Page 12 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
In Brief 11
Reclining Seatbacks
To recline the seatback:1. Lift the lever.
2. Move the seatback to the desired position, and then
release the lever to lock the
seatback in place.
3. Push and pull on the seatback to make sure it is locked in
place. To return the seatback to the upright
position:
1. Lift the lever fully without applying pressure to the
seatback, and the seatback will
return to the upright position.
2. Push and pull on the seatback to make sure it is locked.
See Reclining Seatbacks 049.
Second Row Seats
The rear seatbacks can be folded
down to increase cargo space.
See Rear Seats 051.
Head Restraint
Adjustment
Do not drive until the head restraints
for all occupants are installed and
adjusted properly.
To achieve a comfortable seating
position, change the seatback
recline angle as little as necessary
while keeping the seat and the head
restraint height in the proper
position. See
Head Restraints 047 and Seat
Adjustment 048.
Safety Belts
Refer to the following sections for
important information on how to use
safety belts properly:
.
Safety Belts 053.
. How to Wear Safety Belts
Properly 054.
. Lap-Shoulder Belt 055.
. Lower Anchors and Tethers for
Children (LATCH System) 077.
Page 14 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
In Brief 13
Folding Mirrors
The outside mirrors can be folded
inward to prevent damage when
going through an automatic car
wash. To fold, pull the mirror toward
the vehicle. Push the mirror outward
to return it to the original position.
SeeFolding Mirrors 041.
Steering Wheel
Adjustment
To adjust the steering wheel:
1. Pull the lever down.
2. Move the steering wheel up or down. 3. Pull the lever up to lock the
steering wheel in place.
Do not adjust the steering wheel
while driving.
Interior Lighting
Dome Lamps
The dome lamp controls are in the
headliner above the front seats.
*: Press to turn the lamps off,
even when a door is open.
1: When the button is returned to
the middle position, the lamps turn
on automatically when a door is
opened.
+: Press to turn on the dome
lamps.
Reading Lamps
The reading lamps are in the
overhead console.
Press the lamp lenses to turn the
reading lamps on or off.
For more information about interior
lighting, see Instrument Panel
Illumination Control 0133 or
Courtesy Lamps 0133.
Page 52 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
Seats and Restraints 51
Rear Seats
Folding the Seatback
Either side of the seatback can be
folded down for more cargo space.
Fold a seatback only when the
vehicle is not moving.
Caution
Folding a rear seat with the safety
belts still fastened may cause
damage to the seat or the safety
belts. Always unbuckle the safety
belts and return them to their
normal stowed position before
folding a rear seat.
To fold a seatback down: 1. Slide the front seats forward and place the front seatbacks
in the upright position. See
Seat Adjustment 048 and
Reclining Seatbacks 049. 2. Remove the rear head
restraints. See “Head Restraint
Removal and Reinstallation”
under Lower Anchors and
Tethers for Children (LATCH
System) 077.
3. Pull up on the front edge of the rear seat cushion to release it.
Tilt the seat cushion forward
toward the front of the vehicle.
4. Pull up the release knob on thetop of the seatback.
5. Fold the seatback forward
and down.
6. Repeat Steps 1–5 for the other seatback and seat cushion,
if desired.
Raising the Seatback
{Warning
If either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.
Page 82 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
Seats and Restraints 81
Warning (Continued)
wrapped around a child’s neck.
If the shoulder belt is locked and
tightened around a child’s neck,
the only way to loosen the belt is
to cut it.
Buckle any unused safety belts
behind the child restraint so
children cannot reach them. Pull
the shoulder belt all the way out
of the retractor to set the lock,
and tighten the belt behind the
child restraint after the child
restraint has been installed.
Caution
Do not let the LATCH
attachments rub against the
vehicle’s safety belts. This may
damage these parts. If necessary,
move buckled safety belts to
avoid rubbing the LATCH
attachments.(Continued)
Caution (Continued)
Do not fold the rear seatback
when the seat is occupied. Do not
fold the empty rear seat with a
safety belt buckled. This could
damage the safety belt or the
seat. Unbuckle and return the
safety belt to its stowed position,
before folding the seat.
If you need to secure more than one
child restraint in the rear seat, see
Where to Put the Restraint 076.
This system is designed to make
installation of child restraints easier.
When using lower anchors, do not
use the vehicle's safety belts.
Instead use the vehicle's anchors
and child restraint attachments to
secure the restraints. Some
restraints also use another vehicle
anchor to secure a top tether.
1. Attach and tighten the lower attachments to the lower
anchors. If the child restraint
does not have lower
attachments or the desired seating position does not have
lower anchors, secure the child
restraint with the top tether and
the safety belts. Refer to your
child restraint manufacturer
instructions and the
instructions in this manual.
1.1. Find the lower anchors
for the desired seating
position.
1.2. Put the child restraint on the seat.
For rear outboard seating
positions, if the head
restraint interferes with
the proper installation of
the child restraint, the
head restraint may be
removed. See “Head
Restraint Removal and
Reinstallation” at the end
of this section.
When installing a
rear-facing child restraint,
it may be necessary to
move the front seat
forward to properly install
the child restraint per the
child restraint
Page 84 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
Seats and Restraints 83
raise the head restraint
and route the tether
under the head restraint
and in between the head
restraint posts.
If the rear outboard
seating position you are
using has an adjustable
head restraint and you
are using a dual tether,
raise the head restraint
and route the tether
under the head restraint
and around the head
restraint posts.
3. Before placing a child in the child restraint, make sure it is
securely held in place. To
check, grasp the child restraint
at the LATCH path and attempt to move it side to side and
back and forth. There should
be no more than 2.5 cm (1 in) of
movement for proper
installation.
Head Restraint Removal and
Reinstallation
The rear outboard head restraints
can be removed if they interfere with
the proper installation of the child
restraint, see
“Securing a Child
Restraint Designed for the LATCH
System” previously in this section.
Store the head restraints in a secure
place.
To remove the head restraint:
1. Partially fold the seatback forward. See Rear Seats051
for more information.
2. Press both buttons on the head restraint posts at the same time
and pull up on the head
restraint.
3. Store the head restraints in a secure place.
4. When the child restraint is removed, reinstall the head
restraint before the seating
position is used.
{Warning
With head restraints that are not
installed and adjusted properly,
there is a greater chance that
(Continued)
Page 176 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
Driving and Operating 175
weight of the driver, passengers,
and cargo should never exceed
the vehicle's capacity weight.
Certification Label
Label Example
A vehicle-specific Certification
label is attached to the vehicle's
center pillar (B-pillar). The label
may show the gross weight
capacity of the vehicle, called
the Gross Vehicle Weight Rating
(GVWR). The GVWR includes
the weight of the vehicle, all
occupants, fuel, and cargo.
{Warning
Things inside the vehicle can
strike and injure people in a
sudden stop or turn, or in a
crash.
.Put things in the cargo
area of the vehicle. In the
cargo area, put them as
far forward as possible.
Try to spread the weight
evenly.
.Never stack heavier
things, like suitcases,
inside the vehicle so that
some of them are above
the tops of the seats.
.Do not leave an
unsecured child restraint
in the vehicle.
.Secure loose items in the
vehicle.
.Do not leave a seat
folded down unless
needed.
Starting and
Operating
New Vehicle Break-In
Caution
The vehicle does not need an
elaborate break-in. But it will
perform better in the long run if
you follow these guidelines: . Do not drive at any one
constant speed, fast or slow,
for the first 805 km (500 mi).
Do not make full-throttle
starts. Avoid downshifting to
brake or slow the vehicle.
. Avoid making hard stops for
the first 322 km (200 mi) or
so. During this time the new
brake linings are not yet
broken in. Hard stops with
new linings can mean
premature wear and earlier
replacement. Follow this
(Continued)
Page 324 of 331
Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-9956101) -
2017 - crc - 4/25/16
Index 323
Driving (cont'd)For Better Fuel Economy . . . . . . . 21
Hill and Mountain Roads . . . . . . 170
If the Vehicle is Stuck . . . . . . . . . 172
Loss of Control . . . . . . . . . . . . . . . 168
Off-Road Recovery . . . . . . . . . . . 168
Vehicle Load Limits . . . . . . . . . . . 172
Wet Roads . . . . . . . . . . . . . . . . . . . 169
Winter . . . . . . . . . . . . . . . . . . . . . . . . 170
E
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 205
Electrical System
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 236
Fuses and Circuit Breakers . . . 235
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 238
Overload . . . . . . . . . . . . . . . . . . . . . 235
Emergency OnStar
®. . . . . . . . . . . . . . . . . . . . . . .311
Engine Air Cleaner/Filter . . . . . . . . . . . . . 218
Check and Service Engine
Soon Light . . . . . . . . . . . . . . . . . . 103
Compartment Overview . . . . . . . 212
Coolant . . . . . . . . . . . . . . . . . . . . . . . 219 Engine (cont'd)
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . 108
Cooling System . . . . . . . . . . . . . . . 219
Cooling System Messages . . . .119
Drive Belt Routing . . . . . . . . . . . . 295
Exhaust . . . . . . . . . . . . . . . . . . . . . . 184
Heater . . . . . . . . . . . . . . . . . . . . . . . . 181
Oil Life System . . . . . . . . . . . . . . . 215
Oil Messages . . . . . . . . . . . . . . . . . .119
Oil Pressure Light . . . . . . . . . . . . 109
Overheating . . . . . . . . . . . . . . . . . . 223
Power Messages . . . . . . . . . . . . . 120
Reduced Power Light . . . . . . . . . .110
Running While Parked . . . . . . . . 185
Starting . . . . . . . . . . . . . . . . . . . . . . . 179
Entry Lighting . . . . . . . . . . . . . . . . . . . 134
Event Data Recorders . . . . . . . . . . 308
Exit Lighting . . . . . . . . . . . . . . . . . . . . 134
Extender, Safety Belt . . . . . . . . . . . . 57
Exterior Lamp Controls . . . . . . . . . 129
Exterior Lamps Off Reminder . . . 129
F
Filter, Engine Air Cleaner . . . . . . . . . . . 218
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 130
Flashers, Hazard Warning . . . . . . 131
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 259 Flat Tire (cont'd)
Changing . . . . . . . . . . . . . . . . . . . . . 260
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 279
Fluid Automatic Transmission . . . . . . 217
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 225
Washer . . . . . . . . . . . . . . . . . . . . . . . 224
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 132 Bulb Replacement . . . . . . . . . . . . 232
Folding Mirrors . . . . . . . . . . . . . . . . . . 41
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 198
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 306
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Front Seat Armrest . . . . . . . . . . . . . . 50
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 48
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 50
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201 Additives . . . . . . . . . . . . . . . . . . . . . 202
Economy Driving . . . . . . . . . . . . . . . 21
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 204
Filling the Tank . . . . . . . . . . . . . . . 203
Foreign Countries . . . . . . . . . . . . 202
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 100
