CHEVROLET OPTRA 2004 1.G Owners Manual

Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical
size and rating.
There are spare fuses provided in the engine
compartment fuse block. If you ever have a problem on
the road and do not have a spare fuse, you can borrow
one that has the same amperage. Just pick a feature of
your vehicle that you can get along without — like the
radio or cigarette lighter — and use its fuse, if it is the
correct amperage. Replace it as soon as you can.
There are two fuse blocks in your vehicle: the instrument
panel fuse block and the engine compartment fuse block.
There is a fuse puller located on the engine
compartment fuse block. It can be used to easily
remove fuses from the fuse block.
Instrument Panel Fuse Block
The instrument panel fuse block is located on the end of
the instrument panel, on the driver’s side of the
vehicle. To access the fuses, open the fuse panel door
by pulling out.
To reinstall the door, insert the tabs at the back end
first, then push the door into the instrument panel
to secure it.Sedan shown, Hatchback similar
5-83

5-84

Fuses Usage
AIR BAG Air Bag
WPR Wiper
RADIO/CLK Radio/Clock
ECM Engine Control Module
BLANK Not Used
AUX LTR Extra Jack
TRN SIG
LAMPSTurn Signal Lamps
ABS, CRUISEAnti-lock Brake System, Cruise
Control System
LTR Cigarette Lighter
CLSTRCluster, Brake Transmission Shift
Interlock/Automatic Transaxle Shift
Lock (BTSI) Solenoid
BLANK Not Used
BCK/UP Back-upFuses Usage
BLANK Not Used
TCM Transmission Control Module
CRUISE
SWITCHCruise Switch (Contact Coil)
ENG FUSE
BOX, DRLEngine Fuse Box, Daytime Running
Lamps
HAZRD LAMPS Hazard Lamps
AUTO A/C A/C Switch, Clock
HVACHeating, Ventilation and Air
Conditioning
RKE Remote Keyless Entry
RADIO Radio
S/ROOF Sunroof
DLC Data Link Connector
BLANK Not Used
5-85

Engine Compartment Fuse BlockThe engine compartment fuse block is located on the
driver’s side of the vehicle, near the battery. SeeEngine
Compartment Overview on page 5-12for more
information on location. To access the fuses, press in
the top flap to release the cover.
To reinstall the cover, push the cover until it is secure.
5-86

5-87

Fuses Usage
HEAD LAMPS Headlamps
ECM Engine Control Module
IGN COIL Ignition Coil
I/P FUSE Instrument Panel Fuse
FUEL PUMP Fuel Pump
A/C Air Conditioning
HORN Horn
HI BEAM Headlamp High-Beam
DRIVER’S
PWR WNDWDriver’s Power Window
STOP LAMPS Stoplamps
DR/LCK Door Lock
MIR HTD Heated Mirror
FRT FOG Front Fog
ILLUM LTLicense Plate Lamp, Parking
Lamp Left
INJ Injector
ENG SNSREvaporative Emission (EVAP)
Canister Purge Solenoid, Heated
Oxygen Sensor (HO2S), Cooling Fan
Relay, CMP SensorFuses Usage
LOW BEAM LT Headlamp Low-Beam Left
ILLUM RTIllumination Circuit, Parking Lamp
Right
LOW BEAM RT Headlamp Low-Beam Right
SPARE Spare
SPARE Spare
SPARE Spare
BATT PWR Battery Power
ABS Anti-lock Brake System
HVAC BLWR HVAC Blower
IGN 2 Ignition 2
IGN 1 Ignition 1
FUSE PLR Fuse Puller
COOL FAN
LOWCooling Fan Low
DEFOG Defog
COOL FAN HI Cooling Fan High
PWR WNDW Power Window
5-88

Relays Usage
COOL FAN
LOWCooling Fan Low
FRT FOG Front Fog
ILLUM Illumination Relay
A/C CMPRSR Air Conditioning Compressor
HORN Horn
DEFOG DefogRelays Usage
FUEL PUMP Fuel Pump
MAIN Main Relay
COOL FAN HI Cooling Fan High
PWR WNDW Power Window
HEAD LAMPS Headlamp Relay
5-89

Capacities and Specications
The following approximate capacities are given in English and metric conversions. Please refer toPart D:
Recommended Fluids and Lubricants on page 6-24for more information.
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134a 1.41 lbs 0.64 kg
Brake/Clutch Fluid 0.53 quarts 0.5 L
Cooling System 7.9 quarts 7.5 L
Engine Oil with Filter 4.2 quarts 4.0 L
Fuel Tank 14.5 gallons 55 L
Power Steering Fluid 1.2 quarts 1.1 L
Transaxle, Automatic
Complete Overhaul 7.1–7.5 quarts 6.7–7.1 L
Transaxle, Manual
Complete Drain and Refill 1.9 quarts 1.8 L
Wheel Nut Torque 81 lb ft 110Y
All capacities are approximate. When adding, be sure to fill to the appropriate level, as recommended in this
manual.
Engine Specications
Engine VIN Code Transaxle Spark Plug Gap
2.0L L4 (L34) ZAutomatic and
Manual0.039 inch (1.0 mm)
5-90

Normal Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part Number
Engine Air Cleaner/Filter 96553450
Engine Oil Filter96458873
Spark Plugs93742299
Windshield Wiper Blades (Shepherd’s Hook Type)
Driver’s Side96205561
Passenger’s Side96227855
5-91

✍NOTES
