Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/6/22
Keys, Doors, and Windows 29
Sunroof Switch Express-Open/
Express-Close :To express-open the sunroof,
fully press and release
i(1). Press the
switch again to stop it. To express-close the
sunroof, fully press and release
g(1).
Press the switch again to stop it.
Sunroof Open/Close (Manual Mode) : To
open the sunroof, press and hold
i(1)
at the first switch position until the sunroof
opens the desired amount. Press and hold
g(1) at the first switch position to close
it the desired amount.
Sunroof Vent/Close : From the closed
position, press
f(2) to vent the sunroof.
Press
g(2) to close it.
When the sunroof is opened, an air deflector
will automatically raise.
Sunshade
The sunshade is manually operated.
Physically slide it open or closed as desired.
Automatic Reversal System
The sunroof has an automatic reversal
system that is only active when the sunroof
is operated in express-close mode.
If an object is in the path while express
closing, the reversal system will detect an
object, stop, and open the sunroof again.
If frost or other conditions prevent closing,
override the feature by closing the sunroof
in manual mode. To stop movement, release
the switch.
In the event of closing difficulties like frost
or other conditions, it is possible to override
the reversal system. To override the reversal
system, close in manual mode. To stop the
movement, release the switch.
Dirt and debris may collect on the sunroof
seal or in the track. This could cause an
issue with sunroof operation or noise.
It could also plug the water drainage
system. Periodically open the sunroof and
remove any obstacles or loose debris. Wipe
the sunroof seal and roof sealing area using
a clean cloth, mild soap, and water. Do not
remove grease from the sunroof.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
74 Storage
Storage
Storage Compartments
Storage Compartments . . . . . . . . . . . . . . . . . 74
Instrument Panel Storage . . . . . . . . . . . . . . 74
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Center Console Storage . . . . . . . . . . . . . . . . . 75
Additional Storage Features
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Cargo Management System . . . . . . . . . . . . 76
Roof Rack System
Roof Rack System . . . . . . . . . . . . . . . . . . . . . . . 77
Storage Compartments{
Warning
Do not store heavy or sharp objects in
storage compartments. In a crash, these
objects may cause the cover to open and
could result in injury.
Instrument Panel Storage
Storage is used for small articles, etc.
Glove Box
Lift up on the glove box lever to open it.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
Storage 77
Sliding Load Floor
If equipped with a sliding load floor, open
the liftgate and release the latch on the
load floor tray.
Slide the load floor rearward to access the
cargo management system.
After storing items, make sure to properly
secure the load floor.
The storage area under the van load floor
contains the inflator kit, a tow eye, and
additional storage compartments.
Roof Rack System
The vehicle may be equipped with side-rails
for a roof rack system. Cargo must be
secured with properly installed cross rails
and other accessories designed to carry
cargo. These can be purchased from your
dealer.
{Warning
Before driving and occasionally during a
trip, check that cargo is securely fastened,
rests evenly between the cross rails and
does not block the vehicle's lamps or
windows. Never load cargo directly on
the roof of the vehicle or allow cargo to
hang over the rear or sides of the vehicle.
Never load cargo without first properly
installing cross rails and other accessories
designed to carry cargo. Personal injury,
death or damage to the vehicle or other
property may occur.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
78 Storage
If driving for a long distance, on rough
roads, or at high speeds, occasionally stop
the vehicle to make sure the cargo remains
in its place.
Cargo Weight Limits
Do not exceed the maximum cargo weight
for the roof rack system, including the
weight of the cross rails and any other
accessories used to carry the cargo such as
bike racks or roof boxes. The maximum
cargo weight that can be loaded onto the
roof rack system is 100 kg (220 lb) or the
weight designated in the instructions that
came with the cross rails or other roof rack
accessories, whichever is less.
{Warning
Never load the roof rack with more
weight than specified in this section.
Loading cargo on the roof rack will make
the vehicle's center of gravity higher. To
avoid losing control of the vehicle, avoid
overloading, high speeds, sudden starts,
sharp turns, sudden braking, or abrupt
maneuvers when carrying cargo on the
roof rack.The weight of any cargo carried on the roof
rack system must be included in calculating
the loaded weight of the vehicle. Do not
exceed the maximum vehicle capacity when
loading the vehicle, including cargo carried
on the roof rack system and passengers and
cargo carried in the vehicle. For more
information on vehicle capacity and loading,
see
Vehicle Load Limits 0171.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/6/22
Driving and Operating 199
Do not use ACC when driving on steep hills
or when towing a trailer. ACC will not detect
a vehicle in the lane while driving on steep
hills. If the brakes are applied, ACC
disengages.
Disengaging ACC
There are three ways to disengage ACC:
.Step lightly on the brake pedal.
.Press*.
.Press5.
Erasing Speed Memory
The ACC set speed is erased from memory if
5is pressed or if the ignition is turned off.
Weather Conditions Affecting ACC
If the interior temperature is extremely
high, the instrument cluster may indicate
that ACC is temporarily unavailable. This can
be caused by extreme hot weather
conditions with direct sunlight on the front
camera. ACC will return to normal operation
once the cabin temperature is lower.
Conditions that are associated with low
visibility, such as fog, rain, snow, or road
spray, may limit ACC performance. Waterdroplets from rain or snow that remain on
the windshield may also limit ACC’s ability
to detect objects.
Lighting Conditions Affecting ACC
The ACC front camera can be affected by
poor lighting conditions, and ACC may have
limited performance when:
.There are changes in brightness, such as
entering and exiting tunnels, bridges, and
overpasses.
.Low sun angles cause the camera to not
detect objects, or it is more difficult to
detect objects in the same traffic lane.
.Lighting is poor in the evening or early
morning
.There are multiple changes in brightness
or shadows along the vehicle roadway.
.In a tunnel without the headlamps on,
or in a tunnel when there is a vehicle in
front that does not have its taillamps on.
.Subjected to strong light from opposing
lane traffic in the front of the vehicle,
such as high-beam headlamps from
oncoming traffic.
Accessory Installations and Vehicle
Modifications
Do not install or place any object around
the front camera windshield area that would
obstruct the front camera view.
Do not install objects on top of the vehicle
that overhang and obstruct the front
camera, such as a canoe, kayak, or other
items that can be transported on a roof rack
system. See
Roof Rack System 077.
Do not modify the hood, headlamps, or fog
lamps, as this may limit the camera’s ability
to detect an object.
Cleaning the Sensing System
The camera sensor on the windshield behind
the rearview mirror can become blocked by
snow, ice, dirt, mud, or debris. This area
needs to be cleaned for ACC to operate
properly.
The vehicle headlamps may need to be
cleaned due to dirt, snow, or ice. Objects
that are not illuminated correctly may be
difficult to detect.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
Index 323
Parking or BackingAssistance Systems . . . . . . . . . . . . . . . . . . . . 201
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . 92
Compartment Air Filter . . . . . . . . . . . . . . . . 163
Sensing System . . . . . . . . . . . . . . . . . . . . . . . . . 49
Pedestrian Ahead Indicator . . . . . . . . . . . . . . . 96
Perchlorate Materials Requirements,
California . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Phone Apple CarPlay and
Android Auto . . . . . . . . . . . . . . . . . . . . 127, 149
Bluetooth . . . . . . . . . . . . . . . . . . . . . . 122, 123, 145
Port USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122, 141
Power
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Protection, Battery . . . . . . . . . . . . . . . . . . . . . . 114
Retained Accessory (RAP) . . . . . . . . . . . . . . . 181
Seat Adjustment . . . . . . . . . . . . . . . . . . . . . . . . 32
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Pregnancy, Using Seat Belts . . . . . . . . . . . . . . 43
Privacy Vehicle Data Recording . . . . . . . . . . . . . . . . 306
Program Courtesy Transportation . . . . . . . . . . . . . . . 301 Prohibited Fuels . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Proposition 65 Warning
California . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Proposition 65 Warning, California . . . . . . . 272
Publication Ordering Information . . . . . . . . 304
R
Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Radio AM-FM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
AM-FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Frequency Statement . . . . . . . . . . . . . . . . . . 305
Reception . . . . . . . . . . . . . . . . . . . . . . . . . . 121, 140
Satellite . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121, 140
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Window Washer/Wiper . . . . . . . . . . . . . . . . . 81
Rearview Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . .27 Automatic Dimming . . . . . . . . . . . . . . . . . . . . 27
Reclining Seatbacks . . . . . . . . . . . . . . . . . . . . . . . .33
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Recommended Fluids and Lubricants . . . . . 291
Records Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Recreational Vehicle Towing . . . . . . . . . . . . . 275
Reimbursement Program, GM
Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299 Remote
Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Key Operation . . . . . . . . . . . . . . . . . . . . . . . 10, 15
Vehicle Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Replacing Airbag System . . . . . . . . . . . . . . . . . . . . . . . . . . 54
LATCH System Parts After a Crash . . . . . . 68
Seat Belt System Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Reporting Safety Defects Canadian Government . . . . . . . . . . . . . . . . . 305
General Motors . . . . . . . . . . . . . . . . . . . . . . . . 306
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . 305
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Retained Accessory Power (RAP) . . . . . . . . . . 181
Roads Driving, Wet . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Roadside Assistance Program . . . . . . . . . . . . 300
Roof Rack System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Routing, Engine Drive Belt . . . . . . . . . . . . . . . 296
Running the Vehicle While Parked . . . . . . . .183

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
324 Index
S
SafetyLocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Safety Defects Reporting Canadian Government . . . . . . . . . . . . . . . . . 305
General Motors . . . . . . . . . . . . . . . . . . . . . . . . 306
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . 305
Safety System Check . . . . . . . . . . . . . . . . . . . . . 44
Satellite Radio . . . . . . . . . . . . . . . . . . . . . . . 121, 140
Scheduling Appointments . . . . . . . . . . . . . . . . 301
Sealant Kit, Tire . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Buckle To Drive . . . . . . . . . . . . . . . . . . . . . . . . . 38
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
How to Wear Seat Belts Properly . . . . . . . 39
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . 41
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Replacing after a Crash . . . . . . . . . . . . . . . . . 44
Use During Pregnancy . . . . . . . . . . . . . . . . . . 43
Seats Adjustment, Front . . . . . . . . . . . . . . . . . . . . . . 32
Folding Seatback . . . . . . . . . . . . . . . . . . . . . . . . 35
Head Restraints . . . . . . . . . . . . . . . . . . . . . . . . . 30
Heated Front . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Lumbar Adjustment, Front . . . . . . . . . . . . . . 34
Power Adjustment, Front . . . . . . . . . . . . . . . 32
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Seats (cont'd)
Reclining Seatbacks . . . . . . . . . . . . . . . . . . . . . 33
Securing Child Restraints . . . . . . . . . . . . . . 68, 70
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Vehicle Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163 Accessories and Modifications . . . . . . . . . 216
Climate Control System . . . . . . . . . . . . . . . . 158
Doing Your Own Work . . . . . . . . . . . . . . . . . 216
Electric Parking Brake Light . . . . . . . . . . . . . 95
Maintenance Records . . . . . . . . . . . . . . . . . . 293
Maintenance, General Information . . . . . 286
Parts Identification . . . . . . . . . . . . . . . . . . . . . 294
Scheduling Appointments . . . . . . . . . . . . . . 301
Services Special Application . . . . . . . . . . . . . . . . . . . . . 290
Servicing the Airbag . . . . . . . . . . . . . . . . . . . . . . .53
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128, 150
Shift Lock Control Function Check, Automatic Transmission . . . . . . . . . . . . . . . . . 231
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Out of Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Sidemarker Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 236 Signals, Turn and Lane-Change . . . . . . . . . . . . 111
Software Updates . . . . . . . . . . . . . . . . . . . . . . . . . 119
Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
Special Application Services . . . . . . . . . . . . . . 290
Specifications and Capacities . . . . . . . . . . . . . 295
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Start Assist, Hill . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Start Vehicle, Remote . . . . . . . . . . . . . . . . . . . . . .18
Starter Switch Check . . . . . . . . . . . . . . . . . . . . . . 231
Starting the Engine . . . . . . . . . . . . . . . . . . . . . . .178
Status Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167 Heated Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Wheel Adjustment . . . . . . . . . . . . . . . . . . . . . . 80
Wheel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 117
Steering Wheel Controls . . . . . . . . . . . . . . . . . 136
Stop/Start System . . . . . . . . . . . . . . . . . . . . . . . 179
Stoplamps and Back-Up Lamps Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 236
Storage Center Console . . . . . . . . . . . . . . . . . . . . . . . . . 75
Compartments . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Instrument Panel Areas . . . . . . . . . . . . . . . . . 74
Roof Rack System . . . . . . . . . . . . . . . . . . . . . . . 77

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
17041293) - 2024 - CRC - 12/2/22
Index 325
Storage AreasCargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Cargo Management System . . . . . . . . . . . . 76
Storing the Tire Sealant and Compressor Kit . . . . . . . . . . . . . . . . . . . . . . . . . 266
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Stuck Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
System Airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Engine Air Filter Life . . . . . . . . . . . . . . . . . . . 223
Roof Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
T
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
TaillampsBulb Replacement . . . . . . . . . . . . . . . . . . . . . . 236
Teen Driver . . . . . . . . . . . . . . . . . . . . . . . . . . 129, 152
Text Telephone (TTY) Users . . . . . . . . . . . . . . 299
Theft-Deterrent Systems . . . . . . . . . . . . . . . . . . .25
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243 All-Season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Buying New Tires . . . . . . . . . . . . . . . . . . . . . . 256 Tires (cont'd)
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Compact Spare . . . . . . . . . . . . . . . . . . . . . . . . . 271
Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . 246
Different Size . . . . . . . . . . . . . . . . . . . . . . . . . . 257
If a Tire Goes Flat . . . . . . . . . . . . . . . . . . . . . 260
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . 248, 249
Pressure Light . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Pressure Monitor Operation . . . . . . . . . . . 250
Pressure Monitor System . . . . . . . . . . . . . . 249
Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Sealant and Compressor Kit . . . . . . . . . . . . 261
Sealant and Compressor Kit,
Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Sidewall Labeling . . . . . . . . . . . . . . . . . . . . . . 244
Terminology and Definitions . . . . . . . . . . . 246
Uniform Tire Quality Grading . . . . . . . . . . 257
Wheel Alignment and Tire Balance . . . . 258
Wheel Replacement . . . . . . . . . . . . . . . . . . . . 258
When It Is Time for New Tires . . . . . . . . . 255
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
Top Tier Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Towing General Information . . . . . . . . . . . . . . . . . . . 214
Recreational Vehicle . . . . . . . . . . . . . . . . . . . 275 Traction
Control System (TCS)/Electronic
Stability Control Light . . . . . . . . . . . . . . . . . 97
Control/Electronic Stability Control . . . . 188
Off Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Trademarks and License Agreements . . . . . . . . . . . . . . . . . . . . . . . . 133, 155
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Fluid, Automatic . . . . . . . . . . . . . . . . . . . . . . . 223
Transportation Program, Courtesy . . . . . . . 301
Transporting
a Disabled Vehicle . . . . . . . . . . . . . . . . . . . . . 274
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
TTY Users Customer Assistance . . . . . . . . . . . . . . . . . . . 299
Turn and Lane-Change Signals . . . . . . . . . . . . 111
Turn Signal Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 236
U
Uniform Tire Quality Grading . . . . . . . . . . . . 257
UpdatesSoftware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
USB Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122, 141
