iv
Table of Contents (cont'd)
Maintenance Schedule Service and Appearance Care
Section
7
Section
6
Scheduled Maintenance
Owner Checks and Services
Periodic Maintenance InspectionsRecommended Fluids and Lubricants
Maintenance Records Windshield Wiper Blade Replacement
Tires and Wheels
Appearance Care
Electrical System/Fuses and Circuit Breakers
Capacities and Specifications
Normal Maintenance Replacement Parts Fuel
Checking Fluids and Lubricants
GM Oil Life System™
Engine Air Cleaner/Filter
Passenger Compartment Air Filter
Brakes
Bulb Replacement

6-
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-6 Filling Your Tank
6
-8 Checking Things Under the Hood
6
-12 Engine Oil
6
-18 Engine Air Cleaner/Filter
6
-20 Passenger Compartment Air Filter
6
-21 Automatic Transmission Fluid
6
-24 Rear Axle
6
-25 Four-Wheel Drive
6
-27 Engine Coolant
6
-30 Coolant Surge Tank Pressure Cap
6
-30 Power Steering Fluid
6
-32 Windshield Washer Fluid6
-33 Brakes
6
-37 Battery
6
-38 Bulb Replacement
6
-43 Windshield Wiper Blade Replacement
6
-44 Tires
6
-53 Appearance Care
6
-53 Cleaning the Inside of Your Vehicle
6
-57 Cleaning the Outside of Your Vehicle
6
-61 GM Vehicle Care/Appearance Materials
6
-62 Vehicle Identification Number (VIN)
6
-63 Electrical System
6
-71 Replacement Bulbs
6
-72 Capacities and Specifications
6
-73 Normal Maintenance Replacement Parts

6-13
When to Add Engine Oil
If the oil is at or below the ADD mark, then you'll need
to add at least one quart of oil. But you must use the
right kind. This part explains what kind of oil to use. For
crankcase capacity, see ªCapacities and Specificationsº
in the Index.
NOTICE:
Don't add too much oil. If your engine has
so much oil that the oil level gets above the
cross
-hatched area that shows the proper
operating range, your engine could be damaged.
5300 V8 Engine 8100 V8 Engine
Your vehicle may have a
cap with text and a graphic
or just a graphic as shown.
The engine oil fill cap for the 5300 V8 engines is
located on the driver's side engine valve cover. On the
8100 V8 engine, the oil fill cap is located on the front
of the engine.

6-72
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information. All capacities
are approximate.
When adding refrigerant, see the refrigerant charge label
under the hood for charge capacity information
and requirements.
Engine TypeVIN
Code Spark Plug Gap
VORTEC 5300 V8 T 0.060 inches
(1.52 mm)
VORTEC 8100 V8 G 0.060 inches
(1.52 mm)
Wheels and Tires
Model Description Torque
C/K 1500 6 bolts (14 mm)
140 lb
-ft (190 N´m)
C/K 2500 8 bolts (14 mm)
140 lb
-ft (190 N´m)
Tire Pressure See the Certification/Tire label on the
rear edge of the driver's door.
Cooling System Capacity
After refill, the level must be rechecked. See ªCooling
Systemº in the Index.
Engine Quantity
VORTEC 5300 V8 16.5 quarts (15.6 L)
VORTEC 8100 V8 24.0 quarts (23.0 L)
Engine Oil with Filter Capacity
After refill, the level must be rechecked. Add enough
engine oil so that the fluid is within the proper operating
range. See ªEngine Oilº in the Index.
Engine Quantity
VORTEC 5300 V8
VIN Code T6.0 quarts (5.7 L)
VORTEC 8100 V8
VIN Code G6.5 quarts (6.1 L)
Fuel Tank Capacity
Type Quantity
1500/2500 31.0 U.S. gallons (117.0 L)
