instrument cluster CHEVROLET CAMARO 2001 4.G Owners Manual

2-51 Turn Signal and Lane Change Indicator
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is finished, the lever will return automatically.
An arrow on the instrument
panel cluster will flash in
the direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.As you signal a turn or a lane change, if the arrows don't
flash but just stay on as you signal a turn or lane change,
a signal bulb may be burned out and other drivers won't
see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index).
Headlamp High/Low-Beam Changer
When the high beams are
on, this light located on the
instrument panel cluster
also will be on.
To change the headlamps from low beam to high or high
beam to low, pull the turn signal lever all the way
toward you. Then release it.

2-81
The main components of your instrument panel are the following:
A. Air Vents
B. Main Lamp Control
C. Instrument Panel Cluster
D. Horn
E. Fog Lamp Switch (Option)
F. Acceleration Slip Regulation (ASR) Button
or Second
-Gear Start Button
(V6 Automatic without ASR) (Option)
G. Audio System
H. Comfort Control System
I. Glove BoxJ. Remote Hatch Release (If Equipped)
K. Audio Steering Wheel Controls (If Equipped)
L. Rear Window Defogger Button
M. Convertible Top Switch (If Equipped)
N. Ashtray
O. Shift Lever (Automatic Transmission Shown)
P. Cupholders
Q. Storage Console
R. Parking Brake Lever
S. Cigarette Lighter
T. Accessory Power Outlet

2-82
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how
fast you're going, your engine's rpms, about how much fuel you have left and many other things you'll need to know
to drive safely and economically.
5.7L V8 Engine shown, 3800 V6 Engine similar (United States shown, Canada similar)

2-83 Speedometer and Odometer
Your speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
Your odometer shows how far your vehicle has been
driven, in either miles (used in the United States) or
kilometers (used in Canada).
You may wonder what happens if your vehicle needs a new
odometer installed. If possible, the new one has to be set to
the same reading the old one had. If it can't be, then it's set
at zero, but a label on the driver's door must show the
old reading and when the new one was installed.Trip Odometer
The trip odometer can tell you how far your car has been
driven since you last set the trip odometer to zero.
To set the trip odometer to zero, press the TRIP
OIL/RESET knob on the instrument panel cluster.

2-94 Oil Change Light
This OIL CHANGE light
should come on briefly as a
bulb check when you start
the engine. If the OIL
CHANGE light doesn't
come on, have it serviced.
If the OIL CHANGE light comes on and stays on
for 60 seconds after you start the engine, have the
oil changed.
For additional information, see ªEngine Oil, When to
Changeº in the Index. After changing the engine oil, the
system must be reset. See ªHow to Reset the Oil Change
Lightº in the Index.
Service Vehicle Light
This warning light should
come on in your instrument
panel cluster for a
three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if you have certain
non
-emission related vehicle problems. These problems
may not be obvious and may affect vehicle performance
or durability. Consult a qualified dealer for necessary
repairs to maintain top vehicle performance.

2-95 Check Gages Light
This warning light will
come on briefly when you
start the engine.
If the light comes on and stays on while you are driving,
check your gages to see if they are in the warning areas.
Hatch Ajar Light
This warning light should
come on in your instrument
panel cluster for a
three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if your hatch is open or
ajar and the ignition key is in RUN.
Fuel Gage
Your fuel gage tells you
about how much fuel
you have left when the
ignition is on.
When the indicator nears E (empty), you still have a
little fuel left, but you should get more soon.

2-96
Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage.

At the gas station, the gas pump shuts off before the
gage reads F (full).

It takes more (or less) fuel to fill up than the
gage reads. For example, the gage reads half full, but
it took more (or less) than half of the tank's capacity
to fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate E (empty) when the
ignition is turned off.
Low Fuel Light
If your fuel is low, your vehicle's CHECK GAGES light
on your instrument panel cluster will come on.
See ªCheck Gages Lightº in the Index.
Reduced Engine Power Light
(V6 Engine Only)
The REDUCED ENG PWR
warning light should come
on in your instrument panel
cluster for a three
-second
bulb check when you first
start your vehicle.
If the light doesn't come on, have it serviced.
If the REDUCED ENG PWR warning light comes on, a
noticeable reduction in the vehicle's performance may
occur. The vehicle may be driven at a reduced speed
while the REDUCED ENG PWR light is on, but
acceleration and speed may be reduced. Anytime this
warning light stays on, the vehicle should be taken to an
authorized Chevrolet dealer as soon as possible for
diagnosis and repair.

5-8
Engine Overheating
You will find a coolant temperature gage on your
instrument panel cluster. See ªEngine Coolant
Temperature Gageº in the Index.
Overheated Engine Protection
Operating Mode
This emergency operating mode allows your vehicle to be
driven to a safe place in an emergency situation. Should an
overheated engine condition exist, an overheat protection
mode which alternates firing groups of cylinders helps
prevent engine damage. In this mode, you will notice a
significant loss in power and engine performance. The low
coolant light may come on and the temperature gage will
indicate an overheat condition exists. Towing a trailer in
the overheat protection mode should be avoided.
NOTICE:
After driving in the overheated engine protection
operating mode, to avoid engine damage, allow
the engine to cool before attempting any repair.
The engine oil will be severely degraded. Repair
the cause of coolant loss, change the oil and reset
the oil life system. See ªEngine Oilº in the Index.
If Steam Is Coming From Your Engine

6-64
Main Fuse Block
Fuse Usage
STOP/HAZARD Hazard Flashers, Brake
Switch Assembly
TURN B/U Traction Control/Second
-Gear
Start Switch, Back
-Up Lamp
Switch, Turn Flasher, Daytime
Running Lamps (DRL) ModuleFuse Usage
STG
WHL CNTRLSteering Wheel Controls
RADIO ACCY Delco Monsoon Radio Amplifier,
Remote CD Player (Trunk)
TAIL LPS Daytime Running Lamps (DRL)
Module, Headlamp Switch
HVAC HVAC Selector Switch,
Rear Defogger Switch/Timer
PWR ACCY Parking Lamp Relay, Hatch
Release Relay, Power Mirror
Switch, Radio, Shock Sensor,
Instrument Cluster
COURTESY Body Control Module (BCM)
GAUGES Body Control Module (BCM),
Brake
-Transmission Shift
Interlock (BTSI), Instrument
Cluster, Daytime Running
Lamps (DRL) Module
AIR BAG Air Bag System

6-65
Fuse Usage
CIG/ACCY Cigarette Lighter, Data Link
Connector (DLC)
DEFOG/SEATS Rear Defogger Switch/Timer,
Power Seats
IGN Aftermarket Use Only
STG
WHL CNTRLSteering Wheel
Controls Illumination
WIPER/WASH Wiper Motor Assembly,
Wiper/Washer Switch
BATT Aftermarket Use Only
WINDOWS Power Windows Switch (RH, LH),
Express
-Down Module,
Convertible Top SwitchFuse Usage
IP DIMMER Door Illumination Lamp (LH, RH),
Headlamp Switch, Fog Lamp
Switch, Instrument Cluster, HVAC
Control Assembly, PRNDL
Illumination Lamp, Ashtray Lamp,
Radio, Rear Window Defogger
Switch/Timer, Traction Control
(ASR)/Second
-Gear Start Switch,
Convertible Top Switch
ACCY Aftermarket Use Only
RADIO Body Control Module (BCM),
Radio, Amplifier, Steering Wheel
Controls
-Radio
