Page 251 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-24
4. Attach the ratchet to the extension with the UP side
facing you.
5. Turn the ratchet clockwise. That will raise the jack
lift head a little.6. Position the jack under the vehicle.

Page 252 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-25
Front Position
A. Front Jack Location
B. Jack
C. Ratchet and ExtensionRear Position
A. Rear Jack Location
B. Jack
C. Ratchet and Extension

Page 253 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-26
CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by

Page 254 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-27
7. Raise the vehicle by turning the ratchet clockwise.
Make sure the UP mark faces you. Raise the vehicle
far enough off the ground so there is enough room
for the compact spare tire to fit under

Page 255 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-28
CAUTION:
Never use oil or grease on studs or nuts. If you
do, the nuts might come loose. Your wheel could
fall off, causing a serious accident.
10. Put on the compact spare tire. Put the nuts on

Page 256 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-29
12. Tighten the wheel
nuts firmly in a
crisscross sequence
as shown. Turn the
ratchet clockwise
with the UP mark
facing you.
CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can c

Page 257 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-30 Storing a Flat or Spare Tire and Tools
CAUTION:
Storing a jack, a tire or other equipment in the
passenger compartment of the vehicle could
cause injury. In a sudden stop or collision, loose
equi

Page 258 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-31
5. Make sure the tire is stored securely. Push, pull, and
then try to rotate or turn the tire. If the tire moves,
use the ratchet/wheel wrench to tighten the cable.
Return the jacking equipment t

Page 259 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-32
NOTICE:
When the compact spare is installed, dont take
your vehicle through an automatic car wash with
guide rails. The compact spare can get caught on
the rails. That can damage the tire and wh

Page 260 of 400

CHEVROLET ASTRO CARGO VAN 2002 2.G Owners Manual 5-33
If Youre Stuck: In Sand, Mud,
Ice or Snow
In order to free your vehicle when it is stuck, you will
need to spin the wheels, but you dont want to spin
your wheels too fast. The method known as
