Fuse Description
F/INJN Fuel Injectors
PCM IGN Mass Air Flow (MAF) Sensor
Heated Oxygen Sensor #1 and #2
Evaporative Emissions (EVAP)
Canister Purge Solenoid Valve
ELEK IGN Electronic Ignition (EI)
Control Module
10 I/P Fuse Block
12 Passenger's Side Underhood
Electrical Center, IGN SYST Relay,
R/CMPT REL fuse, PCM BAT fuse
13 FAN CONT #1 Relay
Relay Description
14 FUEL PUMP
15 A/C CMPR
16 FAN CONT #2
-- Secondary
Cooling Fan (Passenger's Side)
17 FAN CONT #1
-- Primary Cooling
Fan (Driver's Side)
18 IGN SYSTUnderhood Electrical Center
-- Driver's Side

yellowblue
6-62
Fuse Description
FAN #3 FAN #3 Relay
PARK LPS Headlamp Switch
HORN Horn Relay
ABS Anti
-Lock Brake System
11 Circuit Breaker C, Starter Relay,
STR WHL Control # 2,
Power Accessory #2, and
Theft
-Deterrent RelayFuse Description
12 HD LPS
-- Circuit Breaker to
Headlamp Switch
13 ABS
-- ABS Relay
Relay Description
14 ABS
-- Anti-Lock Brake System
15 FAN #3
-- Secondary Cooling Fan
(Passenger's Side)
16 HORN
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-Up 3156 or 3057. . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp 891T2. . . . . . . . . . .
Front Parking/Turn Signal 3357NA. . . . . . . . . . . . . . .
Headlamp, High
-Beam 9005. . . . . . . . . . . . . . . . . . .
Headlamp, Low
-Beam 9006. . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb Number
Dome 10230955. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
Chevrolet dealer service department.

yellowblue
6-63
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
4T60E:
Automatic Transaxle
Pan Removal and Replacement 7.0 quarts (6.7 L). . .
After Complete Overhaul 9.6 quarts (9.2 L). . . . . . . .
4T65E:
Automatic Transaxle
Pan Removal and Replacement 7.4 quarts (7.0 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
When draining/replacing converter, more fluid will
be needed.
Cooling System Including Reservoir
3100 (Code M) V6 11.6 quarts (10.9 L). . . . . . . . . . . .
3800 (Code K) V6 11.7 quarts (11.0 L). . . . . . . . . . . . Refrigerant (R
-134a),
Air Conditioning*1.88 lbs. (0.85 kg) . . . . . . . . . . . .
Engine Crankcase
- Oil and
Filter Change
3100 (Code M) V6 4.5 quarts (4.3 L). . . . . . . . . . . . .
3800 (Code K) V6 4.5 quarts (4.3 L). . . . . . . . . . . . .
Fuel Tank
3100 (Code M) V6 16.6 gallons (62.8 L). . . . . . . . . . .
3800 (Code K) V6 16.6 gallons (62.8 L). . . . . . . . . . .
*See ªAir Conditioning Refrigerantsº later in
this section.
Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.

yellowblue
6-64 Engine Specifications
3100 (Code M) V6 3800 (Code K) V6. . . . . . . . . . . . . . . . . . . . . .
Type V6 V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID 231 CID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compression Ratio 9.6:1 9.25:1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-61-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) 195
F (91
C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 160 @ 5200 200 @ 5200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
6-65
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
All Engines A1208C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery
3100 (Code M) V6 600 CCA. . . . . . . . . . . . . . . . . .
3800 (Code K) V6 690 CCA. . . . . . . . . . . . . . . . . . .
Engine Oil Filter
3100 (Code M) V6 PF47. . . . . . . . . . . . . . . . . . . . .
3800 (Code K) V6 PF47. . . . . . . . . . . . . . . . . . . . . .
PCV Valve
3100 (Code M) V6 CV892C. . . . . . . . . . . . . . . . . . . . Radiator Cap
All Engines RC27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plugs
3100 (Code M) V6 AC Type 41
-940 . . . . . . . . . . . . . .
Gap: 0.060 inches (.152 cm)
3800 (Code K) V6 AC Type 41
-921 . . . . . . . . . . . . . .
Gap: 0.060 inches (1.52 cm)
Windshield Wiper
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Type hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 107.5 inches (273.0 cm). . . . . . . . . . . . . .
Tread Width (Front) 59.5 inches (151.2 cm). . . . . . . .
Tread Width (Rear) 59.1 inches (150.0 cm). . . . . . . .
Length 200.9 inches (510.4 cm). . . . . . . . . . . . . . . . .
Width 72.5 inches (184.1 cm). . . . . . . . . . . . . . . . . . .
Height 54.8 inches (139.2 cm). . . . . . . . . . . . . . . . . . .

yellowblue
6-66
-NOTES

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance
7
-13 Part B: Owner Checks and Services7
-17 Part C: Periodic Maintenance Inspections
7
-19 Part D: Recommended Fluids and Lubricants
7
-20 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.

yellowblue
7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you are skilled enough to do some work on your
vehicle, you will probably want to get the service
information. See ªService and Owner Publicationsº in
the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains what
you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº
explains important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº
lists some recommended products to help keep your
vehicle properly maintained. These products, or their
equivalents, should be used whether you do the work
yourself or have it done.
ªPart E: Maintenance Recordº provides a place
for you to record the maintenance performed on your
vehicle. Whenever any maintenance is performed, be
sure to write it down in this part. This will help you
determine when your next maintenance should be done.
In addition, it is a good idea to keep your maintenance
receipts. They may be needed to qualify your vehicle for
warranty repairs.

yellowblue
7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries. Or you
may drive it to work, to do errands or in many
other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.
The proper fluids and lubricants to use are listed in Part
D. Make sure whoever services your vehicle uses these.
All parts should be replaced and all necessary repairs
done before you or anyone else drives the vehicle.
This schedule is for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.
