Filling a Portable Fuel Container
{CAUTION:
Never ll a portable fuel container while it
is in your vehicle. Static electricity
discharge from the container can ignite the
gasoline vapor. You can be badly burned
and your vehicle damaged if this occurs.
To help avoid injury to you and others:
Dispense gasoline only into approved
containers.
Do not ll a container while it is inside a
vehicle, in a vehicle’s trunk, pickup
bed, or on any surface other than the
ground.
CAUTION: (Continued)
CAUTION: (Continued)

Bring the ll nozzle in contact with the
inside of the ll opening before
operating the nozzle. Contact should
be maintained until the lling is
complete.
Do not smoke while pumping
gasoline.
Do not use a cellular phone while
pumping gasoline.
371

Checking Things Under
the Hood
{CAUTION:
An electric fan under the hood can start up
and injure you even when the engine is not
running. Keep hands, clothing, and tools
away from any underhood electric fan.
{CAUTION:
Things that burn can get on hot engine
parts and start a re. These include
liquids like fuel, oil, coolant, brake uid,
windshield washer and other uids, and
plastic or rubber. You or others could be
burned. Be careful not to drop or spill
things that will burn onto a hot engine.
Hood Release
To open the hood, do the following:
1. Pull the hood
release lever with
this symbol on
it. It is located inside
the vehicle on the
lower left side of the
instrument panel.
372

2. Then go to the front of the vehicle and nd
the secondary hood release lever. The lever
is located under the front edge of the
grille near the center. Move the release lever
to the side and raise the hood.
Before closing the hood, be sure all the ller caps
are on properly. Then pull the hood down and
close it rmly.
Engine Compartment Overview
Your vehicle may be equipped with front
compartment underhood sight shields, which
surround the vehicle’s engine cover. These sight
shields will need to be removed in order to access
some of the underhood components in your vehicle.
To remove the sight shields, turn the fasteners on
each shield to the left until they pop out. Then
remove the fasteners and lift the shields up and
away from the tower to tower brace.
373

3.6L V6 Engine
374

After you have removed the sight shields (if equipped) on the 3.6L V6 engine, here is what you will see:
A. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 488.
B. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 404.
C. Battery. SeeBattery on page 408.
D. Passenger Compartment Air Filter. See
Passenger Compartment Air Filter on page 239.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 403.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 380.G. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 380.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 405.
I. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on
page 393andCooling System on page 396.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 386.
375

4.6L V8 Engine
376

After you have removed the sight shields (if equipped) on the 4.6L V8 engine, here is what you will see:
A. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 488.
B. Battery. SeeBattery on page 408.
C. Passenger Compartment Air Filter. See
Passenger Compartment Air Filter on page 239.
D. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 404.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 403.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 380.G. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 380.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 405.
I. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on
page 393andCooling System on page 396.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 386.
377

4.4L V8 STS-V Engine
378

After you have removed the sight shields (if equipped) on the 4.4L V8 STS-V engine, here is what
you will see:
A. Battery. SeeBattery on page 408.
B. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 488.
C. Passenger Compartment Air Filter. See
Passenger Compartment Air Filter on page 239.
D. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 404.
E. Intercooler System Pressure Cap. SeeEngine
Coolant on page 389.
F. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 403.
G. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 380.
H. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 380.I. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 405.
J. Engine Coolant Surge Tank and Pressure Cap.
SeeCoolant Surge Tank Pressure Cap on
page 393andCooling System on page 396.
K. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 386.
If your vehicle is equipped with front compartment
underhood sight shields, before closing the
hood be sure to reinstall the sight shields. To
reinstall the shields, locate the tabs on the left and
right sides and insert them into the openings in
the tower to tower brace. Then insert the fasteners
into the top of the shield and push the fasteners
back into place.
379

Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time
you get fuel. In order to get an accurate reading,
the oil must be warm and the vehicle must be
on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 373
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil several
minutes to drain back into the oil pan. If you
do not do this, the oil dipstick might not
show the actual level.
2. Pull out the dipstick and clean it with a paper
towel or cloth, then push it back in all the
way. Remove it again, keeping the tip down,
and check the level.
When to Add Engine Oil
V6 Engine
V8 Engine
380
