6-69
Fuse Usage
I/P
-1 HVAC Blower Control and Relay
IGN Ignition Switch, Relay and Starter
Enable Relay
I/P
-2 Instrument Panel Fuse Center
Relay Description
AIR SOL Air Solenoid
AIR PUMP Air Pump
A/C COMP Air Conditioning Compressor
FUEL PUMP Fuel Pump
STARTER Starter
IGN Engine Controls, Cruise Control,
Air Conditioning
Replacement Bulbs
Back-Up 3155. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp 921. . . . . . . . . . . . .
Front Parking and Turn Signal 3157 NAK. . . . . . . . . .
Headlamp (Low
-Beam) 9006. . . . . . . . . . . . . . . . . . .
Headlamp (High
-Beam) 9005. . . . . . . . . . . . . . . . . .
Sidemarker Lamps 194. . . . . . . . . . . . . . . . . . . . . . . .
Taillamps Only 194. . . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Lamps 3057. . . . . . . . . . . . . . . . . . . .

yellowblue
6-70
Capacities and Specifications
The following approximate capacities are given in English
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Air Conditioning
See the refrigerant information . . .
label under the hood.
Automatic Transmission
Drain and Refill 5 quarts (4.7 L). . . . . . . . . . . . . . . . .
Overhaul
3800 V6 8.8 quarts (8.3 L). . . . . . . . . . . . . . . . . . . .
5.7L V8 10.8 quarts (10.2 L). . . . . . . . . . . . . . . . . . .
Cooling System
3800 V6
With Manual Transmission 11.6 quarts (11.0 L). . . . .
With Automatic Transmission 11.4 quarts (10.8 L). .
5.7L V8
With Manual Transmission 11.9 quarts (11.3 L). . . . .
With Automatic Transmission 11.8 quarts (11.2 L). .
Crankcase
With Oil and Filter Change
3800 V6 4.5 quarts (4.2 L). . . . . . . . . . . . . . . . . . . .
5.7L V8 5.5 quarts (5.2 L). . . . . . . . . . . . . . . . . . . .
Fuel Tank 16.8 gallons (63.6 L). . . . . . . . . . . . . . . . . . Manual Transmission
Five-Speed 3.4 quarts (3.2 L). . . . . . . . . . . . . . . . .
Six
-Speed 4.0 quarts (3.8 L). . . . . . . . . . . . . . . . . .
Rear Axle Lubricant 1.75 quarts (1.7 L). . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. Recheck fluid level after filling.
Engine Specifications
Type
VIN Engine Code K V6. . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code G V8. . . . . . . . . . . . . . . . . . . . . .
Fuel Delivery Fuel Injection. . . . . . . . . . . . . . . . . .
Valve Arrangement In
-Head . . . . . . . . . . . . . . . . . . .
Displacement
3800 V6 231 cubic inches (3791 cc). . . . . . . . . . . . .
5.7L V8 350 cubic inches (5662 cc). . . . . . . . . . . . .
Firing Order
3800 V6 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 1
-8-7-2-6-5-4-3 . . . . . . . . . . . . . . . . . . . . .
Wheel Nut Torque 100 lb
-ft (140 N´m) . . . . . . . . . . .
Thermostat Starts
to Open 177
-184F (81-85C) . . . . . . . . . . . . . .

yellowblue
6-71
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Air Cleaner Filter A1163C. . . . . . . . . . . . . . . . . . . . . .
Battery 75
-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter
3800 V6 PF47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 PF44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filter
3800 V6 6627. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 GF578. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PCV Valve
3800 V6 CV892C. . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 CV895C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Cap RC24. . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plug
3800 V6 41
-921 (0.060 inch gap) . . . . . . . . . . . . . . .
5.7L V8 41
-931 (0.060 inch gap) . . . . . . . . . . . . . . . Windshield Wiper Blade Replacement
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 24 inches (610 cm). . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length 193.5 inches (491.5 cm). . . . . . . . . . . . . . . .
Width 74.1 inches (188.3 cm). . . . . . . . . . . . . . . . . .
Height
Coupe 51.3 inches (130.3 cm). . . . . . . . . . . . . . . . .
Convertible 52.0 inches (131.2 cm). . . . . . . . . . . . .
Wheelbase 101.1 inches (256.6 cm). . . . . . . . . . . . . .
Front Tread 60.7 inches (154.2 cm). . . . . . . . . . . . . . .
Rear Tread 60.6 inches (154.0 cm). . . . . . . . . . . . . . .

yellowblue
6-72
-NOTES

7-
Second Printing for Chevrolet Camaro Owner's Manual ± 1999
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How This Section is Organized
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance7
-16 Part B: Owner Checks and Services
7
-20 Part C: Periodic Maintenance Inspections
7
-22 Part D: Recommended Fluids and Lubricants
7
-24 Part E: Maintenance Record

Second Printing for Chevrolet Camaro Owner's Manual ± 1999
yellowblue
7-2
X±07±0701±S
X±07±0702±S
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.

Second Printing for Chevrolet Camaro Owner's Manual ± 1999
yellowblue
7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you are skilled enough to do some work on your
vehicle, you will probably want to get the service
information. See ªService and Owner Publicationsº in
the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains what
you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº
explains important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº
lists some recommended products to help keep your
vehicle properly maintained. These products, or their
equivalents, should be used whether you do the work
yourself or have it done.
ªPart E: Maintenance Recordº provides a place
for you to record the maintenance performed on your
vehicle. Whenever any maintenance is performed, be
sure to write it down in this part. This will help you
determine when your next maintenance should be done.
In addition, it is a good idea to keep your maintenance
receipts. They may be needed to qualify your vehicle for
warranty repairs.

Second Printing for Chevrolet Camaro Owner's Manual ± 1999
yellowblue
7-4
Part A: Scheduled Maintenance
Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries. Or you
may drive it to work, to do errands or in many
other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.
The proper fluids and lubricants to use are listed in Part
D. Make sure whoever services your vehicle uses these.
All parts should be replaced and all necessary repairs
done before you or anyone else drives the vehicle.
This schedule is for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.

yellowblue
Scheduled Maintenance
7-5
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.
Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to the
completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the maintenance
be recorded.* Your vehicle has an Engine Oil Life Monitor. This
monitor will show you when to change the engine oil
and filter
-- usually between 3,000 miles (5 000 km) and
7,500 miles (12 500 km) since your last oil change.
Under severe conditions, the indicator may come on
before 3,000 miles (5 000 km). Never drive your vehicle
more than 7,500 miles (12 500 km) or 12 months
without an oil and filter change.
The system won't detect dust in the oil. So if you drive
in a dusty area, be sure to change your oil and filter
every 3,000 miles (5 000 km) or sooner if the
OIL CHANGE Light comes on. Remember to reset
the Oil Life Monitor whenever the oil is changed. For
more information, see ªOil Change Lightº in the Index.
+ A good time to check your brakes is during tire
rotation. See ªBrake System Inspectionº under ªPeriodic
Maintenance Inspectionsº in Part C of this schedule.

Scheduled Maintenance
yellowblue
7-6
7,500 Miles (12 500 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
15,000 Miles (25 000 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Inspect engine air cleaner filter if you are driving in dusty conditions. Replace
filter if necessary.
An Emission Control Service. (See footnote
.)
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches 90F
(32C) or higher.
± In hilly or mountainous terrain.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
