Page 311 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-42
CAUTION:
Extended mobility tires are constructed
differently than other tires and could explode
during improper service. You or others could be
injured or killed if you attempt to repair, replace

Page 312 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-43 Inflation -- Tire Pressure
The Tire-Loading Information label, which is on the
rear edge of the drivers door, shows the correct
inflation pressures for your tires when theyre cold.
ªColdº mea

Page 313 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-44
How to Check
Use a good quality pocket
-type gage to check tire
pressure. You cant tell if your tires are properly inflated
simply by looking at them. Radial tires may look
properly inflated eve

Page 314 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-45
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
If a tires inflation pressure is between 5 psi (35 kPa)
and

Page 315 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-46 Tire Rotation
The tires on your vehicle are different sizes front to rear.
Due to this, your tires should not be rotated. Each tire
and wheel should be used only in the position it is in.
When It

Page 316 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-47
CAUTION:
Mixing tires could cause you to lose control while
driving. If you mix tires of different sizes (other
than those originally installed on your vehicle) or
types (radial and bias
-belted

Page 317 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-48 Uniform Tire Quality Grading
Quality grades can be found where applicable on the tire
sidewall between tread shoulder and maximum section
width. For example:
Treadwear 200 Traction AA Temperature

Page 318 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-49
Temperature -- A, B, C
The temperature grades are A (the highest), B, and C,
representing the tires resistance to the generation of
heat and its ability to dissipate heat when tested under
contr

Page 319 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-50 Wheel Replacement
Replace any wheel that is bent, cracked, or badly rusted
or corroded. If wheel nuts keep coming loose, the wheel,
wheel bolts and wheel nuts should be replaced. If the
wheel lea

Page 320 of 383

CHEVROLET CORVETTE 2001 5.G Owners Manual 6-51
CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could come
off and cause an accident. When you change a
w
