2-7
Remote Keyless Entry (If Equipped)
If your vehicle has this feature, you can lock and unlock
your doors or unlock your trunk from about 3 feet (1 m)
up to 30 feet (9 m) away using the remote keyless entry
transmitter supplied with your vehicle.
In addition, the system illuminates the interior lamps for
a set period of time.
The remote keyless entry
system consists of a
receiver, which is located
in the vehicle, and two
hand held transmitters.Your keyless entry system operates on a radio frequency
subject to Federal Communications Commission (FCC)
Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.

2-8
At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the left
or right, hold the transmitter higher, and try again.

Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.

If you're still having trouble, see your dealer or a
qualified technician for service.Operation
The following functions are available with the remote
keyless entry system:
LOCK: All doors will automatically lock when the
LOCK button is pressed. In addition, if all doors and
the trunk are closed, the headlamps will flash once, the
interior lamps will turn off, and the vehicle anti
-theft
system will arm. If you press the LOCK button again
within five seconds, the horn will chirp to let you know
that the system is armed. The THEFT SYSTEM light
will flash on the instrument panel to let you know the
system is armed. If a door or the trunk is open when
you press the LOCK button, the doors will lock, but the
security system will not arm until all the doors and the
trunk are closed.
Your dealer can change the settings to disable the
headlamp flash feature and horn chirp. Your dealer can
also change the settings to allow the horn to chirp twice
on the first press of the UNLOCK button. See your
dealer for more information.

2-9
UNLOCK: The driver's door will unlock when the
UNLOCK button on the transmitter is pressed. In
addition, the headlamps will flash twice, the dome lamp
will turn on for about 20 seconds or until the ignition
is turned on, and the security system will disarm. The
THEFT SYSTEM light will stop flashing. If you press
UNLOCK again within five seconds, all remaining
doors will unlock.
Your dealer can change the settings to disable the
headlamp flash feature and horn chirp. Your dealer can
also change the settings to allow the horn to chirp twice
on the first press of the UNLOCK button. See your
dealer for more information.
If you use the key to lock or unlock your door or trunk
while the system is armed, you will hear a pre
-alarm
chirp. This will last for 10 seconds, then the full alarm
will sound. This can be avoided by pressing any key fob
button or turning the ignition to START.
If you hear three chirps when you press the UNLOCK
or LOCK button on your transmitter, that means
your security system alarm was triggered while you
were away.Trunk Release: The trunk will unlock anytime when
the vehicle symbol on the transmitter is pressed and the
vehicle speed is less that 2 mph (3 km/h). The headlamps
will flash twice. When the trunk is unlocked using the
transmitter, the security system will be temporarily
disarmed until the trunk is opened and closed again or a
period of one minute elapses at which time the system
will re
-arm.
Your dealer can change the settings to disable the headlamp
flash feature. See your dealer for more information.
Horn Symbol: The horn will sound and the headlamps
and dome lamp will flash alternately when this button is
pressed. This can be turned off by pressing the horn
symbol button again or by turning the ignition to ON.
The alarm will sound for two minutes unless cancelled
by the driver.

2-10
Radio Personalization Feature
Your vehicle can store different radio preset stations
and other settings depending on which keyless entry
transmitter you use to unlock the doors with. The radio
will recall all the stored settings associated with that
transmitter. Any radio setting changes will be assigned
to the transmitter last used to unlock the doors.
This feature can be disabled by your dealer if you desire.
Contact your dealer for further information.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have only four transmitters
matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to touch any
of the circuitry. Static from your body transferred to
these surfaces may damage the transmitter.

2-11 Replacing the Battery in the Remote
Keyless Entry System Transmitter
To replace the battery in the transmitter:
1. Use a small coin or flat
-tip screwdriver to separate
the bottom half from the top half of the transmitter.
2. Remove the battery and replace it with the new one.
Make sure the positive (+) side of the battery faces
down. For battery replacement, use a three
-volt
battery, type CR2032, or equivalent.
3. Read the instructions inside the case.4. Put the two halves back together. Make sure the
cover is on tightly, so water won't get in.
5. Check the operation of the transmitter with your
vehicle. If the transmitter does not work, try
resynchronizing the transmitter with the receiver.
Resynchronization
Your remote keyless entry system is equipped with a
security system that prevents anyone from recording and
playing back your signal. The transmitter does not send
the same signal twice to the receiver. The receiver will not
respond to a signal that has been sent to it more than once.
Normally, the transmitter and receiver resynchronize
automatically. However, under certain circumstances,
manual resynchronization may be required.
To resynchronize your transmitter and receiver, follow
these directions:
1. Stand close to your vehicle.
2. Press and hold the LOCK and UNLOCK buttons
on the transmitter at the same time.
3. Hold the buttons for at least 10 seconds. During
this time, the doors should lock and unlock once.
This confirms the resynchronization. If the doors
do not lock and unlock, see your dealer for service.

2-12
Trunk
To unlock the trunk from the outside, insert the key and
turn the trunk lock cylinder or use the remote keyless
entry transmitter (if equipped).
When closing the trunk, close from the center to ensure
it fully latches.
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.
CAUTION: (Continued)
CAUTION: (Continued)

Turn the fan on your heating or cooling
system to its highest speed with the setting
on any airflow selection except MAX.
That will force outside air into your vehicle.
See ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Remote Trunk Release (If Equipped)
Pull upward on the remote
release handle, located on
the floor near the left side
of the driver's seat, to
release the trunk lid.

2-13
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition. If you take the key with you, and you have an
automatic transaxle, it will be locked. And remember to
lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your key?

If possible, park in a busy, well lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Lock all the doors except the driver's.

If your vehicle has a remote keyless entry system,
take the transmitter with you.

2-14
Passlock

Your vehicle is equipped with the Passlock
theft
-deterrent system.
Passlock is a passive theft
-deterrent system. Passlock
enables fuel if the ignition lock cylinder is turned with a
valid key. If a correct key is not used or the ignition lock
cylinder is tampered with, fuel is disabled.
During normal operation, the THEFT SYSTEM light
will go off approximately five seconds after the key is
turned to the ON ignition position.
If the engine stalls and the THEFT SYSTEM light
flashes, wait until the light stops flashing before trying
to restart the engine. Remember to release the key from
START as soon as the engine starts.
If the engine is running and the THEFT SYSTEM light
comes on, you will be able to restart the engine if you
turn the engine off. However, your Passlock system is not
working properly and must be serviced by your dealer.
Your vehicle is not protected by Passlock at this time.
You may also want to check the fuses (see ªFuses and
Circuit Breakersº in the Index). See your dealer for service.
In an emergency, call the Chevrolet Roadside Assistance
Center at 1
-800-ROADSIDE (1-800-762-3743).
In Canada call 1
-800-268-6800.
New Vehicle ªBreak-Inº
NOTICE:
Your vehicle doesn't need an elaborate
ªbreak
-in.º But it will perform better in the
long run if you follow these guidelines:

Don't drive at any one speed -- fast or
slow
-- for the first 500 miles (805 km).
Don't make full
-throttle starts.

Avoid making hard stops for the first
200 miles (322 km) or so. During this time
your new brake linings aren't yet broken
in. Hard stops with new linings can mean
premature wear and earlier replacement.
Follow this breaking
-in guideline every
time you get new brake linings.

Don't tow a trailer during break
-in.
See ªTowing a Trailerº in the Index for
more information.

2-15
Ignition Positions
With the ignition key in the ignition, you can turn the
switch to five positions.
ACCESSORY (A): In this position, you can operate
your electrical power accessories. Press in the ignition
switch as you turn it toward you.LOCK (B): This is the only position in which you can
remove the key. This locks your steering wheel, ignition,
shift lever and transaxle.
OFF (C): This position unlocks the steering wheel,
ignition and transaxle, but does not send electrical
power to any accessories. Use this position if your
vehicle must be pushed or towed, but never try to
push
-start your vehicle. A warning chime will sound
if you open the driver's door when the ignition is off
and the key is in the ignition.
RUN (D): This is the position the switch returns to,
after you start your engine and release the switch.
The switch stays in RUN when the engine is running.
But even when the engine is not running, you can use
RUN to operate your electrical power accessories, and
to display some instrument panel warning lights.
START (E): This position starts the engine. When
the engine starts, release the key. The ignition switch
will return to RUN for normal driving.
Even if the engine is not running, the positions
ACCESSORY and RUN allow you to operate
electrical accessories, such as the radio.

2-16
CAUTION:
On manual transaxle vehicles, turning the key to
LOCK will lock the steering column and result
in a loss of ability to steer the vehicle. This could
cause a collision. If you need to turn the engine
off while the vehicle is moving, turn the key only
to OFF. Don't press the key release button while
the vehicle is moving.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
Key Release Button (Manual Transaxle)
The ignition key cannot
be removed from the
ignition unless the key
release button is used.
To remove the key, turn the key to OFF. While pressing
the key release button in, turn the key to LOCK. Pull the
key straight out.
Retained Accessory Power
Your vehicle is equipped with a Retained Accessory
Power (RAP) feature which will allow the radio to
continue to work up to 10 minutes after the ignition is
turned to OFF.
Your radio will work when the ignition key is in RUN or
ACCESSORY. Once the key is turned from RUN to OFF,
the radio will continue to work for up to 10 minutes or
until the driver's door is opened.
