7-41
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown in
Part D.
At the First 100, 1,000 and 6,000 Miles
(160, 1 600 and 10 000 km)
For vehicles with dual wheels, check dual wheel nut
torque. For proper torque, see ªWheel Nut Torqueº in
the Index.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the
Index for further details.

yellowblue
7-42 At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages are
working properly. Look for any other loose or damaged
safety belt system parts. If you see anything that might
keep a safety belt system from doing its job, have it
repaired. Have any torn or frayed safety belts replaced.
Also look for any opened or broken air bag coverings,
and have them repaired or replaced. (The air bag system
does not need regular maintenance.)
Wiper Blade Check
Inspect wiper blades for wear or cracking. Replace blade
inserts that appear worn or damaged or that streak or
miss areas of the windshield. Also see ªWiper Blades,
Cleaningº in the Index.
Air Cleaner Filter Restriction Indicator Check
Your vehicle has an indicator located on the air cleaner in
the engine compartment that lets you know when the air
cleaner filter is dirty and needs to be changed. Check
indicator at least twice a year or when your oil is changed,
whichever occurs first. See ªAir Cleanerº in the Index for more information.
Inspect your air cleaner filter restriction indicator more
often if the vehicle is used in dusty areas or under off
road conditions.
Weatherstrip Lubrication
Silicone grease on weatherstrips will make them last
longer, seal better, and not stick or squeak. Apply
silicone grease with a clean cloth. During very cold,
damp weather more frequent application may be
required. (See ªRecommended Fluids and Lubricantsº in
the Index.)
Manual Transmission Check
Check the transmission fluid level; add if needed. See
ªManual Transmission Fluidº in the Index. Check for
leaks. A fluid loss may indicate a problem. Have the
system inspected and repaired if needed.
Automatic Transmission Check
Check the transmission fluid level; add if needed. See
ªAutomatic Transmission Fluidº in the Index. A fluid
loss may indicate a problem. Check the system and
repair if needed.

yellowblue
7-43
Hydraulic Clutch System Check
Check the fluid level in the clutch reservoir. See
ªHydraulic Clutch Fluidº in the Index. A fluid loss in
this system could indicate a problem. Have the system
inspected and repaired at once.
At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specified in Part D.
Body Lubrication Service
Lubricate all fuel doors, body hood and body door
hinges, tailgate and tailgate handle pivot points, latches,
locks and folding seat hardware. Part D tells you what to
use. More frequent lubrication may be required when
exposed to a corrosive environment.Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the regular
brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. On automatic transmission vehicles, try to start the
engine in each gear. The starter should work only in
PARK (P) or NEUTRAL (N). If the starter works in
any other position, your vehicle needs service.
On manual transmission vehicles, put the shift lever
in NEUTRAL (N), push the clutch down halfway
and try to start the engine. The starter should work
only when the clutch is pushed down all the way to
the floor. If the starter works when the clutch isn't
pushed all the way down, your vehicle needs service.

yellowblue
7-44
Brake-Transmission Shift Interlock (BTSI) Check
(Automatic Transmission)
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle. It should be parked on a
level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the RUN
position, but don't start the engine. Without applying
the regular brake, try to move the shift lever out of
PARK (P) with normal effort. If the shift lever
moves out of PARK (P), your vehicle's BTSI
needs service.Ignition Transmission Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.

With an automatic transmission, the key should turn
to LOCK only when the shift lever is in PARK (P).

With a manual transmission, the key should turn to
LOCK only when you press the key release button.
On all vehicles, the key should come out only in LOCK.

yellowblue
7-45
Parking Brake and Automatic Transmission
PARK (P) Mechanism Check
CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in case
it begins to roll. Be ready to apply the regular
brake at once should the vehicle begin to move.
Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.

To check the parking brake's holding ability:
With the engine running and transmission in
NEUTRAL (N), slowly remove foot pressure from
the regular brake pedal. Do this until the vehicle is
held by the parking brake only.

To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release all brakes.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.

yellowblue
8-12
CURRENT PUBLICATIONS FOR 1999 CHEVROLET
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $20.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $15.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 CHEVROLET SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

9-yellowblue
9-1
Section 9 Index
A
ccessory Power Outlet 2-59 . . . . . . . . . . . . . . . . . . . . . . . . .
Adding Equipment to the Outside of Your Vehicle 6-3 . . . . . .
Air Bag 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding Equipment 1-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off Light 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off Switch 1-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-25, 2-65 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-28 . . . . . . . . . . . . . . .
When Should it Inflate 1-27 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner Filter Restriction Indicator Check 7-42 . . . . . . . .
Air Conditioning 3-3, 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-78 . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-58 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-66 . . . . . . . . . . . . . . . . . . . . . .
Antenna 3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-28, 6-76, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock
Brake System Warning Light 2-68, 4-7 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Appearance Care 6
-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Materials, GM Vehicle Care/ 6-68 . . . . . . . . . . . .
Arbitration Program 8-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest Storage Compartment 2-56 . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Equipment, Adding 3-25 . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission
Check 7
-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-20, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Park Mechanism Check 7-45 . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle, Front 6-27, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle, Locking Rear 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle, Rear 6-25, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Keyless Entry 2-8 . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 8-4 . . . . . . . . . . . . . . . . . . .
Blizzard, Driving In 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-3
Wheels 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-64 . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2, 3-3 . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch Fluid, Hydraulic 6-24, 7-48 . . . . . . . . . . . . . . . . . . . . .
Clutch, System Check 7-42 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Guides, Rear 1-43 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Care 3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player 3-17, 3-21 . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player Care 3-27 . . . . . . . . . . . . . . . . . . . . . . . .
Compass, Rearview Mirror with 2-45 . . . . . . . . . . . . . . . . . . .
Console Storage 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-28, 6-76, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholders 2-53, 2-54, 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance for Text Telephone Users 8-4 . . . . . . . . .
Customer Assistance Information 8-1 . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
Damage, Finish 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage, Sheet Metal 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps Indicator Light 2-74 . . . . . . . . . . . .
Dead Battery 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Defects, Reporting Safety 8
-10 . . . . . . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogger, Rear Window 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogging and Defrosting 3-6 . . . . . . . . . . . . . . . . . . . . . . . . .
Dolby Noise Reduction 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door
Locks 2
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Pocket 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Third 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Downshifting 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver Position 1-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving
City 4
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defensive 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In a Blizzard 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In the Rain 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Night 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off-Road 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Curves 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Grades While Towing a Trailer 4-58 . . . . . . . . . . . . . . .
On Hill and Mountain Roads 4-34 . . . . . . . . . . . . . . . . . . . .
On Snow and Ice 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Through Water 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wet Roads 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken Driving 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dual Tire Operation 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-4
Easy Entry Seat 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Equipment, Adding 2-13, 3-27, 6-69 . . . . . . . . . . .
Electrical System 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrochromic Day/Night Rearview Mirror 2-45 . . . . . . . . . .
Engine 6-10, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-28, 6-76, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-69 . . . . . . . . . . . . . . . . . . . . .
Cooling System Capacity 6-77 . . . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-31, 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Blocks 6-70, 6-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-31 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Fuse/Relay Center 6-73 . . . . . . . . . . . . . . . . . . .
Engine Oil 6-13, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Gage 2-72 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-30, 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fan Control, Climate Control System 3-2, 3-3 . . . . . . . . . . . .
Fender Marker Lamp Bulb Replacement 6-44 . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-8 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air 6-17, 6-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-21, 6-26 . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle 6
-27, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle Locking Feature 2-22 . . . . . . . . . . . . . . . . . . . . . . .
Front Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamp Bulb Replacement 6-41, 6-42 . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tank Capacity 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-70 . . . . . . . . . . . . . . . . . . . . . . .
Fusible Links 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-5
Gages
Engine Coolant Temperature 2-69 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-72 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage Door Opener 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transmission 2-16 . . . . . . . . . . . . .
Gear Positions, Manual Transmission 2-19, 2-20 . . . . . . . . . .
Glove Box 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 8-5 . . . . .
GM Vehicle Care/Appearance Materials 6-68 . . . . . . . . . . . . .
Gross Axle Weight Rating 4-43 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-43 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-39, 6-40 . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-36 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heating 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hill and Mountain Roads 4
-34 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Clutch Fluid 6-24, 7-48 . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Clutch System Check 7-42 . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transmission Lock Check 7-44 . . . . . . . . . . . . . . . . .
Illuminated Entry 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-44 . . . . . . . . . . . . . . . . .
Inspections 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Axle 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator and Heater Hose 7-46 . . . . . . . . . . . . . . . . . . . . . .
Steering 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle Linkage 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transfer Case (Four-Wheel Drive) 7-47 . . . . . . . . . . . . . . .
Instrument Panel 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intensity Control 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
