Features and Controls
ON (C): Position to which the switch
returns after
you start your engine and
release the switch. The switch stays in the
“ON’ position when the engine is
running. But even when the engine is not
running, you can use
“ON’ to operate
your electrical power accessories and to
display some instrument panel warning
and indicator lights.
START (D): Starts the engine. When the
engine starts, release the key. The ignition
switch will return to
“ON’ for normal
driving.
When the engine is not running, “ACC”
and
“ON’ allow you to operate your
electrical accessories, such as the radio
and ventilation fan.
A warning chime will sound if you open
the driver’s door when the ignition is in
“ACC” or “LOCK” and the key is in the
ignition.
NOTICE:
If your key seems stuck in “LOCK”
and you can’t
turn it, be sure it is all
the way in. If it is, then turn the steer-
ing wheel left and right while you
turn the key hard. But turn the key
only with your hand. Using a tool to
force it could break the key or the
ignition switch. If none of this works,
then your vehicle needs service.
Starting Your Engine
Automatic transmission: Move your
shift lever to
“P” (Park) or “N’ (Neutral).
Your engine won’t start in any other
position
- that’s a safety feature. To
restart when you’re already moving, use
“N’ (Neutral) only.
NOTICE:
Don’t try to shift to “P’ (Park) if your
Geo is moving.
If you do, you could
damage the transmission. Shift to
“P”
(Park) only when your vehicle is
stopped.
Manual transmission: The gear selector
should be in neutral. Hold the clutch
pedal to the floor and start the engine.
Your vehicle won’t start if the clutch
pedal is
not all the way down - that’s
a safety feature.
To start your engine:
1. Without pushing the accelerator pedal,
turn your ignition key
to “START.”
When the engine starts, let
go of the
key.
... 40
ProCarManuals.com

I1 1
Malfunction Indicator Lamp (Check
Engine Light)
A computer monitors operation of your
fuel, ignition and emission control
1 systems. This light should come on when
the ignition is
on, but the engine is not
running, as a check to show you it is
working.
If it does not come on at all,
have it fixed right away. If it stays on. or
comes on while
you are driving, the
computer
is indicating that you have a
problem.
You should take your vehicle in
for service soon.
NOTICE:
If you keep driving your vehicle with
this light on. after
a while the ernis-
sion controls won't work as well,
your
fuel economy won't be as good
and your engine may
not run as
smoothly. This could lead to costly
repairs
not covered by your warranty.
Engine Oil Pressure Light
If you have a problem with your oil? this
light may stay
on after you start your
engine, or come
on when you are driving.
This indicates that there is not enough
pressure
to keep your engine properly
ILJbricated and
cool. The engine could be
low on oil, or have some other oil related
problem. Have
it fixed right away.
The oil light could also come
on in three
other situations.
When the ignition is on but the engine
is not running, the light will come on
as a test to show you it is working, but
the light will
go out when you turn the
engine to
"START." If it doesn't come
on with the ignition
on, you may have
71
ProCarManuals.com

~ Service and Appearance Care
r
NOTICE:
Continuing to drive
with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates may
cause a brake squeal when the brakes are
first applied or lightly applied. This does
not mean something is wrong with your
brakes.
Your rear drum brakes don’t have wear
indicators, but if you ever hear a rear
brake rubbing noise, have the rear brake linings inspected. Also, the rear brake
drums should be removed and inspected
each time the tires are removed for
rotation or changing. When you have the front brakes replaced, have
the rear
brakes inspected, too.
Brake linings should always be replaced
as complete axle sets.
Brake Pedal Travel
See your dealer if the brake pedal does
not return to normal height, or if there is a
rapid increase in pedal travel. This could
be a sign
of brake trouble.
Brake Adjustment
Every time you make a brake stop, your
disc brakes adjust for wear.
If your brake pedal goes down farther
than normal, your rear drum brakes may
need adjustment. Adjust them by backing
up and firmly applying the brakes a few
times.
Replacing Brake System Parts
The braking system on a modern vehicle
is complex. Its many parts have to be of
top quality and work well together
if the
vehicle is
to have really good braking.
Vehicles we design and test have
top-quality GM brake parts in them, as
your Geo does when it is new. When you replace parts
of your braking system -
for example,
when your brake linings
wear down and you have to have new
ones put in
- be sure you get new
genuine
GM replacement parts. If you
don’t, your brakes may no longer work
properly. For example, if someone puts in
brake linings that are wrong for your
vehicle, the balance between your front
and rear brakes can change, for the worse.
The braking performance you’ve come to
expect can change in many other ways if
someone puts in the wrong replacement
brake parts.
Battery
Every new Geo has a Delco Freedoms
battery.
You never have to add water to
one
of these. When it’s time for a new
battery, we recommend a Delco
Freedoma battery. Get one that has the
catalog number shown on the original
battery’s label.
Vehicle Storage
If you’re not going to drive your vehicle
for
25 days or more, take off the black,
negative
(-) cable from the battery. This
. . .I76
ProCarManuals.com

-
Service and Appearance Care
When It’s Time for New Tires
One way to tell when it’s time for new
tires
is to check the treadwear indicators,
which will appear
when your tires have
only
2/32 inch (1.6 mm) or less of tread
remaining.
You need a new tire
if
0 You can see the indicators at three or
more places around
the tire.
0 You can see cord or fabric showing
through the tire’s rubber.
The tread or sidewall is cracked, cut
or snagged deep enough to show cord
or fabric.
The tire has a bump, bulge or split.
. . ,186
0 The tire has a puncture, cut, or other
damage that can’t be repaired well
because of the size or location
of the
damage.
Buying New Tires
To find out what kind and size of tires you
need,
look at the Certificationnire label.
The tires installed on your vehicle when it
was new had a Tire Performance Criteria
Specification (TPC Spec) number on each
tire’s sidewall. When you get new tires,
get ones with that same TPC Spec
number. That way, your vehicle
will
continue to have tires that are designed to
give proper endurance, handling, speed
rating, traction, ride and other things
during normal service on your vehicle. If
your tires have an all-season tread design,
the TPC number will be followed by a
“MS” (for mud and snow).
If you ever replace your tires with those
not having a TPC Spec number, make
sure they are the same size, load range,
speed rating and construction type (bias,
bias-belted or radial) as your original
tires.
Uniform Tire Quality Grading
The following information relates to the
system developed by the United States
National Highway Traffic Safety
Administration which grades tires by
treadwear, traction and temperature
performance. (This applies only to
vehicles sold
in the United States.)
Treadwear
The treadwear grade is a comparative
rating based on the wear rate
of the tire
when tested under controlled conditions
on a specified government test course. For
example, a tire graded
150 would wear
one and a half
(1 1/2) times as well on the
government course as a tire graded 100.
The relative performance of tires depends
ProCarManuals.com

Service and Appearance Care
Main Fuse Block
1 - Generator to Battery Circuit (60A)
2
- Circuits Only Active When
Ignition Switch is
in “ACC,” “ON”
or “START” (50A)
3
- Circuits Always Active (40A)
4 - Circuits Always Active (30A)
. . .198
nstrument Panel Fuse Block
- Right Headlight (15A)
~ - Left Headlight; High Beam Indicatol
Light
( 1 SA)
I- Taillights; Interior Light; Sidemarker Lights; Instrument Cluster Lights
( 1 SA)
. - Stop Lights; Horn (15A)
~ - Hazard Lights (15A)
I - Door Lock (Option) (20A)
’ - Lighter; Radio (20A)
1 - Ignition System; Warning and
1 - Turn Signal Lights; Back-up Lights
Indicator Lights
( 1 SA)
( 1 SA)
10 - Wiper/Washer ( 15A)
1 1 - Rear Defogger (1 5A)
12 - Heater
(25A)
13
- Rear Wheel Anti-Lock Main Relay
(20A)
14 - Electronic Fuel Injection Main
Relay
( 15A)
ProCarManuals.com

Customer Assistance for the Hearing
Customer Assistance Information
. . 233
Customer Satisfaction Procedure
... 234
or Speech Impaired (TDD)
..... 234
Damage. Finish
............... 194
Damage. Sheet Metal
............ 193
Daytime Running Lights
......... 56
Daytime Running Lights Indicator Light
....................... 72
Deep Standing Water.
Driving through
.............. 41
Defects. Safety
Reporting to General Motors
.... 236
Reporting to the Canadian
Reporting to the United States
Government
............... 236
Government
............... 236
Defensive Driving
.............. 100
Defogger. Rear Window ......... 86
Defogging and Defrosting
Windows
................... 85
Dehumidifying ................. 85
Dimensions. Vehicle ............ 202
Doing Your Own Service Work
.... 156
Dome Light ................... 57
Door Locks
.................... 37
Door Storage Compartments
...... 60
Downhill. Driving
.............. 1 12
Drive. Four-wheel
.............. 46
Drive. Four-wheel (Service)
...... 170 Driver Position
(Safety Belts)
... 20
Driving
Across an Incline
............. 11 3
At Night .................... 1 16
City
........................ 119
Defensive
................... 100
Downhill
................... 1 12
Drunken
.................... 100
Freeway
.................... 120
Guidelines
.................. 107
In Mud. Sand. Ice or Snow ..... 1 15
In the Rain .................. 117
In Water .................... 115
0ff.Road. With Your Geo Four-
Wheel-Drive Vehicle
........ 108
On Curves .................. 104
On Off-Road Hills
............ I10
On Snow or Ice
.............. 123
Through Deep Standing Water
... 41
Uphill
...................... 111
Winter
...................... 122
With a Trailer
................ 127
Your Tracker. About ........... 3
Drunken Driving
............... 100
Easy Entry Seats
.............. 12
Electrical Equipment. Add-on
..... 196
Emergencies. Braking in
......... 104
Emergencies. Steering in
......... 105 Engine
Coolant
..................... 170
Coolant (Block) Heater
........ 41
Coolant Temperature Gage
..... 70
Exhaust
..................... 51
Identification
................ 196
Oil
........................ 162
Oil Pressure Light
............ 71
Overheating
................. 140
Specifications
................ 200
Starting Your
................ 40
Environment. Your Vehicle
and the
..................... 204
Exhaust. Engine
................ 51
Extender. Safety Belt
....... 1 .... 33
Exterior Bright Metal Parts.
Protecting
................... 192
Fabric Protection
.............. 190
Fan Control Lever
.............. 84
Features and
Controls ........... 35
Filling Your Tank ............... 158
Filter. Air. Replacement
.......... 166
Finish Care (Paint)
.............. 192
Finish Damage (Paint)
........... 194
Flashers. Hazard Warning
........ 132
Flat Tire. Changing a
............ 146
Flat.
If a Tire Goes .............. 146
Flow-Through Ventilation System . . 86
245 ..
ProCarManuals.com

Index
Fluid Automatic Transmission
....... 167
Brake
...................... 174
Manual Transmission
.......... 168
Power Steering ............... 173
Recommended
............... 225
Windshield Washer
........... 174
Foreign Countries. Fuels
in ....... 1.57
Foreign Material Paint Damage
.... 194
Four-wheel Drive
.............. 46
Four-wheel Drive (Service) ....... 170
Four-Wheel-Drive Vehicle. Off-Road
Driving With Your Geo
........ 108
Freeway Driving ............... 120
Freewheeling Hubs
Automatic
................. 47
Manual
..................... 46
Ashtray
..................... 63
Axle
....................... 170
Seat ........................ 10
Seat Side Pockets ............. 61
Seatbacks. Reclining .......... IO
Towing Hook-ups ............. 138
Fuel ......................... 156
FuelGage
..................... 69
Fuels in Foreign Countries ........ 157
Fuse Block, Instrument Panel ..... 198
Fuse Block, Main ............... 198
Fuses and Circuit Breakers ....... 196
Folding Rear
Seat
............... 13
Front Gages
Engine Coolant Temperature
.... 70
Fuel
....................... 69
Warning Lights and Indicators ... 68
Gasolines for Cleaner Air ........ 157
Glass
......................... 19 1
Glove Box .................... 60
GM Participation
in RBB Auto Line .
Alrernative Dispute Resolution
Program
.................. 235
Grips . Passenger Assist .......... 62
Guidelines. Driving ............. 107
Halogen Bulbs
............... 177
Hazard Warning Flashers
......... 132
Head Restraints
................ I1
Headlights .................... 177
Heater Controls
................ 84
Heater. Engine Coolant
(Block) .... 41
Heating ....................... 84
Highway Hypnosis
.............. 12 1
Hill and Mountain Roads ......... 121
Hill. Approaching a ............. 1 IO
Hitches ....................... 126
Hood Release .................. IS9
Hood . Checking Things under the . . 159
Hook.Ups . Front Towing ......... 138
Hook.Ups. Rear Towing
......... I39
Horn ......................... 53
Headlight High/Low Beam ....... 56
How to Add Coolant to the
How
to Add Coolant to the
Hubs. Freewheeling
Coolant
Recovery Tank
........ 142
Radiator
............... . .144
Automatic
................... 47
Manual
..................... 46
Hydroplaning .................. 118
Hypnosis. Highway
............. 121
Identification Number. Vehicle .... 196
Identification. Engine ............ 196
If a Tire Goes Flat .............. 146
If You’re Stuck: In Sand. Mud. Ice
or Snow .................... 153
Ignition Switch
................. 39
Incline
. Driving Across an ........ 113
Incline. Stalling on
an ........... 114
Intlation - Tire Pressure .......... 184
Inside Day/Night Rearview Mirror
...................... 59
Inside Rearview Mirror
.......... 59
Instrument Cluster .............. 66
Instrument Panel ............... 64
Instrument Panel Bins
........... 61
Instrument Panel Fuse Block ...... 198
Instrument Panel
. Cleaning the
Topof
..................... 191
Interior Lights ................. 57
Jump Starting
................. 133
... 246
ProCarManuals.com

1 Keys ....................... 36
Label. Certification/Tire
........ 18 1
Label. Service Parts Identification . . 196
Lamp. Malfunction Indicator
...... 7 1
Lane Change Indicator.
Turn Signal and
.............. 54
Lap-Shoulder Belt (Safety Belts)
... 20
Larger Children (Safety Belts)
..... 32
Leaving Your Vehicle
............ 37
Leaving Your Vehicle with the
Engine Running
.............. 49
Lighter. Ashtrays and
............ 62
Lights Brake System Warning
......... 69
Bulb Replacement
............ 177
Charging System
............. 70
Check Engine
................ 71
Daytime Running ............. 56
Daytime Running Lights
Indicator
.................. 72
Dome
...................... 57
Engine Oil Pressure
........... 71
Gages and Indicators. Warning
. . 68
Interior ..................... 57
Malfunction Indicator Lamp
.... 71
Operation
of ................. 55
Safety Belt Reminder .......... 19
Lights On Reminder
............. 55
Loading Your Vehicle .... . 181 Locks.
Door ................... 37
Loss of Control
................ 107
Lubricant Front Axle
.................. 170
Rear Axle
................... 169
Recommended
............... 225
Transfer Case
................ 170
Main Fuse Block
............. 198
Maintenance Inspections. Periodic
.......... 223
Record
..................... 228
Schedule
.................... 203
Services. Scheduled
........... 206
Underbody
.................. 194
When Trailer Towing
.......... 129
Malfunction Indicator Lamp
...... 71
Manual
Adjust Mirrors. Outside
........ 60
Freewheeling Hubs ........... 46
Transmission Fluid
............ 168
Windows
................... 52
Master Cylinder. Brake
.......... 174
Mirrors Convex Outside
.............. 59
Inside Daymight Rearview
..... 59
Inside Rearview
.............. 59
Outside Manual Adjust
........ 60
Mountain Roads. Hill and ........ 121
Transmission. Five-Speed
...... 44 New
Vehicle “Break-In”
....... 39
Night Driving
.................. 116
Night Vision
................... 117
Nuts. Wheel
................... 202
Odometer. Speedometer and
..... 66
Odometer. Trip
................. 67
Off-Road Driving After
....................... 116
Before You Go
............... 108
Getting Familiar With
......... 109
Loading Your Vehicle for
....... 108
On Hills
.................... 110
With Your Geo Four-Wheel-Drive
Vehicle
................... 108
Off-Road Recovery
............. 105
Oil. Engine .................... 162
Opening and Closing Your Rear
Window
.................... 75
Opening and Closing Your
sunroof ..................... 74
Operation
of Lights ............. 55
Outside Manual Adjust Mirrors .... 60
Overheating. Engine
............ 140
Owner Checks and Services
....... 218
P (Park) Shifting into ...
P (Park). Shifting out of ...
.... 48
.... 49
247 ... ProCarManuals.com

Index
Steam Corning from Your Engine . . 140
Column. Adjustable
........... 53
Fluid. Power ................. 173
Power
...................... 104
Steering
...................... 104
In Emergencies ............... 105
Tips
........................ 104
Compartments. Door
.......... 60
Storage
Preparing Your Canvas Top for
. . 80
Vehicle
..................... 176
Stuck: In Sand. Mud. Ice or Snow
. . 153
Sun Visors
.................... 61
Sunroof. Opening and Closing
Your
....................... 74
Switch. Ignition
................ 39
Symbols. Vehicle
............... 7
Symbols. Safety Warnings and .... 5
Tachometer .................. 68
Tailgate
....................... 38
Tank. Filling Your .............. 158
Temperature Control Lever ....... 84
Terrain. Scanning
the ............ 109
Theft ......................... 39
Theft Deterrent Feature AM/FM Stereo
with Cassette Tape
AM/FM Stereo
with Cassette Tape
and Compact Disc Player
..... 96
Player
.................... 91
Thermostat .................... 172
... 250
Tips. Steering ................ 104
Tips. Ventilation
................ 87
Tires
......................... 183
Balance. Wheel Alignment and
. . 187
Buying New ................. 186
Chains
..................... 188
Inflation Pressure
............. 184
Inspection and Rotation
........ 185
Temperature Grades
........... 187
Traction Grades
.............. 187
Treadwear
................... 186
Uniform Quality Grading
....... 186
When It’s Time for New
....... 186
AM/FM Stereo
............... 89
and Compact Disc Player
..... 93
Player
.................... 90
Top Strap (Child Restraints)
....... 28
Top. Convertible
................ 72
Torque
Lock .................. 49
Towing
A Trailer .................... 125
Rear Hook-Ups
.............. 139
Recreational Vehicle
.......... 129
Your Vehicle
................. 136
Trailer Brakes
.................. 127
Changing a Flat .............. 146
Loading
.................... 18 I
Tone. Setting the
AM/FM Stereo
with Cassette Tape
AM/FM Stereo
with Cassette Tape
Front Hook-Ups
.............. 138 Trailer. Towing
a
............... 125
Transfer Case
.................. 47
Transfer Case (Service)
.......... 170
Transmission Automatic
................... 42
Fluid. Automatic
............. 167
Fluid. Manual
................ 168
Manual
..................... 44
Transportation. Courtesy
......... 237
Traveling to Remote Areas
....... 109
Trip Odometer
................. 67
Trip. Before Leaving on a Long
.... 120
Turn Signal and Lane Change
Indicator
.................... 54
Turn SignalLights Control/Headlight
Beam Lever
................. 54
Underbody Maintenance ....... 194
Understanding Radio Reception ... 97
Uniform Tire Quality Grading
..... 186
Uphill. Driving ................. 111
Used Oil. What to Do With ....... 165
Used Replacement Wheels
........ 189
Using the Recovery Hooks ....... 154
Vehicle Control of a
................. 102
Damage Warnings ............ 6
Dimensions ................. 202
Environment and Your
......... 204
Identification Number
(VIN) .... 196
ProCarManuals.com
