CHEVROLET BLAZER 2002 2.G Owners Manual

3-54
Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
left speakers, push the AUDIO knob until BAL appears
on the display. Turn the knob to adjust the sound to the
left or right speakers. The middle position balances the
sound between the speakers.
To adjust the fade between the front and rear speakers,
push and hold the AUDIO knob until FAD appears on
the display. Turn the knob to adjust the sound to the
front or rear speakers. The middle position balances the
sound between the speakers.
To adjust the balance and fade to the middle position,
select balance or fade and push and hold the AUDIO
knob. The radio will beep once and will adjust the
display level to the middle position.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when tone
or speaker controls are not displayed. The radio will
produce one beep and CENTERED will appear on
the display.Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS mode gives you many useful new
features. With RDS, the radio can do the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS features are only available for use on FM stations
which broadcast RDS information. The RDS features of
your radio rely upon receiving specific RDS information
from these stations. These features will only work when
the RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, contact the radio station.
When you are tuned to an RDS station, the station
name will appear on the display, instead of the
frequency. Most RDS stations provide their station
name, the time of day and a Program Type (PTY) for
their current programming.

3-55
Finding a PTY Station
P
-TYPE (Program Type): This button is used to turn
on and off Program Type (PTY) selections. PTY and the
light next to the button will turn on. The last selected
PTY will appear on the display for five seconds.
Turn the P
-TYPE knob to select the PTY you want to
listen to. Press the SEEK arrows to find radio stations
for the PTY you want to listen to. The last PTY selected
will be used for seek or scan modes. If a station with the
selected PTY is not found, NONE FOUND will appear
on the display. If both P
-TYPE and TRAF are on, the
radio will search for stations with traffic announcements
and the selected PTY.
To use the PTY interrupt feature, press and hold the
P
-TYPE button until you hear a beep on the PTY
you want to interrupt on. When you are listening to a
compact disc, the last selected RDS FM station will
interrupt play if that selected program type format
is broadcast.AM FM (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same program type. Press and hold AM FM for two
seconds to turn alternate frequency on. AF ON will
appear on the display. The radio may switch to stronger
stations. Press and hold AM FM again for two seconds to
turn alternate frequency off. AF OFF will appear on the
display. The radio will not switch to other stations. When
you turn the ignition off and then on again, the alternate
frequency feature will automatically be turned on.
Setting PTY Preset Stations
The six numbered pushbuttons let you return to your
favorite PTYs. These buttons have factory PTY presets.
You can set up to 12 PTYs (six FM1 and six FM2) by
performing the following steps:
1. Press AM FM to select FM1 or FM2.
2. Press P
-TYPE to activate program type mode.
3. Turn the P
-TYPE knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.

3-56
RDS Messages
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the current radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
INFO (Information): If the current station has a
message, INFO will appear on the display. Press this
button to see the message. If the whole message does
not appear on the display, parts of the message will
appear every three seconds until the message is
completed. To see the parts of the message faster than
every three seconds, press this button again. A new
group of words will appear on the display. Once the
complete message has been displayed, INFO will
disappear from the display until another new message
is received.TRAF (Traffic): Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the current station broadcasts traffic announcements.
If the current station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NONE FOUND will appear on the display.
When a traffic announcement comes on the current radio
station or a related network station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.

3-57
Playing a Compact Disc
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.
LOAD CD
: Press the LOAD side of this button to
load CDs into the compact disc player. This compact
disc player will hold up to six discs.
To insert one disc, do the following:
1. Turn the ignition on.
2. Press and release the LOAD side of the LOAD
CD button.
3. Wait for the light, located to the right of the slot, to
turn green.
4. Load a disc. Insert a disc partway into the slot, label
side up. The player will pull the disc in.
When a disc is inserted, the CD symbol will be
displayed. If you select an equalization setting for your
disc, it will be activated each time you play a disc.
If the radio is on or off, the disc will begin to
play automatically.
To insert multiple discs, do the following:
1. Turn the ignition on.2. Press and hold the LOAD side of the LOAD CD
button for two seconds.
You will hear a beep and the light, located to the
right of the slot, will begin to flash.
3. Once the light stops flashing and turns green, load a
disc. Insert a disc partway into the slot, label side up.
The player will pull the disc in.
Once the disc is loaded, the light will begin flashing
again. Once the light stops flashing and turns green
you can load another disc. The disc player takes up
to six discs. Do not try to load more than six.
To load more than one disc but less than six, complete
Steps 1 through 3. When you have finished loading
discs, with the radio on or off, press the LOAD side of
the LOAD CD button to cancel the loading function.
The radio will begin to play the last CD loaded.
When a disc is inserted, the CD symbol will be
displayed. If more than one disc has been loaded, a
number for each disc will be displayed. If you select an
equalization setting for your disc, it will be activated
each time you play a disc.
If the radio is on or off, the last disc loaded will begin to
play automatically.
As each new track starts to play, the track number will
appear on the display.

3-58
Playing a Specific Loaded Compact Disc
For every CD loaded, a number will appear on the radio
display. To play a specific CD, first press the CD AUX
button to start playing a CD. Then press the numbered
pushbutton that corresponds to the CD you want to play.
A small bar will appear under the CD number that is
playing, and the track number will appear.
If an error appears on the radio display, see ªCompact
Disc Messagesº later in this section.
LOAD CD
(Eject): The CD eject side of this
button will eject a disc or discs, if you have multiple
discs loaded. To eject a disc or discs from the disc
player, perform one of the following steps:

Press and release the CD eject side of the LOAD CD
button to eject the disc that is currently playing, or

to eject all of the discs, press the CD eject side of the
LOAD CD button for two seconds, you will hear a
beep, and the light will flash to let you know when a
disc is being ejected.
When the CD eject side of the LOAD CD button is
pressed, the receiver will eject the disc and REMOVE
CD will be displayed. You can now remove the disc.If the disc is not removed, after 25 seconds, the disc will
be automatically pulled back into the receiver. If you try
to push the disc back into the receiver, before the
25 second time period is complete, the receiver will
sense an error and will try to eject the disc several times
before stopping.
Do not repeatedly press the CD eject side of the LOAD
CD eject button to eject a disc after you have tried to
push it in manually. The receiver's 25
-second eject
timer will reset at each press of eject, which will cause
the receiver to not eject the disc until the 25
-second time
period has elapsed.
Once the player stops and the disc is ejected, remove
the disc. After removing the disc, press the PWR knob
off and then on again. This will clear the disc
-sensing
feature and enable discs to be loaded into the
player again.

REV (Reverse): Press and hold this button to reverse
quickly within a track. You will hear sound at a reduced
volume. Release it to play the passage. The display will
show elapsed time.
FWD  (Forward): Press and hold this button to
advance quickly within a track. You will hear sound at a
reduced volume. Release it to play the passage. The
display will show elapsed time.

3-59
RPT (Repeat): With repeat, you can repeat one track or
an entire disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and hold
the RPT button for two seconds. RPT will appear on
the display. Press RPT again to turn if off.
RDM (Random): With random, you can listen to
the tracks in random, rather than sequential order, on
one disc or on all of the discs. To use random, do one of
the following:

To play the tracks on the disc you are listening to in
random order, press and hold RDM for more than
two seconds. You will hear a beep and RANDOM
ONE will appear on the display. Press RDM again to
turn if off.

Press and release the RDM button to play the tracks
on all of the discs that are loaded, in random order.
RANDOM ALL will appear on the display. Press
RDM to turn it off.AUTO EQ (Automatic Equalization): Press AUTO
EQ to select the desired preset equalization setting while
playing a compact disc. The equalization will be
automatically set whenever you play a compact disc.
See ªAUTO EQº listed previously for more information.


SEEK : To seek, press the left arrow while playing
a CD to go to the start of the current track, if more than
ten seconds have passed. Press the right arrow to go to
the next track. If you press the button more than once,
the player will continue moving backward or forward
through the disc.


SCAN : To scan one disc, press and hold either
SCAN arrow for more than two seconds until SCAN
appears on the display and you hear a beep. Use this
feature to listen to each track of the currently selected
disc for ten seconds. The sound will mute while
scanning. SCAN will appear on the display. Press either
SCAN arrow again, to stop scanning.
To scan all loaded discs, press and hold either SCAN
arrow for more than four seconds until DISC SCAN
appears on the display and you hear a beep. Use this
feature to listen to the first track, for ten seconds for
each disc loaded. The sound will mute while scanning to
the next track. DISC SCAN will appear on the display.
Press either SCAN arrow again, to stop scanning.

3-60
P-TYPE (Program Type): Press this knob to see how
long the current track has been playing. To change what
is normally shown on the display (track or elapsed
time), press the knob until you see the display you want,
then hold the knob until the display flashes.
AM FM: Press this button to play the radio when a
disc(s) is in the player.
Using Song List Mode
The integrated six
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into the song list feature, perform the
following steps:
1. Turn the disc player on and load it with at least one
disc. See ªLOAD CDº listed previously in this
section for more information.
2. Check to see that the disc changer is not in song list
mode. S
-LIST should not appear in the display. If
S
-LIST is present, press the SONG LIST button to
turn it off.3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK SCAN right
arrow button to locate the track that you want to
save. The track will begin to play.
4. Press and hold the SONG LIST button for two or
more seconds to save the track into memory. When
SONG LIST is pressed a beep will be heard
immediately. After two seconds of pressing SONG
LIST continuously, two beeps will sound to confirm
that the track has been saved.
5. Repeat Steps 3 and 4 for saving other selections.
If you attempt to save more than 20 selections, S
-LIST
FULL will appear on the display.
To play the song list, press the SONG LIST button.
One beep will be heard and S
-LIST will appear on the
display. The recorded tracks will begin to play in the
order that they were saved.
You may seek through the song list by using the SEEK
SCAN arrows. Seeking past the last saved track will
return you to the first saved track.

3-61
To delete tracks from the song list, perform the
following steps:
1. Turn the disc player on.
2. Press the SONG LIST button to turn song list on.
S
-LIST will appear on the display.
3. Press the SEEK SCAN arrows to select the desired
track to be deleted.
4. Press and hold the SONG LIST button for two
seconds. When pressing SONG LIST, one beep will
be heard immediately. After two seconds of pressing
the SONG LIST button continuously, two beeps will
be heard to confirm that the track has been deleted.
After a track has been deleted, the remaining tracks are
moved up the list. When another track is added to the
song list, the tracks will be added to the end of the list.
To delete the entire song list, perform the
following steps:
1. Turn the disc player on.
2. Press the SONG LIST button to turn song list on.
S
-LIST will appear on the display.
3. Press and hold the SONG LIST button for more than
four seconds. A beep will be heard, followed by
two beeps after two seconds and a final beep will beheard after four seconds. S
-LIST EMPTY will
appear on the display indicating that the song list has
been deleted.
If a disc is ejected, and the song list contains saved
tracks from that disc, those tracks are automatically
deleted from the song list. Any tracks saved to the song
list again are added to the bottom of the list.
To end song list mode, press the SONG LIST button.
One beep will be heard and S
-LIST will be removed
from the display.
Compact Disc Messages
CHECK CD: If this message appears on the radio
display, it could be due to one of the following reasons:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If the CD is not playing correctly, for any other reason,
try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error message, write it down and provide it to your
dealer when reporting the problem.

3-62 Rear Seat Audio (RSA) (If Equipped)
This feature allows rear seat passengers to listen to and
control any of the music sources: AM
-FM, cassette
tapes and CDs, through the Rear Seat Audio (RSA)
controller. However, the rear seat passengers can only
control the music sources that the front seat passengers
are not listening to. For example, rear seat passengers
may listen to a cassette tape through headphones while
the driver listens to the radio through the front speakers.
The rear seat passengers have control of the volume for
each set of headphones. Be aware that the front seat
audio controls always have priority over the RSA
controls. If the front seat passengers switch the source
for the main radio to a remote source, the RSA will play
the same remote source. The rear speakers will be muted
when the RSA power is turned on. You may operate the
RSA functions even when the main radio is off.
Primary Radio Controls
The following function is controlled by the knob on the
main radio:
PWR (Power): Push this knob twice to turn RSA off.Rear Seat Audio Controls
The following functions are controlled by the RSA
system buttons:
PWR (Power): Press this button to turn RSA on or off.

3-63
VOL (Volume): Press this knob lightly so it extends.
Turn the knob clockwise to increase volume and
counterclockwise to decrease volume. Push the knob
back into its stored position when you're not using it.
The left knob controls the left headphone and the right
knob controls the right headphone.
SEEK : While listening to AM FM, press the right
or left arrow to seek to the next or previous station and
stay there. The sound will mute while seeking. The
SEEK button is inactive if the AM FM mode on the
front radio is in use.
While listening to a cassette tape, press the right arrow
to hear the next selection on the tape. Press the left
arrow to go back to the previous selection. The SEEK
button is inactive if the tape mode on the front radio is
in use.While listening to a CD, press the right arrow to hear the
next track on the CD. Press the left arrow to go back to
the start of the current track (if more than eight seconds
have played). The SEEK button is inactive if the CD
mode (if equipped) on the front radio or the CD changer
is in use.
To scan stations, press and hold either SEEK arrow until
the radio goes into SCAN mode. The radio will go to a
station, play for a few seconds, then go on to the next
station. Press either SEEK arrow again to stop scanning.
The SCAN function is inactive if the AM FM mode on
the front radio is in use.
AM FM: Press this button to switch between AM, FM1
and FM2. If the front passengers are already listening to
AM FM, the RSA controller will not switch between the
bands and cannot change the frequency.
Press AM FM to return to listening to the radio when a
cassette tape or CD is playing. The inactive tape or CD
will remain safely inside the radio for future listening.
