Page 301 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-79
The eight-wire harness contains the following
trailer circuits:
Yellow: Left Stop/Turn Signal
Dark Green: Right Stop/Turn Signal
Brown: Taillamps
White: Ground
Light Green: Back
-up Lamps


Page 302 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-80
If your vehicle is equipped with the ªHeavy-Duty
Traileringº option, please refer to ªHeavy
-Duty Trailer
Wiring Packageº, earlier in this section.
When the camper
-wiring harness is ordered

Page 303 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-81 Auxiliary Battery (If Equipped)
The auxiliary battery provision can be used to supply
electrical power to additional equipment that you may
choose to add, such as a slide
-in camper.
If your vehi

Page 304 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-82 Power Take-Off (PTO) (If Equipped)
NOTICE:
If you have a PTO that will exceed 35 hp installed on
your vehicle, it could damage the transfer case or
transmission. When having a PTO installed on y

Page 305 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-83
Using PTO speed control in Preset Mode
(Factory Setting):
1. Engage the PTO.
2. Select PARK (P) or NEUTRAL (N) range.
Apply the parking brake in NEUTRAL (N) is
selected. Torque Converter Clutch

Page 306 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 4-84
Variable Mode: PTO speed control mode can be used
for both stationary and mobile applications. This mode
allows PTO to be controlled in a fashion similar to how
cruise control sets vehicle speed.

Page 307 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 5-
5-1
Section 5 Problems on the Road
Here youll find what to do about some problems that can occur on the road.
5
-2 Hazard Warning Flashers
5
-2 Other Warning Devices
5
-3 Jump Starting
5
-8 Towing

Page 308 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 5-2
Hazard Warning Flashers
Your hazard warning flashers let you warn others. They
also let police know you have a problem. Your front and
rear turn signal lamps will flash on and off.
Press the butto

Page 309 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 5-3
Jump Starting
If your battery has run down, you may want to use
another vehicle and some jumper cables to start your
vehicle. But please use the following steps to do it safely.
CAUTION:
Batteries

Page 310 of 468

CHEVROLET SILVERADO 2001 1.G Owners Manual 5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles arent touching
each other. If they are, it could cause a ground
connection you dont want. You wouldnt b
