6-61 Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself. This
greatly reduces the chance of fires caused by electrical
problems. See ªFuses and Circuit Breakersº in the Index
for more information.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
If you ever have a problem on the road and don't have a
spare fuse, you can borrow one that has the same
amperage. Just pick some feature of your vehicle that
you can get along without
-- like the radio or cigarette
lighter
-- and use its fuse, if it is the correct amperage.
Replace it as soon as you can.Instrument Panel Fuse Block
The fuse block access door
is on the driver's side edge
of the instrument panel. Pull
off the cover to access the
fuse block.
You can remove fuses with
a fuse extractor. The fuse
extractor is mounted to the
fuse block access door.
To remove fuses, if you don't have a fuse extractor, hold
the end of the fuse between your thumb and index finger
and pull straight out.
You may have spare fuses attached to the inside of
the fuse block access door. These can be used to
replace a bad fuse. However, make sure that it is the
correct amperage.

yellowblue
6-62
Fuse/Circuit
BreakerUsage
1 Stop/TCC Switch, Buzzer, CHMSL,
Hazard Lamps, Stoplamps
2 Transfer Case
3 Courtesy Lamps, Cargo Lamp, Glove
Box Lamp, Dome/Reading Lamps,
Vanity Mirrors, Power MirrorsFuse/Circuit
BreakerUsage
4 Instrument Cluster, DRL Relay, Lamp
Switch, Keyless Entry, Low Coolant
Module, Illuminated Entry Module,
DRAC (Diesel Engine)
5 Rear Comfort Controls
6 Cruise Control
7 Auxiliary Power Outlet
8 Crank
9 License Lamp, Parking Lamps,
Taillamps, Roof Marker Lamps,
Tailgate Lamps, Front Sidemarkers,
Fog Lamp Relay, Door Switch
Illumination, Fender Lamps,
Headlamp Switch Illumination
10 Air Bag System
11 Wiper Motor, Washer Pump
12 A/C, A/C Blower, High Blower Relay
13 Power Amp, Rear Liftglass, Cigarette
Lighter, Door Lock Relay, Power
Lumbar Seat

yellowblue
6-63
Fuse/Circuit
BreakerUsage
14 4WD Indicator, Cluster, Front and
Rear Comfort Controls (If Equipped),
Instrument Switches, Radio
Illumination, Chime Module
15 DRL Relay, Fog Lamp Relay
16 Front and Rear Turn Signals,
Back
-Up Lamps, BTSI Solenoid
17 Radio (Ignition)
18 4WAL/VCM, ABS, Cruise Control
19 Radio (Battery)
20 PRNDL, Automatic Transmission,
Speedometer, Check Gages,
Warning Lights
21 Security/Steering
22 Not Used
23 Rear Wiper, Rear Washer Pump
24 Front Axle, 4WD Indicator Lamp,
TP2 Relay (Gasoline Engine)
A Power Door Lock, Six
-Way Power
Seat, Keyless Entry Module
B Power WindowsUnderhood Fuse/Relay Center
The underhood fuse/relay center is located in the rear of
the engine compartment near the brake fluid reservoir.
Move the retainer clips for the cover to access the
fuse block.
You can remove fuses with a fuse extractor. The fuse
extractor is mounted to the interior fuse block. To
remove fuses if you don't have a fuse extractor, hold the
end of the fuse between your thumb and index finger
and pull straight out.

yellowblue
6-64
Name Circuits Protected
ECM
-B Fuel Pump, PCM/VCM
RR DEFOG Rear Window Defogger
(If Equipped)
IGN
-E Auxiliary Fan Relay Coil, A/C
Compressor Relay, Hot Fuel Module
FUEL SOL Fuel Solenoid (Diesel Engine)
GLOW PLUG Glow plugs (Diesel Engine)
HORN Horn, Underhood LampsName Circuits Protected
AUX FAN Auxiliary Fan
ECM
-1 Injectors, PCM/VCM
HTD ST
-FR Heated Front Seats
A/C Air Conditioning
HTD MIR Heated Outside Mirrors (If Equipped)
ENG
-1 Ignition Switch, EGR, Canister
Purge, EVRV Idle Coast Solenoid,
Heated O
2, Fuel Heater
(Diesel Engine), Water Sensor
(Diesel Engine)
HTD ST
-RR Not Used
LIGHTING Headlamp and Panel Dimmer
Switch, Fog and Courtesy Fuses
BATT Battery, Fuse Block Busbar
IGN
-A Ignition Switch
IGN
-B Ignition Switch
ABS Anti
-Lock Brake Module
BLOWER Hi Blower and Rear Blower Relays
STOP/HAZ Stoplamps
HEATED SEATS Heated Seats (If Equipped)

yellowblue
6-65
Replacement Bulbs
LAMP OR BULB TRADE NO. POWER RATING AT 12.8V, WATTS QTY
HEADLAMPS
2 Headlamp System (Sealed Beam)
Low/High Beam H6054 35/65 2
4 Headlamp System (Composite)
Low Beam 9006 55 2
High Beam 9005 65 2
LAMP OR BULB TRADE NO. QTY
EXTERIOR
Front Marker Lamp 194 2
Front Parking and Turn Lamp 2357NA 4
Rear Parking Lamp 3057 2
Rear Stop and Turn Lamp 3057 2
Back
-up Lamp3156 2
Roof Marker Lamp* 194 5
License Plate Lamp 194 2
Underhood Lamp 93 1
*Suburban Only

yellowblue
6-66
LAMP OR BULB TRADE NO. QTY
INTERIOR
Dome Lamps
211
-22
Reading Lamps
211
-24
Roof Console Lamps* 168 2
Door Courtesy Lamp 194 2/4*
Four
-Wheel-Drive Indicator**194 1
Four
-Wheel-Drive Shift Lever**194 1
Instrument Panel Compartment Lamp 194 1
Ashtray Lamp 194 1
Sunshade Vanity Mirror 74 4
*Suburban Only
**Manual Transfer Case

yellowblue
6-67
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº in the Index for more information.
Engine Identification -- Gasoline Engines
EngineªVORTECº 5700 ªVORTECº 7400
Type V8 V8
RPO Code L31 L29
VIN Code R J
Fuel System SFI* SFI*
*Sequential Fuel Injection
Wheels and Tires
MODEL DESCRIPTION TORQUE
C 1500 5 bolts (14 mm)
140 lb
-ft (190 N´m)
K 1500, C
-K 25006 bolts (14 mm)
140 lb-ft (190 N´m)
C
-K 25008 bolts (14 mm)
140 lb-ft (190 N´m)
Tire Pressure See the Certification/Tire label
on the rear edge of the driver's
door or the incomplete vehicle
document in the cab.

yellowblue
6-68 Cooling System Capacity (Approximate)
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
ENGINE VIN QTY Without Rear Heater QTY With Rear Heater
ªVORTECº 5700 V8 R 17.5 Quarts (16.5 L) 20 Quarts (19 L)
ªVORTECº 7400 V8 J 25 Quarts (23.5 L) 27.5 Quarts (26 L)
Crankcase Capacity (Approximate)
After refill, the level must be rechecked. Add enough engine oil so that the fluid is within the proper operating range.
See ªEngine Oilº in the Index.
ENGINE VIN
QUANTITY WITH FILTER

ªVORTECº 5700 V8 R 5 Quarts (4.8 L)
ªVORTECº 7400 V8 J 6.6 Quarts (6.3 L)

Oil filter should be changed at every oil change.
Fuel Tank Capacity (Approximate)
TYPE QUANTITY
Utility 30 Gallons (113 L)TYPE QUANTITY
Suburban
- Gasoline 44 Gallons (167 L)
Suburban
- Diesel 42 Gallons (159 L)
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the air conditioning system in your vehicle needs refrigerant, be sure
the proper refrigerant is used. If you're not sure, ask your dealer.
See refrigerant charge label under the hood for charge capacity information and requirements.

yellowblue
6-69
Normal Maintenance Replacement Parts -- Gasoline Engines
Replacement part numbers listed in this section are based on the latest information available at the time of printing,
and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was
built, or if you have any questions, please contact your GM truck dealer.
EngineªVORTECº 5700 V8 ªVORTECº 7400 V8
VIN R J
Oil Filter
AC Type PF1218
AC Type PF1218
Air Cleaner Filter
AC Type A1300C

AC Type A1300C


PCV Valve AC Type CV769C AC Type CV774C
Spark Plugs
AC Type 41
-932 AC Type 41-932
Spark Plug Gap 0.060 in. (1.52 mm) 0.060 in. (1.52 mm)
Fuel Filter AC Type GF626 AC Type GF626
Wiper Blades (Front) GM Part No. 22154886 GM Part No. 22154886
Wiper Blade Type (Front) Trico Trico
Wiper Blade Length (Front) 18 inches (45.0 cm) 18 inches (45.0 cm)
Wiper Blade (Rear) GM Part No. 22154396 GM Part No. 22154396
Wiper Blade Type (Rear) Trico Trico
Wiper Blade Length (Rear) 14 inches (35.5 cm) 14 inches (35.5 cm)

Four
-Wheel-Drive Vehicles -- use a PF52 oil filter.


A1301C High
-capacity air cleaner filter.

yellowblue
6-70
-NOTES
