engine CHEVROLET TRACKER 2000 2.G Owners Manual

6-60
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment
can keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by fuses, circuit breakers and thermal links
in the wiring itself. This greatly reduces the chance of
fires caused by electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the correct size.
If you ever have a problem on the road and don't have a
spare fuse, you can borrow one. Just pick some feature
of your vehicle that you can get along without
-- like the
radio or cigarette lighter
-- and use its fuse, if it is the
size you need. Replace it as soon as you can.
Before replacing a fuse, turn every vehicle electrical
switch off.
There are two fuse blocks in your vehicle: the
instrument panel fuse block and the engine
compartment fuse block.

6-62
Fuse Usage
CIG Cigar Lighter, Radio, Power Mirror
D/L Door Locks
STP Brake Light, Horn, Center High
-Mounted
Stop Lamp
FOG Not Used
DEF Rear Window Defogger, DRL
S/H Not Used
TRN Turn Signal, Back
-Up Light
WIP Windshield Wiper/Washer, Rear Window
Wiper/Washer
Please note, fuses for the air bags are located next to the
instrument panel fuse block.
Engine Compartment Fuse Block
The main fuse box in your engine compartment protects
all electrical loads.
For access to the main fuses, pull off the cover. A spare
fuse is also inside the fuse box.

6-64
Replacement Bulbs
Lamps Bulb Number. . . . . . . . . . . . . . . . . . . . . . . . .
Back
-up Lamp 921. . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome GM Part No. 96051559. . . . . . . . . . . . . . . . . . .
or equivalent
Front Parking and Turn Signal 1157 NA. . . . . . . . . . .
Headlamp (Halogen)
Right Hand GM Part No. 91174685. . . . . . . . . . . . .
or equivalent
Left Hand GM Part No. 91174687. . . . . . . . . . . . . .
or equivalent
Rear Hazard and Turn Signal 921. . . . . . . . . . . . . . . .
Rear Parking and Stop GM Part No. 91174349. . . . . .
or equivalent
Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions.
Air ConditioningSee the refrigerant . . . . . . . . . . . .
information label under the hood.Cooling System
1.6L Engine 5.8 quarts (5.5 L). . . . . . . . . . . . . . . . . .
2.0L Engine 6.9 quarts (6.5 L). . . . . . . . . . . . . . . . . .
Crankcase with Filter
1.6L Engine 4.4 quarts (4.2 L)**. . . . . . . . . . . . . . . .
2.0L Engine 5.5 quarts (5.2 L)**. . . . . . . . . . . . . . . .
Fuel Tank
Tw o
-Door Convertible 14.8 U.S. Gallons (56 L). . . . .
Four
-Door Hardtop 17.4 U.S. Gallons (66 L). . . . . . .
Automatic Transmission
Drain and Refill 2.6 quarts (2.5 L)*. . . . . . . . . . . . . .
Manual Transmission
Four
-Wheel Drive 1.6 quarts (1.5 L)*. . . . . . . . . . . .
Tw o
-Wheel Drive 2.0 quarts (1.9 L)*. . . . . . . . . . . .
Differential
Front 1.1 quarts (1.0 L)*. . . . . . . . . . . . . . . . . . . . . . .
Rear 2.3 quarts (2.2 L)*. . . . . . . . . . . . . . . . . . . . . . .
Transfer Case1.8 quarts (1.7 L) . . . . . . . . . . . . . . .
*Recheck fluid level after filling. See ªAutomatic
Transmission Fluidº or ªManual Transmission Fluidº in
the Index.
**When changing the oil filter, additional oil may be
needed. Recheck the oil level after filling. See ªEngine
Oilº in the Index.

6-65 1.6L Engine Specifications
VIN Engine Code 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 190
F (88
C) . . . . . . . . . . .
2.0L Engine Specifications
VIN Engine Code C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 127. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 179
F (82
C) . . . . . . . . . . .
Wheel and Tires
Wheel Nut Torque 69 lb-ft (95 N´m) . . . . . . . . . . . . .
Tire Pressure See the Tire
-Loading . . . . . . . . . . . . . .
Information label. See ªLoading
Your Vehicleº in the Index.
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter GM Part No. 91174457. . . .
or equivalent
Engine Oil Filter
1.6L Engine GM Part No. 25011520. . . . . . . . . . . . .
or equivalent (PF
-53)
2.0L Engine GM Part No. 91173772. . . . . . . . . . . . .
PCV Valve
1.6L Engine GM Part No. 96068664. . . . . . . . . . . . .
or equivalent
2.0L Engine GM Part No. 91174516. . . . . . . . . . . . .
or equivalent
Spark Plugs GM Part No. 91173854. . . . . . . . . . . . . .
or equivalent
Passenger Compartment
Air Filter GM Part No. 91175057. . . . . . . . . . . . . . . .
or equivalent

Scheduled Maintenance
7-5
Short Trip/City Definition
Follow the Short Trip/City Scheduled Maintenance if
any one of these conditions is true for your vehicle:

Most trips are less than 5 to 10 miles (8 to 16 km).
This is particularly important when outside
temperatures are below freezing.

Most trips include extensive idling (such as frequent
driving in stop
-and-go traffic).

You frequently tow a trailer or use a carrier on top of
your vehicle.

If the vehicle is used for delivery service, police, taxi
or other commercial application.
One of the reasons you should follow this schedule if
you operate your vehicle under any of these conditions
is that these conditions cause engine oil to break
down sooner.
Short Trip/City Intervals
Every 3,000 Miles (5 000 km): Engine Oil and Filter
Change (or 3 months, whichever occurs first).
Every 6,000 Miles (10 000 km): Passenger
Compartment Air Filter Inspection. Tire Rotation.
Every 15,000 Miles (25 000 km): Engine Air Cleaner
Filter Inspection, if driving in dusty conditions. Front
Wheel Bearing Repack (2WD only) (or at each brake
relining, whichever occurs first). Automatic
Transmission Service (severe conditions only).
Manual Transmission Fluid Change. Transfer Case
Fluid Change. Differential Fluid Change. Valve Lash
(Clearance) Adjustment (1.6L Code 6 engine only).
Propeller Shafts and U
-Joints Inspection (or every
15 months, whichever occurs first).
(Continued)

Scheduled Maintenance
7-6
Short Trip/City Intervals
Every 30,000 Miles (50 000 km): Engine Air Cleaner
Filter Replacement. Passenger Compartment Air
Filter Replacement. Spark Plug Replacement. Engine
Accessory Drive Belt Inspection (or every 24 months,
whichever occurs first). Cooling System Service
(or every 30 months, whichever occurs first).
Fuel Tank, Cap and Lines Inspection. Fuel Filter
Replacement (or every 30 months, whichever
occurs first).
Every 45,000 Miles (75 000 km): Automatic
Transmission Fluid Hose Replacement
(or every 45 months, whichever occurs first).
Every 50,000 Miles (83 000 km): Positive Crankcase
Ventilation (PCV) Valve Replacement.
Short Trip/City Intervals
Every 60,000 Miles (100 000 km): Fuel Tank Cap
Gasket Replacement. Emission System Hoses
Inspection. Camshaft Timing Belt Replacement
(1.6L Code 6 engine only). Brake Fluid Service.
Spark Plug Wire Replacement (or every 60 months,
whichever occurs first). Wiring Harness and
Connectors Inspection (or every 60 months,
whichever occurs first).
At 90,000 Miles (150 000 km): Camshaft Timing Belt
Inspection (1.6L Code 6 engine only).
Every 100,000 Miles (166 000 km): Automatic
Transmission Service (normal conditions). Evaporative
Emissions Canister Replacement.
These intervals only summarize maintenance services.
Be sure to follow the complete scheduled maintenance
on the following pages.

Scheduled Maintenance
7-7
Long Trip/Highway Definition
Follow this scheduled maintenance only if none of
the conditions from the Short Trip/City Scheduled
Maintenance are true. Do not use this schedule if the
vehicle is used for trailer towing, driven in a dusty area
or used off paved roads. Use the Short Trip/City
schedule for these conditions.
Driving a vehicle with a fully warmed engine under
highway conditions causes engine oil to break
down slower.
Long Trip/Highway Intervals
Every 7,500 Miles (12 500 km): Engine Oil and Filter
Change (or every 7.5 months, whichever occurs first).
Tire Rotation.
Every 15,000 Miles (25 000 km): Automatic
Transmission Service (severe conditions only).
Passenger Compartment Air Filter Inspection. Valve
Lash (Clearance) Adjustment (1.6L Code 6 engine
only). Propeller Shafts and U
-Joints Inspection
(or every 15 months, whichever occurs first).
Every 30,000 Miles (50 000 km): Engine Accessory
Drive Belt Inspection (or every 24 months, whichever
occurs first). Cooling System Service (or every
30 months, whichever occurs first). Fuel Tank, Cap and
Lines Inspection. Spark Plug Replacement. Engine Air
Cleaner Filter Replacement. Passenger Compartment
Air Filter Replacement. Front Wheel Bearing Repack
(2WD only) (or at each brake relining, whichever
occurs first). Manual Transmission Fluid Change.
Transfer Case Fluid Change. Differential Fluid Change.
Fuel Filter Replacement (or every 30 months,
whichever occurs first).
(Continued)

Scheduled Maintenance
7-8
Long Trip/Highway Intervals
Every 45,000 Miles (75 000 km): Automatic
Transmission Fluid Hose Replacement
(or every 45 months, whichever occurs first).
Every 50,000 Miles (83 000 km): Positive Crankcase
Ventilation (PCV) Valve Replacement.
Every 60,000 Miles (100 000 km): Fuel Tank Cap
Gasket Replacement. Emission System Hoses
Inspection. Camshaft Timing Belt Replacement
(1.6L Code 6 engine only). Spark Plug Wire
Replacement (or every 60 months, whichever occurs
first). Wiring Harness and Connectors Inspection
(or every 60 months, whichever occurs first).
Brake Fluid Service.
Long Trip/Highway Intervals
At 90,000 Miles (150 000 km): Camshaft Timing Belt
Inspection (1.6L Code 6 engine only).
Every 100,000 Miles (166 000 km): Automatic
Transmission Service (normal conditions).
Evaporative Emissions Canister Replacement.
These intervals only summarize maintenance services.
Be sure to follow the complete scheduled maintenance
on the following pages.

Short Trip/City Scheduled Maintenance
7-10
3,000 Miles (5 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.
6,000 Miles (10 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.

Inspect passenger compartment air filter.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
9,000 Miles (15 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.
12,000 Miles (20 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.

Inspect passenger compartment air filter.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Short Trip/City Scheduled Maintenance
7-11
15,000 Miles (25 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.

Inspect engine air cleaner filter if you are driving in dusty conditions. Replace
filter if necessary.
An Emission Control Service. (See footnote
.)
For Two
-Wheel-Drive vehicles only: Clean and repack the front wheel
bearings (or at each brake relining, whichever occurs first).
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90F (32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the fluid
and filter every 100,000 miles (166 000 km).
Change manual transmission fluid.
Change transfer case fluid.
(Continued)
ACTUAL
SERVICED BY:MILEAGE
DATE
