7-20
(39) = Air brake service:

Inspect brake lines and hoses for proper hook
-up,
binding, leaks, cracks, chafing, etc. Inspect drum
brake linings for wear or cracks. Inspect other brake
parts at each wheel, including drums, wheel
cylinders and piston heat shields, boots and wheel
speed sensor wiring. Check brake pedal for excessive
free play or travel (or every 6 months, whichever
occurs first) and have serviced if needed. Check
brakes more often if driving habits and conditions
result in frequent braking. Replace air dryer cartridge
only if excessive oil or moisture is present. A small
amount of oil in the system is normal and should not
be considered as a reason to replace the cartridge.

Test air lines for leaks; tighten as needed. Replace
compressor filter.

Inspect air parking brake chamber for leaks and
damage. Inspect lines and hoses for leaks, cracks,
chafing, etc. Also check all attachments for
tightness, wear or damage. Note: The spring brake
section of the rear brake diaphragms are
non
-serviceable.

Replace the air compressor filter element, mounted
on the air compressor. For remote air compressor
intake service, refer to engine air cleaner filter
replacement.
Remove, disassemble, clean and inspect the safety
valve, standard brake chamber, quick release valve,
quick release/double check valve combination,
parking brake control valve, double check valve,
pressure protection valve and alcohol injector.

Remove, disassemble and clean the application
valve; replace parts showing wear.

Remove, disassemble, clean and inspect the spring
brake control valve; replace rubber parts.
(40) = Clean and lubricate air brake automatic slack
adjuster. Check pushrod travel and auto adjustment
operation. Have serviced if needed.
(41) = Air brake chamber service: Check operation,
mounting, clamps and air lines and check for leaks.
(42) = Trailer brake hand control valve service: Check
operation; lubricate cam and follower.
(46) = Tighten the wheel stud nuts to the specified
torque values at 100 miles (160 km). Thereafter, tighten
them 1,000 miles (1 600 km) after each time the wheel
is removed. See ªTightening the Wheel Nutsº in
the Index.

7-21
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
For your safety and that of others, any of the
safety
-related components that may have been damaged
in an accident should be checked and any needed repairs
made before operating the vehicle.
At the minimum, these routine checks should be made
every 6 months or 6,000 miles (10 000 km), whichever
occurs first. Whenever repairs are needed, have them
completed before operating the vehicle.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.Engine Oil Level Check
Check the engine oil level and add the proper oil
if necessary. See ªEngine Oilº in the Index for
further details.
Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
Tire Inflation Check
Check tire inflation cold. Make sure tires are inflated to
the pressures specified on the GVW Rating label. See
ªLoading Your Vehicleº and ªTiresº in the Index for
further details.

7-22 At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light (if equipped)
and all your belts, buckles, latch plates, retractors and
anchorages are working properly. Look for any other
loose or damaged safety belt system parts. If you see
anything that might keep a safety belt system from
doing its job, have it repaired. Have any torn or frayed
safety belts replaced.
Wiper Blade Check
Inspect wiper blades for wear or cracking. Replace blade
inserts that appear worn or damaged or that streak or
miss areas of the windshield. Also see ªWiper Blades,
Cleaningº in the Index.Engine Air Cleaner Filter Restriction
Indicator Check
Your vehicle has an indicator located on the air cleaner
in the engine compartment that lets you know when the
air cleaner filter is dirty and needs to be changed. Check
indicator at least twice a year or when your engine oil is
changed, whichever occurs first. See ªEngine Air
Cleanerº in the Index for more information. Inspect your
air cleaner filter restriction indicator more often if the
vehicle is used in dusty areas.
Weatherstrip Lubrication
Silicone grease on weatherstrips will make them last
longer, seal better, and not stick or squeak. Apply
silicone grease with a clean cloth. During very cold,
damp weather more frequent application may be
required. See ªRecommended Fluids and Lubricantsº in
the Index.

7-23
Body Lubrication Service
Lubricate all exposed surfaces such as door checks, door
lock bolts, lock strike plates, door latches and dovetail
bumper wedges. Where oil holes are provided a dripless
oil can be used. The seat adjusters, seat track, door
weatherstrips and rubber cap bumpers should also be
lubricated.
Part C tells you what to use. More frequent lubrication
may be required when exposed to a corrosive
environment.
Parking Brake Check
Park on a fairly steep hill and hold the vehicle with the
parking brake only. This checks holding ability.Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake and the
regular brakes. See ªParking Brakeº in the Index
if necessary.
Do not use the accelerator pedal, and be ready to turn
off the engine immediately if it starts.
3. On automatic transmission vehicles, try to start the
engine in each gear. The starter should work only in
PARK (P), if equipped, or NEUTRAL (N). If the
starter works in any other position, your vehicle
needs service.

7-24
Automatic Transmission Shift Indicator Check
Check that the indicator points to the gear chosen.
Steering Check
Be alert for any changes in steering action, abnormal
front tire wear or steering wheel position. An inspection
or service is needed when the steering wheel is harder to
turn or has too much free play, or if there are strange
sounds when turning or parking.
Brake System Check
Be alert to illumination of the low air warning lamp or
for the tone alarm, or changes in braking action, such
as repeated pulling to one side, unusual sounds when
braking or increased brake pedal travel. Make sure air
brake system reservoirs are drained daily with full
system air pressure, and check system for leaks. Any
of these conditions could indicate the need for brake
system inspection and/or service.Engine Cooling System Service
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.
Exhaust System Check
Be alert for any changes in the sound of the exhaust
system or any smell of fumes. These are signs the
system may be leaking. Have it checked and/or repaired
at once. Refer to ªEngine Exhaustº and ªRunning Your
Engine While You're Parkedº in the Index.
Windshield Wipers and Washers Check
Check operation and condition of the wiper blades.
Check the flow of the washer spray.

7-26
Fluid Leaks Check
Check for fuel, coolant, oil or other fluid leaks by
looking at the surface beneath the vehicle after it has
been parked for awhile.
Underbody Inspection
Corrosive materials used for ice, snow removal and dust
control can collect on the underbody. If these materials
are not removed, accelerated corrosion (rust) can occur
on underbody parts such as fuel lines, frame, floor pan
and exhaust system. At least every spring, flush these
materials from the underbody with plain water. Take
care to clean well any areas where mud and other debris
can collect. Sediment packed in closed areas of the
frame should be loosened before being flushed.
Engine Cover Check
Check that the cab's engine cover and seal (if equipped)
are not torn or damaged. Be sure that the cover is
clamped down firmly to the floor.At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specified in Part C.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
Tractor Protection (Breakaway) Valve Check
On air brake models, remove, disassemble, clean and
inspect the tractor protection (breakaway) valve.
