2-60 Fog Lamps (Option)
Use your fog lamps for better vision in foggy or
misty conditions.
Your fog lamp switch is
located on your console,
above the audio system.Your parking lamps must be on or your fog lamps
won't work.
To turn the fog lamps on, push the right side of the fog
lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side
of the switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps
go off, the fog lamps will come on again.
If your vehicle has the content theft
-deterrent/alarm
system and your fog lamp switch is on, the fog lamps
may flash along with the parking lamps to indicate
operation of the content theft
-deterrent/alarm system.
See ªContent Theft
-Deterrent/Alarm Systemº in
the Index.

2-83
The main components of your instrument panel are the following:
A. Air Vents
B. Exterior Lamp Control
C. Instrument Panel Cluster
D. Horn
E. Fog Lamp Switch (Option)
F. Acceleration Slip Regulation (ASR) Button (Option)
G. Audio System
H. Comfort Control System
I. Glove Box
J. Remote Hatch Release (If Equipped)K. Audio Steering Wheel Controls (If Equipped)
L. Rear Window Defogger Button
M. Convertible Top Switch (If Equipped)
N. Ashtray
O. Shift Lever (Automatic Transmission Shown)
P. Cupholders
Q. Storage Console
R. Parking Brake Lever
S. Cigarette Lighter
T. Accessory Power Outlet

3-4 Defogging and Defrosting
1. Turn the mode knob to the defrost symbol.
2. Turn the temperature knob to the desired setting.
3. Turn the fan knob to the desired speed.
The side window defogging works equally as well in the
heater, blend and defrost modes.
Rear Window Defogger (If Equipped)
(Defogger): Press the button with the defogger
symbol to turn on the rear window warming grid.
An indicator light will come on to remind you that the
defogger is on. The defogger will turn off automatically
after about 10 minutes of use. If you turn it on again,
the defogger will operate for about five minutes only.
You can turn the defogger off by pressing the button
again. The indicator light will go off when the system is
turned off.
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Do not attach anything like a temporary vehicle license
or a decal across the defogger grid on the rear window.

6-67
Fuse Usage
COURTESY Body Control Module (BCM)
GAUGES Body Control Module (BCM),
Brake
-Transmission Shift
Interlock (BTSI), Instrument
Cluster, Daytime Running
Lamps (DRL) Module
AIR BAG Air Bag System
CIG/ACCY Cigarette Lighter, Data Link
Connector (DLC)
DEFOG/SEATS Rear Defogger Switch/Timer,
Power Seats
IGN Aftermarket Use Only
STG
WHL CNTRLSteering Wheel
Controls Illumination
WIPER/WASH Wiper Motor Assembly,
Wiper/Washer SwitchFuse Usage
BATT Aftermarket Use Only
WINDOWS Power Windows Switch (RH, LH),
Express-Down Module,
Convertible Top Switch
IP DIMMER Door Illumination Lamp
(LH, RH), Headlamp Switch, Fog
Lamp Switch, Instrument Cluster,
HVAC Control Assembly, PRNDL
Illumination Lamp, Ashtray Lamp,
Radio, Rear Window Defogger
Switch/Timer, Traction Control
(ASR)/Second
-Gear Start Switch,
Convertible Top Switch
ACCY Aftermarket Use Only
RADIO Body Control Module (BCM),
Radio, Amplifier, Steering
Wheel Controls
-Radio
