glove box CHEVROLET SPARK 2019 Owner's Manual

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
62 Seats and Restraints
Warning (Continued)
Occupants should not lean on or
sleep against the door or side
windows in seating positions with
seat-mounted side impact airbags
and/or roof-rail airbags.
{Warning
Children who are up against,
or very close to, any airbag when
it inflates can be seriously injured
or killed. Always secure children
properly in the vehicle. To read
how, seeOlder Children 072 or
Infants and Young Children 074.
There is an airbag readiness light
on the instrument cluster, which
shows the airbag symbol. The
system checks the airbag electrical
system for malfunctions. The light
tells you if there is an electrical
problem. See Airbag Readiness
Light 0103.
Where Are the Airbags?
The driver frontal airbag is in the
center of the steering wheel.
The front outboard passenger
frontal airbag is in the passenger
side instrument panel.
The driver knee airbag is below the
steering column. The front outboard
passenger knee airbag is below the
glove box.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
92 Storage
Storage
Storage Compartments
Storage Compartments . . . . . . . . 92
Glove Box . . . . . . . . . . . . . . . . . . . . . 92
Additional Storage Features
Cargo Cover . . . . . . . . . . . . . . . . . . . 92
Cargo Tie-Downs . . . . . . . . . . . . . . 93
Roof Rack System
Roof Rack System . . . . . . . . . . . . . 93
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Glove Box
Lift up on the glove box lever to
open it.
Additional Storage
Features
Cargo Cover
{Warning
An unsecured cargo cover could
strike people in a sudden stop or
turn, or in a crash. Store the
cargo cover securely or remove it
from the vehicle.
{Warning
Do not place objects on the cargo
cover. Sudden stops or turns can
cause objects to be thrown in the
vehicle. You or others could be
injured.
The cargo cover can be used to
cover items in the rear of the
vehicle. The cargo cover is larger
than the tailgate opening. Turn it for
easy removal or installation.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
162 Climate Controls
Operation Tips
.Clear away any ice, snow,
or leaves from air inlets at the
base of the windshield that could
block the flow of air into the
vehicle.
. Clear snow off the hood to
improve visibility and help
decrease moisture drawn into
the vehicle.
. Keep the path under the front
seats clear of objects to help
circulate the air inside of the
vehicle more effectively.
. Use of non-GM approved hood
deflectors can adversely affect
the performance of the system.
Check with your dealer before
adding equipment to the outside
of the vehicle.Maintenance
Air Intake
The air intake at the base of the
windshield under the hood must be
kept clear to allow the flow of air
into the vehicle. Clear away any ice,
snow, or leaves.
Passenger Compartment
Air Filter
The filter reduces the dust, pollen,
and other airborne irritants from
outside air that is pulled into the
vehicle. The filter should be replaced as part
of routine scheduled maintenance.
See
Maintenance Schedule 0291.
To find out what type of filter to use,
see Maintenance Replacement
Parts 0300.
1. Open the glove box completely
and loosen the bolts on the
outboard side.
2. Push in both sides of the glove box and pull to remove.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
Climate Controls 163
3. Open the filter cover byreleasing the tabs on both
sides and pulling up the cover.
4. Replace the air filter.
5. Close the air filter cover and tabs.
6. Reinstall the glove box.
See your dealer if additional
assistance is needed.
Air Conditioning Regular
Operation
To ensure continuous efficient
performance, operate the air
conditioning for a few minutes once a month. The air conditioning will
not operate if the outside
temperature is too low.
Caution
Damage caused by improper
refrigerant usage could lead to
costly repairs and may not be
covered by the vehicle warranty.
Refrigerant systems should only
be serviced by qualified
personnel. Always use the correct
refrigerant.
{Warning
Performing service work to the
climate control system could
cause personal injury or damage
to the vehicle. Climate control
systems are serviced by qualified
personnel only.
Service
All vehicles have a label underhood
that identifies the refrigerant used in
the vehicle. The refrigerant system
should only be serviced by trained
and certified technicians. The air
conditioning evaporator should
never be repaired or replaced by
one from a salvage vehicle.
It should only be replaced by a new
evaporator to ensure proper and
safe operation.
During service, all refrigerants
should be reclaimed with proper
equipment. Venting refrigerants
directly to the atmosphere is harmful
to the environment and may also
create unsafe conditions based on
inhalation, combustion, frostbite,
or other health-based concerns.
The air conditioning system requires
periodic maintenance. See
Maintenance Schedule
0291.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
302 Technical Data
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 302
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . 302
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . . 303
Engine Drive Belt Routing . . . . 304
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the driver side of the vehicle. It can
be seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement parts. See
“Engine Specifications”
under Capacities and Specifications
0 303 for the vehicle's engine code.
Service Parts
Identification Label
There may be a label on the inside
of the glove box that contains the
following information:
.
Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a
barcode on the certification label on
the center (B) pillar to scan for this
same information.

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
Index 335
Fuel (cont'd)Recommended . . . . . . . . . . . . . . . 207
Top Tier . . . . . . . . . . . . . . . . . . . . . . 206
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 242
Fuses and Circuit Breakers . . . 242
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 245
G
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 235
GaugesFuel . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Odometer . . . . . . . . . . . . . . . . . . . . . 102
Speedometer . . . . . . . . . . . . . . . . . 102
Tachometer . . . . . . . . . . . . . . . . . . . 102
Trip Odometer . . . . . . . . . . . . . . . . 102
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . . . 99
General Information Service and Maintenance . . . . . 289
Towing . . . . . . . . . . . . . . . . . . . . . . . . 210
Vehicle Care . . . . . . . . . . . . . . . . . . 213
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 92
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 309
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 236
Hazard Warning Flashers . . . . . . . 128
Head Restraints . . . . . . . . . . . . . . . . . 47
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 236
Automatic . . . . . . . . . . . . . . . . . . . . . 127
Bulb Replacement . . . . . . . . . . . . 236
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 126
Flash-to-Pass . . . . . . . . . . . . . . . . . 126
Headlamps, Front Turn Signal, Sidemarker, and
Parking Lamps . . . . . . . . . . . . . . 237
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 237
High-Beam On Light . . . . . . . . . . .113
High/Low Beam Changer . . . . . 126
Lamps On Reminder . . . . . . . . . .113
Heated Front Seats . . . . . . . . . . . . . . 50
Heated Mirrors . . . . . . . . . . . . . . . . . . . 42
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 181
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 159
High-Beam On Light . . . . . . . . . . . . 113
Hill and Mountain Roads . . . . . . . . 169
Hill Start Assist (HSA) . . . . . . . . . . 192
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 215 Hood Ajar Light . . . . . . . . . . . . . . . . . 114
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
How to Wear Seat Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . . 54
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Hydraulic Clutch . . . . . . . . . . . . . . . . 222
I
Ignition Positions . . . . . . . . . . 175, 177
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . . . 233
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 39
Light . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Indicator Owner Manual . . . . . . . . . . . . . . . . 107
Vehicle Ahead . . . . . . . . . . . . . . . . 109
Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . 74
Information Publication Ordering . . . . . . . . . . 315
Instrument Cluster . . . . . . . . . . . . . . 100
Interior Rearview Mirrors . . . . . . . . . 42
Introduction . . . . . . . . . . . . . . . . . . 2, 132
J
Jack Auxiliary . . . . . . . . . . . . . . . . . . . . . . 143
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 273

Chevrolet Spark Owner Manual (GMNA-Localizing-U.S./Canada-12146335) -
2019 - CRC - 4/26/18
Index 339
Routing, Engine Drive Belt . . . . . . 304
Running the Vehicle WhileParked . . . . . . . . . . . . . . . . . . . . . . . . 186
S
Safety Defects ReportingCanadian Government . . . . . . . . 316
General Motors . . . . . . . . . . . . . . . 317
U.S. Government . . . . . . . . . . . . . 316
Safety Locks . . . . . . . . . . . . . . . . . . . . . 36
Safety System Check . . . . . . . . . . . . 59
Satellite Radio . . . . . . . . . . . . . . . . . . 139
Scheduling Appointments . . . . . . . 311
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . 53 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Extender . . . . . . . . . . . . . . . . . . . . . . . . 59
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . 54
Lap-Shoulder Belt . . . . . . . . . . . . . . 56
Reminders . . . . . . . . . . . . . . . . . . . . 103
Replacing after a Crash . . . . . . . . 60
Use During Pregnancy . . . . . . . . . . 58
Seats Adjustment, Front . . . . . . . . . . . . . . . 48
Head Restraints . . . . . . . . . . . . . . . . 47
Heated Front . . . . . . . . . . . . . . . . . . . 50
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Reclining Seatbacks . . . . . . . . . . . . 49 Securing Child Restraints . . . . 86, 88
Security
OnStar . . . . . . . . . . . . . . . . . . . . . . . 321
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 38
Vehicle Alarm . . . . . . . . . . . . . . . . . . . 38
Service . . . . . . . . . . . . . . . . . . . . . . . . . 163 Accessories and
Modifications . . . . . . . . . . . . . . . . 214
Climate Control System . . . . . . . 159
Doing Your Own Work . . . . . . . . 214
Maintenance Records . . . . . . . . 301
Maintenance, General Information . . . . . . . . . . . . . . . . . . 289
Parts Identification Label . . . . . 302
Scheduling Appointments . . . . . .311
Vehicle Soon Light . . . . . . . . . . . . 107
Services Special Application . . . . . . . . . . . 296
Servicing the Airbag . . . . . . . . . . . . . 70
Settings . . . . . . . . . . . . . . . . . . . . . . . . 153
Shift Lock Control Function Check, Automatic
Transmission . . . . . . . . . . . . . . . . . . 233
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 183
Out of Park . . . . . . . . . . . . . . . . . . . 184
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 128 Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . 272
Special Application Services . . . . 296
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 303
Speedometer . . . . . . . . . . . . . . . . . . . 102
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . .110
Start Assist, Hill . . . . . . . . . . . . . . . . . 192
Starter Switch Check . . . . . . . . . . . 232
Starting the Engine . . . . . . . . . . . . . 179
Steering . . . . . . . . . . . . . . . . . . . . . . . . 166 Power, Warning Lights . . . . . . . . 109
Wheel Adjustment . . . . . . . . . . . . . . 96
Wheel Controls . . . . . . . . . . . . . . . . . 96
Stoplamps and Back-up Lamps
Bulb Replacement . . . . . . . . . . . . 240
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . . . 92
Glove Box . . . . . . . . . . . . . . . . . . . . . . 92
Roof Rack System . . . . . . . . . . . . . . 93
Storage Compartments . . . . . . . . . . 92
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 171
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 44
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
