CHEVROLET MALIBU 2001 5.G Owners Manual

3-30
Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position, select
the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set all
tone and speaker controls to the middle position, press
and hold the P
-TYPE LIST/AUDIO knob when no tone
or speaker control is active. The radio will produce one
beep and display ALL with the level display in the
middle position.
FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers and
counterclockwise to move the sound to the rear
speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the fade to the middle position, select thecontrol and press and hold the P
-TYPE LIST/AUDIO
knob. The radio will produce one beep and set the
display level to the middle position. To set all tone and
speaker controls to the middle position, press and hold
the P
-TYPE LIST/AUDIO knob when no tone or
speaker control is active. The radio will produce one
beep and display ALL with the level display in the
middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS, the radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.

3-31
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information is
available. In rare cases, a radio station may broadcast
incorrect information that will cause the radio features
to work improperly. If this happens, please contact the
radio station.
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.
DISP: Press this knob to change what appears on the
display while using RDS. The display options are station
name, station frequency, PTY and the name of the
program (if available). Press and hold the display knob
to set the default display of the RDS station from the
displays available.Accessing RDS Stations:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST/AUDIO knob to display the program type list.
2. Turn the knob either clockwise or counterclockwise
to select a program type. The list is alphabetical. If
you select ANY TYPE your radio will seek to the
first PTY available.
3. Push the SEEK TYPE button to activate search.
TRAF: Press this button to receive traffic
announcements. If the current tuned station does not
broadcast traffic announcements, the radio will seek to a
station that does. The traf icon will flash on the display.
When the radio finds a station that broadcasts traffic
announcements, it will stop. If no station is found, NO
TRAF will appear on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette tape,
CD or FM radio by enabling the traffic interrupt feature.
Press the TRAF button once to seek to an RDS station
that supports the traffic interrupt feature if the current
tuned station does not. The traf icon will flash on the
display when seeking for a station that supports traffic
interrupt. When the traffic interrupt feature is on, TRAF
will appear on the display.

3-32
When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or a
cassette tape or compact disc is playing. The traf icon
and TRAFFIC will appear on the display while the
traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.
VOL: Turn this knob clockwise to increase volume
when RDS interrupts regular play. Turn it
counterclockwise to decrease volume.
INFO: If the current station has a message, INFO will
appear on the display. These text messages are from the
RDS broadcaster to the listening public and may be
general information such as artist and song title, call in
phone numbers, etc. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To scroll
through the message at your own speed press the INFO
button again for less than one second. A new group of
words will appear on the display. Once the complete
message has been displayed, INFO will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to.P-TYPE LIST/AUDIO: Turn this knob clockwise or
counterclockwise to select the Program Type (PTY) you
want to listen to. TYPE and a PTY will appear on the
display. Press the SEEK TYPE button and the radio will
seek to the first RDS broadcaster of the selected PTY.
If the radio cannot find the desired PTY, NONE will
appear on the display and the radio will return to the last
station you were listening to.
SEEK TYPE: Press this button to go to a station with
the last selected PTY. TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a cassette
tape or compact disc is playing. If the cassette tape or
compact disc player is playing, play will stop for the
announcement and resume when the announcement
is finished.

3-33
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
ALTERNATE FREQUENCY: This RDS feature
allows the radio to switch frequencies to the best quality
station with the same programming. Alternate frequency
is off by default from the factory. Press and hold AM
FM for two seconds to turn alternate frequency on or
off. AF ON or AF OFF will appear on the display and
the radio will beep once. The radio will not switch to
other stations when alternate frequency is off.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off, the
tape can be inserted and will begin playing. A tape
symbol is shown on the display whenever a tape is
inserted. If you hear nothing but a garbled sound, the
tape may not be in squarely. Press EJT to remove the
tape and start over.While the tape is playing, use the VOL, P-TYPE
LIST/AUDIO and SEEK controls just as you do for the
radio. The display will show TAPE and an arrow
showing which side of the tape is playing.
If you want to insert a tape when the ignition is off, first
press EJT or DISP.
If CHK TAPE appears on the radio display, the tape
won't play because of an error.
CHK TAPE may be displayed when the tape is tight and
the player can't turn the tape hubs. Remove the tape.
Hold the tape with the open end down and try to turn the
right hub counterclockwise with a pencil. Turn the tape
over and repeat. If the hubs do not turn easily, your
tape may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.
CHK TAPE may be displayed when the tape is broken.
Try a new tape.
CHK TAPE may be displayed when the tape is wrapped
around the tape head. Attempt to get the cassette out.
Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.

3-34
PREV (1): Press this button or the left SEEK arrow to
go to the previous selection on the tape if the selection
has been playing for less than three seconds. If the
PREV button or the left SEEK arrow is pressed and
the current selection has been playing for more than
13 seconds, it will go to the beginning of the current
selection. If the PREV button or the left SEEK arrow is
pressed and the current selection has been playing from
three to 13 seconds, it will go to the beginning of the
previous selection or the beginning of the current
selection, depending on the position on the tape. SEEK
and a ª
-1º will appear on the display while the cassette
player is in PREV mode. If PREV or the left SEEK
arrow is pressed additional times or held, the radio will
go to displayed number of previous selections up to ª9º.
SEEK and a negative number will appear on the display.
Your tape must have at least three seconds of silence
between each selection for PREV to work. The sound
will mute while seeking.
NEXT (2): Press this button to go to the next selection
on the tape. If you press the button more than once, the
player will continue moving forward through the tape.
SEEK and a positive number will appear on the display.
Your tape must have at least three seconds of silence
between each selection for NEXT to work. To forward
through each selection press the right SEEK arrow.
The sound will mute while seeking.REV (3): Press this button to reverse the tape rapidly.
Press it again to return to playing speed. The radio will
play the last selected station while the tape reverses. The
station frequency and REV will appear on the display.
You may select stations during REV operation by using
the TUNE, SEEK and the P SCAN controls.
FWD (4): Press this button to advance quickly to
another part of the tape. Press the button again to return
to playing speed. The radio will play the last selected
station while the tape advances. The station frequency
and FWD will appear on the display. You may select
stations during FWD operation by using the TUNE,
SEEK and the P SCAN controls.
SIDE (5): Press this button to play the other side of
the tape. TAPE and an up or down arrow will appear on
the display.

(6): Press this button to reduce background noise.
NR ON will appear on the display. Press it again to turn
Dolby off. NR OFF will appear on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.

3-35
SEEK: SEEK (right arrow) is the same as NEXT,
and SEEK (left arrow) is the same as PREV. If the
button is held or pressed more than once, the player will
continue moving forward or backward through the tape.
SEEK and a positive or negative number will appear on
the display.
AM FM: Press this button to play the radio when
a tape is in the player. The tape will stop but remain in
the player.
TAPE CD: With a tape in the player and the radio
playing, press this button to play a tape. Press AM FM
to return to the radio when a tape is playing. Press TAPE
CD to switch between the tape and compact disc if both
are loaded. The inactive tape or CD will remain safely
inside the radio for future listening.
EJT: Press this button located next to the cassette
slot to remove a tape. The radio will play. EJT may be
activated with the radio off. Cassette tapes may be
loaded with the radio off if this button is pressed first.CLEAN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the cassette eject button for
five seconds to reset the CLEAN indicator. The radio
display will display CLEANED to show the indicator
was reset.
Tight/Loose Tape Sensor Defeat
With the radio off and the ignition on, press and hold the
TAPE CD button to disable the tight/loose tape sensing
feature to enable play of some tape head cleaners and
portable CD adapters. The radio will display READY
and flash the cassette icon. The tight/loose tape sensing
feature will then be disabled until the next time a
cassette is ejected.

3-36
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. The disc should begin playing.
The display will show the CD symbol. If you want to
insert a compact disc with the ignition off, first press
DISP or EJT.
If you're driving on a very rough road or if it's very hot,
the disc may not play and CHECK CD may appear on
the display. When the road becomes smooth or the
temperature returns to normal, the disc should play. If
the disc comes out, it could be one of the following:

The disc is upside down.

It is dirty, scratched or wet.

It is very humid. (If so, wait about an hour and
try again.)
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.
PREV (1): Press this button or the left SEEK arrow to
go to the previous track if the current selection has been
playing for less than eight seconds. If the PREV button
or the left SEEK arrow is pressed and the current
selection has been playing for more than eight seconds,
it will go to the beginning of the current selection.TRACK and the track number will appear on the
display. If you hold the button or press it more than
once, the player will continue moving back through the
disc. The sound will mute while seeking.
NEXT (2): Press this button or the right SEEK arrow to
go to the next track. TRACK and the track number will
appear on the display. If you hold the button or the right
SEEK arrow, or press it more than once, the player will
continue moving forward through the disc. The sound
will mute while seeking.
REV (3): Press and hold this button to reverse quickly
within a track. Press and hold this button for less than
two seconds to reverse at six times the normal playing
speed. Press and hold it for more than two seconds to
reverse at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.
FWD (4): Press and hold this button to advance quickly
within a track. Press and hold this button for less than
two seconds to advance at six times the normal playing
speed. Press and hold it for more than two seconds to
advance at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.

3-37
RDM (6): Press this button to hear the tracks in random,
rather than sequential, order. RDM ON will show on the
display. RDM T and the track number will appear on
the display when each track starts to play. Press RDM
again to turn off random play. RDM OFF will appear on
the display.
SEEK: Press the SEEK (left arrow) button to go to the
start of the current or previous track. Press the SEEK
(right arrow) button to go to the start of the next track.
If either of the SEEK buttons is held or pressed more
then once, the player will continue moving backward or
forward through the CD.
DISP: Press this button to see how long the current
track has been playing. ET and the elapsed time will
appear on the display. To change what is normally
shown on the display (track or elapsed time), press the
button until you see the display you want, then hold
the button for two seconds. The radio will produce
one beep.AM FM: Press this button to play the radio when
a disc is in the player. The disc will stop but remain in
the player.
TAPE CD: With a CD in the player and the radio
playing, press this button to play a CD. Press AM FM to
return to the radio when a CD is playing. Press TAPE CD
to switch between the tape and compact disc if both are
loaded. The inactive tape or CD will remain safely inside
the radio for future listening.
EJT: Press this button located below the CD slot
to remove the disc. The radio will play. EJT may be
activated with either the ignition or radio off. CDs may
be loaded with the radio and ignition off if this button is
pressed first.
CAL ERR: This message is displayed when the radio
has not been calibrated properly for the vehicle. You
must return to the dealership for service.
LOCKED: This message is displayed when the
THEFTLOCK

system has locked up. You must
return to the dealership for service.

3-38 Personal Choice Radio Controls
(If Equipped)
With this feature, your vehicle will recall the latest radio
settings as adjusted the last time your vehicle was
operated. This feature allows two different drivers to
store and recall their own radio settings for AM and FM
presets, last tuned station, volume, tone and audio
source (radio, cassette or CD). The settings recalled by
the radio are determined by which transmitter was used
to enter the vehicle. After the UNLOCK button is
pressed on the transmitter and the ignition is in RUN,
the radio settings will automatically adjust to where they
were last set by the identified driver. All vehicles are
shipped with this feature on. This feature can be
disabled by your dealer if desired.
Theft-Deterrent Feature Non-RDS Radios
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOC will be displayed.
With THEFTLOCK activated, your radio will not
operate if stolen.
Theft-Deterrent Feature RDS Radios
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOCKED will be displayed.
When the radio and vehicle are turned off, the blinking
red light indicates that THEFTLOCK is armed.
With THEFTLOCK activated, your radio will not
operate if stolen.

3-39 Understanding Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km). Tall
buildings or hills can interfere with FM signals, causing
the sound to come and go.
Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be loud
and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.To help avoid hearing loss or damage:

Adjust the volume control to the lowest setting.

Increase volume slowly until you hear comfortably
and clearly.
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Delco Electronics
radio or other systems, and even damage them.
Your vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.
