The following explains your cooling system and how to
add coolant when it is low. If you have a problem
with engine overheating, seeEngine Overheating on
page 5-36.
A 50/50 mixture of clean, drinkable water and
DEX-COOL
®coolant will:
•Give freezing protection down to−34°F (−37°C).
•Give boiling protection up to 252°F (122°C).
•Protect against rust and corrosion.
•Help keep the proper engine temperature.
•Let the warning lights and gages work as they
should.
Notice:Using coolant other than DEX-COOL
®may
cause premature engine, heater core or radiator
corrosion. In addition, the engine coolant may
require changing sooner, at 30,000 miles (50 000 km)
or 24 months, whichever occurs rst. Any repairs
would not be covered by your warranty. Always use
DEX-COOL
®(silicate-free) coolant in your vehicle.
What to Use
Use a mixture of one-halfclean, drinkable waterand
one-half DEX-COOL®coolant which won’t damage
aluminum parts. If you use this coolant mixture,
you don’t need to add anything else.
{CAUTION:
Adding only plain water to your cooling
system can be dangerous. Plain water, or
some other liquid such as alcohol, can boil
before the proper coolant mixture will. Your
vehicle’s coolant warning system is set for the
proper coolant mixture. With plain water or the
wrong mixture, your engine could get too hot
but you would not get the overheat warning.
Your engine could catch re and you or others
could be burned. Use a 50/50 mixture of clean,
drinkable water and DEX-COOL
®coolant.
Notice:If you use an improper coolant mixture,
your engine could overheat and be badly damaged.
The repair cost would not be covered by your
warranty. Too much water in the mixture can freeze
and crack the engine, radiator, heater core and
other parts.
If you have to add coolant more than four times a year,
have your dealer check your cooling system.
Notice:If you use the proper coolant, you do not
have to add extra inhibitors or additives which claim
to improve the system. These can be harmful.
5-33

Checking Coolant
The coolant surge tank is located in the engine
compartment on the driver’s side of the vehicle.
{CAUTION:
Turning the surge tank pressure cap when the
engine and radiator are hot can allow steam
and scalding liquids to blow out and burn you
badly. Never turn the surge tank pressure
cap — even a little — when the engine and
radiator are hot.
The vehicle must be on a level surface. When your
engine is cold, the coolant level should be at the COLD
FILL mark or higher.
If the low coolant warning
light comes on and stays
on, it means you’re
low on engine coolant.
SeeLow Coolant Warning Light on page 3-36for further
information.
5-34

Engine Overheating
You will find a coolant temperature warning gage on
your vehicle’s instrument panel, as well as a low coolant
warning light. Your vehicle also has a check gages
warning light on the instrument panel.
If Steam Is Coming From Your Engine
{CAUTION:
Steam from an overheated engine can burn
you badly, even if you just open the hood. Stay
away from the engine if you see or hear steam
coming from it. Just turn it off and get
everyone away from the vehicle until it cools
down. Wait until there is no sign of steam or
coolant before you open the hood.
If you keep driving when your engine is
overheated, the liquids in it can catch re. You
or others could be badly burned. Stop your
engine if it overheats, and get out of the
vehicle until the engine is cool.
Notice:If your engine catches re because you
keep driving with no coolant, your vehicle can
be badly damaged. The costly repairs would not be
covered by your warranty.
5-36

300,000 Miles (480 000 km)
❑Remove, disassemble, clean and inspect the air
brake air dryer (or every 3 years, or 10,800 hours,
whichever occurs first). Replace desiccant on
Bendix-Westinghouse units.
Footnotes
† = The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to
the completion of the vehicle’s useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the
maintenance be recorded.
(1)= If your vehicle has an Allison automatic
transmission, your GM owner’s manual is supplemented
by an Allison Transmission
®Operator’s Manual.
Always refer to these manuals for related maintenance
services.
(2)= Refer to the Caterpillar
®Diesel Engine Operation
and Maintenance Manual for oil recommendations
and change intervals.
(3)= An Emission Control Service.
(4)= A Noise Emission Control Device.
(5)= Applies only to vehicles sold in the United States.(6)= Check fluid level in brake master cylinder, power
steering pump, axle, transmission and hydraulic
spring parking brake pump (if equipped). A low fluid
level in the brake master cylinder can indicate
worn brake linings and should be checked accordingly.
(7)= Inspect brake lines and hoses for proper
hook-up, binding, leaks, cracks, chafing, etc. Inspect
disc brake pads for wear and rotors for surface
condition. Inspect caliper assemblies. Check brake
pedal for excessive free play or travel (or every
6 months, whichever occurs first) and have serviced if
needed. Check brakes more often if driving habits
and conditions result in frequent braking.
(8)= Inspect parking brake drum and linings for wear or
cracks and check linkage and adjustment.
(9)= This vehicle has the GM Oil Life System. This
system will show you when to change the engine oil and
filter – usually between 3,000 miles (5 000 km) and
7,500 miles (12 000 km) since your last oil change.
Under severe conditions, the indicator may come on
before 3,000 miles (5 000 km). Never drive your vehicle
more than 7,500 miles (12 000 km) or 12 months
without an oil and filter change.
Remember to reset the Oil Life System whenever the oil
is changed. For more information, seeChange Engine
Oil Light on page 3-39.
6-19

Exhaust System Check
Be alert for any changes in the sound of the exhaust
system or any smell of fumes. These are signs the
system may be leaking. Have it checked and/or repaired
at once. Refer toEngine Exhaust on page 2-37and
Running Your Engine While You Are Parked on
page 2-38.
Windshield Wipers and Washers Check
Check operation and condition of the wiper blades.
Check the flow of the washer spray.
Defroster Check
Move the control to the defrost symbol and the fan to HI
or the high symbol. Then check the airflow from the
ducts at the inside base of the windshield.
Mirrors and Sun Visors Check
Check that friction joints hold mirrors and sun visors in
place.
Seat Adjuster Check
When adjusting a manual seat, be sure seat adjusters
latch by attempting to move the seat after latching.
Lamps Check
Check panel lighting, warning lights, indicator lights and
interior lamps. On the outside, check: license plate
lamps, sidemarker lamps, reflectors or lights on outside
mirrors, headlamps, parking lamps, identification and
clearance lamps, taillamps, brake lamps, turn signals,
backup lamps and hazard warning flashers. Have
headlamp aim checked at once if beams seem
improperly aimed.
Glass, Mirrors, Lamps and/or
Reectors Condition Check
Look for broken, scratched, dirty or damaged glass,
mirrors, lamps or reflectors that could reduce the view
or visibility or cause injury. Replace, clean or repair
promptly.
Door Latches Check
Check that doors close, latch and lock tightly. Check for
broken, damaged or missing parts that might prevent
tight latching.
6-27

Audio System(s).............................................3-45
AM-FM Radio.............................................3-46
Care of Your Cassette Tape Player................3-57
Care of Your CD Player...............................3-59
Care of Your CDs........................................3-59
Chime Level Adjustment...............................3-59
Fixed Mast Antenna.....................................3-59
Radio with Cassette.....................................3-48
Radio with CD............................................3-53
Setting the Time..........................................3-45
Theft-Deterrent Feature................................3-57
Understanding Radio Reception.....................3-57
Automatic Ether Injection System......................5-66
Automatic Transmission...........................2-13, 2-19
Fluid..........................................................5-31
Operation...................................................2-28
Automatic Transmission External Filter...............5-31
Automatic Transmission Shift Indicator Check......6-26
Axle, Two-Speed Rear Axle Electric
Shift Control...............................................2-26
B
Battery..........................................................5-55
Battery Replacement......................................... 2-5
Bench Seat, Split............................................. 1-6
Body Lubrication Service..................................6-25Brake
Diesel Engine Exhaust.................................2-25
Exhaust Indicator Light.................................3-40
Parking Warning Light..................................3-34
System Warning Light..................................3-31
Trailer Hand Control Valve.............................. 4-9
Brake Adjustment............................................5-49
Brake Fluid....................................................5-46
Brake Pedal Travel.........................................5-49
Brake System Check.......................................6-26
Brakes..........................................................5-46
Braking........................................................... 4-6
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-11
Bucket Seats................................................... 1-2
Bulb Replacement
Replacement Bulbs......................................5-63
C
Canada........................................................... 7-4
Canadian Owners................................................ ii
Capacities and Specifications............................5-93
Carbon Monoxide...................................4-25, 2-37
2

Care of
Safety Belts................................................5-79
Your Cassette Tape Player............................3-57
Your CD Player...........................................3-59
Your CDs ...................................................3-59
Cassette Tape Messages.................................3-52
CD Adapter Kits.............................................3-52
Center Console Storage Area...........................2-42
Center Passenger Position, Safety Belts.............1-22
Charging System Light....................................3-30
Chassis Lubrication.........................................5-51
Check
Engine Light...............................................3-37
Gages Warning Light...................................3-42
Checking Coolant............................................5-34
Checking Engine Oil................................5-21, 5-25
Checking Things Under the Hood......................5-18
Checking Your Restraint Systems......................1-61
Chemical Paint Spotting...................................5-83
Child Restraints
Child Restraint Systems...............................1-33
Infants and Young Children...........................1-29
Older Children.............................................1-27
Securing a Child Restraint in a Rear
Outside Seat Position...............................1-39
Securing a Child Restraint in the Center
Rear Seat Position (Crew Cab
®) or Center
Front Position..........................................1-41Child Restraints (cont.)
Securing a Child Restraint in the Right
Front Seat Position...................................1-43
Top Strap...................................................1-38
Where to Put the Restraint...................1-35, 1-37
Chime Level Adjustment..................................3-59
Chugger-Snubber Lock-Out Feature.................... 1-7
Cigarette Lighter.............................................3-18
Cleaning
Inside of Your Vehicle..................................5-77
Outside of Your Vehicle................................5-80
Underbody Maintenance...............................5-83
Weatherstrips..............................................5-79
Cleaning Exterior Lamps/Lenses.......................5-80
Cleaning Fabric/Carpet....................................5-77
Cleaning Glass Surfaces..................................5-79
Cleaning Interior Plastic Components.................5-79
Cleaning the Top of the
Instrument Panel.........................................5-79
Cleaning Vinyl................................................5-78
Climate Control System...................................3-19
Outlet Adjustment........................................3-22
Rear Heating System...................................3-23
Clutch Brake (Vehicles with Non-Synchronized
Transmission)..............................................2-32
Clutch Pedal Free Travel.................................5-51
Cold Weather Starting (Diesel Engine)...............2-20
Cold Weather Starting
(Caterpillar
®Diesel).....................................2-15
3

Compact Disc Messages..................................3-56
Control of a Vehicle.......................................... 4-5
Coolant
Engine Temperature Gage............................3-35
Heater, Engine............................................2-23
Low Warning Light.......................................3-36
Surge Tank Pressure Cap.............................5-35
Cooling System..............................................5-38
Cooling System Capacity.................................5-94
Cruise Control................................................3-10
Current and Past Model Order Forms.................. 7-8
Customer Assistance Information
Customer Assistance for Text Telephone
(TTY) Users.............................................. 7-3
Customer Assistance Offices........................... 7-3
Customer Satisfaction Procedure..................... 7-2
Reporting Safety Defects to General Motors...... 7-7
Reporting Safety Defects to the Canadian
Government.............................................. 7-7
Reporting Safety Defects to the United
States Government.................................... 7-6
Roadside Assistance Program......................... 7-4
Service Publications Ordering Information......... 7-7
D
Daytime Running Lamps..................................3-14
Daytime Running Lamps Indicator Light.............3-41
Defensive Driving............................................. 4-2Defogging and Defrosting.................................3-20
Defroster Check..............................................6-27
Diesel Engine
Exhaust Brake............................................2-25
Fuel............................................................ 5-8
Starting......................................................2-14
Starting Your DURAMAX™...........................2-19
Diesel Engine Warm-Up...................................2-16
Differential Lock Control, Inter-Axle....................4-10
Differential Lock Control, Rear Axle...................4-10
Differential Lock Indicator Light.........................3-40
Doing Your Own Service Work........................... 5-4
Dome Lamps.................................................3-15
Door
Locks.......................................................... 2-6
Power Door Locks......................................... 2-7
Door Latches Check........................................6-27
Double-Clutching.............................................2-30
Driver
Position, Safety Belt.....................................1-13
Driving
At Night.....................................................4-17
City...........................................................4-21
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Freeway.....................................................4-22
Hill and Mountain Roads..............................4-23
In Rain and on Wet Roads...........................4-18
Winter........................................................4-25
4

Driving on Snow or Ice....................................4-26
Driving Through Deep Standing Water...............4-20
Driving Through Flowing Water.........................4-20
Dual Tire Operation.........................................5-69
E
Eaton®Fuller®Five and Six-Speed
Transmissions and TTC Spicer Seven-Speed
Transmissions.............................................2-30
Eaton
®Fuller®Nine and Ten-Speed
Non-Synchronized Manual Transmissions........2-32
Electric Air Compressor...................................5-51
Electrical Connections......................................4-36
Electrical System
Add-On Equipment......................................5-86
Fuses and Circuit Breakers...........................5-87
Fusible Links..............................................5-87
Headlamp Wiring.........................................5-86
Power Windows and Other Power Options......5-87
Windshield Wiper Fuses...............................5-87
Elevated Idle/Exhaust Restrictor........................2-21
Engine
Air Cleaner/Filter.........................................5-30
Battery.......................................................5-55
Change Engine Oil Light...............................3-39
Check and Service Engine Soon Light............3-37Engine (cont.)
Checks Before Operating..............................2-22
Coolant..............................................5-32, 5-35
Coolant Heater............................................2-23
Coolant Temperature Gage...........................3-35
Diesel Engine Exhaust Brake........................2-25
Drive Belt Routing......................................5-103
Exhaust.....................................................2-37
Fan Noise..................................................5-43
Oil .....................................................5-20, 5-25
Overheating................................................5-36
Overspeed Warning Light..............................3-39
Reduced Power Light...................................3-41
Shutdown Warning Light...............................3-39
Starting Your Diesel.....................................2-14
Starting Your DURAMAX™ Diesel..................2-19
Starting Your Gasoline..................................2-12
Engine Alarm and Automatic Shutdown..............2-16
Engine Coolant Level Check.............................6-24
Engine Cooling System Service........................6-26
Engine Cover Check.......................................6-28
Engine Oil Additives................................5-23, 5-29
Engine Oil Level Check...................................6-24
Engine Road Speed Governor..........................3-25
Engine Speed Limiting.....................................3-25
Engine Starter Over-Crank Protection.................2-12
Event Data Records (EDR)................................ 7-5
Exhaust Brake Indicator Light...........................3-40
5

Exhaust Restrictor (Diesel Engines)...................2-18
Exhaust System Check....................................6-27
Express-Down Feature.....................................2-10
Extender, Safety Belt.......................................1-26
Exterior Lamps...............................................3-13
F
Filter
Engine Air Cleaner......................................5-30
Filter Minder Gage..........................................3-44
Finding a Station............................3-46, 3-49, 3-53
Finish Care....................................................5-80
Finish Damage...............................................5-83
Fixed Mast Antenna........................................3-59
Flat Tire........................................................5-75
Flat Tire, Changing.........................................5-76
Fluid
Automatic Transmission................................5-31
Manual Transmission....................................5-32
Power Steering...........................................5-43
Windshield Washer......................................5-44
Fluid Leaks Check..........................................6-28
FM ...............................................................3-57
Folding the Rear Seat (Crew Cab).................... 1-7
Footnotes......................................................6-19
Fore-and-Aft Adjustment.................................... 1-4Four-Wheel and Six-Wheel Drum Brakes
(Air Only)...................................................5-49
Four-Wheel Disc Brakes
(Hydraulic Only)..........................................5-49
Front Wheel Bearings with Oil-Filled Hubs..........5-67
Fuel............................................................... 5-6
Additives...................................................... 5-7
Diesel Engine Fuel........................................ 5-8
Filling a Portable Fuel Container....................5-18
Filling Your Tank..........................................5-17
Filter..........................................................5-64
Filter Replacement.......................................5-15
Fuels in Foreign Countries............................5-16
Gage.........................................................3-42
Gasoline Octane........................................... 5-6
Gasoline Specifications.................................. 5-6
Primary Filter and Water Separator................5-65
Running Out of Fuel....................................5-15
Secondary Filter and Water Separator/Heater....5-66
Very Cold Weather Operation........................5-10
Water in Fuel..............................................5-10
Water in Warning Light.................................3-43
What Fuel to Use.......................................... 5-8
Fuel Filter (Diesel Engines)..............................5-65
Fuel Filter (Gasoline Engines)...........................5-64
Fuel Priming..................................................5-13
Fuses
Fuses and Circuit Breakers...........................5-87
Windshield Wiper.........................................5-87
6
