Rear Heating System
If you have a crew cab
and your vehicle has a
rear heater, the
thumbwheel for this
feature is located on
the headliner.
To increase and decrease the flow of heated air to
the rear floor vents, turn the thumbwheel to the
desired fan speed. To turn the fan off, turn
the thumbwheel all the way down.
Warning Lights, Gages, and
Indicators
This part describes the warning lights and gages
that may be on your vehicle. The pictures will
help you locate them.Warning lights and gages can signal that
something is wrong before it becomes serious
enough to cause an expensive repair or
replacement. Paying attention to your warning
lights and gages could also save you or others
from injury.
Warning lights come on when there may be or
is a problem with one of your vehicle’s functions.
As you will see in the details on the next few
pages, some warning lights come on briefly when
you start the engine just to let you know they
are working. If you are familiar with this section,
you should not be alarmed when this happens.
Gages can indicate when there may be or is a
problem with one of your vehicle’s functions. Often
gages and warning lights work together to let you
know when there is a problem with your vehicle.
When one of the warning lights comes on and
stays on when you are driving, or when one of the
gages shows there may be a problem, check
the section that tells you what to do about
it. Waiting to do repairs can be costly and even
dangerous.
161

{CAUTION:
If the airbag readiness light ever comes
on when you have turned off the airbag, it
means that something may be wrong with
the airbag system. The right front
passenger’s airbag could inate even
though the switch is off. If this ever
happens, do not let anyone whom the
national government has identied as a
member of a passenger airbag risk group
sit in the right front passenger’s position
(for example, do not secure a rear-facing
child restraint in the right front
passenger’s seat) until you have your
vehicle serviced. SeeAirbag Off Switch on
page 76andAirbag Readiness Light on
page 165for more on this, including
important safety information.
Charging System Light
The charging system
light may be located in
the instrument panel
cluster, or with the
auxiliary warning lights
in the center of the
instrument panel.
It should come on briefly when you turn on the
ignition, before the engine is running, as a check to
show that it is working.
If it stays on, or comes on while you are driving,
have your vehicle checked right away. You
could have a loose generator drive belt or some
other problem.
Driving while this light is on will drain your battery.
If you must drive a short distance with the light
on, turn off your radio and other accessories.
Sustained driving with a generator failure could
result in a lack of back-up braking if the engine
quits or the power steering pump should fail.
167

Parking Brake Warning Light
This light will also come on when you set the
parking brake. The light will stay on if your parking
brake does not release fully.
Air Brake System Warning Light
Vehicles with air brake systems have a brake
system warning light on the instrument panel.
The LOW AIR warning light should come on, as a
check, whenever you start the engine. However,
it is designed to come on, and stay on, when brake
reservoir pressure has dropped below 60 psi
(410 kPa).When the warning light comes on while you are
driving, you should drive only as far as the nearest
point of safety and then stop the vehicle. Here’s
a very important thing for you to know:{CAUTION:
If the air brake system warning light
comes on and the warning tone sounds,
the vehicle can stop suddenly and without
further warning. This is because the
parking brake will come on if the pressure
falls below 35 to 45 psi (240 to 310 kPa).
You or others could be injured. If the air
brake system warning light comes on and
the warning tone sounds, stop as soon as
you can. You will not know how quickly
the system is losing pressure, so be
aware that the parking brake may come
on suddenly.
United StatesCanada
171

Anti-Lock Brake System
Warning Light
This light will come on
briefly when you start
your engine, then
it will turn off. This
is normal.
If the light stays on, or comes on when you are
driving, your vehicle needs service. If the BRAKE
or LOW AIR warning light is not on, you still
have brakes, but you do not have the anti-lock
brake feature. If the BRAKE and/or LOW AIR
warning light is on, you do not have anti-lock
brakes and there is a problem with your regular
brakes. SeeBrake System Warning Light on
page 169andAnti-Lock Brake System (ABS) on
page 212for more information.
The anti-lock brake system warning light should
come on briefly when you turn the ignition
key to ON. If the light does not come on then,
have it fixed so it will be ready to warn you if
there is a problem.
Trailer Anti-Lock Brake System
Warning Light
This light is located
above the climate
controls in the center of
the instrument panel.
If your vehicle is connected to a trailer with
anti-lock brakes, this light should come on briefly,
as a check, when you turn on the ignition.
When this light comes on and stays on, it means
there is something wrong in the trailer anti-lock
brake system. Have the system repaired
immediately.
If an anti-lock brake system equipped trailer is not
connected, this light is not functional.
172

Engine Coolant Temperature Gage
This gage shows the engine coolant temperature.
If the gage pointer moves into the red area,
your engine coolant might have overheated and
your engine may be too hot. You should pull off the
road, stop your vehicle and turn off the engine
as soon as possible.
SeeEngine Overheating on page 288. If you have
a Caterpillar
®diesel engine, also see your
Caterpillar®Operation & Maintenance Manual.
Low Coolant Warning Light
You have a low coolant
warning light. If this light
comes on, your system
is low on coolant and the
engine may overheat.
The warning light should come on briefly, as a
check, when you turn on the ignition.
When it comes on, you will also hear a warning
tone at several beats per second for 10 seconds.
SeeEngine Coolant (Gas and DURAMAX
®/Isuzu
Engines) on page 284orEngine Coolant
(Caterpillar
®Diesel Engines) on page 287and
have your vehicle serviced as soon as you can.
This light may also come on if your vehicle is
equipped with the automatic engine shutdown
system and engine shutdown has begun.
SeeEngine Alarm and Automatic Shutdownunder
Starting the Diesel Engine on page 100.
United StatesCanada
173

Wait to Start Indicator
If your vehicle has the DURAMAX®6.6L diesel
engine, it will have glow plugs and an air
intake heater. If your vehicle has the Isuzu 6H
diesel engine, it will have glow plugs and an inlet
heater. If your vehicle has a Caterpillar
®engine,
it will have an inlet heater.
The light in the center of
the instrument panel will
come on when the inlet
heater or glow plugs are
on and the ignition key is
in RUN.
Wait until the indicator light goes off before turning
the ignition key to START.
Malfunction Indicator Lamp
Service Engine Soon Light
If this light comes on or
flashes while you are
driving, two things
may happen.
First, you will not notice any difference in engine
performance, but your tail pipe emissions may
increase. Second, your engine may not run
properly or may stall without warning. If either of
these things happen, drive or tow your vehicle
to your dealer for service.
This light should come on when the ignition is on,
but the engine is not running, as a check to
show you it is working. If it does not come on at
all, have it repaired.
Notice:If you keep driving your vehicle with
this light on, after awhile, your emission
controls may not work as well, your fuel
economy may not be as good, and your engine
may not run as smoothly. This could lead to
costly repairs that may not be covered by your
warranty.
174

Oil Pressure Gage
The engine oil pressure gage, on the lower right
portion of your instrument panel cluster, shows
engine oil pressure in psi (pounds per square inch)
or in kPa (kilopascals). Oil pressure may vary
with outside temperature and oil viscosity,
but readings of 30 to 40 psi (205 to 275 kPa) on
gasoline engines at operating temperature
and moderate road speeds are normal. If you
have a diesel engine, the normal operating range
should be between 35 and 70 psi (240 to 480 kPa).A reading in the low pressure zone may be
caused by a dangerously low oil level or other
problem.
If you have a Caterpillar
®diesel engine, also see
your Caterpillar®Operation & Maintenance
Manual.
{CAUTION:
Do not keep driving if the oil pressure is
low. If you do, your engine can become so
hot that it catches re. You or others
could be burned. Check your oil as soon
as possible and have your vehicle
serviced.
Notice:Lack of proper engine oil maintenance
may damage the engine. The repairs would
not be covered by your warranty. Always follow
the maintenance schedule in this manual for
changing engine oil.
United StatesCanada
175

Low Oil Level Light
Your vehicle may have
a low oil level light.
This light should come on as a check, when you
start your engine. If the light fails to come on, have
it repaired as soon as possible so you will be
aware when the oil level is low.
Vehicles that have Caterpillar
®diesel engines may
not have a low oil level light. In this case, the light
will neither come on as a check when you start your
engine, nor will it come on to indicate a low oil level.
If this light comes on and stays on, it means your
engine is low on oil. You need to check the oil level
right away. SeeEngine Oil (Caterpillar
®DieselEngine) on page 268orEngine Oil (Gasoline
Engine) on page 268orEngine Oil (DURAMAX
®/
Isuzu Diesel Engine) on page 272for further
information.
Notice:Lack of proper engine oil maintenance
may damage the engine. The repairs would
not be covered by your warranty. Always follow
the maintenance schedule in this manual for
changing engine oil.
Change Engine Oil Light
The change engine oil
light should come on
briefly as a bulb
check when you start
the engine. If the
light does not come on,
have it serviced.
If the change engine oil light comes on and stays
on after you start the engine, have the oil
changed.
176

For additional information on when to change
engine oil for gasoline engines or DURAMAX®
diesel engines, seeEngine Oil (Caterpillar®Diesel
Engine) on page 268orEngine Oil (Gasoline
Engine) on page 268orEngine Oil (DURAMAX
®/
Isuzu Diesel Engine) on page 272andScheduled
Maintenance on page 363. To reset the change
engine oil light, seeEngine Oil Life System
(Gasoline Engine) on page 276orEngine Oil Life
System (DURAMAX
®Diesel) on page 278or
Engine Oil Life System (Caterpillar®Diesel Engine)
on page 279.
Engine Overspeed Warning Light
If your vehicle has this
light, it will come on if
your engine is operating
at too many revolutions
per minute (rpm).
It will also come on for a moment as a check
when you start your engine.
If it comes on when you’re driving, reduce your
engine speed immediately.
Engine Shutdown Warning Light
If your vehicle has the
engine shutdown
feature, this light will
come on when engine
shutdown is active.
For more information, seeEngine Alarm and
Automatic ShutdownunderStarting the Diesel
Engine on page 100.
177

Transmission Temperature Gage
If you have an automatic
transmission and this
gage, it is located above
the switchbank in the
center of the instrument
panel.
When your ignition is on, the gage shows the
temperature of the transmission oil. A reading in
the warning zone, the red area beginning at 300°F
(150°C), means you must stop driving and
check into the cause. One possible cause is a low
oil level in the transmission.
Notice:If you drive your vehicle with the
transmission temperature gage above normal
operating range, you can damage the
transmission. This could lead to costly repairs
that would not be covered by your warranty.
Do not drive your vehicle while the
transmission temperature gage reading is
above normal. See your dealer for service.
Exhaust Brake Indicator Light
If your vehicle is
equipped with an
exhaust brake, you will
have this light, located
above the climate
controls in the center of
the instrument panel.
The exhaust brake indicator light will come on and
stay on whenever the diesel engine exhaust brake
or exhaust restrictor is active. For more information,
seeDiesel Engine Exhaust Brake on page 112and
Exhaust Restrictor (Engine Warm-Up) on page 108.
Differential Lock Indicator Light
If your vehicle has this
feature, this light is
located in the center of
the instrument panel.
The light is on when the
rear differential lock
system is in use.
178
