Page 415 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
414 Vehicle Care
.Use only approved cleaning
solutions for aluminum,
chrome, or stainless steel.
Some cleaners are highly
acidic or contain alkaline
substances and can damage
the moldings.
.Always dilute a concentrated
cleaner according to the
manufacturer’s instructions.
.Do not use cleaners that are
not intended for
automotive use.
.Use a nonabrasive wax on
the vehicle after washing to
protect and extend the
molding finish.
Cleaning Exterior Lamps/
Lenses, Emblems, Decals,
and Stripes
Use only lukewarm or cold
water, a soft cloth, and a car
washing soap to clean exterior
lamps, lenses, emblems,
decals, and stripes. Follow
instructions under "Washing
the Vehicle" previously in this
section.Lamp covers are made of
plastic, and some have a UV
protective coating. Do not
clean or wipe them when dry.
Do not use any of the
following on lamp covers:
.Abrasive or caustic agents.
.Washer fluids and other
cleaning agents in higher
concentrations than
suggested by the
manufacturer.
.Solvents, alcohols, fuels,
or other harsh cleaners.
.Ice scrapers or other hard
items.
.Aftermarket appearance
caps or covers while the
lamps are illuminated, due to
excessive heat generated.
Caution
Failure to clean lamps
properly can cause damage
to the lamp cover that would
not be covered by the
vehicle warranty.
Caution
Using wax on low gloss black
finish stripes can increase
the gloss level and create a
non-uniform finish. Clean low
gloss stripes with soap and
water only.
Air Intakes
Clear debris from the air
intakes, between the hood and
windshield, when washing the
vehicle.
Shutter System
Page 416 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 415
The vehicle may have a
shutter system designed to
help improve fuel economy.
Keep the shutter system clear
of debris, snow and ice. If the
check engine light is activated,
please check to see if the
shutter system is clear of
debris, snow or ice.
Windshield and Wiper
Blades
Clean the outside of the
windshield with glass cleaner.
Clean rubber blades using a
lint-free cloth or paper towel
soaked with windshield
washer fluid or a mild
detergent. Wash the
windshield thoroughly when
cleaning the blades. Bugs,
road grime, sap, and a buildup
of vehicle wash/wax
treatments may cause wiper
streaking.
Replace the wiper blades if
they are worn or damaged.
Damage can be caused byextreme dusty conditions,
sand, salt, heat, sun, snow,
and ice.
Weatherstrips
Apply weatherstrip lubricant
on weatherstrips to make
them last longer, seal better,
and not stick or squeak.
Lubricate weatherstrips at
least once a year. Hot, dry
climates may require more
frequent application. Black
marks from rubber material on
painted surfaces can be
removed by rubbing with a
clean cloth. See
Recommended Fluids and
Lubricants
0429.
Tires
Use a stiff brush with tire
cleaner to clean the tires.
Caution
Using petroleum-based tire
dressing products on the
vehicle may damage the
paint finish and/or tires.
(Continued)
Caution (Continued)
When applying a tire
dressing, always wipe off
any overspray from all
painted surfaces on the
vehicle.
Wheels and Wheel Trim
Use a soft, clean cloth with
mild soap and water to clean
the wheels. After rinsing
thoroughly with clean water,
dry with a soft, clean towel.
A wax may then be applied.
Caution
Chrome wheels and chrome
wheel trim may be damaged
if the vehicle is not washed
after driving on roads that
have been sprayed with
magnesium chloride or
calcium chloride. These are
used on roads for conditions
such as dust and ice. Always
wash the chrome with soap
and water after exposure.
Page 429 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
428 Service and Maintenance
Exterior Lights
.Visual inspection
Windshield and Wipers
.Visual inspection
Battery
.Battery visual inspection
.Battery test results
.Battery cables and
connections
Systems, Fluids, and
Visible Leak Inspection
.Engine oil
.Transmission
.Drive axle
.Transfer case
.Engine cooling system
.Power steering, if equipped
.Fuel system
.Windshield washer fluid
Tire Inspection
.Tire pressure, tread depth,
and wear
.Rotation, if applicable
.Alignment check, optional
.Reset tire pressure monitor
.Check tire sealant expiration
date, if equipped
.Check spare tire, if equipped
Brakes
.Check brake system
Visible and Functional
Inspections
.Seat belt components
.Exhaust system
.Accelerator pedal
.Passenger compartment air
filter, if equipped
.Engine air filter
.Hoses
.Belts
.Shocks and struts
.Steering components
.Axle boots or driveshaft and
u-joints
.Compartment lift struts,
if equipped
.Floor mats secured, no
interference with pedals
.Horn
.Ignition lock, if equipped
.Starter switch
.Evaporative control system
Lubricate
.Chassis components
Special Application
Services
.Severe Commercial Use
Vehicles Only: Lubricate
chassis components every
oil change.
.Have underbody flushing
service performed. See
"Underbody Maintenance" in
Exterior Care 0412.
Page 430 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Service and Maintenance 429
Recommended Fluids, Lubricants, and Parts
Recommended Fluids and Lubricants
Fluids and lubricants identified below by name or specification, including fluids or lubricants not
listed here, can be obtained from your dealer.Usage Fluid/Lubricant
Automatic Transmission DEXRON-VI Automatic Transmission Fluid. Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL Coolant. See Cooling System 0338.
Engine Oil Engine oil meeting the dexos1 specification of the proper SAE viscosity grade. ACDelco dexos1 full synthetic is recommended.
See Engine Oil0332.
Hood Latch Assembly,
Secondary Latch, Pivots, Spring Anchor, and Release Pawl Lubriplate Lubricant Aerosol or lubricant meeting requirements
of NLGI #2, Category LB or GC-LB.
Hydraulic Brake System DOT 4 Hydraulic Brake Fluid.
Key Lock Cylinders, Hood and Door Hinges Multi-Purpose Lubricant, Superlube. See your dealer.
Front Axle/Rear Axle See your dealer.
Transfer Case (All-Wheel Drive) Transfer Case Fluid. See your dealer. Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements.
Page 466 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
INDEX 465
ElectricalEquipment, Add-On . . . . . . . 325
System Overload . . . . . . . . . . 352
Electrical System Engine CompartmentFuse Block . . . . . . . . . . . . . . . . . 354
Fuses and Circuit
Breakers . . . . . . . . . . . . . . . . . . . . 353
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . 360
Emergency
OnStar . . . . . . . . . . . . . . . . . . . . . . . . 452
Engine Air Cleaner/Filter . . . . . . . . . . 337
Air Filter Life System . . . . . 336
Check Light(Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . 126
Compartment Overview . . . . . . . . . . . . . . . . . . . . 331
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 123
Coolant Temperature Warning Light . . . . . . . . . . . . . . 133
Cooling System . . . . . . . . . . . . 338
Drive Belt Routing . . . . . . . . . 434
Exhaust . . . . . . . . . . . . . . . . . . . . . . 256
Heater . . . . . . . . . . . . . . . . . . . . . . . . 252 Engine (cont'd)
Oil Life System . . . . . . . . . . . . . 335
Oil Pressure Light . . . . . . . . . . 134
Overheating . . . . . . . . . . . . . . . . . 342
Power Messages . . . . . . . . . . . 143
Running While Parked . . . 256
Starting . . . . . . . . . . . . . . . . . . . . . . 248
Entry Lighting . . . . . . . . . . . . . . . . . 154
Equipment, Towing . . . . . . . . . 322
Event Data Recorders . . . . . 449
Exit Lighting . . . . . . . . . . . . . . . . . . . 154
Extended Parking . . . . . . . . . . . 255
Extender, Seat Belt . . . . . . . . . . . 64
Exterior Lamp Controls . . . . . . . . . . . . . . 148
Lamps Off Reminder . . . . . . 150
Lighting Battery Saver . . . 155
F
FilterEngine Air Cleaner . . . . . . . . 337
Flash-to-Pass . . . . . . . . . . . . . . . . . . 150
Flashers, Hazard
Warning . . . . . . . . . . . . . . . . . . . . . . . 152
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 389 Changing . . . . . . . . . . . . . . . . . . . . . 398
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 421 Fluid
Automatic
Transmission . . . . . . . . . . . . . . 336
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 345
Washer . . . . . . . . . . . . . . . . . . . . . . . 343
Folding Mirrors . . . . . . . . . . . . . . . . . 35
Forward Collision Alert (FCA)System . . . . . . . . . . . . . . . . . . . . . . . 297
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . 446
Front Heated and VentilatedSeats . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Pedestrian Braking (FPB) System . . . . . . . . . . . . . 302
Storage . . . . . . . . . . . . . . . . . . . . . . . 103
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . 311
Economy, Driving forBetter . . . . . . . . . . . . . . . . . . . . . . . 229
Filling a Portable Fuel Container . . . . . . . . . . . . . . . . . . . 313
Filling the Tank . . . . . . . . . . . . . . 311
Foreign Countries . . . . . . . . . . 311
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Low Fuel Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Page 471 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
470 INDEX
PrivacyVehicle Data
Recording . . . . . . . . . . . . . . . . . . 448
Problems with Route Guidance . . . . . . . . . . . . . . . . . . . . . . 186
Program Courtesy
Transportation . . . . . . . . . . . 442
Prohibited Fuels . . . . . . . . . . . . . . 310
Proposition 65 Warning California . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Proposition 65 Warning, California . . . 404
Publication Ordering Information . . . . . . . . . . . . . . . . . . 445
R
Radiator . . . . . . . . . . . . . . . . . . . . . . . . 338
RadioAM-FM Radio . . . . . . . . . . . . . . . . 163
Data System (RDS) . . . . . . . . . 167
Frequency Statement . . . . 446
HD Radio Technology . . . . . 166
Reception . . . . . . . . . . . . . . . . . . . . . 168
Satellite . . . . . . . . . . . . . . . . . . . . . . . 167
Reading Lamps . . . . . . . . . . . . . . . 153
Rear
Camera Mirror . . . . . . . . . . . . . . . . 37 Rear (cont'd)
Cross Traffic Alert
(RCTA) System . . . . . . . . . . . . 297
Heated Seats . . . . . . . . . . . . . . . . . 56
Pedestrian Alert . . . . . . . . . . . 296
Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Storage . . . . . . . . . . . . . . . . . . . . . . . 103
Vision Camera (RVC) . . . . . 286
Window Washer/Wiper . . . 113
Rearview Mirrors . . . . . . . . . . . . . . 36 Automatic Dimming . . . . . . . . . 36
Reclining Seatbacks . . . . . . . . . . 47
Recognition
Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
Recommended Fluids and Lubricants . . . . . . . . . . . . . 429
Records Maintenance . . . . . . . . . . . . . . . . . 431
Recreational Vehicle
Towing . . . . . . . . . . . . . . . . . . . . . . . . 409
Reimbursement Program, GM Mobility . . . . 439
Remote Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Key Operation . . . . . . . . . . . . . . . . . . 9
Vehicle Start . . . . . . . . . . . . . . . . . . . 18 Replacement Parts
Airbags . . . . . . . . . . . . . . . . . . . . . . . . . 78
Maintenance . . . . . . . . . . . . . . . . 430
Replacing Airbag System . . . . . . . . . . . . . . . 78
LATCH System PartsAfter a Crash . . . . . . . . . . . . . . . 95
Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . 65
Reporting Safety Defects Canadian Government . . . 447
General Motors . . . . . . . . . . . . 447
U.S. Government . . . . . . . . . . 447
Restraints Where to Put . . . . . . . . . . . . . . . . . 85
Retained Accessory
Power (RAP) . . . . . . . . . . . . . . . . 253
Reverse Automatic Braking . . . . . . . . . . . . . . . . . . . . . . . . 294
Reverse Tilt Mirrors . . . . . . . . . . 36
Roads Driving, Wet . . . . . . . . . . . . . . . . . 238
Roadside Assistance Program . . . . . . . . . . . . . . . . . . . . . . 439
Roof
Rack System . . . . . . . . . . . . . . . . . 106
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . 42
Rotation, Tires . . . . . . . . . . . . . . . . 381
Page 475 of 476

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
474 INDEX
W
WarningBrake System Light . . . . . . . . 128
Caution and Danger . . . . . . . . . . 3
Hazard Flashers . . . . . . . . . . . . 152
Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . 118
Washer Fluid . . . . . . . . . . . . . . . . . . 343
Wheels Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 387
Different Size . . . . . . . . . . . . . . . 385
Replacement . . . . . . . . . . . . . . . . 387
When It Is Time for
New Tires . . . . . . . . . . . . . . . . . . . . 382
Where to Put the Restraint . . . . . . . . . . . . . . . . . . . . . . . 85
Windows . . . . . . . . . . . . . . . . . . . . . . . . . 39 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Windshield Replacement . . . . . . . . . . . . . . . . 349
Wiper/Washer . . . . . . . . . . . . . . . 110 Winter
Cover . . . . . . . . . . . . . . . . . . . . . . . . . . 251
Driving . . . . . . . . . . . . . . . . . . . . . . . . 239
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . 366
Wiper Blade Replacement . . . . . . . 347
Rear Washer . . . . . . . . . . . . . . . . . 113
Wireless Charging . . . . . . . . . . . .115
