CHEVROLET SSR 2006 1.G Repair Manual

Keys...............................................................2-3
Remote Keyless Entry System.........................2-5
Remote Keyless Entry System Operation...........2-6
Doors and Locks.............................................2-8
Door Locks....................................................2-8
Power Door Locks..........................................2-9
Programmable Automatic Door Locks..............2-10
Tailgate.......................................................2-10
Windows........................................................2-11
Power Windows............................................2-12
Sun Visors...................................................2-13
Theft-Deterrent Systems..................................2-13
Content Theft-Deterrent.................................2-13
Passlock
®....................................................2-15
Starting and Operating Your Vehicle................2-15
New Vehicle Break-In....................................2-15
Ignition Positions..........................................2-16
Retained Accessory Power (RAP)...................2-17
Starting the Engine.......................................2-17
Automatic Transmission Operation...................2-19
Manual Transmission Operation......................2-21
Parking Brake..............................................2-23Shifting Into Park (P).....................................2-23
Shifting Out of Park (P).................................2-24
Parking Your Vehicle
(Manual Transmission)...............................2-25
Parking Over Things That Burn.......................2-25
Engine Exhaust............................................2-26
Running the Engine While Parked...................2-26
Mirrors...........................................................2-27
Manual Rearview Mirror.................................2-27
Automatic Dimming Rearview Mirror with
Universal Home Remote.............................2-27
Outside Power Heated Mirrors........................2-28
Outside Convex Mirror...................................2-29
Outside Automatic Dimming Heated Mirror........2-29
Universal Home Remote System......................2-30
Universal Home Remote System Operation......2-30
Storage Areas................................................2-34
Glove Box...................................................2-34
Cupholder(s)................................................2-34
Instrument Panel Storage Area.......................2-34
Center Console Storage Area.........................2-35
Map Pocket.................................................2-35
Section 2 Features and Controls
2-1

Cargo Cover................................................2-35
Floor Tracks................................................2-38
Cargo Net System........................................2-40
Side-Saddle Storage.....................................2-45
Cargo Management System...........................2-45Convertible Top..............................................2-45
Lowering the Convertible Top.........................2-47
Raising the Convertible Top...........................2-48
Vehicle Personalization...................................2-53
Memory Seat...............................................2-53
Section 2 Features and Controls
2-2

Keys
{CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. They
could operate the power windows or other
controls or even make the vehicle move. The
children or others could be badly injured or
even killed. Do not leave the keys in a vehicle
with children.
2-3

One key is used for the
ignition, the doors and all
locks except the center
console and trailer hitch.
If you need a new key, contact your dealer for
assistance. In an emergency, contact Chevrolet
Roadside Assistance. SeeRoadside Assistance
Program on page 7-6for more information.
Notice:If you ever lock your keys in your vehicle,
you may have to damage the vehicle to get in.
Be sure you have spare keys.Center Console Storage Area Key
A separate key is provided
for locking the center
console storage area.
2-4

Trailer Hitch Keys
If your vehicle has the GM Accessory Trailer Hitch,
three keys are provided for the receiving hitch lock. All
three keys operate the receiving hitch lock. See
“Hitches” underTowing a Trailer on page 4-35for
additional information.
Remote Keyless Entry System
Your keyless entry system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
2-5

At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:
•Check the distance. You may be too far from your
vehicle. You may need to stand closer during
rainy or snowy weather.
•Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the
left or right, hold the transmitter higher, and
try again.
•Check to determine if battery replacement is
necessary. See “Battery Replacement” under
Remote Keyless Entry System Operation on
page 2-6.
•If you are still having trouble, see your dealer or a
qualified technician for service.
Remote Keyless Entry System
Operation
You can lock and unlock your doors and cargo area
from about 3 feet (1 m) up to 30 feet (9 m) away using
the remote keyless entry transmitter supplied with
your vehicle.
W(Unlock):When
you press unlock, the
driver’s door will unlock
automatically, the parking
lamps may flash, the
horn may sound, and the
interior lights will turn on.
2-6

If your vehicle has the memory seat feature and you
have previously programmed a seat position, the driver’s
seat will move to that position when you press the
unlock button. SeeMemory Seat on page 2-53for
more information.
Q(Lock):Press lock to lock all the doors. Press lock
again within three seconds and the horn will chirp.
F(Cargo Cover Release):To release the cargo
cover, press the button with this symbol on it. The
convertible top must be all the way up or down for this
feature to work properly. See “Roof Tonneau” under
Lowering the Convertible Top on page 2-47for more
information. The cargo cover can also be released using
the cargo cover release button located in the glove box.
SeeCargo Cover on page 2-35for more information.
L(Remote Alarm):Press the button with the horn
symbol on it, to sound the horn and make the
headlamps and taillamps flash for up to 30 seconds.
This can be turned off by pressing the horn button again,
or by waiting for 30 seconds, or by starting the vehicle.
You can program different feedback settings for up to
two drivers using the Driver Information Center (DIC). For
more information seeDriver Information Center (DIC) on
page 3-42.
Matching Transmitter(s) to
Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can
be purchased through your dealer. Remember to bring
any remaining transmitters with you when you go to
your dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock
your vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won’t
work at the normal range in any location. If you have
to get close to your vehicle before the transmitter works,
it’s probably time to change the battery.
The Driver Information Center (DIC) will display a Rfa X
Battery Low message when the transmitter battery is
low. SeeDIC Warnings and Messages on page 3-45.
2-7

Notice:When replacing the battery, use care not to
touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.
To replace the battery in the remote keyless entry
transmitter, do the following:
1. Insert a thin coin in the slot between the covers
of the transmitter housing. Gently pry the
transmitter apart.
2. Remove and replace the battery with a three-volt
CR2032 or equivalent battery.
3. Align the covers and snap them together.
4. Check the operation of the transmitter.Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers — especially children — can
easily open the doors and fall out of a
moving vehicle. When a door is locked, the
handle will not open it. You increase the
chance of being thrown out of the vehicle
in a crash if the doors are not locked. So,
wear safety belts properly and lock the
doors whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.
2-8

There are several ways to lock and unlock your vehicle.
From the outside, use your key or the remote keyless
entry transmitter. SeeRemote Keyless Entry System
Operation on page 2-6for more information.
To lock or unlock the driver’s door from the outside with
the key, insert the key and turn it clockwise to lock or
counterclockwise to unlock.
From the inside, use the manual or power door locks.
To lock or unlock either door from the inside, pull up or
push down on the manual lock.Power Door Locks
Your power door lock
switch is located on the
console switchbank.
SeeCenter Console
Switchbank on page 3-19
for more information.
K(Unlock):Press this symbol to unlock the doors
from inside your vehicle.
Q(Lock):Press this symbol to lock the doors from
inside your vehicle.
If the key is in the ignition and the driver’s door is
opened, the driver’s door will not lock with the power
door lock switch.
2-9

Programmable Automatic
Door Locks
Your vehicle is programmed from the factory to
automatically lock and unlock under certain conditions. If
all the doors are closed, when you move the shift lever
out of PARK (P) all of the doors will lock on a vehicle with
an automatic transmission or when the vehicle reaches a
speed of 8 mph (13 kph) on a vehicle with a manual
transmission. Every time you move the shift lever back
into PARK (P), the doors will unlock for a vehicle with an
automatic transmission or when the key is removed from
the ignition for a vehicle with a manual transmission. If
someone needs to get out while you are not in PARK (P)
or while the key is in the ignition, have that person use the
manual or power lock. When the door is closed again, it
will not lock automatically. Use the manual or power lock
to lock the door again.
Customizing Your Automatic Door
Locks Feature
The automatic door locks can be programmed to the
preferred settings for up to two drivers. SeeDIC Vehicle
Personalization on page 3-52for more information.
Tailgate
To open the tailgate, do the following:
1. Open the cargo cover using the remote keyless
entry transmitter or the cargo cover release
button in the glovebox. SeeRemote Keyless Entry
System Operation on page 2-6andCargo Cover
on page 2-35for more information.
2. Pull up on the handle inside and lower the tailgate.
To close the tailgate, do the following:
1. Close the cargo cover before closing the tailgate.
2. Push the tailgate upward to return it to its upright,
latched position. Push and pull on the tailgate to
make sure it is secure.
2-10
