Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Heater/Air Conditioning Controls
(If Equipped)
3
-4 Air Conditioning (If Equipped)
3
-4 Heating
3
-5 Defogging and Defrosting
3
-5 Rear Window Defogger (If Equipped)
3
-6 Rear Heater (If Equipped)
3
-6 Ventilation System
3
-7 Audio Systems
3
-7 Setting the Time
3
-8AM-FM Radio3
-11 AM-FM Radio with Cassette Tape Player
(If Equipped)
3
-17 AM-FM Radio with Compact Disc Player
(If Equipped)
3
-21 Theft-Deterrent Feature
3
-21 Understanding Radio Reception
3
-22 Tips About Your Audio System
3
-23 Care of Your Cassette Tape Player
3
-24 Care of Your Compact Discs
3
-24 Care of Your Compact Disc Player
3
-24 Fixed Mast Antenna
3
-24 Chime Level Adjustment

3-11 AM FM Radio with Cassette Tape Player
(If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob to increase or to
decrease volume.
RCL (Recall): Press this knob to switch the display
between time and radio station frequency. Time display
is available with the ignition turned off.Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE: Turn this knob to choose radio stations.
SEEK : Press the right or the left arrow to seek to
the next or to the previous station and stay there.
To scan stations, press and hold one of the SEEK arrows
for two seconds until you hear a beep. The radio will go
to a station, play for a few seconds and flash the station
frequency, then go on to the next station. Press one of
the SEEK arrows again to stop scanning presets.
To scan preset stations, press and hold one of the SEEK
arrows for more than four seconds until you hear
two beeps. The radio will go to the first preset station
stored on the pushbuttons, play for a few seconds and
flash the station frequency, then go on to the next preset
station. Press one of the SEEK arrows again to stop
scanning presets.
The radio will seek and scan only to stations that are in
the selected band and only to those with a strong signal.

3-14
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off, the
tape can be inserted and will begin playing. If you hear
nothing but a garbled sound, the tape may not be in
squarely. Press the eject button to remove the tape and
start over.
While the tape is playing, use the VOL, AUDIO and
SEEK controls just as you do for the radio. The radio
will display UP if the top side of the tape is playing.
DN (Down) will appear if the bottom side is playing.
If you want to insert a tape while the ignition is off, first
press the eject button or the RCL knob.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.1 PREV (Previous): Your tape must have at least
three seconds of silence between each selection for
previous to work. Press this pushbutton to go to the
previous selection on the tape if the current selection has
been playing for less than 3 seconds. If pressed when the
current selection has been playing from 3 to 13 seconds,
it will go to the beginning of the previous selection or
the beginning of the current selection, depending on
the position on the tape. If pressed when the current
selection has been playing for more than 13 seconds,
it will go to the beginning of the current selection.
Pressing this pushbutton multiple times will increase the
number of selections to be searched back, up to
-9.
Pressing the NEXT pushbutton will cancel the
selection(s).
2 NEXT: Your tape must have at least three seconds of
silence between each selection for next to work. Press
this pushbutton to go to the next selection on the tape.
Pressing this pushbutton multiple times in the next mode
will increase the number of selections to searched
forward. Pressing the PREV pushbutton will cancel
the selection(s).

3-15
3 REV (Reverse): Press this pushbutton to reverse the
tape rapidly. FR will appear on the display. Press it again
to return to playing the tape. The radio will play while
the tape reverses. You may select stations during reverse
operation by using the TUNE or SEEK controls or by
using the scan or preset scan features.
4 FWD (Forward): Press this pushbutton to advance
quickly to another part of the tape. FF will appear on the
display. Press this pushbutton again to return to playing
the tape. The radio will play while the tape advances.
You may select stations during forward operation by
using the TUNE or SEEK controls or by using the scan
or preset scan features.
5 SIDE: Press this pushbutton to play the other side of
the tape.
6 RPT (Repeat): Your tape must have at least three
seconds of silence between each selection for repeat to
work. Press this pushbutton once to hear a selection
over again. RPT will appear on the display. Press this
button again to turn off repeated play. OFF will appear
on the display. SEEK : The right arrow is the same as the NEXT
pushbutton, and the left arrow is the same as the PREV
pushbutton. If the arrows are held or pressed more than
once, the player will continue moving forward or
backward through the tape.
AM FM: Press this button to listen to the radio when a
tape is playing. The inactive tape will remain safely
inside the radio for future listening.
TAPE: Press this button to play a cassette tape when
listening to the radio. CAS will appear on the display.
(EJECT): Press this button to eject a tape. Eject
may be activated with the radio off. Cassette tapes may
be loaded with the radio and vehicle off if this button is
pressed first.

3-16
Cassette Tape Messages
ERR (Error): If the player detects a tight or broken
tape, this message will appear on the display and the
player will eject the tape. The radio will go back to
playing the last station selected.
CLN (Clean): If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after deactivating the
tight/loose tape sensor feature on your tape player.
To deactivate this feature, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE button for two seconds
until one beep is produced. CAS will flash on the
display, showing that the TIGHT/LOOSE TAPE
sensor is no longer active.
4. Insert the adapter into the cassette slot.
The override feature will remain active until the eject
button is pressed.

3-17 AM-FM Radio with Compact Disc Player
(If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob to increase or to
decrease volume.
RCL (Recall): Press this knob to switch the display
between the radio station frequency and the time.
Time display is available with the ignition turned off.Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE: Turn this knob to choose radio stations.
SEEK : Press the right or the left arrow to seek to
the next or to the previous station and stay there.
To scan stations, press and hold one of the SEEK arrows
for two seconds until you hear a beep. The radio will go
to a station, play for a few seconds and flash the station
frequency, then go on to the next station. Press one of
the SEEK arrows again to stop scanning presets.
To scan preset stations, press and hold one of the SEEK
arrows for more than four seconds until you hear a
double beep. The radio will go to the first preset station
stored on the pushbuttons, play for a few seconds and
flash the station frequency, then go on to the next preset
station. Press one of the SEEK arrows again to stop
scanning presets.
The radio will seek and scan only to the stations that
are in the selected band and only to those with a
strong signal.

3-19
Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
the left speakers, press and release AUDIO until BAL
appears on the display. Then press and hold the up or the
down arrow to move the sound toward the right or the
left speakers.
To adjust the fade between the front and rear speakers,
press and release AUDIO until FAD appears on the
display. Then press and hold the up or the down arrow to
move the sound toward the front or the rear speakers.
To adjust balance or fade to the middle position, select
BAL or FAD. Then press and hold AUDIO for more
than two seconds until you hear a beep. L and a zero or
F and a zero will appear on the display.
To adjust both tone controls and both speaker controls to
the middle position, end out of audio mode by waiting
for the display to change to the time display. Then press
and hold AUDIO for more than two seconds until you
hear a beep. CEN will appear on the display.
Fade may not be available if you have a regular
cab model.Radio Messages
CAL (Calibrated): Your audio system has been
calibrated for your vehicle from the factory. If CAL
appears on the display it means that your radio has not
been configured properly for your vehicle and must be
returned to the dealership for service.
LOC (Locked): This message is displayed when the
Theftlock

system has locked up. Your vehicle must be
returned to the dealership for service.
Playing a Compact Disc
Insert a disc partway into the slot, label side up.
The player will pull it in. The disc should begin playing.
The display will show CD. If you want to insert a
compact disc with the ignition off, first press RCL or
the eject button.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.

3-20
1 PREV (Previous): Press this pushbutton to go to the
previous track if the current track has been playing for
less than eight seconds. If pressed when the current track
has been playing for more than eight seconds, it will go
to the beginning of the current track. The track number
will appear on the display. If you hold this pushbutton or
press it more than once, the player will continue moving
back through the disc.
2 NEXT: Press this pushbutton to go to the next track.
The track number will appear on the display. If you hold
this pushbutton or press it more than once, the player
will continue moving forward through the disc.
3 REV (Reverse): Press and hold this pushbutton to
reverse quickly within a track. Release it to play the
passage. The display will show elapsed time while
reversing.
4 FWD (Forward): Press and hold this pushbutton to
advance quickly within a track. Release it to play the
passage. The display will show elapsed time while
forwarding.
5 RDM (Random): Press this pushbutton to hear the
tracks in random, rather than sequential, order. RND
will appear on the display. Press this pushbutton again to
turn off random play. OFF will appear on the display.6 RPT (Repeat): Press this pushbutton once to hear
a track over again. RPT will appear on the display.
The current track will continue to repeat. Press this
pushbutton again to turn off repeated play. OFF will
appear on the display.
SEEK : The right arrow is the same as the NEXT
pushbutton, and the left arrow is the same as the PREV
pushbutton. If the arrows are held or pressed more than
once, the player will continue moving forward or
backward through the tracks.
RCL (Recall): Press this button to see the current track
number or how long the current track has been playing.
AM FM: Press this button to listen to the radio when a
CD is playing. The inactive CD will remain safely inside
the radio for future listening.
CD: Press this button to play a compact disc when
listening to the radio. CD will appear on the display.
(Eject): Press this button to eject a CD. Eject
may be activated with either the ignition or radio off.
CDs may be loaded with the radio and ignition off if
this button is pressed first.

3-22 Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be loud
and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.
To help avoid hearing loss or damage do the following:
1. Adjust the volume control to the lowest setting.
2. Increase volume slowly until you hear comfortably
and clearly.NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Electronics radio or
other systems, and even damage them. Your
vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check federal rules
covering mobile radio and telephone units.

3-23 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN to indicate
that you have used your tape player for 50 hours without
resetting the tape clean timer. If this message appears on
the display, your cassette tape player needs to be
cleaned. It will still play tapes, but you should clean it as
soon as possible to prevent damage to your tapes and
player. If you notice a reduction in sound quality, try a
known good cassette to see if the tape or the tape player
is at fault. If this other cassette has no improvement in
sound quality, clean the tape player.
For best results, use a scrubbing action, non
-abrasive
cleaning cassette with pads which scrub the tape head
as the hubs of the cleaner cassette turn. The
recommended cleaning cassette is available through
your dealer (GM Part No. 12344789).The cut tape detection feature of your cassette tape
player may identify the cleaning cassette as a damaged
tape. To prevent the cleaning cassette from being
ejected, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE button for two seconds
until the radio produces one beep. CAS will flash on
the display for five seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.
After the cleaning cassette is ejected, the cut tape
detection feature will be active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
