2. Place the new transmitter into the transmitter
pocket, located inside the center console storage
area located between the driver and front passenger
seats, with the transmitter buttons facing the front
of the vehicle.
3. Insert the vehicle key into the key lock cylinder
located on the driver door.
4. Turn the key to the unlock position ve times within
ve seconds.5. The DIC message displays OFF/ACC TO LEARN.
6. Press Acc. on the ignition switch.
7. The DIC reads WAIT 10 MINUTES and counts
down to zero.
8. The DIC displays OFF/ACC TO LEARN again.
9. Press Acc. on the ignition switch.
10. Steps 7, 8 and 9 will be repeated two more times.
11. A beep sounds and the DIC reads READY
FOR FOB 1. All previously known transmitter
programming has been erased.
12. A beep sounds once programming in complete.
The DIC displays READY FOR FOB #2.
13. To program additional transmitters, take
transmitter 1 out of the transmitter pocket and
place transmitter 2 in the pocket. Up to four
transmitters can be programmed. The DIC will
then display MAX # FOBS LEARNED and will
exit the programming mode.
14. Remove the transmitter from the transmitter pocket
and press
Ktwice on each newly programmed
transmitter to complete the process.
2-9

Starting the Vehicle with a Low
Transmitter Battery
If the transmitter battery is weak, the DIC may display
NO FOBS DETECTED when trying to start the vehicle.
To start the vehicle, place the transmitter in the center
console storage area transmitter pocket with the buttons
facing to the front of the vehicle. Then, with the vehicle in
P (Park) OR N (Neutral), press the brake pedal and
/.
Replace the transmitter battery as soon as possible.
Change the transmitter battery if the DIC displays
KEY FOB BATTERY LOW.
Battery Replacement
Notice:When replacing the battery, do not touch
any of the circuitry on the transmitter. Static
from your body could damage the transmitter.1. Separate the transmitter with a at, thin object
inserted into the slot on the side of the transmitter.
2. Remove the old battery. Do not use a metal object.
3. Insert the new battery, positive side facing down.
Replace with a CR2032 or equivalent battery.
4. Snap the transmitter back together.
2-10

Remote Vehicle Start
This feature allows you to start the engine from outside
the vehicle.
Before the remote vehicle start system can be operated,
it must be turned on through the vehicle personalization
system.
You can also program the remote vehicle start system to
start up the vehicle’s automatic climate control system. If
this feature is turned on, the system monitors the outside
temperature and turns on the rear window defogger, front
window defogger, and heated or ventilated seats, if your
vehicle has them. See “Personal Settings Menu” under
Vehicle Personalization on page 2-61.
/(Remote Start):This button will be on the RKE
transmitter if you have remote start.
To start the vehicle using the remote start feature:
1. Aim the remote keyless access transmitter at the
vehicle.
2. Press the transmitter’s
Q, release it, and then
immediately press and hold the transmitter’s
/for at
least three seconds or until the vehicle’s turn signal
lamps ash. The vehicle’s doors will be locked.
When the vehicle starts, the parking lamps will turn
on and remain on while the vehicle is running.3. If it is the rst remote start since the vehicle has
been driven, repeat these steps, while the engine
is still running, to extend the engine running time
by 10 minutes. Remote start can be extended
one time.
If the vehicle is left running it will automatically shut off
after 10 minutes unless a time extension has been done.
To manually shut off a remote start, do one of the
following:
Aim the keyless access transmitter at the vehicle and
press the remote start button until the parking lamps
turn off.
Turn on the hazard warning ashers.
Press the Acc. button (ignition switch). SeeIgnition
Positions on page 2-26.
Turn on the valet lockout switch. SeeValet Lockout
Switch on page 2-23.
When you enter the vehicle during a remote start,
press the brake pedal and press the start button on the
keyless ignition switch to transition from remote start
operation to normal vehicle operation.
Laws in some local communities may restrict the use
of remote starters. For example, laws may require
a person using remote start to have the vehicle in
view when doing so. Check local regulations for any
requirements on remote starting of vehicles.
2-11

Do not use the remote start feature if your vehicle is low
on fuel. Your vehicle may run out of fuel.
The remote start feature provides two separate starts,
each with 10 minutes of engine running. If you press
the lock button and then hold the remote start button
on the keyless access transmitter again for at least
three seconds before the rst 10 minutes of engine
running time has expired, 10 minutes is added to the
remaining minutes. For example, if the remote start is
initiated again after ve minutes of the engine run time,
10 minutes is added and you now have 15 minutes with
the engine running. Once two remote starts or 20 minutes
of the engine running have been provided, the vehicle
must be started using the keyless access with pushbutton
start feature, if the engine needs to be restarted. See
Starting the Engine on page 2-27for more information
regarding the keyless ignition.The remote start feature will not operate if any of the
following occur:
The check engine light is displayed. See “Check
Engine Light” underMalfunction Indicator Lamp
on page 3-66.
The valet lockout switch is on.
The keyless access transmitter is in the vehicle.
The vehicle’s hood is open.
The vehicle personalization feature is not enabled.
An unauthorized vehicle entry or a vehicle theft
was attempted.
If your vehicle has the remote start feature, the keyless
access transmitter functions will have an increased
range of operation. However, the range may be
less while the vehicle is running.
There are other conditions which can affect the
performance of the transmitter, seeKeyless Access
System on page 2-4.
2-12

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. You increase the chance of
being thrown out of the vehicle in a crash if
the doors are not locked. So, wear safety
belts properly and lock the doors whenever
you drive.
Young children who get into unlocked vehicles
may be unable to get out. A child can be
overcome by extreme heat and can suffer
permanent injuries or even death from heat
stroke. Always lock your vehicle whenever
you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.From the outside:
Pull the door handle. If you have the keyless
access transmitter, the vehicle recognizes the
transmitter and automatically unlocks the door.
Another way to lock or unlock the vehicle, is to
press the lock or unlock button on the keyless
access transmitter. SeeVehicle Personalization
on page 2-61for information on how to program
the keyless access feature.
From the inside:
Press the power door lock switch located on each
front door. SeePower Door Locks on page 2-13
for more information.
Push down or pull up on the manual door lock knob
for the rear door. The knob is located at the top of
the door panel near the window.
Power Door Locks
The power door lock switches are located on the
front doors.
"(Unlock):Press to unlock the doors.
Q(Lock):Remove the key from the ignition and press
to lock the doors.
2-13

Programmable Automatic Door
Locks
The vehicle was programmed so when the doors are
closed, the ignition is on, and the shift lever is moved
out of P (Park), all the doors will lock.
The front doors can still be opened from the inside while
the doors are locked. If a rear passenger needs to exit the
vehicle, have that person use the manual knob or use the
power door lock switch on either front door. When the
door is closed again, it will not lock automatically. Use
the manual knob or the power door lock switch to lock
the door.
The doors were also pre-programmed to unlock every
time the shift lever is moved into P (Park).
The power door locks can be programmed through the
radio display. The radio display allows you to choose
various lock and unlock settings. For more information
on programming, seeVehicle Personalization on
page 2-61.
Rear Door Security Locks
The vehicle has rear door security locks to prevent
passengers from opening the rear doors from the inside.
Open the rear doors to
access the security locks
on the inside edge of
each door.
To set the locks, insert a key into the slot and turn it to
the horizontal position. The door can only be opened from
the outside with the door unlocked. To return the door to
normal operation, turn the slot to the vertical position.
2-14

Lockout Protection
The vehicle can be programmed to sound the horn
three times and unlock the driver’s door when all doors
are closed and there is a keyless access transmitter
inside the interior of the vehicle. When the driver’s
door is reopened, the key in reminder chime will sound
continuously. The vehicle will remain locked only when at
least one transmitter has been removed from the vehicle
and both doors are closed. SeeVehicle Personalization
on page 2-61.
Trunk
{CAUTION:
Exhaust gases may enter the vehicle if it is
driven with the liftgate, trunk/hatch open, or with
any objects that pass through the seal between
the body and the trunk/hatch or liftgate. Engine
CAUTION: (Continued)
CAUTION: (Continued)
exhaust contains Carbon Monoxide (CO) which
cannot be seen or smelled. It can cause
unconsciousness and even death.
If the vehicle must be driven with the liftgate, or
trunk/hatch open:
Close all of the windows
Fully open the air outlets on or under the
instrument panel
Adjust the Climate Control system to a setting
that brings in only outside air and set the fan
speed to the highest setting. See Climate
Control System in the Index.
If the vehicle is equipped with a power liftgate,
disable the power liftgate function.
For more information about carbon monoxide, see
Engine ExhaustEngine Exhaust on page 2-36.
2-15

Trunk Lid Release
There are three ways to open the trunk lid.
V(Trunk Lid Release):Press this button
located on the driver’s door. The vehicle must
be in P (Park) or N (Neutral) and the valet mode
turned off. To disable valet mode, seeValet
Lockout Switch on page 2-23.
Press the trunk lid release button on the keyless
access transmitter. SeeKeyless Access System
Operation on page 2-5. The vehicle must be
in P (Park) or N (Neutral) and the valet mode
turned off.
Squeeze the trunk release button located on the
rear of the trunk lid above the license plate. If the
vehicle is locked, the keyless access transmitter
must be within three feet (one meter) of the trunk
opening for it to be recognized and allow the trunk to
open. If the vehicle doors are unlocked, the trunk is
also unlocked and the keyless access transmitter
does not have to be at the rear of the vehicle to open
it. The vehicle must be in P (Park) and the valet
mode turned off.
2-16

If your vehicle has lost battery power, you can still
access the trunk by unlocking and lowering the rear seat
pass-through door and pulling the emergency trunk
release handle.
Rear Seat Pass-Through Door
To open the door:
1. Pull the rear seat armrest down.
2. If the door is locked, insert the key into the lock and
turn it counterclockwise.
3. Press the button above the lock and lower the door.
To open the trunk lid, pull the emergency trunk release
handle located in the trunk on the other side of the
door opening. See “Emergency Trunk Release Handle”
following.
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk release
handle as a tie-down or anchor point when securing
items in the trunk as it could damage the handle.
There is a glow-in-the-dark trunk release handle located
inside the trunk near the back of the rear seats. This
handle will glow following exposure to light. Pull down
the release handle to open the trunk from the inside of
the vehicle.
2-17

Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome by the extreme heat and
suffer permanent injuries or even death from heat
stroke. Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the windows
closed in warm or hot weather.
2-18
