CHEVROLET TRACKER 1999 2.G Owners Manual

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-61 Instrument Panel Fuse Block
JE±16±0019±X
This fuse box is under the left side of the instrument
panel. The fuses here protect each separate circuit
including headlamps. If you have electrical failure,
check here first.
JE±16±0022±X
Fuse Usage
P/W Power Windows
DOM Dome Light
TAIL License Plate Light, Clearance/Marker
Lights, Instrument Panel Illumination
HAZ Hazard Lights
IG O
2 Sensor Heater, Cruise Control,
Ignition Coil, Meter, G Sensor

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-62
Fuse Usage
CIG Cigar Lighter, Radio, Power Mirror
D/L Door Locks
STP Brake Light, Horn, Center High
-Mounted
Stop Lamp
FOG Not Used
DEF Rear Window Defogger, DRL
S/H Not Used
TRN Turn Signal, Back
-Up Light
WIP Windshield Wiper/Washer, Rear Window
Wiper/Washer
Please note, fuses for the air bags are located next to the
instrument panel fuse block.
Engine Compartment Fuse Block
JE±16±0020±X
The main fuse box in your engine compartment protects
all electrical loads.
For access to the main fuses, pull off the cover. A spare
fuse is also inside the fuse box.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-63
JE±16±0023±X
Fuse Usage
1 Accessory Power Outlet
2 Electronic Fuel Injection System
3 Right Headlamp
4 Left Headlamp, High
-Beam Indicator
5 Heater
6 Hazard Lamps, Rear Combination
Lamps, Dome Light, HornFuse Usage
7 Cigar Lighter, Radio, I.G. Coil, Meter,
Wiper, Washer, Rear Defroster, Turn
Signals, Back
-Up Lamps
8 Anti
-Lock Brake System
9 All Electrical Loads
10 Air Conditioning
Replacement Bulbs
Lamps Bulb Number. . . . . . . . . . . . . . . . . . . . . . . . .
Back
-up Lamp 921. . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome GM Part No. 96051559. . . . . . . . . . . . . . . . . . .
or equivalent
Front Parking and Turn Signal 1157 NA. . . . . . . . . . .
Headlamp (Halogen)
Right Hand GM Part No. 91174685 or equivalent. .
Left Hand GM Part No. 91174687 or equivalent. . .
Rear Hazard and Turn Signal 921. . . . . . . . . . . . . . . .
Rear Parking and Stop GM Part No. 91174349. . . . . .
or equivalent
Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-64
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions.
Air ConditioningSee the refrigerant . . . . . . . . . . . . .
information label under the hood.
Cooling System
1.6L Engine 5.8 quarts (5.5 L). . . . . . . . . . . . . . . . . .
2.0L Engine 6.9 quarts (6.5 L). . . . . . . . . . . . . . . . . .
Crankcase with Filter
1.6L Engine 4.4 quarts (4.2 L)**. . . . . . . . . . . . . . . .
2.0L Engine 5.5 quarts (5.2 L)**. . . . . . . . . . . . . . . .
Fuel Tank
Tw o
-Door Convertible 14.8 gallons (56 L). . . . . . . . .
Four
-Door Hardtop 17.4 gallons (66 L). . . . . . . . . . .
Automatic Transmission
Drain and Refill 2.6 quarts (2.5 L)*. . . . . . . . . . . . . .
Manual Transmission
Four
-Wheel Drive 1.6 quarts (1.5 L)*. . . . . . . . . . . .
Tw o
-Wheel Drive 2.0 quarts (1.9 L)*. . . . . . . . . . . . Differential
Front 1.1 quarts (1.0 L)*. . . . . . . . . . . . . . . . . . . . . . .
Rear 2.3 quarts (2.2 L)*. . . . . . . . . . . . . . . . . . . . . . .
Transfer Case1.8 quarts (1.7 L) . . . . . . . . . . . . . . . .
*Recheck fluid level after filling. See ªAutomatic
Transmission Fluidº or ªManual Transmission Fluidº in
the Index.
**When changing the oil filter, additional oil may be
needed. Recheck the oil level after filling. See ªEngine
Oilº in the Index.
1.6L Engine Specifications
VIN Engine Code 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 190
F (88
C) . . . . . . . . . . .
2.0L Engine Specifications
VIN Engine Code C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 127. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 179
F (82
C) . . . . . . . . . . .

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-65 Wheel and Tires
Wheel Nut Torque 69 lb-ft (95 N´m) . . . . . . . . . . . . .
Tire Pressure See the Tire
-Loading . . . . . . . . . . . . . .
Information label. See ªLoading
Your Vehicleº in the Index.
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
See the refrigerant charge label under the hood for
information regarding refrigerant capacity.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter GM Part No. 91174457. . . .
or equivalent
Engine Oil Filter
1.6L Engine GM Part No. 25011520. . . . . . . . . . . . .
or equivalent (PF
-53)
2.0L Engine GM Part No. 25014441. . . . . . . . . . . . .
or equivalent (PF
-1245)
PCV Valve
1.6L Engine GM Part No. 96068664. . . . . . . . . . . .
or equivalent
2.0L Engine GM Part No. 91174516. . . . . . . . . . . .
or equivalent
Spark Plugs GM Part No. 91173854. . . . . . . . . . . . . .
or equivalent
Passenger Compartment
Air Filter GM Part No. 91175057. . . . . . . . . . . . . . . .
or equivalent

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
6-66 Vehicle Dimensions
Length
Tw o
-Door Convertible 148.8 inches (378.0 cm). . . . .
Four
-Door Hardtop 159.8 inches (405.9 cm). . . . . . .
Width
Tw o
-Door Convertible 66.7 inches (169.4 cm). . . . . .
Four
-Door Hardtop 66.7 inches (169.4 cm). . . . . . . .
Height
Tw o
-Door Convertible
Tw o
-Wheel Drive 66.5 inches (168.9 cm). . . . . . . .
Four
-Wheel Drive 66.5 inches (168.9 cm). . . . . . . .
Four
-Door Hardtop
Tw o
-Wheel Drive 65.7 inches (166.9 cm). . . . . . . .
Four
-Wheel Drive 66.5 inches (168.9 cm). . . . . . . . Wheelbase
Tw o
-Door Convertible 86.6 inches (220.0 cm). . . . . .
Four
-Door Hardtop 97.6 inches (247.9 cm). . . . . . . .
Tread
Front 57.3 inches (145.5 cm). . . . . . . . . . . . . . . . . . . .
Rear 57.5 inches (146.1 cm). . . . . . . . . . . . . . . . . . . .

7-
Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-9 Short Trip/City Scheduled Maintenance
7
-30 Long Trip/Highway Scheduled Maintenance7
-45 Part B: Owner Checks and Services
7
-49 Part C: Periodic Maintenance Inspections
7
-51 Part D: Recommended Fluids and Lubricants
7
-54 Part E: Maintenance Record

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
7-2
X±07±0701±S
X±07±0702±S
Have you purchased the GM Protection Plan?
The Plan supplements your new vehicle warranties.
See your Warranty and Owner Assistance booklet, or
your dealer for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
7-3
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you are skilled enough to do some work on your
vehicle, you will probably want to get the service
information. See ªService and Owner Publicationsº in
the Index.
ªPart B: Owner Checks and Servicesº tells you what
should be checked and when. It also explains what you
can easily do to help keep your vehicle in good condition.ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service department
or another qualified service center should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products to help keep your vehicle
properly maintained. These products, or their
equivalents, should be used whether you do the work
yourself or have it done.
ªPart E: Maintenance Recordº provides a place for
you to record the maintenance performed on your
vehicle. Whenever any maintenance is performed, be
sure to write it down in this part. This will help you
determine when your next maintenance should be done.
In addition, it is a good idea to keep your maintenance
receipts. They may be needed to qualify your vehicle for
warranty repairs.

Second Printing for Chevrolet Tracker Owner's Manual ± 1999
yellowblue
7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your vehicle
in good working condition. But we don't know exactly
how you'll drive it. You may drive very short distances
only a few times a week. Or you may drive long
distances all the time in very hot, dusty weather. You may
use your vehicle in making deliveries. Or you may drive
it to work, to do errands or in many other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.
This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.The proper fluids and lubricants to use are listed in
Part D. Make sure whoever services your vehicle uses
these. All parts should be replaced and all necessary
repairs done before you or anyone else drives
the vehicle.
These schedules are for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.
Selecting the Right Schedule
First you'll need to decide which of the two schedules is
right for your vehicle. Here's how to decide which
schedule to follow:
