CADILLAC XTS 2017 1.G Owners Manual
Manufacturer: CADILLAC, Model Year: 2017, Model line: XTS, Model: CADILLAC XTS 2017 1.GPages: 314, PDF Size: 3.71 MB
Page 301 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
300 TECHNICAL DATA
Engine Specifications
EngineVIN Code Horsepower TorqueSpark Plug Gap
3.6L V6 Engine (LF3) 8 306 kW @ 6000 rpm
(410 hp @ 6000 rpm) 500
Y @1900–
5600 rpm
(369 lb ft @ 1900– 5600 rpm) 0.75–0.90 mm
(0.030–.035 in)
3.6L V6 Engine (LFX) 3 227 kW @ 6800 rpm
(305 hp @ 6800 rpm) 264
Y @5200 rpm
(358 lb ft @ 5200 rpm) 0.95–1.10 mm
(0.037–.043 in)
Vehicle Top Speed
Vehicle Top Speed MetricEnglish
3.6L V6 Engine (LF3) 219 km/h136 mph
3.6L V6 Engine (LFX) 209 km/h130 mph
Page 302 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
TECHNICAL DATA 301
Engine Drive Belt Routing
Page 303 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
302 CUSTOMER INFORMATION
Customer
Information
Vehicle Data Recording and
Privacy
Vehicle Data Recording andPrivacy . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Event Data Recorders . . . . . . . . . . . . 302
Infotainment System . . . . . . . . . . . . . 303
Vehicle Data Recording
and Privacy
The vehicle has a number of
computers that record information
about the vehicle’s performance and
how it is driven. For example, the
vehicle uses computer modules to
monitor and control engine and
transmission performance, to monitor
the conditions for airbag deployment
and deploy them in a crash, and,
if equipped, to provide antilock
braking to help the driver control the
vehicle. These modules may store data
to help the dealer technician service
the vehicle. Some modules may also
store data about how the vehicle is
operated, such as rate of fuel
consumption or average speed. These
modules may retain personal
preferences, such as radio presets, seat
positions, and temperature settings.
Event Data Recorders
This vehicle is equipped with an event
data recorder (EDR). The main
purpose of an EDR is to record, in
certain crash or near crash-like situations, such as an airbag
deployment or hitting a road obstacle,
data that will assist in understanding
how a vehicle's systems performed.
The EDR is designed to record data
related to vehicle dynamics and safety
systems for a short period of time,
typically 30 seconds or less. The EDR
in this vehicle is designed to record
such data as:
.
How various systems in your
vehicle were operating.
. Whether or not the driver and
passenger safety belts were
buckled/fastened;
. How far (if at all) the driver was
depressing the accelerator and/or
brake pedal; and
. How fast the vehicle was traveling.
These data can help provide a better
understanding of the circumstances in
which crashes and injuries occur.
Note
EDR data are recorded by your vehicle
only if a non-trivial crash situation
occurs. No data are recorded by the
EDR under normal driving conditions
and no personal data (e.g., name,
Page 304 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
CUSTOMER INFORMATION 303
gender, age, and crash location) are
recorded. However, other parties, such
as law enforcement, could combine
the EDR data with the type of
personally identifying data routinely
acquired during a crash investigation.
To read data recorded by an EDR,
special equipment is required, and
access to the vehicle or the EDR is
needed. In addition to the vehicle
manufacturer, other parties, such as
law enforcement, that have the special
equipment, can read the information
if they have access to the vehicle or
the EDR.
GM will not access these data or share
it with others except: with the consent
of the vehicle owner or, if the vehicle
is leased, with the consent of the
lessee; in response to an official
request of police or similar
government office; as part of GM's
defense of litigation; or, as required by
law. Data that GM collects or receives
may also be used for GM research
needs or may be made available to
others for research purposes, where a
need is shown and the data is not tied
to a specific vehicle or vehicle owner.Infotainment System
Using the navigation system may
result in the storage of destinations,
addresses, telephone numbers, and
other trip information. See the
infotainment manual for information
on stored data and for deletion
instructions.
Page 305 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
304 INDEX
IndexA
Accessories and Modifications . . . . . 222
Accessory Power . . . . . . . . . . . . . . . . . . . . 180
Adaptive Cruise Control . . . . . . . . . . . . 194
Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . . . . . . . 154
Adaptive Forward Lighting (AFL) Light . . . . . . . . . . . . . . . . . . . . . . . . 127
Add-On Electrical Equipment . . . . . . 220
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 54
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 55
Air Cleaner/Filter, Engine . . . . . . . . . . 231
Air Conditioning . . . . . . . . . . . . . . .159, 163
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 166
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
How Does an Airbag Restrain? . . . . . 74
Passenger Sensing System . . . . . . . . . 75
What Makes an Airbag Inflate? . . . . 73
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 74
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Where Are the Airbags? . . . . . . . . . . . . 71 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Passenger Status Indicator . . . . . . . 119
Readiness Light . . . . . . . . . . . . . . . . . . . 119
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
System Check . . . . . . . . . . . . . . . . . . . . . . . 69
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 39
Alert
Side Blind Zone (SBZA) . . . . . . . . . . 210
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 255
All-Wheel Drive . . . . . . . . . . . . . . . .185, 242
Antilock Brake System (ABS) . . . . . . 185 Warning Light . . . . . . . . . . . . . . . . . . . . 123
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 282
Armrest Rear Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 100
Ashtrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Assistance Systems for Driving . . . . 206
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 202
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . . . . 42
Page 306 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
INDEX 305
Automatic (cont'd)Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Forward Braking . . . . . . . . . . . . . . . . . . 208
Headlamp System . . . . . . . . . . . . . . . . 153
Level Control . . . . . . . . . . . . . . . . . . . . . . 191
Transmission . . . . . . . . . . . . . . . . . . . . . . 183
Transmission Fluid . . . . . . . . . . . . . . . 231
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 184
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Jump Starting . . . . . . . . . . . . . . . . . . . . . 273
Power Protection . . . . . . . . . . . . . . . . . . 157
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . . . . . . 134
Blade Replacement, Wiper . . . . . . . . . 244
Brake Parking, Electric . . . . . . . . . . . . . . . . . . 186
System Warning Light . . . . . . . . . . . . 122
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240 Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
System Messages . . . . . . . . . . . . . . . . . 135 Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Automatic Forward . . . . . . . . . . . . . . . 208
Break-In, New Vehicle . . . . . . . . . . . . . . 177
Bulb Replacement . . . . . . . . . . . . . . . . . . 247 Back-up Lamps . . . . . . . . . . . . . . . . . . . 245
Headlamp Aiming . . . . . . . . . . . . . . . . 245
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 245
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . . . . . 245
License Plate Lamps . . . . . . . . . . . . . . 246
Buying New Tires . . . . . . . . . . . . . . . . . . . 264
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Capacities and Specifications . . . . . . 299
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . . . . . 182
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Winter Driving . . . . . . . . . . . . . . . . . . . . 172
Cargo Management System . . . . . . . . . . . . . 102
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . 101
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . 100
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 266
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Charging System Light . . . . . . . . . . . . . 120 Check
Malfunction Indicator Engine
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Child Restraints Infants and Young Children . . . . . . . . 82
Lower Anchors and Tethers forChildren . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Older Children . . . . . . . . . . . . . . . . . . . . . . 81
Securing . . . . . . . . . . . . . . . . . . . . . . . . .94, 95
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . 110
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 248
Cleaning
Exterior Care . . . . . . . . . . . . . . . . . . . . . . 278
Interior Care . . . . . . . . . . . . . . . . . . . . . . 282
Climate Control Systems
Dual Automatic . . . . . . . . . . . . . . . . . . . 159
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Cluster, Instrument . . . . . . . . . . . . . . . . . 112
Compact Spare Tire . . . . . . . . . . . . . . . . . 272
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Page 307 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
306 INDEX
Control of a Vehicle . . . . . . . . . . . . . . . . 168
Convenience Net . . . . . . . . . . . . . . . . . . . . 102
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 41
CoolantEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Engine Temperature Gauge . . . . . . 117
Engine Temperature WarningLight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .159, 163
Cooling System . . . . . . . . . . . . . . . . . . . . . 233 Engine Messages . . . . . . . . . . . . . . . . . . 136
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 155
Cover Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 191 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Cruise Control, Adaptive . . . . . . . . . . . 194
D
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 303
Data Recorders, Event . . . . . . . . . . . . . . 302
Daytime Running Lamps (DRL) . . . 153
Defensive Driving . . . . . . . . . . . . . . . . . . . 168
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 35
Distracted Driving . . . . . . . . . . . . . . . . . . 168
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 155 Door
Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . 128
Ajar Messages . . . . . . . . . . . . . . . . . . . . . 136
Delayed Locking . . . . . . . . . . . . . . . . . . . . 35
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 35
Rear Seat Pass-Through . . . . . . . . . . . . 63
Drive Belt Routing, Engine . . . . . . . . . 301
Drive Systems All-Wheel Drive . . . . . . . . . . . . . . 185, 242
Driver Assistance Systems . . . . . . . . . 201
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 128
Driving Assistance Systems . . . . . . . . . . . . . . . 206
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . . . . . 215
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 168
For Better Fuel Economy . . . . . . . . . . . 24
Hill and Mountain Roads . . . . . . . . 171
If the Vehicle is Stuck . . . . . . . . . . . . 173
Loss of Control . . . . . . . . . . . . . . . . . . . . 170
Off-Road Recovery . . . . . . . . . . . . . . . . 170
Vehicle Load Limits . . . . . . . . . . . . . . 173
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 171
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . . . . . 159
E
Electric Parking Brake . . . . . . . . . . . . . . 186
Electric Parking Brake Light . . . . . . . 122
Electrical Equipment, Add-On . . . . . 220
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Fuses and Circuit Breakers . . . . . . . 248
Instrument Panel Fuse Block . . . . 251
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 231
Check and Service Engine
Soon Light . . . . . . . . . . . . . . . . . . . . . . . 120
Compartment Overview . . . . . . . . . . 224
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Coolant Temperature Gauge . . . . . 117
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 125
Cooling System . . . . . . . . . . . . . . . . . . . 233
Cooling System Messages . . . . . . . . 136
Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Drive Belt Routing . . . . . . . . . . . . . . . . 301
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Oil Life System . . . . . . . . . . . . . . . . . . . . 230
Oil Messages . . . . . . . . . . . . . . . . . . . . . . 137
Page 308 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
INDEX 307
Engine (cont'd)Oil Pressure Light . . . . . . . . . . . . . . . . . 126
Overheated Protection
Operating Mode . . . . . . . . . . . . . . . . . 238
Overheating . . . . . . . . . . . . . . . . . . . . . . . 237
Power Messages . . . . . . . . . . . . . . . . . . 137
Running While Parked . . . . . . . . . . . 182
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 156
Equipment, Towing . . . . . . . . . . . . . . . . . 219
Event Data Recorders . . . . . . . . . . . . . . 302
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 157
Exterior Lamp Controls . . . . . . . . . . . . 151
Exterior Lamps Off Reminder . . . . . . 152
Exterior Lighting Battery Saver . . . . 157
F
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 231
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 153
Flashers, Hazard Warning . . . . . . . . . . 154
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 285
Fluid Automatic Transmission . . . . . . . . . 231
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241 Fluid (cont'd)
Power Steering . . . . . . . . . . . . . . . . . . . . 238
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 42
Forward Automatic Braking . . . . . . . . 208
Forward Collision Alert (FCA)
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Front Seats Heated and Ventilated . . . . . . . . . . . . . 58
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212 Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Economy Driving . . . . . . . . . . . . . . . . . . . 24
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 215
Filling the Tank . . . . . . . . . . . . . . . . . . . 213
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Low Fuel Warning Light . . . . . . . . . 126
System Messages . . . . . . . . . . . . . . . . . 137
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Fuses and Circuit Breakers . . . . . . . 248
Instrument Panel Fuse Block . . . . 251
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
G
GaugesEngine Coolant Temperature . . . . 117
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Speedometer . . . . . . . . . . . . . . . . . . . . . . 115
Tachometer . . . . . . . . . . . . . . . . . . . . . . . 116
Trip Odometer . . . . . . . . . . . . . . . . . . . . 116
Warning Lights andIndicators . . . . . . . . . . . . . . . . . . . . . . . . 111
General Information Service and Maintenance . . . . . . . . 287
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 222
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
H
Hazard Warning Flashers . . . . . . . . . . 154
Head Restraints . . . . . . . . . . . . . . . . . . . . . . 50
Head-up Display . . . . . . . . . . . . . . . . . . . . 131
Headlamps Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . . . . . 154
Aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 153
Bulb Replacement . . . . . . . . . . . . . . . . 245
Daytime Running
Lamps (DRL) . . . . . . . . . . . . . . . . . . . . 153
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 153
Page 309 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
308 INDEX
Headlamps (cont'd)High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . . . . . 245
High-Beam On Light . . . . . . . . . . . . . . 127
High/Low Beam Changer . . . . . . . . . 152
Lamps On Reminder . . . . . . . . . . . . . . 127
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Steering Wheel . . . . . . . . . . . . . . . . . . . . 104
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . 42
Heating . . . . . . . . . . . . . . . . . . . . . . . . .159, 163
High-Beam On Light . . . . . . . . . . . . . . . . 127
High-Speed Operation . . . . . . . . . . . . . . 257
Hill and Mountain Roads . . . . . . . . . . 171
Hill Start Assist (HSA) . . . . . . . . . . . . . 188
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . .159, 163
I
Ignition Positions . . . . . . . . . . . . . . . . . . . 177
Indicator Vehicle Ahead . . . . . . . . . . . . . . . . . . . . . 124
Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 Infotainment . . . . . . . . . . . . . . . . . . . . . . . . 158
Infotainment System . . . . . . . . . . . . . . . 303
Instrument Cluster . . . . . . . . . . . . . . . . . 112
Instrument Panel
Storage Area . . . . . . . . . . . . . . . . . . . . . . . . 99
Instrument Panel Overview . . . . . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . . . 43
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . 273
K
Key and Lock Messages . . . . . . . . . . . . 137
Keyless Entry Remote (RKE) System . . . . . . . . . . . . . . 27
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
L
Lamps
Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Daytime Running (DRL) . . . . . . . . . . 153
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Exterior Controls . . . . . . . . . . . . . . . . . . 151
Exterior Lamps Off Reminder . . . . 152
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
License Plate . . . . . . . . . . . . . . . . . . . . . . 246
Malfunction Indicator . . . . . . . . . . . . 120
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Lamps (cont'd)
On Reminder . . . . . . . . . . . . . . . . . . . . . . 127
Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Lane Departure
Warning (LDW) . . . . . . . . . . . . . . . . . . . 211
Lane Departure Warning Light . . . . 123
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . 65
LATCH System Replacing Parts after a Crash . . . . . . 93
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . . . . 87
LED Lighting . . . . . . . . . . . . . . . . . . . . . . . . 245
Level Control Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 191
Light Adaptive Forward Lighting(AFL) Light . . . . . . . . . . . . . . . . . . . . . . 127
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . 110
Lighting
Adaptive Forward . . . . . . . . . . . . . . . . . 154
Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Illumination Control . . . . . . . . . . . . . . 155
LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123 Airbag Readiness . . . . . . . . . . . . . . . . . 119
Antilock Brake System (ABS)Warning . . . . . . . . . . . . . . . . . . . . . . . . . 123
Page 310 of 314
Cadillac XTS Owner Manual (GMNA-Localizing-MidEast-10292881) - 2017 -
crc - 7/1/16
INDEX 309
Lights (cont'd)Brake System Warning . . . . . . . . . . . 122
Charging System . . . . . . . . . . . . . . . . . . 120
Cruise Control . . . . . . . . . . . . . . . . . . . . . 127
Door Ajar . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Electric Parking Brake . . . . . . . . . . . . 122
Engine Coolant Temperature
Warning . . . . . . . . . . . . . . . . . . . . . . . . . 125
Engine Oil Pressure . . . . . . . . . . . . . . . 126
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 153
High-Beam On . . . . . . . . . . . . . . . . . . . . 127
High/Low Beam Changer . . . . . . . . . 152
Lane Departure Warning . . . . . . . . . 123
Low Fuel Warning . . . . . . . . . . . . . . . . 126
Safety Belt Reminders . . . . . . . . . . . . 118
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Service Electric Parking Brake . . . 123
StabiliTrak
®OFF . . . . . . . . . . . . . . . . . . 124
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 125
Traction Control System (TCS)/StabiliTrak
®. . . . . . . . . . . . . . 125
Traction Off . . . . . . . . . . . . . . . . . . . . . . . 124
Limited-Slip Rear Axle . . . . . . . . . . . . . 190
Locks
Automatic Door . . . . . . . . . . . . . . . . . . . . . 35
Delayed Locking . . . . . . . . . . . . . . . . . . . . 35
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Lockout Protection . . . . . . . . . . . . . . . . . 36 Locks (cont'd)
Power Door . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Loss of Control . . . . . . . . . . . . . . . . . . . . . . 170
Low Fuel Warning Light . . . . . . . . . . . 126
Low-Profile Tires . . . . . . . . . . . . . . . . . . . . 256
Lower Anchors and Tethers for
Children (LATCH System) . . . . . . . . . 87
Lumbar Adjustment . . . . . . . . . . . . . . . . . 54
Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 54
M
Magnetic Ride Control . . . . . . . . . . . . . 190
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Maintenance Schedule . . . . . . . . . . . . . 288 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . . . . . 295
Malfunction Indicator Lamp . . . . . . . 120
Manual Mode . . . . . . . . . . . . . . . . . . . . . . . 184
Massage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Memory Features . . . . . . . . . . . . . . . . . . . . 12
Memory Seats . . . . . . . . . . . . . . . . . . . . . . . . 57
Messages
Airbag System . . . . . . . . . . . . . . . . . . . . . 141
Battery Voltage and Charging . . . . 134
Brake System . . . . . . . . . . . . . . . . . . . . . . 135
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Door Ajar . . . . . . . . . . . . . . . . . . . . . . . . . . 136 Messages (cont'd)
Engine Cooling System . . . . . . . . . . . 136
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . 137
Engine Power . . . . . . . . . . . . . . . . . . . . . 137
Fuel System . . . . . . . . . . . . . . . . . . . . . . . 137
Key and Lock . . . . . . . . . . . . . . . . . . . . . . 137
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Object Detection System . . . . . . . . . 138
Ride Control System . . . . . . . . . . . . . . 141
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Service Vehicle . . . . . . . . . . . . . . . . . . . . 142
Starting the Vehicle . . . . . . . . . . . . . . 142
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Transmission . . . . . . . . . . . . . . . . . . . . . . 142
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Vehicle Reminder . . . . . . . . . . . . . . . . . 143
Vehicle Speed . . . . . . . . . . . . . . . . . . . . . 143
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . 143
Window . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Mirrors Automatic Dimming . . . . . . . . . . . . . . . . 42
Automatic Dimming Rearview . . . . . 43
Convex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Tilt in Reverse . . . . . . . . . . . . . . . . . . . . . . 42
