Fuel lines CHEVROLET TRACKER 2000 2.G Owners Manual

4-29 After Off-Road Driving
Remove any brush or debris that has collected on
the underbody, chassis or under the hood.
These accumulations can be a fire hazard.
After operation in mud or sand, have the brake linings
cleaned and checked. These substances can cause
glazing and uneven braking. Check the body structure,
steering, suspension, wheels, tires and exhaust system
for damage. Also, check the fuel lines and cooling
system for any leakage.
Your vehicle will require more frequent service due to
off
-road use. Refer to the Maintenance Schedule for
additional information.
Driving at Night
Night driving is more dangerous than day driving.
One reason is that some drivers are likely to be
impaired
-- by alcohol or drugs, with night vision
problems, or by fatigue.

6-3
CAUTION:
You can be injured and your vehicle could be
damaged if you try to do service work on a
vehicle without knowing enough about it.

Be sure you have sufficient knowledge,
experience, the proper replacement parts
and tools before you attempt any vehicle
maintenance task.

Be sure to use the proper nuts, bolts and
other fasteners. ªEnglishº and ªmetricº
fasteners can be easily confused. If you use
the wrong fasteners, parts can later break
or fall off. You could be hurt.
Adding Equipment to the Outside of
Your Vehicle
Things you might add to the outside of your vehicle can
affect the airflow around it. This may cause wind noise
and affect windshield washer performance. Check with
your dealer before adding equipment to the outside of
your vehicle.
Fuel
Use regular unleaded gasoline rated at 87 octane or
higher. It is recommended that the gasoline meet
specifications which have been developed by the
American Automobile Manufacturers Association
(AAMA) and endorsed by the Canadian Motor Vehicle
Manufacturers Association for better vehicle
performance and engine protection. Gasolines meeting
the AAMA specification could provide improved
driveability and emission control system performance
compared to other gasolines.
Be sure the posted octane is at least 87. If the octane is
less than 87, you may get a heavy knocking noise when
you drive. If it's bad enough, it can damage your engine.
If you're using fuel rated at 87 octane or higher and you
hear heavy knocking, your engine needs service. But
don't worry if you hear a little pinging noise when
you're accelerating or driving up a hill. That's normal,
and you don't have to buy a higher octane fuel to get rid
of pinging. It's the heavy, constant knock that means
you have a problem.

6-4
If your vehicle is certified to meet California Emission
Standards (indicated on the underhood emission control
label), it is designed to operate on fuels that meet
California specifications. If such fuels are not available
in states adopting California emissions standards, your
vehicle will operate satisfactorily on fuels meeting
federal specifications, but emission control system
performance may be affected. The malfunction indicator
lamp on your instrument panel may turn on and/or your
vehicle may fail a smog
-check test. (See ªMalfunction
Indicator Lampº in the Index.) If this occurs, return to
your authorized Chevrolet dealer for diagnosis to
determine the cause of failure. In the event it is
determined that the cause of the condition is the type of
fuels used, repairs may not be covered by your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane
-enhancing additive
called methylcyclopentadienyl manganese tricarbonyl
(MMT); ask your service station operator whether or not
the fuel contains MMT. General Motors does not
recommend the use of such gasolines. If fuels containing
MMT are used, spark plug life may be reduced and your
emission control system performance may be affected.
The malfunction indicator lamp on your instrument
panel may turn on. If this occurs, return to your
authorized Chevrolet dealer for service.To provide cleaner air, all gasolines in the United States
are now required to contain additives that will help
prevent deposits from forming in your engine and fuel
system, allowing your emission control system to
function properly. Therefore, you should not have to add
anything to the fuel. In addition, gasolines containing
oxygenates, such as ethers and ethanol, and
reformulated gasolines may be available in your area to
contribute to clean air. General Motors recommends that
you use these gasolines, particularly if they comply with
the specifications described earlier.
NOTICE:
Your vehicle was not designed for fuel that
contains methanol. Don't use it. It can corrode
metal parts in your fuel system and also damage
plastic and rubber parts. That damage wouldn't
be covered under your warranty.

6-57
Finish Damage
Any stone chips, fractures or deep scratches in the finish
should be repaired right away. Bare metal will corrode
quickly and may develop into a major repair expense.
Minor chips and scratches can be repaired with touch
-up
materials available from your dealer or other service
outlets. Larger areas of finish damage can be corrected
in your dealer's body and paint shop.
Underbody Maintenance
Chemicals used for ice and snow removal and dust
control can collect on the underbody. If these are not
removed, accelerated corrosion (rust) can occur on the
underbody parts such as fuel lines, frame, floor pan
and exhaust system even though they have
corrosion protection.
At least every spring, flush these materials from the
underbody with plain water. Clean any areas where mud
and other debris can collect. Dirt packed in closed areas
of the frame should be loosened before being flushed.
Your dealer or an underbody car washing system can do
this for you.
Chemical Paint Spotting
Some weather and atmospheric conditions can create a
chemical fallout. Airborne pollutants can fall upon and
attack painted surfaces on your vehicle. This damage
can take two forms: blotchy, ringlet
-shaped
discolorations, and small irregular dark spots etched into
the paint surface.
Although no defect in the paint job causes this,
Chevrolet will repair, at no charge to the owner, the
surfaces of new vehicles damaged by this fallout
condition within 12 months or 12,000 miles (20 000 km)
of purchase, whichever occurs first.

Scheduled Maintenance
7-6
Short Trip/City Intervals
Every 30,000 Miles (50 000 km): Engine Air Cleaner
Filter Replacement. Passenger Compartment Air
Filter Replacement. Spark Plug Replacement. Engine
Accessory Drive Belt Inspection (or every 24 months,
whichever occurs first). Cooling System Service
(or every 30 months, whichever occurs first).
Fuel Tank, Cap and Lines Inspection. Fuel Filter
Replacement (or every 30 months, whichever
occurs first).
Every 45,000 Miles (75 000 km): Automatic
Transmission Fluid Hose Replacement
(or every 45 months, whichever occurs first).
Every 50,000 Miles (83 000 km): Positive Crankcase
Ventilation (PCV) Valve Replacement.
Short Trip/City Intervals
Every 60,000 Miles (100 000 km): Fuel Tank Cap
Gasket Replacement. Emission System Hoses
Inspection. Camshaft Timing Belt Replacement
(1.6L Code 6 engine only). Brake Fluid Service.
Spark Plug Wire Replacement (or every 60 months,
whichever occurs first). Wiring Harness and
Connectors Inspection (or every 60 months,
whichever occurs first).
At 90,000 Miles (150 000 km): Camshaft Timing Belt
Inspection (1.6L Code 6 engine only).
Every 100,000 Miles (166 000 km): Automatic
Transmission Service (normal conditions). Evaporative
Emissions Canister Replacement.
These intervals only summarize maintenance services.
Be sure to follow the complete scheduled maintenance
on the following pages.

Scheduled Maintenance
7-7
Long Trip/Highway Definition
Follow this scheduled maintenance only if none of
the conditions from the Short Trip/City Scheduled
Maintenance are true. Do not use this schedule if the
vehicle is used for trailer towing, driven in a dusty area
or used off paved roads. Use the Short Trip/City
schedule for these conditions.
Driving a vehicle with a fully warmed engine under
highway conditions causes engine oil to break
down slower.
Long Trip/Highway Intervals
Every 7,500 Miles (12 500 km): Engine Oil and Filter
Change (or every 7.5 months, whichever occurs first).
Tire Rotation.
Every 15,000 Miles (25 000 km): Automatic
Transmission Service (severe conditions only).
Passenger Compartment Air Filter Inspection. Valve
Lash (Clearance) Adjustment (1.6L Code 6 engine
only). Propeller Shafts and U
-Joints Inspection
(or every 15 months, whichever occurs first).
Every 30,000 Miles (50 000 km): Engine Accessory
Drive Belt Inspection (or every 24 months, whichever
occurs first). Cooling System Service (or every
30 months, whichever occurs first). Fuel Tank, Cap and
Lines Inspection. Spark Plug Replacement. Engine Air
Cleaner Filter Replacement. Passenger Compartment
Air Filter Replacement. Front Wheel Bearing Repack
(2WD only) (or at each brake relining, whichever
occurs first). Manual Transmission Fluid Change.
Transfer Case Fluid Change. Differential Fluid Change.
Fuel Filter Replacement (or every 30 months,
whichever occurs first).
(Continued)

Short Trip/City Scheduled Maintenance
7-13
24,000 Miles (40 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.

Inspect passenger compartment air filter.

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
27,000 Miles (45 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.
30,000 Miles (50 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first).
An Emission Control Service.

Replace passenger compartment air filter.

Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Inspect engine accessory drive belts (or every 24 months, whichever occurs
first). An Emission Control Service.
(Continued)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Short Trip/City Scheduled Maintenance
7-21

Replace spark plug wires (or every 60 months, whichever occurs first).
An Emission Control Service.

Inspect the underhood wiring harness for loose connections, chafed wires and
damage (or every 60 months, whichever occurs first).
An Emission Control Service. (See footnote
.)
Drain, refill and bleed the brake system.
Replace the camshaft timing belt (1.6L Code 6 engine only).
An Emission Control Service. (See footnote
.)
Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Replace engine air cleaner filter.
An Emission Control Service.
Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
Replace fuel filter (or every 30 months, whichever occurs first).
An Emission Control Service. (See footnote
.)
(Continued)

Short Trip/City Scheduled Maintenance
7-27

Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Drain, flush and refill cooling system (or every 30 months, whichever occurs
first). See ªEngine Coolantº in the Index for what to use. Inspect hoses.
Clean radiator, condenser, pressure cap and neck. Pressure test the cooling
system and pressure cap.
An Emission Control Service. (See footnote
.)
Replace spark plugs.
An Emission Control Service.
Replace engine air cleaner filter.
An Emission Control Service.
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
Change manual transmission fluid.
Change transfer case fluid.
Change differential fluid.
Inspect the valve lash and adjust if necessary (1.6L Code 6 engine only).
An Emission Control Service.
(Continued)

Long Trip/Highway Scheduled Maintenance
7-34
30,000 Miles (50 000 km) (Continued)

Replace engine air cleaner filter.
An Emission Control Service.

Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Change manual transmission fluid.
Change transfer case fluid.
Change differential fluid.
Replace fuel filter (or every 30 months, whichever occurs first, or sooner if
filter is clogged).
An Emission Control Service. (See footnote
.)
Inspect the valve lash and adjust if necessary (1.6L Code 6 engine only).
An Emission Control Service.
Inspect propeller shafts and u
-joints for looseness and damage (or every
15 months, whichever occurs first). Inspect more frequently if used off
-road
or for pulling a trailer. Tighten u
-joint flange bolts if necessary.
