warning CHEVROLET TRAX 2018 Owner's Manual

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
Vehicle Care 295
Warning (Continued)
HANDLING.For more information
go to www.P65Warnings.ca.gov/
passenger-vehicle.
See California Proposition
65 Warning 0227 and the back
cover.
{Warning
Batteries can hurt you. They can
be dangerous because:
. They contain acid that can
burn you.
. They contain gas that can
explode or ignite.
. They contain enough
electricity to burn you.
If you do not follow these steps
exactly, some or all of these
things can hurt you.
Caution
Ignoring these steps could result
in costly damage to the vehicle
that would not be covered by the
vehicle warranty. Trying to start
the vehicle by pushing or pulling it
will not work, and it could damage
the vehicle.
1.4L L4 Engine Shown, 1.8L L4 Engine Similar
1. Discharged BatteryNegative Grounding Point 2. Discharged Battery Positive
Terminal
3. Good Battery Negative Terminal
4. Good Battery Positive Terminal
The jump start negative grounding
point (1) for the discharged battery
is the engine block or an engine
mounting bolt. Connect to a spot as
far away from the discharged
battery as possible.
The jump start positive terminal on
the discharged battery (2) is located
in the engine compartment on the
driver side of the vehicle.
The jump start positive terminal (4)
and negative terminal (3) are on the
battery of the vehicle providing the
jump start.
The positive jump start connection
for the discharged battery is under a
trim cover. Open the cover to
expose the terminal.
1. Check the other vehicle. It must have a 12-volt battery
with a negative ground system.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
296 Vehicle Care
Caution
If the other vehicle does not have
a 12-volt system with a negative
ground, both vehicles can be
damaged. Only use a vehicle that
has a 12-volt system with a
negative ground for jump starting.
2. Position the two vehicles so that they are not touching.
3. Set the parking brake firmly and put the shift lever in
P (Park) with an automatic
transmission, or Neutral with a
manual transmission. See
Shifting Into Park 0196 with an
automatic transmission,
or Parking 0198 with a manual
transmission.
Caution
If any accessories are left on or
plugged in during the jump
starting procedure, they could be
(Continued)
Caution (Continued)
damaged. The repairs would not
be covered by the vehicle
warranty. Whenever possible, turn
off or unplug all accessories on
either vehicle when jump starting.
4. Turn the ignition off. Turn off all lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running
and can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode.
People have been hurt doing this,
and some have been blinded.
Use a flashlight if you need more
light.
Battery fluid contains acid that
can burn you. Do not get it on
you. If you accidentally get it in
your eyes or on your skin, flush
the place with water and get
medical help immediately.
{Warning
Fans or other moving engine
parts can injure you badly. Keep
your hands away from moving
parts once the engine is running.
5. Connect one end of the red positive (+) cable to the
positive (+) terminal on the
discharged battery.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
308 Vehicle Care
Caution (Continued)
the appearance and feel of
leather or soft trim, and are not
recommended.
Do not use cleaners that increase
gloss, especially on the instrument
panel. Reflected glare can decrease
visibility through the windshield
under certain conditions.
Caution
Use of air fresheners may cause
permanent damage to plastics
and painted surfaces. If an air
freshener comes in contact with
any plastic or painted surface in
the vehicle, blot immediately and
clean with a soft cloth dampened
with a mild soap solution.
Damage caused by air fresheners
would not be covered by the
vehicle warranty.
Cargo Cover and
Convenience Net
If equipped, wash with warm water
and mild detergent. Do not use
chlorine bleach. Rinse with cold
water, and then dry completely.
Care of Seat Belts
Keep belts clean and dry.
{Warning
Do not bleach or dye seat belt
webbing. It may severely weaken
the webbing. In a crash, they
might not be able to provide
adequate protection. Clean and
rinse seat belt webbing only with
mild soap and lukewarm water.
Allow the webbing to dry.
Floor Mats
{Warning
If a floor mat is the wrong size or
is not properly installed, it can
interfere with the pedals.
Interference with the pedals can
cause unintended acceleration
and/or increased stopping
distance which can cause a crash
and injury. Make sure the floor
mat does not interfere with the
pedals.
Use the following guidelines for
proper floor mat usage.
. The original equipment floor
mats were designed for your
vehicle. If the floor mats need
replacing, it is recommended
that GM certified floor mats be
purchased. Non-GM floor mats
may not fit properly and may
interfere with the accelerator or
brake pedal. Always check that
the floor mats do not interfere
with the pedals.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
Service and Maintenance 311
The Tire Rotation and Required
Services are the responsibility of the
vehicle owner. It is recommended to
have your dealer perform these
services every 12 000 km/7,500 mi.
Proper vehicle maintenance helps to
keep the vehicle in good working
condition, improves fuel economy,
and reduces vehicle emissions.
Because of the way people use
vehicles, maintenance needs vary.
There may need to be more
frequent checks and services. The
Additional Required Services -
Normal are for vehicles that:
.Carry passengers and cargo
within recommended limits on
the Tire and Loading Information
label. See Vehicle Load Limits
0 184.
. Are driven on reasonable road
surfaces within legal driving
limits.
. Use the recommended fuel. See
Fuel 0221.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart. The Additional Required Services -
Severe are for vehicles that are:
.
Mainly driven in heavy city traffic
in hot weather
. Mainly driven in hilly or
mountainous terrain
. Frequently towing a trailer
. Used for high speed or
competitive driving
. Used for taxi, police, or delivery
service
Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause
serious injury. Perform
maintenance work only if the
required information, proper tools,
and equipment are available.
If they are not, see your dealer to (Continued)
Warning (Continued)
have a trained technician do the
work. SeeDoing Your Own
Service Work 0228.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
Index 353
IndexA
About Driving the Vehicle . . . . . . . . . 2
Accessories andModifications . . . . . . . . . . . . . . . . . . 228
Accessory Power . . . . . . . . . . . . . . . 195
Add-On Electrical Equipment . . . 224
Additional Information
OnStar . . . . . . . . . . . . . . . . . . . . . . . 347
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 318
Adjustments Lumbar, Front Seats . . . . . . . . . . . . 58
Agreements Trademarks and License . . . . . 169
Air Cleaner/Filter, Engine . . . . . . . 238
Air Conditioning . . . . . . . . . . . . . . . . 171
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 174
Air Intake . . . . . . . . . . . . . . . . . . . . . . . 174
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 173
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . 83
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 76
Passenger Sensing System . . . . 78
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 76 Airbag System (cont'd)
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 77
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 75
Where Are the Airbags? . . . . . . . . 74
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . 82
Passenger Status Indicator . . . .117
Readiness Light . . . . . . . . . . . . . . .117
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 82
System Check . . . . . . . . . . . . . . . . . . 72
Alarm Vehicle Security . . . . . . . . . . . . . . . . 46
Alert Side Blind Zone (SBZA) . . . . . . 217
All-Season Tires . . . . . . . . . . . . . . . . 269
All-Wheel Drive . . . . . . . . . . . . 205, 249
AM-FM Radio . . . . . . . . . . . . . . . . . . . 150
Antenna Backglass . . . . . . . . . . . . . . . . . . . . 152
Multi-band . . . . . . . . . . . . . . . . . . . . 153
Antilock Brake System (ABS) . . . 206 Warning Light . . . . . . . . . . . . . . . . . 121

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
354 Index
Appearance CareExterior . . . . . . . . . . . . . . . . . . . . . . . 301
Interior . . . . . . . . . . . . . . . . . . . . . . . . 305
Apple CarPlay and Android Auto . . . . . . . . . . . . . . . . . . 164
Armrest Front Seat . . . . . . . . . . . . . . . . . . . . . . 60
Rear Seat . . . . . . . . . . . . . . . . . . . . . . 65
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 331
Audio
Bluetooth . . . . . . . . . . . . . . . . . . . . . 157
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . 42
Headlamp System . . . . . . . . . . . . 140
Transmission . . . . . . . . . . . . . . . . . 200
Transmission Fluid . . . . . . . . . . . 238
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 201
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 250
Auxiliary Jack . . . . . . . . . . . . . . . . . . . 156
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 153B
Backglass Antenna . . . . . . . . . . . . . 152
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 144
Load Management . . . . . . . . . . . . 143
Power Protection . . . . . . . . . . . . . 144
Battery - North America . . . . 249, 294
Blade Replacement, Wiper . . . . . 251
Bluetooth Overview . . . . . . . . . . . . . . . . 159, 160
Bluetooth Audio . . . . . . . . . . . . . . . . 157
Brake System Warning Light . . . . . . . . 121
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 247 Antilock . . . . . . . . . . . . . . . . . . . . . . . 206
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 207
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 247
Parking . . . . . . . . . . . . . . . . . . . . . . . 206
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 179
Break-In, New Vehicle . . . . . . . . . . 188
Bulb Replacement Halogen Bulbs . . . . . . . . . . . . . . . . 254
Headlamp Aiming . . . . . . . . . . . . . 254
Headlamps . . . . . . . . . . . . . . . . . . . 254 Bulb Replacement (cont'd)
Headlamps, Front Turn
Signal, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 255
License Plate Lamps . . . . . . . . . 260
Taillamps, Turn Signal, Sidemarker, Stoplamps,
and Backup Lamps . . . . . . . . . . 257
Buying New Tires . . . . . . . . . . . . . . . 282
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 110
California Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 228
California Proposition
65 Warning . . . . . . . . . .227, 249, 294, Back Cover
Camera Rear Vision (RVC) . . . . . . . . . . . . 212
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 325
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 199
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 44
Winter Driving . . . . . . . . . . . . . . . . 183

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
Index 355
CargoCover . . . . . . . . . . . . . . . . . . . . . . . . . 104
Management System . . . . . . . . . 104
Caution, Danger, and Warning . . . . 3
Chains, Tire . . . . . . . . . . . . . . . . . . . . 287
Charging System Light . . . . . . . . . 118
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . .118
Ignition Transmission Lock . . . 250
Child Restraints
Infants and Young Children . . . . . 85
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 90
Older Children . . . . . . . . . . . . . . . . . . 84
Securing . . . . . . . . . . . . . . . . . . .98, 100
Systems . . . . . . . . . . . . . . . . . . . . . . . . 88
Circuit Breakers . . . . . . . . . . . . . . . . 261
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 301
Interior Care . . . . . . . . . . . . . . . . . . 305
Climate Control Systems . . . . . . . 171 Air Conditioning . . . . . . . . . . . . . . 171
Heating . . . . . . . . . . . . . . . . . . . . . . . 171
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Cluster, Instrument . . . . . . . . . . . . . 113
Clutch, Hydraulic . . . . . . . . . . . . . . . 238
Collision Damage Repair . . . . . . . 334 Compact Spare Tire . . . . . . . . . . . . 293
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . 103
Compass . . . . . . . . . . . . . . . . . . . . . . . 110
Connections OnStar . . . . . . . . . . . . . . . . . . . . . . . 344
Control
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 208
Control of a Vehicle . . . . . . . . . . . . . 179
Convenience Net . . . . . . . . . . . . . . . 105
Convex Mirrors . . . . . . . . . . . . . . . . . . 49
Coolant Engine TemperatureWarning Light . . . . . . . . . . . . . . . 124
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . 171
Cooling System . . . . . . . . . . . . . . . . . 240
Courtesy Lamps . . . . . . . . . . . . . . . . 142
Courtesy Transportation
Program . . . . . . . . . . . . . . . . . . . . . . . 333
Cover
Cargo . . . . . . . . . . . . . . . . . . . . . . . . . 104
Cruise Control . . . . . . . . . . . . . . . . . . 210 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Cupholders . . . . . . . . . . . . . . . . . . . . . 103
Customer Assistance . . . . . . . . . . . 330
Offices . . . . . . . . . . . . . . . . . . . . . . . . 329 Customer Assistance (cont'd)
Text Telephone (TTY)
Users . . . . . . . . . . . . . . . . . . . . . . . 330
Customer Information
Service PublicationsOrdering Information . . . . . . . . 336
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . 327
D
Damage Repair, Collision . . . . . . . 334
Danger, Warning, and Caution . . . . 3
Data CollectionOnStar . . . . . . . . . . . . . . . . . . . . . . . 340
Data Recorders, Event . . . . . . . . . 339
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 139
Defensive Driving . . . . . . . . . . . . . . . 178
Delayed Locking . . . . . . . . . . . . . . . . . 42
Diagnostics OnStar . . . . . . . . . . . . . . . . . . . . . . . 346
Distracted Driving . . . . . . . . . . . . . . . 177
Dome Lamps . . . . . . . . . . . . . . . . . . . 142
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 127
Delayed Locking . . . . . . . . . . . . . . . . 42
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Power Locks . . . . . . . . . . . . . . . . . . . . 42

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
356 Index
Drive Belt Routing, Engine . . . . . . 326
Drive SystemsAll-Wheel Drive . . . . . . . . . . 205, 249
Driver Behavior . . . . . . . . . . . . . . . . . 177
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . 127
Driving
Defensive . . . . . . . . . . . . . . . . . . . . . 178
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 178
Environment . . . . . . . . . . . . . . . . . . 177
For Better Fuel Economy . . . . . . . 26
Hill and Mountain Roads . . . . . . 182
If the Vehicle is Stuck . . . . . . . . . 184
Loss of Control . . . . . . . . . . . . . . . 180
Off-Road Recovery . . . . . . . . . . . 180
Vehicle Load Limits . . . . . . . . . . . 184
Wet Roads . . . . . . . . . . . . . . . . . . . 181
Winter . . . . . . . . . . . . . . . . . . . . . . . . 183
Driving the Vehicle . . . . . . . . . . . . . . . . 2
E
Electrical Equipment, Add-On . . . . . . . . . . . . . . . . . . . . . . . 224
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 261
Fuses and Circuit Breakers . . . 261 Electrical System (cont'd)
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 265
Overload . . . . . . . . . . . . . . . . . . . . . 260
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 267
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 342
Engine
Air Cleaner/Filter . . . . . . . . . . . . . 238
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . .118
Compartment Overview . . . . . . . 231
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 124
Cooling System . . . . . . . . . . . . . . . 240
Drive Belt Routing . . . . . . . . . . . . 326
Exhaust . . . . . . . . . . . . . . . . . . . . . . 199
Heater . . . . . . . . . . . . . . . . . . . . . . . . 194
Oil Life System . . . . . . . . . . . . . . . 236
Oil Pressure Light . . . . . . . . . . . . 125
Overheating . . . . . . . . . . . . . . . . . . 244
Power Messages . . . . . . . . . . . . . 134
Reduced Power Light . . . . . . . . . 126
Running While Parked . . . . . . . . 199
Starting . . . . . . . . . . . . . . . . . . . . . . . 192
Entry Lighting . . . . . . . . . . . . . . . . . . . 143
Event Data Recorders . . . . . . . . . . 339 Exit Lighting . . . . . . . . . . . . . . . . . . . . 143
Extended Parking . . . . . . . . . . . . . . . 198
Extender, Seat Belt . . . . . . . . . . . . . . 70
Exterior Lamp Controls . . . . . . . . . 138
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 144
F
Filter,Engine Air Cleaner . . . . . . . . . . . 238
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 139
Flashers, Hazard Warning . . . . . . 140
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 287 Changing . . . . . . . . . . . . . . . . . . . . . 288
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 308
Fluid Automatic Transmission . . . . . . 238
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 247
Power Steering . . . . . . . . . . . . . . . 245
Washer . . . . . . . . . . . . . . . . . . . . . . . 246
Fog Lamps
Front . . . . . . . . . . . . . . . . . . . . . . . . . 141
Folding Mirrors . . . . . . . . . . . . . . . . . . 49
Folding Seatback . . . . . . . . . . . . . . . . 61
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 216
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 337

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
Index 357
Front Fog LampLight . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Front Seat Armrest . . . . . . . . . . . . . . 60
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 57
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 60
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Additives . . . . . . . . . . . . . . . . . . . . . 222
Economy Driving . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 223
Filling the Tank . . . . . . . . . . . . . . . 222
Foreign Countries . . . . . . . . . . . . 221
Gauge . . . . . . . . . . . . . . . . . . . . . . . . .115
Low Fuel Warning Light . . . . . . . 125
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 261
Fuses and Circuit Breakers . . . 261
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 265
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 267
G
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 253
GaugesFuel . . . . . . . . . . . . . . . . . . . . . . . . . . .115 Gauges (cont'd)
Odometer . . . . . . . . . . . . . . . . . . . . . .115
Speedometer . . . . . . . . . . . . . . . . . .115
Tachometer . . . . . . . . . . . . . . . . . . . .115
Trip Odometer . . . . . . . . . . . . . . . . .115
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . .112
General Information Service and Maintenance . . . . . 310
Towing . . . . . . . . . . . . . . . . . . . . . . . . 224
Vehicle Care . . . . . . . . . . . . . . . . . . 227
Glove Box . . . . . . . . . . . . . . . . . . . . . . 103
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 331
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 254
Hazard Warning Flashers . . . . . . . 140
Head Restraints . . . . . . . . . . . . . . . . . 56
Headlamps
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 254
Automatic . . . . . . . . . . . . . . . . . . . . . 140
Bulb Replacement . . . . . . . . . . . . 254
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 139
Flash-to-Pass . . . . . . . . . . . . . . . . . 139
High-Beam On Light . . . . . . . . . . 126
High/Low Beam Changer . . . . . 139 Headlamps (cont'd)
Lamps On Reminder . . . . . . . . . 127
Heated Front Seats . . . . . . . . . . . . . . 60
Heated Mirrors . . . . . . . . . . . . . . . . . . . 49
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 194
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 171
High-Beam On Light . . . . . . . . . . . . 126
Hill and Mountain Roads . . . . . . . . 182
Hill Start Assist (HSA) . . . . . . . . . . 207
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
How to Wear Seat Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 66
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Hydraulic Clutch . . . . . . . . . . . . . . . . 238
I
Ignition Positions . . . . . . . . . . 188, 190
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . . . 250
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 47 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Indicator
Owner Manual . . . . . . . . . . . . . . . . 120
Vehicle Ahead . . . . . . . . . . . . . . . . 123
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 85

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11354406) - 2018 - crc - 10/12/17
358 Index
Instrument Cluster . . . . . . . . . . . . . . 113
Instrument PanelStorage Area . . . . . . . . . . . . . . . . . 103
Interior Rearview Mirrors . . . . . . . . . 50
Introduction . . . . . . . . . . . . . . . . . . 2, 145
J
Jack Auxiliary . . . . . . . . . . . . . . . . . . . . . . 156
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 294
K
Keyless EntryRemote (RKE) System . . . . . 31, 34
Keys . . . . . . . . . . . . . . . . . . . . . . . . . 28, 29
L
Labeling, Tire Sidewall . . . . . . . . . . 270
Lamps Courtesy . . . . . . . . . . . . . . . . . . . . . . 142
Daytime Running (DRL) . . . . . . 139
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 142
Exterior Controls . . . . . . . . . . . . . . 138
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 144
Front Fog . . . . . . . . . . . . . . . . . . . . . 141 Lamps (cont'd)
Headlamps, Front Turn
Signal, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 255
License Plate . . . . . . . . . . . . . . . . . 260
Malfunction Indicator (Check Engine) . . . . . . . . . . . . . .118
On Reminder . . . . . . . . . . . . . . . . . 127
Reading . . . . . . . . . . . . . . . . . . . . . . 142
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 219
Lane Departure Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Lap-Shoulder Belt . . . . . . . . . . . . . . . 67
LATCH System
Replacing Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . . . 97
LATCH, Lower Anchors and
Tethers for Children . . . . . . . . . . . . 90
LED Lighting . . . . . . . . . . . . . . . . . . . . 254
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 143
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Illumination Control . . . . . . . . . . . 141
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Lights Airbag Readiness . . . . . . . . . . . . . .117 Lights (cont'd)
Antilock Brake System
(ABS) Warning . . . . . . . . . . . . . . 121
Brake System Warning . . . . . . . 121
Charging System . . . . . . . . . . . . . .118
Check Engine (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . .118
Cruise Control . . . . . . . . . . . . . . . . 127
Door Ajar . . . . . . . . . . . . . . . . . . . . . 127
Engine Coolant Temperature Warning . . . . . . . 124
Engine Oil Pressure . . . . . . . . . . 125
Flash-to-Pass . . . . . . . . . . . . . . . . . 139
Front Fog Lamp . . . . . . . . . . . . . . 126
High-Beam On . . . . . . . . . . . . . . . . 126
High/Low Beam Changer . . . . . 139
Immobilizer . . . . . . . . . . . . . . . . . . . 126
Lane Departure Warning . . . . . . 122
Low Fuel Warning . . . . . . . . . . . . 125
Operate Pedal . . . . . . . . . . . . . . . . 122
Reduced Engine Power . . . . . . 126
Seat Belt Reminders . . . . . . . . . . .116
Service Vehicle Soon . . . . . . . . . 120
StabiliTrak OFF . . . . . . . . . . . . . . . 123
Tire Pressure . . . . . . . . . . . . . . . . . 124
Traction Control System (TCS)/StabiliTrak . . . . . . . . . . . . 124
Traction Off . . . . . . . . . . . . . . . . . . . 123
