12 In Brief
Instrument Panel (Driver Side)
1. Instrument Panel Light LevelControl. See Instrument Panel
Illumination Control 095.
2. Power Take Off (PTO) Main Switch. See Power Take-Off
(PTO) 0237.
3. Power Take Off (PTO) Engine Speed Control Switch. See
Power Take-Off (PTO) 0237. 4. Rear Body Interior Light
Switch. See Cargo Lamp 096.
5. Instruments, Warning Lights and Indicator Lights. See
Instrument Cluster 069.
6. Horn Button. See Horn065. 7. Rear Power Window Lock
Switch. See Power Windows
0 35.
8. Outside Rearview Mirror Heater Switch. See Heated
Mirrors 034.
9. Cruise Control Main Switch. See Cruise Control 0223.
10. Hazard Warning Flasher Switch. See Hazard Warning
Flashers 094.
11. Rear Power Window Switch. SeePower Windows 035.
12. Diesel Particulate Filter (DPF) Switch. See Diesel Particulate
Filter 0180.
13. Odometer Check Switch. See Odometer 070.
Engine Oil Level Check Switch.
See Engine Oil 0245.
14. Door Lock Switch. See Power
Door Locks 033.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
64 Instruments and Controls
Instruments and
Controls
Controls
Steering Wheel Adjustment . . . . 65
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Windshield Wiper/Washer . . . . . . 66
Power Outlets . . . . . . . . . . . . . . . . . 67
Warning Lights, Gauges, and
Indicators
Warning Lights, Gauges, andIndicators . . . . . . . . . . . . . . . . . . . . 68
Instrument Cluster . . . . . . . . . . . . . 69
Speedometer . . . . . . . . . . . . . . . . . . 70
Odometer . . . . . . . . . . . . . . . . . . . . . . 70
Trip Odometer . . . . . . . . . . . . . . . . . 70
Tachometer . . . . . . . . . . . . . . . . . . . . 71
Fuel Gauge . . . . . . . . . . . . . . . . . . . . 71
Engine Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . . . 72
Diesel Exhaust Fluid (DEF) Gauge . . . . . . . . . . . . . . . . . . . . . . . . 72
Seat Belt Reminders . . . . . . . . . . . 72
Battery Warning Light . . . . . . . . . . 73
Malfunction Indicator Lamp (Check Engine Light) . . . . . . . . . 73
Service Vehicle Soon Light . . . . 74 Brake System Warning Light
(Parking Brake Light) . . . . . . . . . 74
Antilock Brake System (ABS) Warning Light . . . . . . . . . . . . . . . . 76
Exhaust Brake Light . . . . . . . . . . . 77
Service Transmission Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . 77
Automatic Transmission Fluid Temperature Warning Light . . . 78
Overdrive Off Light . . . . . . . . . . . . . 78
Wait-to-Start Light . . . . . . . . . . . . . 79
Engine Oil Pressure Light . . . . . . 79
Engine Oil Level Indicator Light . . . . . . . . . . . . . . . . . . . . . . . . . 79
Diesel Exhaust Fluid (DEF) Warning Light . . . . . . . . . . . . . . . . 80
Engine Shutdown Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . 80
Idle Shutdown Light . . . . . . . . . . . . 80
Reduced Engine Power Light . . . . . . . . . . . . . . . . . . . . . . . . . 81
High-Beam On Light . . . . . . . . . . . 81
Daytime Running Lamps (DRL) Indicator Light . . . . . . . . . . . . . . . . 81
Cruise Control Light . . . . . . . . . . . 82
Information Displays
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 82
Vehicle Messages
Vehicle Messages . . . . . . . . . . . . . 86
Warning Buzzers . . . . . . . . . . . . . . 91

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
70 Instruments and Controls
Speedometer
The speedometer shows the
vehicle's speed in either kilometers
per hour (km/h) or miles per
hour (mph).
Odometer
The odometer shows how far the
vehicle has been driven, in either
kilometers or miles.
Each time the reset knob is pressed
with the engine control switch in the
ON position, the odometer/trip meter
shows ODO, TRIP A, and TRIP B in
this sequence. With the key
removed, the odometer and trip
meter continue to indicate for about
five minutes.
Odometer Check Switch
Press the Odometer Check switch
to display the odometer and trip
meter mileage after the key is
turned off. The fuel gauge will also
operate when this switch is pressed.
The DIC and some lights will
illuminate on the instrument panel.
Trip Odometer
The trip odometer shows how far
the vehicle has been driven since
the trip odometer was last reset.
Press the trip odometer reset stem
next to the odometer to switch
between the odometer and trip
odometer.To reset the trip odometer to zero,
press and hold the trip odometer
reset stem while TRIP A or TRIP B
is displayed. The engine control
switch should be in the ON position.
When the battery is disconnected,
TRIP A and TRIP B will be reset to
zero. The per trip fuel economy is
also reset by the TRIP B reset. See
Driver Information Center (DIC)
0
82.
When you turn the engine control
switch to the ON position, the
odometer/trip odometer shows what
was displayed the last time the
engine control switch was turned to
LOCK or ACC.
To set the odometer to display each
time you turn the engine control
switch to the ON position, turn the
engine control switch to LOCK or
ACC while the odometer is
displayed. With the reset stem
pressed, turn the engine control
switch to the ON position and then
within three seconds, turn the
engine control switch back to the

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
Instruments and Controls 71
LOCK or ACC position. Follow the
same procedure to cancel the
setting.
Tachometer
The tachometer displays the engine
speed in revolutions per
minute (rpm). The red zone
indicates a range of dangerous
engine speeds beyond permissable
levels. Do not drive your vehicle
with the needle in the red zone.
Caution
Exercise extreme care when
shifting down on a steep
downslope. The engine speed
may exceed the critical speed,
which can damage the vehicle.
Fuel Gauge
With the engine control switch in the
ON position, the fuel gauge
indicates about how much fuel is left
in the tank.To check the fuel level with the
engine control switch in the LOCK
position, press the Odometer Check
switch.
Fill the tank well before it
approaches empty. After filling up
the fuel tank, it takes awhile for the
fuel gauge needle to stabilize after
the engine control switch is turned
to the ON position. If the fuel tank is
filled while the engine is off, but the
engine control switch is in the ON
position, the fuel gauge needle
takes awhile to show the correct
reading.
See
“Low Fuel Warning Light” in
Driver Information Center (DIC) 082
and Running Out of Fuel 0233.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
Instruments and Controls 85
display. Complete the resetting by
pressing and holding the DIC
selector for more than two seconds.
To cancel the setting procedure,
press the DIC selector once. The
display will go back to the previous
screen.
Resetting/Setting the Change
Interval (Odometer Reading)
Engine Oil and Filter Light :On
the DIC, go to the engine oil and
filter light. Enter the resetting screen
by pressing and holding the DIC
selector for more than two seconds.
Complete the resetting by pressing
and holding the DIC selector for
more than two seconds.
Transmission and Differential
Gear Oil Light, Fuel Filter Light,
Power Steering Fluid Light, and
Tire Rotation Light : On the DIC,
go to the particular maintenance
item to reset/adjust. Enter the
setting change screen by pressing
and holding the DIC selector. Set
the change interval by turning the
DIC selector. (Transmission and
Differential Oil, Steering Fluid, and Tire Rotation Only). Turn clockwise
to increase distance and
counterclockwise to decrease
distance. The distance increases
and decreases by 4,000 km
(2,500 mi) increments. Complete the
resetting by pressing and holding
the DIC selector.
Transmission and Differential Gear
Oil and Power Steering Fluid: Initial
value: 48,000 km (30,000 mi).
Adjustable minimum value:
32,000 km (20,000 mi). Adjustable
maximum value: 48,000 km
(30,000 mi).
Tire Rotation: Initial value: OFF.
Adjustable minimum value:
6,000 km (4,000 mi). Adjustable
maximum value: 62,000 km
(39,000 mi).
Starter Indicator Light :
On the
DIC, go to the starter indicator light.
Enter the resetting screen by
pressing and holding the DIC
selector for more than ten seconds.
Complete the resetting by pressing
and holding the DIC selector for
more than ten seconds. If you want to cancel the setting
procedure, press the DIC selector
once. The display will go back to the
previous screen.
Diesel Exhaust Fluid (DEF)
Gauge
With the engine control switch in the
ON position, this gauge indicates
the approximate quantity of DEF
remaining in the DEF tank. F means
the tank is full and E means the
tank is almost empty. When only
one green bar is showing, the DEF
tank is almost empty and should be
refilled soon. If the vehicle is driven
too long with only one bar, the green
will change to amber and additional
warnings and indicators will display.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
298 Vehicle Care
Warning (Continued)
Consult your dealer before
replacing wheels. Never use
wheels that are not designed for
the vehicle. Doing so would
impede safe vehicle operation.
You should replace your tires when:
. Your tires are worn to a point
where 3.2 mm (4/32 in.) (front)
and 1.6 mm (2/32 in.) (rear) or
the cord or fabric is exposed.
. Your tire tread or sidewall is
cracked, cut or snagged deeply
enough to expose the core,
fabric or steel components.
. Your tire has a hump, bulge or
split.
. Your tire sustains a puncture, cut
or other damage that cannot be
correctly repaired because of the
size or location of the damage.
When replacing tires, you should
use the same size, load range and
construction type (bias or radial) as
the original tires on your vehicle. Use of any other size or type tire
may affect load carrying capacity,
ride, handling, speedometer/
odometer calibration, vehicle ground
clearance and tire clearance to the
chassis. If replacing only a single
tire, it should be put on the same
axle with other tires of equal
diameter.
When replacing or rotating tires, all
tires on an axle should be of the
same tread design and should have
the same outside diameter within
certain limitations, particularly on
LSD models. Consult your
authorized dealer or tire dealer.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
Vehicle Care 299
Recommended replacement tire for Greenhouse Gas (GHG) emissions
Tire sizeTire makerTire name Rolling
resistance
LT215/85R16E BRIDGESTONE CORPORATION
Duravis R250 LRRA
THE YOKOHAMA RUBBER CO., LTD. TY213A MC2 LRRA
225/70R19.5F BRIDGESTONE CORPORATION
M895Z LRRA
THE YOKOHAMA RUBBER CO., LTD. TY287 MC2 LRRA
If the original equipment tires are
low rolling tires, it is recommended
to use the LRRA tires shown in the
above table.
Refer to the emission control
identifiers on Greenhouse Gas
(GHG) emission plate for your
original equipment tires. Also,
please refer to “VIN, Weight Rating,
and Greenhouse Gas (GHG)
Emissions Plate” for the location of
the Greenhouse Gas (GHG)
emission plate. See Vehicle
Identification Number (VIN) 0353. Wheel Replacement
Recommendations
Wheels must be replaced if they
become damaged (for example:
bent, heavily rusted, leak air) or if
wheel nuts often become loose. Do
not use bent wheels that have been
straightened and do not use inner
tubes in leaking wheels which are
designed for tubeless tires. Such
wheels may have structural damage
and could fail without warning.
When replacing wheels for any
reason, the new wheels should be
equal in load capacity, diameter, width, offset and mounting types to
those originally installed in your
vehicle.
A wheel of the wrong size or type
may adversely affect wheel and
bearing life, brake cooling,
speedometer/odometer calibration,
stopping ability, headlight aim,
bumper height, vehicle ground
clearance and tire or tire chain
clearance on the body and chassis.
Replacement with "used" wheels is
not advised. They may have been
subjected to harsh treatment or very
high mileage and could fail without
warning.

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
Customer Information 367
Roadside Assistance
Program
Call 1-888-899-1327. (Text
Telephone (TTY): 1-888-889-2438.)
Service is available 24 hours a day,
365 days a year.
Calling for Assistance
When calling Roadside Assistance,
have the following information
ready:
.Your name, home address, and
home telephone number.
. Telephone number of your
location.
. Location of the vehicle.
. Model, year, color, and license
plate number of the vehicle.
. Odometer reading, Vehicle
Identification Number (VIN), and
delivery date of the vehicle.
. Description of the problem.
Coverage
Services are provided for the
duration of the vehicle’s powertrain
warranty.
Anyone driving the vehicle is
covered.
Roadside Assistance is not a part of
the New Vehicle Limited Warranty.
General Motors North America and
Chevrolet reserve the right to make
any changes or discontinue the
Roadside Assistance program at
any time without notification.
General Motors North America and
Chevrolet reserve the right to limit
services or payment to an owner or
driver if they decide the claims are
made too often, or the same type of
claim is made many times.
Services Provided
.Emergency Tow from a Public
Road or Highway: Tow to the
nearest Chevrolet dealer for
warranty service, or if the vehicle
was in a crash and cannot be driven. Assistance is not given
when the vehicle is stuck in the
sand, mud, or snow.
Services Not Included in
Roadside Assistance
.
Impound towing caused by
violation of any laws.
. Legal fines.
. Mounting, dismounting,
or changing of snow tires,
chains, or other traction devices.
Service is not provided if a vehicle
is in an area that is not accessible
to the service vehicle or is not a
regularly traveled or maintained
public road, which includes ice and
winter roads. Off-road use is not
covered.
Scheduling Service
Appointments
When the vehicle requires warranty
service, contact your dealer and
request an appointment. By
scheduling a service appointment
and advising the service consultant

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
376 Index
FuelBiodiesel . . . . . . . . . . . . . . . . . . . . . 228
Cold Weather Operation . . . . . . 230
Diesel Engines . . . . . . . . . . . . . . . 227
Economy Driving . . . . . . . . . . . . . . . 24
Filling the Tank . . . . . . . . . . . . . . . 235
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Running out of Fuel . . . . . . . . . . . 233
Water in Fuel . . . . . . . . . . . . . . . . . 231
Fuel for Diesel Engines . . . . . . . . . 227
G
Gauges
Diesel Exhaust Fluid (DEF) . . . . . 72
Engine Coolant Temperature . . . 72
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Odometer . . . . . . . . . . . . . . . . . . . . . . . 70
Speedometer . . . . . . . . . . . . . . . . . . . 70
Tachometer . . . . . . . . . . . . . . . . . . . . . 71
Trip Odometer . . . . . . . . . . . . . . . . . . 70
Warning Lights andIndicators . . . . . . . . . . . . . . . . . . . . . 68
General Information Vehicle Care . . . . . . . . . . . . . . . . . . 240
Getting In and Out of the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 29 Glove Box . . . . . . . . . . . . . . . . . . . . . . . 55
GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . 366
H
Hazard Warning Flashers . . . . . . . . 94
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 277
Bulb Replacement . . . . . . . 277, 280
Daytime Running Lamps(DRL) Indicator Light . . . . . . . . . . 81
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 93
High-Beam On Light . . . . . . . . . . . . 81
High/Low Beam Changer . . . . . . . 93
Heated Mirrors . . . . . . . . . . . . . . . . . . . 34
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 172
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 131
High Idle System . . . . . . . . . . . . . . . 174
High-Beam On Light . . . . . . . . . . . . . 81
Hill and Mountain Roads . . . . . . . . 150
Hooks Shopping Bag . . . . . . . . . . . . . . . . . . 57
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
I
Idle Shutdown . . . . . . . . . . . . . . . . . . 174
Idle Shutdown Light . . . . . . . . . . . . . 80
Ignition Positions . . . . . . . . . . . . . . . 166
Information Publication Ordering . . . . . . . . . . 370
Information on Loading the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 58
Instrument Cluster . . . . . . . . . . . . . . . 69
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . 55
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 311
K
Keyless EntryRemote (RKE) System . . . . . . . . . 26
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
L
Lamps
Cargo . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Cornering . . . . . . . . . . . . . . . . . . . . . . . 95
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Exterior Controls . . . . . . . . . . . . . . . . 92
Interior . . . . . . . . . . . . . . . . . . . . . . . . 287

Chevrolet Low Cab Forward 5.2L Diesel Engine 4500/5500 Series (GMNA-
Localizing-U.S.-12407814) - 2019 - crc - 12/13/17
Index 377
Lamps (cont'd)License Plate . . . . . . . . . . . . . . . . . 286
Malfunction Indicator (Check
Engine) . . . . . . . . . . . . . . . . . . . . . . . 73
Roofmarker . . . . . . . . . . . . . . . . . . . 284
Sidemarker . . . . . . . . . . . . . . . . . . . 284
Lap Belt . . . . . . . . . . . . . . . . . . . . . . . . . 48
Lighting Illumination Control . . . . . . . . . . . . . 95
Lights Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . . . 76
Automatic Transmission Fluid Temperature . . . . . . . . . . . . . 78
Battery Warning . . . . . . . . . . . . . . . . 73
Brake System Warning . . . . . . . . . 74
Check Engine (Malfunction Indicator) . . . . . . . . . . . . . . . . . . . . . . 73
Cruise Control . . . . . . . . . . . . . . . . . . 82
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 81
Diesel Exhaust Fluid (DEF) . . . . . 80
Engine Oil Level Indicator . . . . . . 79
Engine Oil Pressure . . . . . . . . . . . . 79
Engine Shutdown Warning . . . . . 80
Exhaust Brake . . . . . . . . . . . . . . . . . . 77
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 93
High-Beam On . . . . . . . . . . . . . . . . . . 81 Lights (cont'd)
High/Low Beam Changer . . . . . . . 93
Idle Shutdown . . . . . . . . . . . . . . . . . . 80
Overdrive Off . . . . . . . . . . . . . . . . . . . 78
Reduced Engine Power . . . . . . . . 81
Seat Belt Reminders . . . . . . . . . . . . 72
Service Transmission
Warning . . . . . . . . . . . . . . . . . . . . . . . 77
Service Vehicle Soon . . . . . . . . . . . 74
Wait to Start . . . . . . . . . . . . . . . . . . . . 79
Loading the Vehicle . . . . . . . . . . . . . . 58
Locks Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Power Door . . . . . . . . . . . . . . . . . . . . . 33
M
Maintenance and CareAdditional . . . . . . . . . . . . . . . . . . . . . 346
Maintenance Schedule . . . . . . . . . 327
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 349
Malfunction Indicator Lamp . . . . . . 73
Messages Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 86
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Heated . . . . . . . . . . . . . . . . . . . . . . . . . 34
N
New Vehicle Break-In . . . . . . . . . . . 165
Noise Control System . . . . . . . . . . 272
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . . 70Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 245
Pressure Light . . . . . . . . . . . . . . . . . . 79
Online Owner Center . . . . . . . . . . . 365
Operating Temperature . . . . . . . . . 171
Outlets
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Overdrive Off . . . . . . . . . . . . . . . . . . . 215
Overdrive Off Light . . . . . . . . . . . . . . 78
Overheating, Engine . . . . . . . . . . . . 259
Owner Checks and Services . . . . 340
P
Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . . . 220
Over Things That Burn . . . . . . . 176
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Perchlorate Materials Requirements, California . . . . . . 240
