Page 311 of 370
Normal Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part GM Part Number ACDelco®Part Number
Engine Air Cleaner/Filter 96553450 —
Engine Oil Filter 96395221 —
Fuel Filter 96335719 —
A/C Filter 96554378 —
Spark Plugs 93742299 —
Windshield Wiper Blades (Hook Type)
Driver’s Side 96478670 —
Passenger’s Side 96498696 —
Rear 96341429 —
5-89
Page 320 of 370
18,000 Miles (30 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
21,000 Miles (35 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
24,000 Miles (40 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +)
27,000 Miles (45 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
30,000 Miles (50 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you
drive regularly under dusty conditions, the filter
may require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Inspect drive belt(s).
❑Inspect timing belt.
❑Drain, flush, and refill cooling system. This service
can be complex; you should have your dealer
perform this service. SeeEngine Coolant on
page 5-20for what to use. Inspect hoses. Clean
radiator, condenser, pressure cap, and neck.
Pressure test the cooling system and pressure cap.
An Emission Control Service.
6-8
Page 322 of 370
48,000 Miles (80 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
51,000 Miles (85 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
54,000 Miles (90 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
57,000 Miles (95 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
60,000 Miles (100 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you
drive regularly under dusty conditions, the filter
may require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Replace spark plug wires.An Emission Control
Service.
❑Inspect drive belt(s).
❑Replace timing belt.
❑Drain, flush, and refill cooling system. This service
can be complex; you should have your dealer
perform this service. SeeEngine Coolant on
page 5-20for what to use. Inspect hoses. Clean
radiator, condenser, pressure cap, and neck.
Pressure test the cooling system and pressure cap.
An Emission Control Service.
6-10
Page 324 of 370
78,000 Miles (130 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
81,000 Miles (135 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
84,000 Miles (140 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
87,000 Miles (145 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
90,000 Miles (150 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 3 months, whichever
occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you
drive regularly under dusty conditions, the filter
may require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Replace fuel filter.An Emission Control Service.
(See footnote †.)
❑Inspect drive belt(s).
❑Inspect timing belt.
❑Drain, flush, and refill cooling system. This service
can be complex; you should have your dealer
perform this service. SeeEngine Coolant on
page 5-20for what to use. Inspect hoses. Clean
radiator, condenser, pressure cap, and neck.
Pressure test the cooling system and pressure cap.
An Emission Control Service.
6-12
Page 326 of 370
7,500 Miles (12 500 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation
on page 5-57for proper rotation pattern and
additional information.(See footnote +.)
15,000 Miles (25 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you drive
regularly under dusty conditions, the filter may
require replacement more often.
❑Inspect engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Inspect drive belt(s).
22,500 Miles (37 500 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation
on page 5-57for proper rotation pattern and
additional information.(See footnote +.)
30,000 Miles (50 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you drive
regularly under dusty conditions, the filter may
require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Inspect drive belt(s).
6-14
Page 328 of 370
60,000 Miles (100 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you drive
regularly under dusty conditions, the filter may
require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Replace spark plug wires.An Emission Control
Service.
❑Inspect drive belt(s).
❑Replace timing belt.
❑Drain, flush, and refill cooling system. This service
can be complex; you should have your dealer
perform this service. SeeEngine Coolant on
page 5-20for what to use. Inspect hoses. Clean
radiator, condenser, pressure cap, and neck.
Pressure test the cooling system and pressure cap.
An Emission Control Service.
❑Inspect EVAP canister and vapor lines. Replace
EVAP vent solenoid valve.An Emission Control
Service. (See footnote †.)❑Inspect PCV system.An Emission Control Service.
(See footnote †.)
❑Change brake/clutch fluid (or every 24 months,
whichever occurs first).
67,500 Miles (112 500 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation
on page 5-57for proper rotation pattern and
additional information.(See footnote +.)
75,000 Miles (125 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you drive
regularly under dusty conditions, the filter may
require replacement more often.
❑Inspect engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Inspect drive belt(s).
6-16
Page 329 of 370
82,500 Miles (137 500 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation
on page 5-57for proper rotation pattern and
additional information.(See footnote +.)
90,000 Miles (150 000 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Replace passenger compartment air filter. If you drive
regularly under dusty conditions, the filter may
require replacement more often.
❑Replace engine air cleaner filter. SeeEngine Air
Cleaner/Filter on page 5-17for more information.
❑Rotate tires. SeeTire Inspection and Rotation on
page 5-57for proper rotation pattern and additional
information.(See footnote +.)
❑Replace spark plugs.An Emission Control Service.
❑Replace fuel filter.An Emission Control Service.
(See footnote †.)
❑Inspect drive belt(s).
❑Inspect timing belt.❑Drain, flush, and refill cooling system. This service
can be complex; you should have your dealer
perform this service. SeeEngine Coolant on
page 5-20for what to use. Inspect hoses. Clean
radiator, condenser, pressure cap, and neck.
Pressure test the cooling system and pressure cap.
An Emission Control Service.
❑Inspect EVAP canister, vapor lines and EVAP vent
solenoid valve.An Emission Control Service. (See
footnote †.)
❑Inspect PCV system.An Emission Control Service.
(See footnote †.)
❑Change brake/clutch fluid (or every 24 months,
whichever occurs first).
97,500 Miles (162 500 km)
❑Change engine oil and filter and replace engine oil
pan drain plug washer (or every 12 months,
whichever occurs first).An Emission Control Service.
❑Rotate tires. SeeTire Inspection and Rotation
on page 5-57for proper rotation pattern and
additional information.(See footnote +.)
6-17
