. Lift the vehicle with the jack, making sure the jack
is centered on the front lifting point.
5-80

Removing the Spare Tire and Tools
(STS Only)
The equipment you will need is located in the trunk.
To gain access to the compact spare tire and jacking
equipment, do the following:
1. Open the trunk. SeeTrunk on page 2-14for more
information.
2. Remove the compact spare tire cover.
3. Turn the nut holding the jack package container
counterclockwise and remove it. Then remove the
jack and wheel wrench.4. Remove the compact spare tire. SeeCompact
Spare Tire (STS Only) on page 5-94for more
information about the compact spare tire.
The tools you will be using include the jack (A) and the
wheel wrench (B).
5-85

3. Find the vehicle’s jacking location using the
diagram above and corresponding hoisting notches
located in the plastic molding on the vehicle’s
frame. The notches in the plastic molding are
marked with a triangle shape to help you nd them.
4. Attach the wheel wrench to the jack.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
5-87
