Page 111 of 357
2-45
This indicator light on your
instrument panel cluster
will come on when the DRL
are on.
A flashing DRL telltale indicates a possible burned out
headlamp, or that the vehicle may need service to repair
a stuck DRL relay.
When the DRL are on, your high and low
-beam
headlamps will be on at a reduced brightness. The
taillamps, sidemarker and other lamps won't be on.
Your instrument panel won't be lit up either.
When you turn on the headlamp switch, your high and
low
-beam headlamps will go out, and your low-beam
headlamps will come on. The other lamps that come on
with your headlamps will also come on.
When you turn off the headlamp switch, the regular
lamps will go off, and your high and low
-beam
headlamps will come on to the reduced brightness.
To idle your vehicle with the DRL off, set the parking
brake. The DRL will stay off until you release the
parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps (If Equipped)
Use your fog lamps for
better vision in foggy or
misty conditions. The
switch for your fog lamps is
next to the instrument panel
intensity control.
Push the top of the switch to turn the fog lamps on. Push
the top of the switch again to turn the fog lamps off.
When using fog lamps, the parking lamps or low
-beam
headlamps must be on.
A light on the switch will come on when the fog lamps
are actually on. Fog lamps will go off whenever the
high
-beam headlamps come on. When the high-beam
headlamps go off, the fog lamps will come on again.
Page 112 of 357
2-46
Interior Lamps
Instrument Panel Intensity Control
You can brighten or dim the
instrument panel lights by
turning the thumbwheel up
or down.
Turn the thumbwheel up all the way to turn on the
interior courtesy lamps.
Illuminated Entry
When you open either a front door or open a rear door,
the lamps inside your vehicle will go on. In addition, if
your vehicle is equipped with remote keyless entry, the
light will come on when the remote keyless entry
UNLOCK button is pressed.After you exit the vehicle and all of the doors have
been closed, the lamps will stay on for an additional
20 seconds before fading off. The lamps will also fade
to off when the key is inserted and turned to RUN or
ACCESSORY, or the lock button on the remote keyless
entry transmitter is pressed.
Front Reading Lamps (If Equipped)
These lamps are located on the rearview mirror. Turn
each one on and off by pressing its switch.
Page 113 of 357
2-47 Map Lamps (If Equipped)
These lamps are located in front of the dome lamp. To
turn the lamps on, press the switch. Press the switch
again to turn them off.
Battery Saver
Your vehicle is equipped with a battery saver feature
designed to protect your vehicle's battery.
When any interior lamp (trunk, reading, dome, etc.)
is left on and the ignition is turned off, the battery
rundown protection system will automatically turn the
lamp off after 20 minutes. This will avoid draining the
battery. This system does not protect against leaving on
the headlamps or parking lamps.
To reactivate the interior lamps, do one of the following:
The ignition must be turned on, or
the activated lamp switch must be turned off,
then on, or
any door must be opened.
The battery rundown protection feature will also be
activated when any door is left open.
Mirrors
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, move the lever
toward you to the night position.
Manual Remote Control Mirror
The outside rearview mirror
should be adjusted so you
can see a little of the side
of your vehicle when
sitting in a comfortable
driving position.
Adjust the driver's outside mirror with the control lever
on the driver's door.
To adjust your passenger's outside mirror, sit in the
driver's seat and have a passenger adjust the mirror
for you.
The mirror is a spring
-loaded breakaway design.
Page 114 of 357
2-48 Power Remote Control Mirrors
(If Equipped)
The power mirror control is
located on the driver's door.
Turn the control clockwise
or counterclockwise to
choose the mirror you want
to adjust.
Then move the control in the direction you want the
mirror to move. Adjust each mirror so you can see a
little of the side of your vehicle when sitting in a
comfortable driving position.
The mirror is a spring
-loaded breakaway design.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Page 115 of 357
2-49 Breakaway Mirrors
Should the mirror control lever not operate the mirror
adjustment, you can reset the adjustment lever on the
driver's side mirror only, by following these steps:
A. Adjustment Lever T End
B. Lever Slide
C. Mirror
D. Spring
E. Adjustment Lever Handle1. Roll down the left door window.
2. Fold the mirror toward the front of the vehicle. Hold
the mirror in position with your left hand.
3. With your right hand, move the adjustment lever
handle (inside the vehicle) in order to align the T end
of the lever with the lever slide.
4. Fold the mirror back to the original position in order
to engage the T end of the lever with the lever slide.
5. Make sure the mirror housing is fully seated to
its base.
Storage Compartments
Center Console Storage Area
To open the center console, pull the lift lever up and the
lid back.
To close the center console, push the lid down until
it clicks.
Page 116 of 357
2-50 Center Console Cupholders
There are two cupholders located at the front of the
center console, in front of the shift lever. There are also
cupholders for the rear seat passengers located under
the center console lid. Open the center console lid all
the way to uncover the rear cupholders. There is also
a large, removeable cupholder inside of the center
console lid.
Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
inside the back wall of the trunk. Put small loads, like
grocery bags, behind the net. It can help keep them from
falling over during sharp turns or quick starts and stops.
Unclip a corner of the convenience net to fit larger
objects behind the net, then reclip it to secure them
in place.
The net isn't for larger, heavier loads. Store them in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
(If Equipped)
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
To clean the center console ashtray, remove the entire
ashtray and empty it.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.
Page 117 of 357
2-51
Sun Visors
To block out glare, you can swing down the visors.
You can also swing them to the side.
Sunroof (If Equipped)
With the ignition on, press
and release the rear of
the switch and the glass
panel will open to the
vent position.Open the sunshade by hand when using the
vent position.
Press and release the rear of the switch again to open the
glass panel and the sunshade. Press the front of the
switch to stop the panel in any position.
Press and hold the front of the switch to close the glass
panel. The sunshade can only be closed by hand.
The sunroof glass panel cannot be opened or closed if
your vehicle has an electrical failure.
Page 118 of 357
2-52
The Instrument Panel -- Your Information System
Page 119 of 357
2-53
The main components of your instrument panel are the following:
A. Fog Lamp Switch (If Equipped)
B. Instrument Panel Intensity Control
C. Turn Signal/Multifunction Lever
D. Instrument Panel Cluster
E. Hazard Warning Flashers Switch
F. Ignition Switch
G. Windshield Wiper/Washer Controls
H. Cigarette Lighter (If Equipped)I. Audio System
J. Climate Controls and Rear Window Defogger
K. Fuse Panel
L. Hood Release Lever
M. Tilt Steering Wheel Lever (If Equipped)
N. Parking Brake Lever
O. Shift Lever
Page 120 of 357
2-54
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know
how fast you're going, about how much fuel is left in the tank, and many other things you'll need to drive safely
and economically.
Optional United States Cluster shown, Base and Canada similar
