Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
402 Service and Maintenance
The Tire Rotation and Required
Services are the responsibility of the
vehicle owner. It is recommended to
have your dealer perform these
services every 12 000 km/7,500 mi.
Proper vehicle maintenance helps to
keep the vehicle in good working
condition, improves fuel economy,
and reduces vehicle emissions.
Because of the way people use
vehicles, maintenance needs vary.
There may need to be more
frequent checks and services. The
Additional Required Services -
Normal are for vehicles that:
.Carry passengers and cargo
within recommended limits on
the Tire and Loading Information
label. See Vehicle Load Limits
0 215.
. Are driven on reasonable road
surfaces within legal driving
limits. .
Use the recommended fuel.
See Recommended Fuel (5.3L
V8 Engine) 0273 or
Recommended Fuel (6.2L
V8 Engine) 0273.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart.
The Additional Required Services -
Severe are for vehicles that are:
. Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer.
. Used for high speed or
competitive driving.
. Used for taxi, police, or delivery
service. Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause
serious injury. Perform
maintenance work only if the
required information, proper tools,
and equipment are available.
If they are not, see your dealer to
have a trained technician do the
work. See
Doing Your Own
Service Work 0302.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
Service and Maintenance 403
Maintenance
Schedule
Owner Checks and Services
At Each Fuel Stop
.Check the engine oil level. See
Engine Oil 0309.
Once a Month
. Check the tire inflation
pressures, including the spare.
See Tire Pressure 0355.
. Inspect the tires for wear. See
Tire Inspection 0362.
. Check the windshield washer
fluid level. See Washer Fluid
0 323.
Engine Oil Change
When the CHANGE ENGINE OIL
SOON message displays, have the
engine oil and filter changed within
the next 1 000 km/600 mi. If driven
under the best conditions, the
engine oil life system may not
indicate the need for vehicle service
for up to a year. The engine oil and
filter must be changed at least once
a year and the oil life system must
be reset. Your trained dealer
technician can perform this work.
If the engine oil life system is reset
accidentally, service the vehicle
within 5 000 km/3,000 mi since the
last service. Reset the oil life
system when the oil is changed.
See Engine Oil Life System 0311.
Power Take Off (PTO) and
Extended Idle Use
When the vehicle is used with the
PTO equipment or used in a way
that requires extended idle time,
one hour of use shall be deemed
the same as 53 km (33 mi). See
Driver Information Center (DIC)
(Base Level) 0163 orDriver
Information Center (DIC) (Uplevel)
0 164 for hourmeter.
Air Conditioning Desiccant
(Replace Every Seven Years)
The air conditioning system requires
maintenance every seven years.
This service requires replacement of
the desiccant to help the longevity
and efficient operation of the air
conditioning system. This service
can be complex. See your dealer.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
404 Service and Maintenance
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the
following services. SeeTire
Rotation 0362.
. Check engine oil level and oil
life percentage. If needed,
change engine oil and filter, and
reset oil life system. See Engine
Oil 0309 andEngine Oil Life
System 0311.
. Check engine coolant level. See
Cooling System 0317.
. Check windshield washer fluid
level. See Washer Fluid 0323.
. Check tire inflation pressures,
including the spare. See Tire
Pressure 0355. .
Inspect tire wear. See Tire
Inspection 0362.
. Visually check for fluid leaks.
. Inspect engine air cleaner filter.
See Engine Air Cleaner/Filter
0 316.
. Inspect brake system. See
Exterior Care 0391.
. Visually inspect steering,
suspension, and chassis
components for damage,
including cracks or tears in the
rubber boots, loose or missing
parts, or signs of wear at least
once a year. See Exterior Care
0 391. Lubricate the suspension
and steering components at
least every other oil change (if
equipped with grease fittings). .
Inspect power steering for
proper attachment, connections,
binding, leaks, cracks,
chafing, etc.
. Visually inspect halfshafts and
drive shafts for excessive wear,
lubricant leaks, and/or damage
including: tube dents or cracks,
constant velocity joint or
universal joint looseness,
cracked or missing boots, loose
or missing boot clamps, center
bearing excessive looseness,
loose or missing fasteners, and
axle seal leaks.
. Check restraint system
components. See Safety System
Check 092.
. Visually inspect fuel system for
damage or leaks.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
406 Service and Maintenance
Maintenance Schedule
Additional Required
Services - Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services.
Check engine oil level and oil life percentage.
Change engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Change transfer case fluid, if equipped with
4WD. (4)@
Replace spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Replace windshield wiper blades. (8)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@ @
Footnotes—Maintenance
Schedule Additional Required
Services - Normal
(1) Or every two years, whichever
comes first. More frequent
passenger compartment air filter replacement may be needed if
driving in areas with heavy traffic,
poor air quality, high dust levels,
or environmental allergens.
Passenger compartment air filter
replacement may also be needed if
there is reduced airflow, windowfogging, or odors. Your GM dealer
can help determine when to replace
the filter.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
408 Service and Maintenance
Maintenance Schedule
Additional Required
Services - Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services.
Check engine oil level and oil life percentage.
Change engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@@@
Change automatic transmission fluid and filter.@@@
Change transfer case fluid, if equipped with
4WD. (4)@@@
Replace spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Replace windshield wiper blades. (8)
@ @ @ @ @ @ @ @ @ @
Replace hood and/or body lift support gas struts.@ @

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
410 Service and Maintenance
Additional
Maintenance and Care
Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional
maintenance services may be
required.
It is recommended that your dealer
perform these services—their
trained dealer technicians know
your vehicle best. Your dealer can
also perform a thorough
assessment with a multi-point
inspection to recommend when your
vehicle may need attention.
The following list is intended to
explain the services and conditions
to look for that may indicate
services are required. Battery
The 12-volt battery supplies power
to start the engine and operate any
additional electrical accessories.
.
To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of
cracking or splitting.
. Trained dealer technicians have
access to tools and equipment
to inspect the belts and
recommend adjustment or
replacement when necessary. Brakes
Brakes stop the vehicle and are
crucial to safe driving.
.
Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping.
. Trained dealer technicians have
access to tools and equipment
to inspect the brakes and
recommend quality parts
engineered for the vehicle.
Fluids
Proper fluid levels and approved
fluids protect the vehicle’s systems
and components. See
Recommended Fluids and
Lubricants 0413 for GM approved
fluids.
. Engine oil and windshield
washer fluid levels should be
checked at every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be
filled.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
418 Technical Data
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions. SeeRecommended Fluids and
Lubricants 0413 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and charge amount, see the refrigerant label under thehood. See your dealer for more information.
Cooling System 16.8 L 17.8 qt
Engine Oil with Filter 7.6 L 8.0 qt
Fuel Tank Short Wheelbase 98.4 L 26.0 gal
Long Wheelbase 119.2 L 31.5 gal
Transfer Case Fluid 1.5 L 1.6 qt
Wheel Nut Torque 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12460269) - 2019 - CRC - 9/11/18
Customer Information 431
Publication Ordering
Information
Service Manuals
Service manuals have the diagnosis
and repair information on the
engine, transmission, axle,
suspension, brakes, electrical
system, steering system, body, etc.
Customer Literature
Owner’s manuals are written
specifically for owners and are
intended to provide basic
operational information about the
vehicle. The owner ’s manual
includes the Maintenance Schedule
for all models.
Customer literature publications
available for purchase include
owner ’s manuals, warranty
manuals, infotainment manuals, and
portfolios. Portfolios include an
owner ’s manual, warranty manual,
infotainment manual, if applicable,
and zip lock bag or pouch.
Current and Past Models
Service manuals and customer
literature are available for many
current and past model year GM
vehicles.
To order, call 1-800-551-4123
Monday–Friday, 8:00 a.m.–6:00 p.m.
eastern time
For credit card orders only (VISA,
MasterCard, or Discover), see
Helm, Inc. at: www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S. funds.
Radio Frequency
Statement
This vehicle has systems that
operate on a radio frequency that
complies with Part 15/Part 18 of the
Federal Communications
Commission (FCC) rules and with
Innovation, Science and Economic
Development (ISED) Canada's
RSP-100 / license-exempt RSS's /
ICES-001.
Operation is subject to the following
two conditions:
1. The device may not cause harmful interference.
2. The device must accept any interference received, including
interference that may cause
undesired operation of the
device.
Changes or modifications to any of
these systems by other than an
authorized service facility could void
authorization to use this equipment.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12460269) - 2019 - CRC - 9/11/18
Index 447
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 301
Accessory Power . . . . . . . . . . . . . . . 227
Active Fuel Management . . . . . . . 229
Adaptive Cruise Control . . . . . . . . 252
Add-On Electrical Equipment . . . 298
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 437
Additional Maintenance
and Care . . . . . . . . . . . . . . . . . . . . . . 410
Adjustable Throttle and Brake Pedal . . . . . . . . . . . . . . . . . . . 220
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . 68
Air Cleaner/Filter, Engine . . . . . . . 316
Air Conditioning . . . . . . . . . . . 194, 198
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 200
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 199
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . 106
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 99
Passenger Sensing System . . 100
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 98 Airbag System (cont'd)
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 99
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 97
Where Are the Airbags? . . . . . . . . 96
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . 105
Passenger Status Indicator . . . 154
Readiness Light . . . . . . . . . . . . . . 153
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . 105
System Check . . . . . . . . . . . . . . . . . . 94
Alarm Vehicle Security . . . . . . . . . . . . . . . . 53
Alert Lane Change . . . . . . . . . . . . . . . . . 269
Side Blind Zone (SBZA) . . . . . . 269
All-Season Tires . . . . . . . . . . . . . . . . 349
All-Terrain Tires . . . . . . . . . . . . . . . . . 350
Antilock Brake System (ABS) . . . 244 Warning Light . . . . . . . . . . . . . . . . . 158
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 391
Interior . . . . . . . . . . . . . . . . . . . . . . . . 396
Armrest Storage . . . . . . . . . . . . . . . . 129

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12460269) - 2019 - CRC - 9/11/18
448 Index
Assistance Program,Roadside . . . . . . . . . . . . . . . . . . . . . . 425
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 264
Assistance Systems for Parking and Backing . . . . . . . . . . 261
Automatic
Door Locks . . . . . . . . . . . . . . . . . . . . . 46
Forward Braking . . . . . . . . . . . . . . 267
Headlamp System . . . . . . . . . . . . 186
Level Control . . . . . . . . . . . . . . . . . 249
Transmission . . . . . . . . . . . . . . . . . 231
Transmission Fluid . . . . . . 313, 316
Automatic Transmission Manual Mode . . . . . . . . . . . . 234, 236
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 329
Auxiliary Roof Mounted Lamp . . . . . . . . . . 188
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 327
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 327
B
Battery Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 192
Load Management . . . . . . . . . . . . 191 Battery (cont'd)
Power Protection . . . . . . . . . . . . . 191
Battery - North America . . . . 326, 381
Blade Replacement, Wiper . . . . . 330
Blind Spot Mirrors . . . . . . . . . . . . . . . 58
Brake Pedal and AdjustableThrottle . . . . . . . . . . . . . . . . . . . . . . 220
System Warning Light . . . . . . . . 157
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 324 Antilock . . . . . . . . . . . . . . . . . . . . . . . 244
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 245
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 324
Parking . . . . . . . . . . . . . . . . . . . . . . . 245
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 204 Automatic Forward . . . . . . . . . . . 267
Break-In, New Vehicle . . . . . . . . . . 219
Bulb Replacement Fog Lamps . . . . . . . . . . . . . . . . . . . 334
Front Turn Signal Lamps . . . . . 334
Halogen Bulbs . . . . . . . . . . . . . . . . 333
Headlamp Aiming . . . . . . . . . . . . . 332
Headlamps . . . . . . . . . . . . . . . . . . . 333
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 333
License Plate Lamps . . . . . . . . . 336 Bulb Replacement (cont'd)
Taillamps, Turn Signal,
Stoplamps, and Back-up
Lamps . . . . . . . . . . . . . . . . . . . . . . 335
Buying New Tires . . . . . . . . . . . . . . . 364
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 138
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 301
California Proposition
65 Warning . . . . . . . . . .301, 326, 381, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 418
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . 230
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 47
Winter Driving . . . . . . . . . . . . . . . . 212
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . 131
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 130
Center Seat . . . . . . . . . . . . . . . . . . . . . 67
Chains, Tire . . . . . . . . . . . . . . . . . . . . 368
