Long Trip/Highway Scheduled Maintenance
yellowblue
7-37
75,000 Miles (125 000 km)

Change engine oil and filter (or every 12 months, whichever occurs first).
An Emission Control Service.

Lubricate chassis components (or every 12 months, whichever occurs first).
(See footnote #.)

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking. (See footnote **.)

Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90
F (32
C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 50,000 miles (83 000 km).
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)ACTUAL
SERVICED BY:MILEAGE
DATE

Long Trip/Highway Scheduled Maintenance
yellowblue
7-38
82,500 Miles (137 500 km)

Change engine oil and filter (or every 12 months, whichever occurs first).
An Emission Control Service.

Lubricate chassis components (or every 12 months, whichever occurs first).
(See footnote #.)

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking. (See footnote **.)

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
90,000 Miles (150 000 km)

Change engine oil and filter (or every 12 months, whichever occurs first).
An Emission Control Service.

Lubricate chassis components (or every 12 months, whichever occurs first).
(See footnote #.)

Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking. (See footnote **.)

For Two
-Wheel-Drive vehicles only: Clean and repack the front wheel
bearings (or at each brake relining, whichever occurs first).

Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90
F (32
C) or higher.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Long Trip/Highway Scheduled Maintenance
yellowblue
7-39
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 50,000 miles (83 000 km).

Replace fuel filter.
An Emission Control Service. (See footnote
.)
Replace air cleaner filter.
An Emission Control Service.
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
97,500 Miles (162 500 km)
Change engine oil and filter (or every 12 months, whichever occurs first).
An Emission Control Service.
Lubricate chassis components (or every 12 months, whichever occurs first).
(See footnote #.)
Check rear/front axle fluid level and add fluid as needed. Check constant
velocity joints and axle seals for leaking. (See footnote **.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)ACTUAL
SERVICED BY:MILEAGE
DATE

yellowblue
7-41
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown
in Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.
Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the Index
for further details.

yellowblue
7-43
Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the
regular brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The starter
should work only in PARK (P) or NEUTRAL (N).
If the starter works in any other position, your
vehicle needs service.Brake
-Transmission Shift Interlock (BTSI) Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough
room around the vehicle. It should be parked on
a level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the RUN
position, but don't start the engine. Without
applying the regular brake, try to move the shift
lever out of PARK (P) with normal effort. If the shift
lever moves out of PARK (P), your vehicle's BTSI
needs service.

yellowblue
7-44
Ignition Transmission Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.

The key should turn to LOCK only when the shift
lever is in PARK (P).

The key should come out only in LOCK.
Parking Brake and Automatic Transmission
PARK (P) Mechanism Check
CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in case
it begins to roll. Be ready to apply the regular
brake at once should the vehicle begin to move.
Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set
the parking brake.

To check the parking brake's holding ability:
With the engine running and transmission in
NEUTRAL (N), slowly remove foot pressure from
the regular brake pedal. Do this until the vehicle is
held by the parking brake only.

To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release all brakes.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.

yellowblue
8-12
CURRENT PUBLICATIONS FOR 1999 CHEVROLET
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $20.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $15.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 CHEVROLET SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

yellowblue
9-2
Brake
Adjustment 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-35 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Shift Interlock Check 7-43 . . . . . . . . . . . . . . .
Wear 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-67 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-13, 2-27, 2-28, 2-30, 4-27, 4-34, 4-35
Care of Your Compact Disc Player 3-31 . . . . . . . . . . . . . . . . .
Care of Your Cassette Tape Player 3-29 . . . . . . . . . . . . . . . . . .
Care of Your Compact Discs 3-31 . . . . . . . . . . . . . . . . . . . . . .
Cassette Deck Service 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-11, 3-13 . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-29 . . . . . . . . . . . . . . . . . . . . . . . .
Center Passenger Position 1-40 . . . . . . . . . . . . . . . . . . . . . . . .
Certification/Tire Label 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Changing a Flat Tire 5
-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Engine Light 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Gages Light 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Transmission Fluid Cold 6-22 . . . . . . . . . . . . . . . . .
Checking Transmission Fluid Hot 6-21 . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-62 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-52 . . . . . . . . . . .
Securing in the Center Seat Position 1-54 . . . . . . . . . . . . . .
Securing in the Right Front Seat Position 1-56 . . . . . . . . . .
Top Strap 1-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-50, 1-51 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-61 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air Filter 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Aluminum Wheels 6
-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-52 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leather 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-55 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-54 . . . . . . . . . . . . . . . . . . .

yellowblue
9-4
Electrical Equipment, Adding 2-18, 3-29, 6-60 . . . . . . . . . .
Electrical System 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System Capacity 6-67 . . . . . . . . . . . . . . . . . . . . . . .
Cover 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-13, 2-27, 2-28, 2-30, 4-27, 4-34, 4-35 . . . . . . .
Fuse Block 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-28 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Gage 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Gage 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-13, 2-27, 2-28, 2-30, 4-27, 4-34, 4-35 . .
Express-Down Window 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-7 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter
Air Cleaner Replacement 6
-69 . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-67, 6-68 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front
Axle 6
-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Area 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 5-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal Lamp Bulb Replacement 6-40 . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-7 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Regulator 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-61 . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-5
Gages
Engine Coolant Temperature 2-63 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage Door Opener 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transmission 2-20 . . . . . . . . . . . . .
Glove Box 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility for Persons with Disabilities 8-5 . . . . . . . . . . . .
GM Vehicle Care/Appearance Materials 6-58 . . . . . . . . . . . . .
Gross Axle Weight Rating 4-28 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-28 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hatch Release 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-37, 6-38 . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-32 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heating 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-22 . . . . . . . . . . . . . . . . . . . . . . . . . Hitches, Trailer 4
-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Prop 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transmission Lock Check 7-44 . . . . . . . . . . . . . . . . .
Inflation, Tire 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-40 . . . . . . . . . . . . . . . . .
Inspections 7-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Axle 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-45 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 7-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transfer Case (All-Wheel Drive) 7-46 . . . . . . . . . . . . . . . .
Instrument Panel 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
