spare wheel CHEVROLET LUMINA 1999 2.G Owners Manual

yellowblue
5-26
To remove a center cap, use the wrench to pry gently at
the notch. Don't use a tool that is narrower than the
wrench to pry at this notch.
If your vehicle has wheel nut caps, remove them using
the wheel wrench.
Removing the Flat Tire and Installing the
Spare Tire
1. Using the wheel wrench, loosen all the wheel nuts.
Don't remove them yet.
2. Turn the jack handle clockwise to raise the jack lift
head a few inches.

yellowblue
5-29
5. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground for the spare tire to fit under the vehicle.
6. Remove all wheel nuts and take off the flat tire.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces and
spare wheel.
8. Install the spare tire.
CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could come
off and cause an accident. When you change a
wheel, remove any rust or dirt from the places
where the wheel attaches to the vehicle. In an
emergency, you can use a cloth or a paper towel
to do this; but be sure to use a scraper or wire
brush later, if you need to, to get all the rust or
dirt off.

yellowblue
5-31
11. Tighten the wheel nuts
firmly in a crisscross
sequence as shown.
CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to become loose
and even come off. This could lead to an accident.
Be sure to use the correct wheel nuts. If you have
to replace them, be sure to get new GM original
equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to
100 lb
-ft (140 N´m).
NOTICE:
Improperly tightened wheel nuts can lead to
brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specification.
Don't try to put a wheel cover on your compact spare
tire. It won't fit. Store the wheel cover in the trunk until
you have the flat tire repaired or replaced.
NOTICE:
Wheel covers won't fit on your compact spare.
If you try to put a wheel cover on your compact
spare, you could damage the cover or the spare.

yellowblue
5-32 Storing the Flat Tire and Tools
CAUTION:
Storing a jack, a tire or other equipment in the
passenger compartment of the vehicle could
cause injury. In a sudden stop or collision, loose
equipment could strike someone. Store all these
in the proper place.
After you've put the compact spare tire on your vehicle,
you'll need to store the flat tire in your trunk. Use the
following procedure to secure the flat tire in the trunk.
Put the flat tire in the trunk so the side that faces out
when it is on the vehicle is facing down. The full
-size
tire will not fit down into the well. Place it so the front is
in the well and the rear is out of the well.
Put the bolt through one of the wheel nut holes, install
the retainer over the bolt, then install the wing nut. Put
the spacer and nut next to the tire in the well. Store the
cover as far forward as possible.
The compact spare is for temporary use only. Replace
the compact spare tire with a full
-size tire as soon as you
can. See ªCompact Spareº in the Index. See the storage
instructions label to replace your compact spare into
your trunk properly.
When you install the wheel cover on the full
-size tire,
tighten the nut caps to 5 lb
-ft (7 N´m).

yellowblue
5-34
Compact Spare Tire
Although the compact spare tire was fully inflated when
your vehicle was new, it can lose air after a time.
Check the inflation pressure regularly. It should be
60 psi (420 kPa).
After installing the compact spare on your vehicle, you
should stop as soon as possible and make sure your spare
tire is correctly inflated. The compact spare is made to
perform well at speeds up to 65 mph (105 km/h) for
distances up to 3,000 miles (5 000 km), so you can finish
your trip and have your full
-size tire repaired or replaced
where you want. Of course, it's best to replace your spare
with a full
-size tire as soon as you can. Your spare will last
longer and be in good shape in case you need it again.
NOTICE:
When the compact spare is installed, don't take
your vehicle through an automatic car wash with
guide rails. The compact spare can get caught on
the rails. That can damage the tire and wheel,
and maybe other parts of your vehicle.
Don't use your compact spare on other vehicles.
And don't mix your compact spare tire or wheel with
other wheels or tires. They won't fit. Keep your spare
tire and its wheel together.
NOTICE:
Tire chains won't fit your compact spare. Using
them can damage your vehicle and can damage
the chains too. Don't use tire chains on your
compact spare.

yellowblue
6-41 Tire Inspection and Rotation
Tires should be rotated every 6,000 to 8,000 miles
(10 000 to 13 000 km). Any time you notice unusual
wear, rotate your tires as soon as possible and check
wheel alignment. Also check for damaged tires or
wheels. See ªWhen It's Time for New Tiresº and
ªWheel Replacementº later in this section for
more information.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The first
rotation is the most important. See ªScheduled
Maintenance Servicesº in the Index for scheduled
rotation intervals.
When rotating your tires, always use the correct rotation
pattern shown here.
Don't include the compact spare tire in your
tire rotation.
After the tires have been rotated, adjust the front and
rear inflation pressures as shown on the Tire
-Loading
Information label. Make certain that all wheel nuts
are properly tightened. See ªWheel Nut Torqueº in
the Index.
CAUTION:
Rust or dirt on a wheel, or on the parts to which
it is fastened, can make wheel nuts become loose
after a time. The wheel could come off and cause
an accident. When you change a wheel, remove
any rust or dirt from places where the wheel
attaches to the vehicle. In an emergency, you can
use a cloth or a paper towel to do this; but be
sure to use a scraper or wire brush later, if you
need to, to get all the rust or dirt off. (See
ªChanging a Flat Tireº in the Index.)

yellowblue
6-43
CAUTION:
Mixing tires could cause you to lose control while
driving. If you mix tires of different sizes or types
(radial and bias
-belted tires), the vehicle may not
handle properly, and you could have a crash.
Using tires of different sizes may also cause
damage to your vehicle. Be sure to use the same
size and type tires on all wheels.
It's all right to drive with your compact spare,
though. It was developed for use on your vehicle.
CAUTION:
If you use bias-ply tires on your vehicle, the
wheel rim flanges could develop cracks after
many miles of driving. A tire and/or wheel could
fail suddenly, causing a crash. Use only radial
-ply
tires with the wheels on your vehicle.
Uniform Tire Quality Grading
The following information relates to the system
developed by the United States National Highway
Traffic Safety Administration, which grades tires by
treadwear, traction and temperature performance. (This
applies only to vehicles sold in the United States.) The
grades are molded on the sidewalls of most passenger
car tires. The Uniform Tire Quality Grading system does
not apply to deep tread, winter
-type snow tires,
space
-saver or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches (25 to 30 cm),
or to some limited
-production tires.
While the tires available on General Motors passenger
cars and light trucks may vary with respect to these
grades, they must also conform to Federal safety
requirements and additional General Motors Tire
Performance Criteria (TPC) standards.

yellowblue
9-3
Cleaning 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Protection 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass Surfaces 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-47 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-49 . . . . . . . . . . . . . . . . . . . . .
Leather 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-50 . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, for Systems with Automatic Tone Control,
Setting the 3
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, for Systems without Automatic Tone Control,
Setting the 3
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player
Care 3
-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Errors 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Spare Tire 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Console Storage 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience Net 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Convex Outside Mirror 2
-40 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bleed Valves 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When Trailer Towing 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Lamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholders 2-40, 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance
for Text Telephone Users 8
-4 . . . . . . . . . . . . . . . . . . . . . . . .
Information 8-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Offices 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
Damage
Finish 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sheet Metal 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 2-36 . . . . . . . . . . . . . . . . . . . . . . . . .
Dead Battery 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defects, Reporting Safety 8-10 . . . . . . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-10
Shifting
Automatic Transaxle 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . .
Into Park (P) 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of Park 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shoulder Belt Height Adjuster 1-14 . . . . . . . . . . . . . . . . . . . . .
Signaling Turns 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding 3-20 . . . . . . . . . . . . . . . . . . . . . . . .
Spare Tire .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact 5
-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing the Flat Tire and Installing the
Spare Tire 5
-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications and Capacities 6-63 . . . . . . . . . . . . . . . . . . . . . .
Specifications, Engine 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . . .
Speedometer 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains, Cleaning 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starter Switch Check 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your V6 Engine 2-15, 2-16 . . . . . . . . . . . . . . . . . . . .
Steam 5-10, 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel, Tilt 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage, Vehicle 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-35 . . . . . . . . . . . . . . . . . .
Sun Visors 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sunroof 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle viii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamp Bulb Replacement 6-36 . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The Instrument Panel 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft 2-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft-Deterrent Feature 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . .
THEFTLOCK
3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt Wheel 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Time, Setting the 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Chains 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Loading 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information Label 4-31 . . . . . . . . . . . . . . . . . . .
Tires 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance 6-45 . . . . . . . . . . . . . . . . . . . . . . . .
Buying New 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Spare 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation Check 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Rotation 6-41 . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing the Spare Tire and Tools 5-24 . . . . . . . . . . . . . . .
Storing the Flat Tire and Tools 5-32 . . . . . . . . . . . . . . . . . . .
Storing the Spare Tire and Tools 5-33 . . . . . . . . . . . . . . . . .
Temperature 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
