Black plate (115,1)Cadillac STS Owner Manual - 2011
Listing All Paired and Connected Phones
The system can list all cell phones paired to it. If a
paired cell phone is also connected to the vehicle, the
system responds with“is connected”after that
phone name.
1. Press and hold
b gfor two seconds.
2. Say “Bluetooth.”
3. Say “List.”
Deleting a Paired Phone
If the phone name you want to delete is unknown, see
“Listing All Paired and Connected Phones.”
1. Press and hold
b gfor two seconds.
2. Say “Bluetooth.”
3. Say “Delete.” The system asks which phone to
delete.
4. Say the name of the phone you want to delete.
Connecting to a Different Phone
To connect to a different cell phone, the Bluetooth
system looks for the next available cell phone in the
order in which all the available cell phones were paired.
Depending on which cell phone you want to connect to,
you may have to use this command several times.
1. Press and hold
b gfor two seconds.
2. Say “Bluetooth”.
3. Say “Change phone.”
.If another cell phone is found, the response will
be“ is now connected.”
.If another cell phone is not found, the original
phone remains connected.
4-115

Black plate (116,1)Cadillac STS Owner Manual - 2011
Storing and Deleting Phone Numbers
The system can store up to 30 phone numbers as name
tags in the Hands‐Free Directory that is shared between
the Bluetooth and OnStar systems.
The following commands are used to delete and store
phone numbers.
Store:This command will store a phone number, or a
group of numbers as a name tag.
Digit Store: This command allows a phone number to
be stored as a name tag by entering the digits one at
a time.
Delete: This command is used to delete individual
name tags.
Delete All Name Tags: This command deletes all
stored name tags in the Hands Free Calling Directory
and the OnStar Turn by Turn Destinations Directory.
Using the “Store”Command
1. Press and holdbgfor two seconds.
2. Say “Store.”
3. Say the phone number or group of numbers you want to store all at once with no pauses, then
follow the directions given by the system to save
a name tag for this number.
Using the “Digit Store” Command
If an unwanted number is recognized by the system,
say“Clear” at any time to clear the last number.
To hear all of the numbers recognized by the system,
say “Verify” at any time.
1. Press and hold
b gfor two seconds.
2. Say “Digit Store.”
3. Say each digit, one at a time, that you want to store. After each digit is entered, the system
repeats back the digit it heard followed by a tone.
After the last digit has been entered, say “Store,”
and then follow the directions given by the system
to save a name tag for this number.
Using the “Delete”Command
1. Press and holdbgfor two seconds.
2. Say “Delete.”
3. Say the name tag you want to delete.
Using the “Delete All Name Tags”
Command
This command deletes all stored name tags in the
Hands‐Free Calling Directory and the OnStar
Turn‐by‐Turn Destinations Directory.
4-116

Black plate (117,1)Cadillac STS Owner Manual - 2011
To delete all name tags:1. Press and hold
b gfor two seconds.
2. Say “Delete all name tags.”
Listing Stored Numbers
The list command will list all stored numbers and
name tags.
Using the “List”Command
1. Press and holdbgfor two seconds.
2. Say “Directory.”
3. Say “Hands‐Free Calling.”
4. Say “List.”
Making a Call
Calls can be made using the following commands.
Dial or Call: The dial or call command can be used
interchangeably to dial a phone number or a stored
name tag.
Digit Dial: This command allows a phone number to be
dialed by entering the digits one at a time.
Re‐dial: This command is used to dial the last number
used on the cell phone.
Using the “Dial”or“Call” Command
1. Press and holdbgfor two seconds.
2. Say “Dial”or“Call.”
3. Say the entire number without pausing, or say the name tag.
Once connected, the person called will be heard
through the audio speakers.
Using the “Digit Dial” Command
The digit dial command allows a phone number to be
dialed by entering the digits one at a time. After each
digit is entered, the system repeats back the digit it
heard followed by a tone.
If an unwanted number is recognized by the system,
say“Clear” at any time to clear the last number.
To hear all of the numbers recognized by the system,
say “Verify” at any time.
1. Press and hold
b gfor two seconds.
2. Say “Digit Dial.”
3. Say each digit, one at a time, that you want to dial. After each digit is entered, the system repeats
back the digit it heard followed by a tone. After the
last digit has been entered, say “Dial.”
Once connected, the person called will be heard
through the audio speakers.
4-117

Black plate (118,1)Cadillac STS Owner Manual - 2011
Using the“Re‐dial”Command
1. Press and holdbgfor two seconds.
2. After the tone, say “Re‐dial.”
Once connected, the person called will be heard
through the audio speakers.
Receiving a Call
When an incoming call is received, the audio
system mutes and a ring tone is heard in the vehicle.
Press
b gand begin speaking to answer the call.
Call Waiting
Call waiting must be supported on the cell phone and
enabled by the wireless service carrier.
.Pressbgto answer an incoming call when
another call is active. The original call is placed
on hold.
.Pressb gagain to return to the original call.
.To ignore the incoming call, no action is required.
Three‐Way Calling
Three‐way calling must be supported on the cell phone
and enabled by the wireless service carrier.
1. While on a call, press
b g.
2. Say “Three‐way call.”
3. Use the dial or call command to dial the number of the third party to be called.
4. Once the call is connected, press
b gto link all
callers together.
Ending a Call
1. Pressb g.
2. Say “End Call.”
Muting a Call
During a call, all sounds from inside the vehicle can be
muted so that the person on the other end of the call
cannot hear them.
.To mute a call, pressbg, and then say
“Mute call.”
.To cancel mute, pressb g, and then say
“Un‐mute call.”
4-118

Black plate (119,1)Cadillac STS Owner Manual - 2011
Transferring a Call
Audio can be transferred between the Bluetooth system
and the cell phone.
The cell phone must be paired and connected with the
Bluetooth system before a call can be transferred. The
connection process can take up to two minutes after the
ignition is turned to ON/RUN.
Transferring Audio from the Bluetooth
System to a Cell Phone
During a call with the audio in the vehicle:1. Press
b g.
2. Say “Transfer Call.”
Transferring Audio to the Bluetooth System
from a Cell Phone
During a call with the audio on the cell phone,
press
bg. The audio transfers to the vehicle. If the
audio does not transfer to the vehicle, use the audio
transfer feature on the cell phone. See your cell phone
manufacturer's user guide for more information.
Voice Pass-Thru
Voice pass‐thru allows access to the voice recognition
commands on the cell phone. See your cell phone
manufacturer's user guide to see if the cell phone
supports this feature.
To access contacts stored in the cell phone:
1. Press and hold
b gfor two seconds.
2. Say “Bluetooth.”
3. Say “Voice.”
The cell phone's normal prompt messages will go
through their cycle according to the phone's operating
instructions.
Dual Tone Multi-Frequency
(DTMF) Tones
The Bluetooth system can send numbers and the
numbers stored as name tags during a call. You can
use this feature when calling a menu‐driven phone
system. Account numbers can also be stored for use.
4-119

Black plate (120,1)Cadillac STS Owner Manual - 2011
Sending a Number or Name Tag
During a Call
1. Pressbg.
2. Say “Dial.”
3. Say the number or name tag to send.
Clearing the System
Unless information is deleted out of the in‐vehicle
Bluetooth system, it will be retained indefinitely. This
includes all saved name tags in the phone book and
phone pairing information. For information on how to
delete this information, see the previou section
“Deleting a Paired Phone” and the previous sections
on deleting name tags.
Other Information
The Bluetooth®word mark and logos are owned by the
Bluetooth®SIG, Inc. and any use of such marks by
General Motors is under license. Other trademarks and
trade names are those of their respective owners.
See Radio Frequency Statement
on page 8‑20for
Federal Communications Commission and Industry
Canada information.
Radio Personalization
For vehicles with a Navigation System, see the
Navigation System manual supplied with the vehicle for
more information on accessing the main menu and for
descriptions of the menu items for the Navigation
system.
Accessing the Main Menu
To access the main menu:
1. Press CNFG or
wto enter the main menu.
2. Turn
wto scroll through the menu items.
The main menu consists of the following menu items:
.eBASS - MID - TREBLE
.xBALANCE - FADER
.eEQ EQUALIZER
.H/A (HOME/AWAY) PRESETS
.AUTOSTORE PRESETS
.CAT CATEGORY
.TA TRAFFIC ANNOUNCE
.RECALL RDS (Radio Data System) MESSAGE
4-120

Black plate (121,1)Cadillac STS Owner Manual - 2011
.ASEEK LOCAL/DISTANT
.8SET CLOCK
.BSET DATE
.4INFO (Information)
.LANG LANGUAGE
.SETUP
Radio Main Menu Item Descriptions
e
BASS - MID (Midrange) - TREBLE:This item allows
the the bass, midrange and treble features of the audio
system to be adjusted. See “Setting the Tone (Bass/
Treble)” underRadio(s)
on page 4‑95for more
information.
xBALANCE - FADER: This item allows the the
balance and fader features of the audio system to be
adjusted. See “Adjusting the Speakers (Balance/Fade)”
under Radio(s)
on page 4‑95for more information.
eEQ (Equalizer): This item allows one of the five
preset equalizations for the audio system to be
selected. See “Audio Equalizer” underRadio(s)
on
page 4‑95for more information.
H/A (Home/Away) PRESETS: This item allows either
the home or away preset radio stations to be selected.
See “Presets Home/Away” underRadio(s)
on
page 4‑95for more information.
AUTOSTORE PRESETS: This item allows the radio to
automatically store stations with the strongest signals
as presets. See “Autostore Presets” underRadio(s)
on
page 4‑95for more information.
CAT (Category): This item allows radio stations based
on preset categories to be selected. See “Activating
Program Type (PTY) Stations” underRadio(s)
on
page 4‑95for more information.
TA (Traffic Announcement): This item allows the
TA feature to be turned on and off. See “TA (Traffic
Announcement)” underRadio(s)
on page 4‑95for
more information.
4-121

Black plate (122,1)Cadillac STS Owner Manual - 2011
RECALL RDS MESSAGE:This item allows the RDS
radio station messages broadcast by a radio station to
be viewed. See “MSG (Message)” underRadio(s)
on
page 4‑95for more information.
ASEEK LOCAL/DISTANT: This item allows the audio
system to seek only local radio stations with the
strongest signal or to seek all radio stations with a
strong signal in a large area. Use LOCAL while in urban
areas where there are several strong radio station
signals and you want to limit the number of stations to
those with the strongest signals only. Use DISTANT
while in rural areas where there are fewer radio station
signals available.
See “Local/Distant Selection” underRadio(s)
on
page 4‑95for more information.
8SET CLOCK: This item allows the clock to be
adjusted.
See Setting the Clock
on page 4‑95for more
information.
BSET DATE: This item allows the date to be adjusted.
See Setting the Clock
on page 4‑95for more
information.
4(Information): This item allows XM satellite radio
service and CD MP3 playback information to be
displayed. See “
4(Information)”underRadio(s)on
page 4‑95
for more information.
LANG (Language): This item allows the language on
the radio display to be changed.
To change the langauge:
1. Press
wto enter the main menu.
2. Turn
wuntil LANGUAGE displays.
3. Press
wto enter the language settings and then
turn
wto scroll through the following available
langauges:
.ENGLISH
.GERMAN
.FRENCH
.SPANISH
.JAPANESE
4. Press
wto set the langauge.
5. Press F6 to exit the display. To return to the original display, repeatedly press F6 or wait for the
display to time out.
4-122

Black plate (123,1)Cadillac STS Owner Manual - 2011
SETUP:The following submenus are available when
this item is selected:
.PERSONAL SETTINGS MENU
.DRIVER SELECTION
.DRIVER EXIT SETTINGS
.CONFIGURE DISPLAY KEYS
SETUP Submenu Items
The following choices are available for programming.
PERSONAL SETTINGS MENU
This item turns the entire list of personalization features
on or off, and allows a preferred setting for up to two
people to be programmed. The number of available
features varies depending on which options the vehicle
has. A check mark appears after it when this item is on.
For more information on the PERSONAL SETTINGS
MENU item, see Vehicle Personalization on page 3‑59.
DRIVER SELECTION
The following submenu displays when this item is
selected:
.DRIVER 1
.DRIVER 2
.RECALL DRIVER SETTINGS
.STORE DRIVER SETTINGS For more information on the DRIVER SELECTION
submenu item, see
“Recalling Driver Settings” and
“Storing Driver Settings” underMemory Seat, Mirrors
and Steering Wheel on page 3‑75.
DRIVER EXIT SETTINGS
The following submenu displays when this item is
selected:
.RECALL EXIT SETTINGS
.STORE EXIT SETTINGS
For more information on the DRIVER EXIT SETTINGS
submenu item, see “Recalling Exit Settings” and
“Storing Exit Settings” underMemory Seat, Mirrors and
Steering Wheel on page 3‑75.
CONFIGURE DISPLAY KEYS
(Base Audio System)
This item allows the four configurable keys located to
the left and right of the audio display to be customized.
See “Configurable Radio Display Keys” underRadio(s)
on page 4‑95for programming information.
Theft-Deterrent Feature
THEFTLOCK®is designed to discourage theft of the
vehicle's radio by learning a portion of the Vehicle
Identification Number (VIN). The radio does not operate
if it is stolen or moved to a different vehicle.
4-123

Black plate (124,1)Cadillac STS Owner Manual - 2011
Audio Steering Wheel Controls
The vehicle has audio steering wheel controls and they
could differ depending on the vehicle’s options.
Some audio controls can be adjusted at the steering
wheel.
¨SEEK©:Press to go to the next or previous radio
station with a strong signal in the selected band while
listening to the radio.
Press
¨or©to go to the next or previous track while a
CD is playing,
SRCE (Source): Press to select between AM, FM,
XM™, or CD.
SCAN: Press and hold to scan radio stations, the radio
goes to the next strongest station in the selected band,
plays for a few seconds, then goes to the next station.
Press SCAN again to stop scanning.
y z(Previous/Next): Press to go to the next or
previous radio station stored as a favorite while listening
to the radio.
Press
yorzto go to the next or previous track while
a CD is playing.
+
e− (Volume): Press to increase or to decrease the
volume.
4-124
